Gira 1493 00 Manual de usuario

Operating instructions

32406912 / 10870484 / 25.05.2023

Remote sensor

Order no. 1493 00

Remote sensor

Table of contents

1 Safety instructions ............................................................................................................ 3

2 Intended use..................................................................................................................... 3

3 Mounting and electrical connection .................................................................................. 3

4 Technical data .................................................................................................................. 3

2 / 4

32406912 10870484 25.05.2023

1 Safety instructions

Electrical devices may be mounted and connected only by electrically skilled

persons.

Serious injuries, fire or property damage are possible. Please read and follow the

manual fully.

2 Intended use

– External sensor for measuring ambient temperature

– Connection to a suitable room temperature controller

3 Mounting and electrical connection

DANGER!

Electric shock when live parts are touched.

Electric shocks can be fatal.

Always disconnect before carrying out work on the device or installation. For this,

switch off all the corresponding circuit breakers, secure against being switched on

again, and check that there is no voltage. Cover up adjacent live parts.

The remote sensor must be mounted in an empty tube so that the sensor is mechan-

ically protected and can be exchanged if necessary.

The supplied device connection terminal is used for connection to Pushbutton

sensor 4 Komfort.

4 Technical data

Dimensions Ø×H 7.8 × 27 mm

Sensor cable S03VV-F 2 x 0.5 mm²

Length connecting cable 4 m

Degree of protection IP 67

Remote sensor resistance values

Temperature

(°C)

Resistance

(kΩ)

Temperature

(°C)

Resistance

(kΩ)

5 89.5 30 26.2

10 68.8 35 20.9

15 53.5 40 16.7

20 41.9 45 13.5

25 33.0 50 11.0

3 / 4

32406912 10870484 25.05.2023

Remote sensor

The resistance values can only be measured if the sensor is disconnected.

Gira

Giersiepen GmbH & Co. KG

Elektro-Installations-

Systeme

Industriegebiet Mermbach

Dahlienstraße

42477 Radevormwald

Postfach 12 20

42461 Radevormwald

Deutschland

Tel +49(0)21 95 - 602-0

Fax +49(0)21 95 - 602-191

www.gira.de

[email protected]

4 / 4

32406912 10870484 25.05.2023

Remote sensor
