H3C S9500 Series Routing Switches

Command Manual

Hangzhou H3C Technologies Co., Ltd.

http://www.h3c.com

Manual Version: T2-08194H-20080520-C-2.03

Product Version: S9500-CMW520-R2132

No part of this manual may be reproduced or transmitted in any form or by any means

without prior written consent of Hangzhou H3C Technologies Co., Ltd.

Trademarks

H3C, , Aolynk, , H3Care,

, TOP G, , IRF, NetPilot,

Neocean, NeoVTL, SecPro, SecPoint, SecEngine, SecPath, Comware, Secware,

Storware, NQA, VVG, V2G, VnG, PSPT, XGbus, N-Bus, TiGem, InnoVision and

HUASAN are trademarks of Hangzhou H3C Technologies Co., Ltd.

All other trademarks that may be mentioned in this manual are the property of their

respective owners.

Notice

The information in this document is subject to change without notice. Every effort has

been made in the preparation of this document to ensure accuracy of the contents, but

all statements, information, and recommendations in this document do not constitute

the warranty of any kind, express or implied.

To obtain the latest information, please access:

http://www.h3c.com

Technical Support

customer_service@h3c.com

http://www.h3c.com

About This Manual

Related Documentation

In addition to this manual, each H3C S9500 Series Routing Switches documentation

set includes the following:

Manual Description

H3C S9500 Series Routing

Switches Installation Manual

It introduces the installation procedure,

commissioning, maintenance and monitoring of

the S9500 series routing switches.

H3C S9500 Series Routing

Switches Operation Manual

It includes Product Overview, Access Volume,

IP Service Volume, IP Routing Volume, IP

Multicast Volume, MPLS VPN Volume, QoS

ACL Volume, Security Volume, System

Volume , OAA Volume and Acronyms.

Organization

H3C Command Manual is organized as follows:

Part Contents

00 Feature List and

Command Index includes Feature List and Command Index.

01 Access Volume

includes Ethernet Interface Commands, POS Interface

Commands, GVRP Commands, Link Aggregation

Commands, Port Mirroring Commands, RPR Commands,

Ethernet OAM Commands, MSTP Commands, VLAN

Commands, QinQ Commands, BPDU Tunneling

Commands, and Port Isolation Commands.

02 IP Services

Volume

includes ARP Commands, DHCP Commands, DNS

Commands, IP Addressing Commands, IP Performance

Commands, UDP Helper Commands, IPv6 Basics

Commands, Dual Stack Commands, Tunneling

Commands, and Adjacency Table Command.

03 IP Routing Volume

includes IP Routing Table Display Commands, BGP

Commands, IS-IS Commands, OSPF Commands, RIP

Commands, Routing Policy Commands, Static Routing

Commands, IPv6 BGP Commands, IPv6 IS-IS

Commands, IPv6 OSPFv3 Commands, IPv6 RIPng

Commands, and IPv6 Static Routing Commands.

Part Contents

04 IP Multicast

Volume

includes Multicast Routing and Forwarding Commands,

IGMP Snooping Commands, IGMP Commands, PIM

Commands, MSDP Commands, IPv6 Multicast Routing,

and Forwarding Commands, MLD Snooping Commands,

MLD Commands, IPv6 PIM Commands, Multicast VLAN

Commands.

05 MPLS VPN

Volume

includes MPLS Basics Commands, MPLS TE Commands,

VPLS Commands, MPLS L2VPN Commands, MPLS

L3VPN Commands, MPLS Hybrid Insertion Commands,

and GRE Commands.

06 QoS ACL Volume includes QoS Commands and ACL Commands.

07 Security Volume

includes 802.1x Commands, AAA, RADIUS HWTACACS

Commands, MAC Authentication Commands, L3+NAT

Commands, Password Control Commands, SSH2.0

Commands, and Portal Commands.

08 System Volume

includes GR Commands, VRRP Commands, HA

Commands, Device Management Commands, NQA

Commands, NetStream Commands, NTP Commands,

RMON Commands, SNMP Commands, File System

Management Commands, System Maintaining and

Debugging Commands, Basic System Configuration

Commands, Information Center Commands, User

Interface Commands, MAC Address Table Management

Commands, PoE Commands, and Clock Monitoring

Commands.

09 OAA Volume includes OAP Module Commands and ACSEI Commands.

10 Unsupported

Commands List of Unsupported Commands.

Conventions

The manual uses the following conventions:

I. Command conventions

Convention Description

Boldface The keywords of a command line are in Boldface.

italic Command arguments are in italic.

[ ] Items (keywords or arguments) in square brackets [ ] are

optional.

{ x | y | ... }

Alternative items are grouped in braces and separated by

vertical bars. One is selected.

Convention Description

[ x | y | ... ]

Optional alternative items are grouped in square brackets

and separated by vertical bars. One or none is selected.

{ x | y | ... } *

Alternative items are grouped in braces and separated by

vertical bars. A minimum of one or a maximum of all can be

selected.

[ x | y | ... ] *

Optional alternative items are grouped in square brackets

and separated by vertical bars. Many or none can be

selected.

&<1-n> The argument(s) before the ampersand (&) sign can be

entered 1 to n times.

# A line starting with the # sign is comments.

II. GUI conventions

Convention Description

< > Button names are inside angle brackets. For example, click

<OK>.

[ ] Window names, menu items, data table and field names

are inside square brackets. For example, pop up the [New

User] window.

/ Multi-level menus are separated by forward slashes. For

example, [File/Create/Folder].

III. Symbols

Convention Description

Warning Means reader be extremely careful. Improper operation

may cause bodily injury.

Caution Means reader be careful. Improper operation may cause

data loss or damage to equipment.

Note Means a complementary description.

Command Manual

H3C S9500 Series Routing Switches OAA Volume Organization

Manual Version

T2-08194H-20080530-C-2.03

Product Version

S9500-CMW520-R2132

Organization

The OAA Volume is organized as follows:

Features (command

manual) Description

OAP Module Introduces the commands for OAP module configuration.

ACSEI Introduces the commands for ACSEI configuration.

Command Manual – OAP Module

H3C S9500 Series Routing Switches Table of Contents

Table of Contents

Chapter 1 OAP Module Configuration Commands....................................................................1-1

1.1 OAP Module Configuration Commands ............................................................................1-1

1.1.1 oap connect slot......................................................................................................1-1

1.1.2 oap reboot slot.........................................................................................................1-2

Command Manual – OAP Module

H3C S9500 Series Routing Switches Chapter 1 OAP Module Configuration Commands

1-1

Chapter 1 OAP Module Configuration Commands

1.1 OAP Module Configuration Commands

1.1.1 oap connect slot

Syntax

oap connect slot slot-number

View

User view

Default Level

2: System level

Parameters

slot-number: Number of the slot where an OAP module resides.

Description

Use the oap connect slot command to switch from the command line interface on the

device to the operating system of the OAP module, and thus you can manage the

system of the OAP module.

You can press Ctrl+k to return from the operating system on the OAP module to the

command line interface on the device.

Examples

# Switch from the command line interface on the device to the operating system of the

OAP module in slot 3.

<Sysname> oap connect slot 3

Connected to OAP!

# After viewing the above information, press Enter to log in to the operating system of

the OAP module.

<H3C>

# Press Ctrl+k to return from the operating system on the OAPmodule to the command

line interface on the device.

Command Manual – OAP Module

H3C S9500 Series Routing Switches Chapter 1 OAP Module Configuration Commands

1-2

1.1.2 oap reboot slot

Syntax

oap reboot slot slot-number

View

User view

Default Level

2: System level

Parameters

slot-number: Number of the slot where an OAP module resides.

Description

Use the oap reboot slot command to reset the system on an OAP module, which is

equal to resetting the OAP module by pressing the reset button on the OAP module.

It is recommended to save the data on the operating system on the OAP module and

shut down the operating system to avoid service interruption and hardware data loss.

After the reset, the operating system on the OAP module reboots automatically.

Examples

# Reset the system on the OAP module in slot 3.

<Sysname> oap reboot slot 3

This command will recover the OAP from shutdown or other failed state.

Warning: This command may lose the data on the hard disk if the OAP is not being

shut down!

Continue? [Y/N]:y

Reboot OAP by command.

Command Manual – ACSEI

H3C S9500 Series Routing Switches Table of Contents

Table of Contents

Chapter 1 ACSEI Configuration Commands ..............................................................................1-1

1.1 ACSEI Server Configuration Commands ..........................................................................1-1

1.1.1 acsei client close.....................................................................................................1-1

1.1.2 acsei client reboot ...................................................................................................1-1

1.1.3 acsei server.............................................................................................................1-2

1.1.4 acsei server enable.................................................................................................1-2

1.1.5 acsei timer clock-sync.............................................................................................1-3

1.1.6 acsei timer monitor..................................................................................................1-4

1.1.7 debugging acsei server...........................................................................................1-4

1.1.8 debugging acsei-client ............................................................................................1-6

1.1.9 display acsei client info .........................................................................................1-10

1.1.10 display acsei client summary ..............................................................................1-12
