Genius SLIM 322 Manual de usuario

English

-1- www.geniusnet.com

1. Please install the driver first and then connect Slim 322 to

the USB port.

2. Installing the Slim 322 driver

Windows Environment

a. Insert the Slim 322 Installation CD into the CD-ROM drive.

b. The Autorun screen will bring up the installation screen. Click on

“Driver” then simply follow the on-screen instructions.

c. Install “DirectX” from the CD.

Notice: If theAutorun screen doesn’t start, please follow these

steps:

zClick on “Start Menu”.

zType D：\SETUP.EXE , then click “Enter” key.

(Assume your CD-ROM is in Drive D)

Mac Environment

a. Insert the Slim 322 Installation CD into the CD-ROM drive.

1 SnapShot Button

You can press the snapshot button to take the

images.

2 Lens

Adjust the focus by twisting the lens

3 Adjustable base

The adjustable base allows you to place the Slim

322 on different sizes of LCD monitors.

Slim 322 Features

Installing the Slim 322

English

-2- www.geniusnet.com

b. Double click on the CD-ROM drive.

c. Click on the file folder of “Slim 322 Driver OSX 1.0”.

d. Click on “Slim 322 Driver Install” then simply follow the

on-screen instructions.

e. Restart the computer

Notice:

zThe Slim 322 can work properly with any video chat

software supported video feature and USB web camera.

The iChat can’t be supported because it only support the

Apple’s web cameras or the IEEE 1394 web camera.

3. Insert the Slim 322’s USB cable to your desktop’s or

laptop’s USB port.

4. Complete software and hardware installation. You can

install the software you would like to use for video

conferencing or chat with your friends.

NOTE

To remove the driver installation:

Windows Environment:

Please go to the taskbar and follow “Start” Æ“Program” Æ“Slim 322”Æ

Click “Uninstall”, then follow the on-screen instructions to remove the

driver.

Mac OSX Environment:

Please go to the HDD of the operation systemÆ“Application”Æ“Slim

322”ÆClick “Uninstall”, then follow the on-screen instructions to remove

the driver.

English

-3- www.geniusnet.com

You can use our software to capture the real-time image, record or

execute the simply security function.

To run the software, please go to the task bar and follow “Start”Æ

Click “Program”ÆChoose “Slim 322”ÆClick “Slim 322”. Or you

may execute the software by simply clicking the shortcut of “Slim 322”.

NOTE

After installing the driver of Slim 322, the system will automatically create a

file (C:\WINDOWS\Album or C:\WINNT\Album)to save the images you take

using the Genius Application.

1. Description for the major icon

Preview mode

Snapshot mode

Video Clip Mode

Security monitoring system

Exit the Genius UI

Camera Control

Genius Application (Windows Only)

English

-4- www.geniusnet.com

NOTE

In the “camera control section”, you can personalize your camera

settings for different circumstances.

English

-5- www.geniusnet.com

1-You can flip the image horizontally or vertically by choosing “Image Mirror” or

“Image Flip”.

-When the light is not sufficient, you may click on “Low Light” to get a clear

image.

2You can adjust different values for different circumstances and environment

3When you want a still image capture, you can drag the bar to select a resolution

size you want.

-VGA: 640 x 480;

-SVGA: 800 x 600

-XGA: 1024 x 768

-SXGA1280 x 960

4You may adjust values toward image appearance. Before adjusting values, you

have to unclick “Auto” to unlock.

5-Press “Reset” to return to the manufacturer’s settings.

-Press “Restore” to return to the previous settings.

-Press “Save” to save the values you set up.

English

-6- www.geniusnet.com

6Select the correct frequency according to the country where you are using the

web camera. (Before doing this, you will need to select “Indoor”.)

7-If your web camera is located in backlight position, you may click “Backlight

compensation” to get a sharper image.

-You can have a black-and-white photo effect by clicking on “B/W Mode”.

1There will be 27 different kinds of video effects/frames for you to select. The

effects can also be applied to the video chat software, like MSN Messenger.

You can directly connect to this effect page from the web camera settings in the

video chat software.

English

-7- www.geniusnet.com

2Besides the 27 kinds of video effects/frames in section 1, you also can bring in

your customized frame. Please note that, in the customized frame, you must have

the color in Pantone 255 in the area, where you want your image show up.

3Auto Change: Once you choose this, the 27 kinds of video effects will take turns

from the first one to the last one.

No effects & frame: Once you choose this, the video effects will be determinate.

English

-8- www.geniusnet.com

In this section, you can enable the “Zoom” function. Please select “Enable

Zoom” before zooming.

-Scroll the bar to zoom in or zoom out

-Press the 4-direction button to move the image upward, downward,

leftward, and rightward.

English

-9- www.geniusnet.com

2. Preview Mode

You can use the function buttons on the control panel to zoom in/out and

move upward/downward/left/right.

Zoom in the image

Zoom out the image

Move the image upward

Move the image downward

Move the image to the left

English

-10- www.geniusnet.com

Move the image to the right

Resolution Selection

There are 2 categories of resolution: RGB24 and

I420. You can select 5 different image resolutions for

each of them. The file size of I420 will be smaller than

RGB24. So, I420 may be the better choice for

transmission.

3. SnapShot Mode

You can press the Snapshot button in the right of the circle to take a

picture right away and share with your friends.

Send photo by e-mail

Shoot continuously
