Genius ISLIM 321R Manual de usuario

English

Table of Contents

iSlim 321R Features 1

Installing the iSlim 321R 2

Setting the LED On/Off and Frequency 3

About Genius Application-WebCAM Mate 4

1. Main Menu 4-8

2. Picture Mode 9-11

3. Video Mode 12-13

4. Security Mode 13-16

Using MSN Messenger,Yahoo Messenger,AOL 16-17

CrazyTalk Avatar Creator 18-42

CrazyTalk CamSuite 43-70

Trouble shooting for web camera 71

English

-1-

Symbol for Separate Collection in European Countries

This symbol indicates that this product is to be collected separately.

The following apply only to users in European countries:

zThis product is designated for separate collection at an appropriate

collection point. Do not dispose of as household waste.

zFor more information, contact the retailer or the local authorities in charge

of waste management.

The iSlim 321R is designed as an all-hours web camera. The infrared

technology allows you to video chat in a low-light environment. Meanwhile,

iSlim 321R is compliant with UVC (USB Video Class); supports Plug & Play,

so no driver is required so it’s the ideal web camera for you!

1. SnapShot Button

You can press the snapshot button to

take still images.

2. Lens

You can adjust the focus by twisting

the lens.

3. Red-Infrared light

The infrared allows you to video chat

in a low-light environment.

4. Microphone

Built-in microphone lets you talk

freely.

5. LED Indicator

The LED will light up when the web

camera is performing a video

application.

6. Universal Clipping Base

The adjustable clipping base fits

easily to almost any panel -

Notebook and LCD monitors.

iSlim 321R Features

English

-2-

iSlim 321R supports UVC (USB Video Class) which can plug and play in

Windows XP SP2, Vista or Mac 10.4.9 and above without using a device

driver.

1. Make sure your PC OS system is Windows XP SP2, Vista or Mac

10.4.9 and above.

2. Plug in the iSlim 321R to a USB port. It is now ready for use with any

application. The web camera can work properly with any video chat

software that supports a video feature.

3. Genius application:

You can use the Genius application software to capture a real-time

image, record or execute simple security functions. The Snapshot

function will work in the Genius application software.

4. In Windows XP SP2 and Vista:

a. Double-click on the My Computer icon. Or click Start ÆMy

Computer.

b. Select “USB Video Device” and double-click, and the video

appears on the screen automatically.

5. In Mac 10.4.9 or above:

Click iChat ÆPreference. Now you can use iSlim 321R for online

chatting.

NOTE

To check if Windows XP system is SP2 (Service Pack 2).

−Click on the My Computer icon on your desktop or in the

Windows Start menu.

−When the menu appears, click Properties.

If your Windows XP system isn’t SP2 (Service Pack 2), go to the

website http://www.microsoft.com to upgrade your version.

Installing the Device

English

-3-

1. After you install WebMate, you’ll find a Genius Manager Icon in the

system tray.

2. Put the mouse pointer on Genius Manager Icon, and click the right

button. Then you can select if you want the LED on or off and the

Frequency at 50Hz or 60Hz.

NOTE

60Hz: USA, Canada, Japan, South Korea, Taiwan, etc.

50Hz: UK, Europe, China, Australia, Singapore, Hong Kong, etc.

Setting the LED On/Off and Frequency

Genius Mana

Icon

English

-4-

You can use Genius WebCAM Mate software to capture the

real-time image, record or execute the simple security function.

NOTE

After installing the Genius Application software, the system will

automatically create a file (C:\WINDOWS\Album or C:\WINNT\Album)

to save the images you take using the Genius Application.

Genius application is compatible to Windows Vista/XP/2000/Me/98SE

1. Main Menu

About Genius Application-WebCAM Mate

English

-5-

Item Mode Description

Picture Mode Still image capture mode.

Video Mode Video recording mode.

Security Mode Security monitoring mode.

Device

Selection Select different webcam device.

Resolution

Selection

Resolution selections according to

device.

MJPG: 640x480, 352x288, 320x240,

176x144, 160x120

YUY2: 640x480, 352x288, 320x240,

176x144, 160x120

Property page View your settings and properties.

Exit Exit the Genius UI.

English

-6-

-Property page

Property page lets you adjust the web cam to your personal liking.

-Video Proc Amp

Item Description

Brightness enables you to adjust the brightness of the displayed

image or video.

Contrast enables you to control the ratio between dark and light.

Hue is any color in the rainbow that you choose to pick.

English

-7-

Item Description

Saturation enables you to set the color reproduction from black

and white to full color image or video.

Sharpness can soften or sharpen images to achieve different

effects.

Gamma enables you to brighten dark areas within the displayed

image or video and visualize more details without over-exposing

already light areas.

You can adjust different values for different circumstances

depending on your environment.

Turn on the backlight compensation to improve the image quality

when you have a scene where the background has a high

illumination level (for instance when you are sitting in front of a

bright light).

English

-8-

-Camera control

Item Description

When resolution is set to 352x288, 320x240, 176x144 and

160x120, you can execute zoom in/out picture function.

Here, the focus option is to turn on and off the infrared LED light

so you can video chat in a low-light environment.

English

-9-

2. Picture Mode

Take a picture right away and share with your friends.

Item Mode Description

Shot Still image capture mode.

Multi-Snapshot Capture continuous still images based

on multi-snapshot number.

Mail Send photo by email.
