Genius I-LOOK 317 Manual de usuario

English

Table of Contents

i-Look 317 Features 1

Installing the i-Look 317 2-3

About Genius Application-WebCAM Mate 3

1. Main Menu 4-8

2. Picture Mode 9-11

3. Video Mode 12-13

4. Security Mode 13-16

Using MSN Messenger,Yahoo Messenger,AOL 16-18

CrazyTalk Avatar Creator 18-40

CrazyTalk CamSuite 41-68

Trouble shooting for web camera 69

English

-1-

Symbol for Separate Collection in European Countries

This symbol indicates that this product is to be collected separately.

The following apply only to users in European countries:

zThis product is designated for separate collection at an appropriate

collection point. Do not dispose of as household waste.

zFor more information, contact the retailer or the local authorities in charge

of waste management.

Add live video to your instant messaging!

Turn your PC into a live broadcast hub with i-Look 317. Works with windows

Vista, XP, 2000, Me, 98SE. Whether you are creating video emails or hosting

one-to-one video chats, this easy to use webcam adds a personal touch to

your online communication. Connect with loved ones easily today with live

video chats!

1.SnapShot Button

You can press the snapshot button

to take images.

2.Microphone

3.LED Indicator

i-Look 317 is connected to the

computer's USB port and the LED

will light up when performing video

application.

4.Manual Lens

Adjust the focus by twisting the

lens.

i-Look 317 Features

English

-2-

You need to install device drivers and applications before using your

webcam.

Do not connect your webcam to your computer before

installing the drivers.

1. Installing the i-Look 317 driver Windows Vista/XP/2000/Me/98SE

Environment

a. Insert the i-Look 317 Installation CD into the CD-ROM drive.

b. The Autorun screen will bring up the installation screen. Click on

“Driver” then simply follow the on-screen instructions.

c. Install DirectX from the CD if your pc didn’t have it on your system or

the version was older.

NOTE

If the Autorun screen doesn’t start, please follow these steps

zClick on “Start Menu”

zType D:\SETUP.EXE, then click the Enter key.

(Assume your CD-ROM is in Drive D)

2. Follow the instructions on the screen to complete the installation.

3. Insert the i-Look 317’s USB cable to your desktop or laptop USB

port.

4. Restart your computer after all the applications have been

installed.

Installing the i-Look 317

English

-3-

5. The software and hardware installation is now complete. You can

install the software you would like to use for video conferencing

or chat with your friends.

NOTE

The web camera can work properly with any video chat software that supports a

video feature.

To remove the driver installation in Windows 98SE/Me/2000/XP/Vista Environment:

Please go to the taskbar and follow “Start ÆProgram Æi-Look 317

ÆClick “Uninstall”, then follow the on-screen instructions to remove the driver.

You can use Genius WebCAM Mate software to capture the

real-time image, record or execute the simple security function.

NOTE

After installing the Genius Application software, the system will

automatically create a file (C:\WINDOWS\Album or

C:\WINNT\Album)to save the images you take using the Genius

Application.

Genius application available in windows Vista/XP/2000/Me/98SE

About Genius Application-WebCAM Mate

English

-4-

1. Main Menu

Item Mode Description

Picture Mode Still image capture mode.

Video Mode Video recording mode.

Security Mode Security monitoring mode.

Device

Selection Select different webcam device.

English

-5-

Item Mode Description

Resolution

Selection

Resolution selections according to

device.

RGB24: 1280x1024 (*), 1024x768 (*),

800x600 (*), 640x480, 352x288,

320x240, 176x144, 160x120

I240: 1280x1024 (*), 1024x768 (*),

800x600 (*), 640x480, 352x288,

320x240, 176x144, 160x120

Property page Preference setting to view your setting

and properties.

Exit Exit the Genius UI.

Remark:

* This resolution is by software interpolation.

English

-6-

-Property page

Stream Property

Item Description

-You can flip the image horizontally or vertically by choosing

“Image Mirror” or “Image Flip”.

-When the light is not sufficient, you may click on “Low Light” to

get a clear image.

You can adjust different values for different circumstances and

environment.

English

-7-

Item Description

You may adjust values toward image appearance. Before

adjusting values, you have to unclick “Auto” to unlock.

-Press “Reset” to return to the manufacturer’s settings.

-Press “Restore” to return to the previous settings.

-Press “Save” to save the values you set up.

Select the correct frequency according to the country where you

are using the web camera. (Before doing this, you will need to

select “Indoor”.)

-If your web camera is located in backlight position, you may click

“Backlight compensation” to get a sharper image.

-You can have a black-and-white photo effect by clicking on “B/W

Mode”.

English

-8-

Item Description

The effects can also be applied to the video chat software, like

MSN Messenger.

English

-9-

2. Picture Mode

Take a picture right away and share with your friends.

Item Mode Description

Shot Still image capture mode.

Multi-Snapshot Capture continuous still images based

on multi-snapshot number.

Mail Send photo by email.
