Instructions for Use

Climapro

Programmable Room Thermostat

Climapro RF

Radio Controlled Programmable

Room Thermostat

Customer Service:

01773 828100

Technical Helpline:

01773 828300

General and Sales enquiries:

Tel. 01773 824639

Fax: 01773 820569

The instructions are an integral part of the control

and must, to comply with the current issue of the Gas

Safety (Installation and Use) Regulations, be handed

to the user on completion of the installation.

General

Page

General Information

General, Documents, Application,

Servicing & Recycling 4-5

Instructions for Use

Control buttons 7

Main display 7

Description of buttons 8

Display symbols 9

Choosing the operating mode 10

Setting the Comfort temperature 11

Setting the “Eco” temperature 12

Domestic hot water temperature adjustments 13

Domestic hot water advance 14

“Holiday” function 15

Setting the day, time and date 16

Setting the 7 day central heating programme 17

Setting the 7 day DHW heating programme 20

Central Heating Temporary Override 24

Information menu 25

Battery Replacement 27

Fault nding 29

Contents

Controls Description

The Climapro is a programmable room thermostat with

separate 7 day programmes for heating and hot water.

This control gives you personalised heating comfort

according to your requirements and will improve the energy

efciency of your heating system.

The modulating regulation built into this thermostat changes

the temperature of the radiators to suit the desired ambient

temperature.

Any other use is considered as inappropriate and is

forbidden.

The manufacturer will not be responsible for any damage

caused by another use. In that case the user shall be

responsible.

General

The installation and the commissioning of the control has

to be carried out by a competent person who is responsible

for the compliance of the installation and the commissioning

according to current regulations.

Maintenance should be carried out by a competent person

in accordance with the rules in force.

Documents

Please keep this manual as well as any documents

enclosed with it safe for future reference.

We accept no liability in case of damage due to the non-

compliance of the instructions of the present manual.

General Information

Cleaning

DO NOT use any abrasive cleaning products as they could

damage the housing or plastic case.

Clean the case of the Climapro with damp cloth.

Make sure that no water goes inside the Climapro.

Recycling

The Climapro comprises of many recyclable parts and

should be disposed of according to the current WEEE

regulations.

The packaging should also be disposed of according to the

current regulations.

General Information

Control Buttons

Diagram 1

Main Display

The LCD will display the following as shown in diagram 2.

(*) Display only possible if an outside sensor is connected to

the boiler.

DISPLAY

MODE

BUTTON

MINUS

BUTTON

PLUS

BUTTON

PROGRAMME

BUTTON

Diagram 2

Current operating

mode

Ambient room

temperature

Current time

Current day

Outside

temperature (*)

Outside sensor

present symbol (*)

Domestic hot

water programme

(when in use)

Description of Buttons

Display Symbols

Button

By pressing several times on the button, you will

access the following settings, see table below.

Button

By pressing on the button several times you can

see the different programmes.

By pressing and holding for 5 seconds you can modify

the heating programme.

Button

By pressing on the button, you reduce the value of

the setting.

Button

By pressing on the button, you increase the value of

the setting.

10 Setting the date

Domestic hot water advance

Mode button settings

Choosing the Operating Mode

1. To change the operating mode, press once.

2. Press until the desired mode ashes.

3. The setting is saved after 10 seconds or by pressing the

button, which will then continue to the next setting.

Off: Heating is off but the domestic hot water is

still operating at the set temperature.

Eco: Heating on at Eco (minimum)

temperature

Comfort: Continuous heating on at Comfort

(desired) temperature

Timed: The heating will operate to the

programmed on and off times Comfort or

Eco.
