Goldair GCT330 Manual de usuario
Operating Instructions
2400W CERAMIC TOWER HEATER WITH WIFI/SMART
HOME
Model: GCT330
WiFi –Downloading and Setting up APP
This APP is supported only on 2.4GHz Wi-Fi channels.
The Goldair app and device pairing process require your 2.4ghz connection to
be separated from your 5ghz connection. For instructions on how to do this
please contact your internet provider.
•Tap REGISTER near the bottom of the screen.
•Read and agree to the Privacy Policy.
•Add your email address.
•Tap 'Obtain verification code'
You will then receive an email with a verification
code.
Download Goldair mobile APP
•Open the APP Store or Google Play on your mobile phone.
•Open 'Search' and enter 'Goldair'
•Click 'GET' and begin to download and install.
Once downloaded to your phone open the APP
•Enter the verification code from your email.
•Create a password.
•Then tap confirm.
If you haven't received a verification code via
email, tap the resend button and when the
verification code is received follow above steps.
Your APP is now registered and ready for pairing
to your device.
Pairing APP to Device
Connect with 2.4ghz Wifi Network
On the Home screen,
tap ‘Add Device’ or
the ‘+’ icon.
Using the categories on
the left, navigate to
your device and tap on
the image.
Confirm you are connected
to a 2.4ghz network. If your
2.4ghz and 5ghz networks
are dual banded, click
‘Common router setting
method’ on how to split, or
contact your internet
provider.
Pairing APP to Device
Connect with 2.4ghz Wifi Network: EZ Mode
The app will default to EZ Mode in the
right hand corner.
Ensure your device’s Wifi LED is flashing
rapidly.
If it is not, hold down the ‘SWING’
button for 5 seconds or until the Wifi
icon begins to flash.
Click ‘Confirm indicator rapidly blink’
and ‘Next’
See instructions below to finalise your device pairing via EZ mode.
Your device will now pair with the app.
Please ensure your device, modem and
phone are as close together as possible
and that your 2.4ghz Wifi signal is strong.
Once the device has paired, choose
to rename it by tapping the Pen icon
Choose the most suitable room type and
click ‘Done’ in the top right hand corner.
Pairing APP to Device
Change ‘EZ Mode’ to ‘AP Mode’ by
clicking in the top right hand corner
Ensure your device’s Wifi LED is
flashing slowly.
If it is not, hold down the ‘SWING’
button for 5 seconds or until the
Wifi icon begins to flash.
Click ‘Confirm indicator slowly
blink’ and ‘Next’
Click ‘Go Connect’ to
connect to the device’s
Hotspot by selecting the
network highlighted on the
screen in your app, e.g.
‘SmartLife- XXXX’
Select the device’s Hotspot
network and you will be returned
to the app. If not, navigate back to
the Goldair app.
Note- if you get a notification
saying ‘Internet may not be
available’ press Dismiss.
Your device will now pair
with the app.
Please ensure your
device, modem and
phone are as close
together as possible.
Connect with 2.4ghz Wifi Network: AP Mode
See instructions below to finalise your device pairing via AP Mode.
Once the device has paired,
choose to rename it by
tapping the Pen icon
Choose the most suitable
room type and click ‘Done’
in the top right hand
corner.
Pairing APP to Device
Connect with Bluetooth
On the Home screen, tap ‘Add
Device’ or the ‘+’ icon.
Ensure your device’s Wifi LED is
flashing rapidly.
If it is not, hold down the ‘SWING’
button for 5 seconds or until the
Wifi icon begins to flash.
On the top right, click ‘Auto
Scan’
The app will now scan for
Bluetooth devices.
When your device appears, click
on the image.
As an alternative way of connecting your device, you can pair via Bluetooth. Please
ensure you have Bluetooth switched on on your mobile phone.
Choose your 2.4ghz Wifi
network and add in the
password. Click ‘Next’
Your device will now pair
with the app.
Please ensure your
device, modem and
phone are as close
together as possible.
Once the device has paired,
choose to rename it by
tapping the Pen icon
Choose the most suitable
room type and click ‘Done’
in the top right hand
corner.
Operating your Device from the APP
Device operation screen
Device settings
Adjust temperature
setting
ON/OFF Power
Choose between
Manual and Auto
(AI) mode
Choose between
HIGH/LOW/FAN
settings
Turn on an ON/OFF
Timer.
Settings: Turn on
Oscillation / set up
weekly timer
schedule.
Current room
temperature
Default/ Target set
temperature
Operating your Device from the APP
Device Operation Screen
•Tap the ‘POWER' icon to operate power
•Tap the '+' and '-' icons to change the temperature settings. Note- changing the temperature will
automatically put you in to Auto (Smart/Ai) mode.
Mode
•Tap the ‘Mode' Icon to switch between manual (adjusting the heat settings manually) and Auto
(Smart/Ai) mode
Heat
•Tap the ‘Heat' icon to choose between Fan, Low and High. Note- you cannot amend the temperature
when you are in Fan mode.
Timer
•Tap the ‘Timer' icon to set the Timer. Choose between 1-9 hours. If you select this function while the
heater is ON, it will set the timer to turn the heater OFF. If you select this function while the heater is on
STANDBY, it will set the timer to turn the heater ON.
Settings
•Tap the ‘Settings’ icon to access additional functionality:
•Swing: Turn oscillation ON or OFF.
•Schedule: Tap the ‘Timer’ icon to set a weekly schedule
Device is Off Device is On ‘Mode' icon 'Heat' icon 'Timer' icon
Operating your Device from the APP
•Select your desired time on the Schedule edit screen
•Tap ‘Repeat' to select what days of the week you want the timer set for.
NOTE: Select as many days as you want, or if you want to set the timer as a one off, don't select any
days.
•Tap ‘Switch' to select whether you want the timer function to turn the heater ON or OFF
•Tap 'SAVE' on the Schedule edit screen to save your timer selection and return to the Schedule main
screen
•To add another timer, select 'Add Schedule’ and repeat the above process.
Note: Make sure the Smartphone or Tablet Clock that you are using has the right time you are providing
from the connection network to the Internet. Possible delay or non-activation of the timer may be
caused by an incorrect time setting on the device you are using.
Schedule edit
screen 'Repeat' icon 'Switch' icon Schedule main
screen
Schedule main
screen
Schedule Function
•Tap ‘Add schedule’ on the schedule main screen to begin setting your weekly schedule.
Set up Tap-To-Run & Create Smart Scenes
Store your favourite settings or set up automated
functions based on conditions in the ‘Smart’ part
of your Goldair app.
Warning- you must remember to turn off any
Smart functions prior to leaving the house or
going away. We recommend you only operate
your Goldair devices when someone is on the
premises.
•Tap ‘Smart’ on the bottom of your mobile phone.
•Tap ‘Create Scene’ or the ‘+’ icon on the top
right.
Click ‘Launch Tap-to-Run’ to save your preferred settings
on your devices to launch at the click of a button. Click
‘Run the device’ and choose a device. Preset your desired
functions such as Power ON/OFF, temperature, mode and
timer as per on the device’s functions. Click ‘Next’
Review your conditions and tasks on this screen, or
choose to add another device or task by clicking the ‘+’
icon.
Click Save to store your settings and your new task will
appear on the Smart homepage. Click it to operate your
desired task.
