Owner’s Manual

For

PWRview™ Automatic Transfer Switch

200 Amp Service Entrance

Model Number

RXEMW200A3

SERIAL NUMBER: _________________________

DATE PURCHASED:________________________

WWW.GENERAC.COM

888-436-3722

Para español , visita: http://www.generac.com/service-support/product-support-lookup

SAVE THIS MANUAL FOR FUTURE REFERENCE

PWRview™

ii Automatic Transfer Switch Owner’s Manual

(000393a)

WARNING

CANCER AND REPRODUCTIVE HARM

www.P65Warnings.ca.gov.

Automatic Transfer Switch Owner’s Manual iii

Section 1: Safety

Introduction ..........................................................1

Read This Manual Thoroughly ....................................1

Safety Rules .........................................................1

Electrical Hazards ................................................2

General Hazards ..................................................3

Section 2: General Information

Unpacking ............................................................5

Equipment Description .......................................5

Transfer Switch Mechanism ........................................5

Utility Service Circuit Breaker (if equipped) .................5

Transfer Switch Data Decal ................................6

Transfer Switch Enclosure .................................6

Safe Use of Transfer Switch ...............................6

Load Management Options .................................6

Smart A/C Module (SACM) .........................................6

Smart Management Module (SMM)

(50 amp and 100 amp sold separately) .......................7

Application Considerations ..........................................7

Section 3: Installation

Introduction to Installation .................................9

Mounting ...............................................................9

Open Enclosure ...................................................9

Connecting Power Source and Generator

Power Supply .....................................................10

Connecting Start Circuit Wires .........................11

Connecting SACM .............................................11

Control of Air Conditioner Load .................................11

Auxiliary Contact ...............................................13

Fault Current Label ............................................13

Installing PWRview Antenna ............................14

Connecting PWRview CTs ................................14

Section 4: Operation

Functional Tests and Adjustments .................. 15

Manual Operation .............................................. 15

Close to Utility Source Side .......................................15

Close to Generator Source Side ...............................16

Return to Utility Source Side .....................................16

Voltage Checks .................................................. 16

Utility Voltage Checks ...............................................16

Generator Voltage Checks ........................................16

Generator Tests Under Load ............................ 16

Checking Automatic Operation ........................ 17

Installation Summary ........................................ 17

Shutting Generator Down While Under Load

or During a Utility Outage ................................. 17

Preparing for Maintenance ............................... 18

Testing The SACM ............................................. 18

SACM Fuse Service ........................................... 18

Testing The SMM ............................................... 18

PWRview Monitor Operation ............................ 18

PWRview Monitor Reset ................................... 19

PWRview Fuse Replacement ........................... 19

Section 5: Drawings and Diagrams

Installation Drawings ........................................ 21

No.10000012171: 150/200A SE ................................21

Interconnection Drawings ................................ 22

No. A0000485206—Liquid-Cooled Generator ..........22

No. A0000485221, SE and non-SE Rated

ATS—Air-Cooled Generator .....................................23

Table of Contents

iv Automatic Transfer Switch Owner’s Manual

This page intentionally left blank.

Safety

Automatic Transfer Switch Owner’s Manual 1

Section 1 Safety

Introduction

Thank you for purchasing a Generac Power Systems Inc.

product. This unit has been designed to provide high

performance, efficient operation, and years of use when

maintained properly.

Read This Manual Thoroughly

If any section of this manual is not understood, contact

the nearest Independent Authorized Service Dealer

(IASD) or Generac Customer Service at 1-888-436-3722

(1-888-GENERAC), or visit www.generac.com for start-

ing, operating, and servicing procedures. The owner is

responsible for proper maintenance and safe use of the

unit.

SAVE THESE INSTRUCTIONS for future reference. This

manual contains important instructions that must be fol-

lowed during placement, operation, and maintenance of

the unit and its components. Always supply this manual

to any individual that will use this unit, and instruct them

on how to correctly start, operate, and stop the unit in

case of emergency.

Safety Rules

The manufacturer cannot anticipate every possible cir-

cumstance that might involve a hazard. The alerts in this

manual, and on tags and decals affixed to the unit, are

not all inclusive. If using a procedure, work method, or

operating technique that the manufacturer does not spe-

cifically recommend, verify that it is safe for others and

does not render the equipment unsafe.

Throughout this publication, and on tags and decals

affixed to the unit, DANGER, WARNING, CAUTION, and

NOTE blocks are used to alert personnel to special

instructions about a particular operation that may be

hazardous if performed incorrectly or carelessly. Observe

them carefully. Alert definitions are as follows:

NOTE: Notes contain additional information important to

a procedure and will be found within the regular text of

this manual.

These safety alerts cannot eliminate the hazards that

they indicate. Common sense and strict compliance with

the special instructions while performing the action or

service are essential to preventing accidents.

(000100a)

Consult Manual. Read and understand manual

completely before using product. Failure to

completely understand manual and product

could result in death or serious injury.

WARNING

(000001)

DANGER

Indicates a hazardous situation which, if not avoided,

will result in death or serious injury.

(000002)

WARNING

Indicates a hazardous situation which, if not avoided,

could result in death or serious injury.

(000003)

CAUTION

Indicates a hazardous situation which, if not avoided,

could result in minor or moderate injury.

Safety

2Automatic Transfer Switch Owner’s Manual

Electrical Hazards

(000129)

DANGER

Electrocution. High voltage is present at

transfer switch and terminals. Contact with live

terminals will result in death or serious injury.

(000104)

DANGER

Electrocution. Water contact with a power

source, if not avoided, will result in death

or serious injury.

(000145)

DANGER

Electrocution. In the event of electrical accident,

immediately shut power OFF. Use non-conductive

implements to free victim from live conductor. Apply

first aid and get medical help. Failure to do so will

result in death or serious injury.

(000237)

DANGER

Electrical backfeed. Use only approved switchgear to

isolate generator from the normal power source.

Failure to do so will result in death, serious injury,

and equipment damage.

Electrocution, equipment and property damage. Handle

transfer switches carefully when installing. Never install

a damaged transfer switch. Doing so could result in

death or serious injury, equipment and property

damage. (000195)

DANGER

(000123)

DANGER

Electrocution. Turn utility supply OFF before

working on utility connections of the transfer

switch. Failure to do so will result in death or

serious injury.

(000157)

DANGER

Electrocution. Do not disable or modify the

connection box door safety switch. Doing so

will result in death or serious injury.

(000191)

DANGER

Automatic start-up. Disconnect utility power and

render unit inoperable before working on unit.

Failure to do so will result in death or serious injury.

(000119)

DANGER

Equipment malfunction. Installing a dirty or damaged

transfer switch will cause equipment malfunction and

will result in death or serious injury.

(000155a)

WARNING

Electric shock. Only a trained and licensed electrician

should perform wiring and connections to unit. Failure to

follow proper installation requirements could result in death,

serious injury, and equipment or property damage.

(000120)

Equipment damage. Verify all conductors are tightened

to the factory specified torque value. Failure to do so

could result in damage to the switch base.

CAUTION

(000121)

Equipment damage. Perform functional tests in the

exact order they are presented in the manual.

Failure to do so could result in equipment damage.

CAUTION

(000134a)

CAUTION

Equipment damage. Exceeding rated voltage and

current will damage the auxiliary contacts. Verify

that voltage and current are within specification

before energizing this equipment.

Safety

Automatic Transfer Switch Owner’s Manual 3

General Hazards

•Competent, qualified personnel should install,

operate and service this equipment. Adhere strictly

to local, state and national electrical and building

codes. When using this equipment, comply with

regulations established by the National Electrical

Code (NEC), CSA Standard; the Occupational

Safety and Health Administration (OSHA), or the

local agency for workplace health and safety.

•If working on this equipment while standing on

metal or concrete, place insulative mats over a dry

wood platform. Work on this equipment only while

standing on such insulative mats.

•Never work on this equipment while physically or

mentally fatigued.

•Any voltage measurements should be performed

with a meter that meets UL3111 safety standards,

and meets or exceeds overvoltage class CAT III.

(000237)

DANGER

Electrical backfeed. Use only approved switchgear to

isolate generator from the normal power source.

Failure to do so will result in death, serious injury,

and equipment damage.

(000129)

DANGER

Electrocution. High voltage is present at

transfer switch and terminals. Contact with live

terminals will result in death or serious injury.

(000123)

DANGER

Electrocution. Turn utility supply OFF before

working on utility connections of the transfer

switch. Failure to do so will result in death or

serious injury.

(000104)

DANGER

Electrocution. Water contact with a power

source, if not avoided, will result in death

or serious injury.

(000188)

DANGER

Electrocution. Do not wear jewelry while

working on this equipment. Doing so will

result in death or serious injury.

(000213)

DANGER

Electrocution. Only authorized personnel should

access transfer switch interior. Transfer switch

doors should be kept closed and locked. Failure to

do so will result in death or serious injury.

(000191)

DANGER

Automatic start-up. Disconnect utility power and

render unit inoperable before working on unit.

Failure to do so will result in death or serious injury.

(000145)

DANGER

Electrocution. In the event of electrical accident,

immediately shut power OFF. Use non-conductive

implements to free victim from live conductor. Apply

first aid and get medical help. Failure to do so will

result in death or serious injury.

(000209b)

WARNING

Loss of life. This product is not intended to

be used in a critical life support application.

Failure to adhere to this warning could result

in death or serious injury.

(000247a)

Equipment damage. This unit is not intended for use as a prime

power source. It is intended for use as an intermediate power

supply in the event of temporary power outage only. Doing so

could result in death, serious injury, and equipment damage.

WARNING

Safety

4Automatic Transfer Switch Owner’s Manual

This page intentionally left blank.

General Information

Automatic Transfer Switch Owner’s Manual 5

Section 2: General Information

Unpacking

Carefully unpack the transfer switch. Inspect closely for

any damage that might have occurred during shipment.

The purchaser must file with the carrier any claims for

loss or damage incurred while in transit.

Check that all packing material is completely removed

from the switch prior to installation.

Equipment Description

This automatic transfer switch is used for transferring

electrical load from a utility (normal) power source to a

generator (standby) power source. Transfer of electrical

loads occurs automatically when the utility power source

has failed or is substantially reduced and the generator

source voltage and frequency have reached an

acceptable level. The transfer switch prevents electrical

feedback between two different power sources (such as

the utility and generator sources) and, for that reason,

codes require it in all standby electric system installations.

The transfer switch consists of a transfer mechanism,

utility service disconnect circuit breaker (if equipped), a

PWRview energy monitor, and a Smart A/C module

incorporating fuses and two terminal blocks for transfer

switch connections.

Transfer Switch Mechanism

See Figure 2-1. This switch is used with a single-phase

system when the single-phase neutral line is to be

connected to a neutral lug and is not to be switched.

Solderless, screw-type terminal lugs are standard.

The conductor size range is as follows:

This transfer switch is suitable for control of motors, electric

discharge lamps, tungsten filament and electric heating

equipment where the sum of motor full load ampere ratings

and the ampere ratings of other loads do not exceed the

ampere rating of the switch and the tungsten load does not

exceed 30 percent of the switch rating.

This UL listed transfer switch is for use in optional

standby systems only (NEC article 702).

A 100A rated switch is suitable for use on circuits capable

of delivering not more than 10,000 RMS symmetrical

amperes, 250 VAC maximum, when protected by a 100A

maximum circuit breaker (Siemens types QP or BQ) or

150A maximum circuit breaker (Square D Q2,

Westinghouse CA-CAH, General Electric TQ2 and

Siemens QJ2).

A 200A rated switch is suitable for use on a circuit

capable of 22,000 RMS symmetrical amperes, 240 VAC

when protected by a circuit breaker without an adjustable

short time response or by fuses.

Figure 2-1. Typical Single-Phase ATS Transfer

Mechanism

Utility Service Circuit Breaker (if equipped)

The utility service circuit breakers for 200 amp models

are:

•Type 225AF, 2-pole

•22,000 A/C

•120/240VAC, 150A/200A

•50/60 Hertz

•Wire range:

– Line: 300 MCM - 6 STR (Cu/Al)

– Load - ATS: 250 MCM - 6 STR (Cu/Al)

•The conductor tightening torque is:

– Line: 375 in-lbs (42.4 Nm)

– Load - ATS: 275 in-lbs. (31 Nm)

Switch

Rating Wire Range Conductor

Tightening Torque

100A #14-1/0 AWG (Cu/Al) 50 in-lbs (5.6 Nm)

150/200A #6-250 MCM (Cu/Al) 275 in-lbs (31 Nm)

A Utility Closing Coil

B Generator Closing Coil

C Utility Lugs (N1 & N2)

D Generator Lugs (E1 & E2)

E Load Lugs (T1 & T2)

000219

General Information

6Automatic Transfer Switch Owner’s Manual

Transfer Switch Data Decal

A data decal is permanently affixed to the transfer switch

enclosure. Use this transfer switch only with the specific

limits shown on the data decal and on other decals and

labels that may be affixed to the switch. This will prevent

damage to equipment and property.

When requesting information or ordering parts for this

equipment, make sure to include all information from the

data decal.

For future reference, record the Model and Serial

numbers in the space provided on the front cover of this

manual.

Transfer Switch Enclosure

The standard switch enclosure is a National Electrical

Manufacturer’s Association (NEMA) and UL 3R type. UL

and NEMA 3R (indoor/outdoor rated) type enclosures

primarily provide a degree of protection against falling

rain and sleet; are undamaged by the formation of ice on

the enclosure.

Safe Use of Transfer Switch

Before installing, operating or servicing this equipment,

read the Safety Rules carefully. Comply strictly with all

Safety Rules to prevent accidents and/or damage to the

equipment. The manufacturer recommends that a copy

of the Safety Rules be posted near the transfer switch.

Also, be sure to read all instructions and information

found on tags, labels and decals affixed to the

equipment.

Two publications that outline the safe use of transfer

switches are the following:

•NFPA 70; National Electrical Code

•UL 1008: Standard for Safety—Automatic Transfer

Switches

NOTE: It is essential to use the latest version of any

standard to guarantee correct and current information.

Load Management Options

Load management systems are designed to work

together to prevent a generator from being overloaded by

large appliance loads. A Smart A/C Module (SACM) is

provided as standard equipment with this switch. An

optional Smart Management Module (SMM) is also

available.

Smart A/C Module (SACM)

Up to four air conditioner loads can be managed by the

SACM. The SACM manages the loads by “shedding” the

connected loads in the event of a drop in generator

frequency (overload). Loads to be “shed” are in 4 priority

levels on the module.

See Figure 2-2. Priorities A/C 1-4 (A) have connections

for an air conditioner. To control an air conditioner, no

additional equipment is required. Internal normally closed

relays interrupt the 24 VAC thermostat control signal to

disable the air conditioner load.

Four LEDs, located on the SACM (B), illuminate when a

load is connected and powered.

See Figure 2-2. The SACM has a test button (C) used to

simulate an overload condition. This button operates

even when the transfer signal is inactive. The Generator

Control Wiring is connected to terminals (D).

Figure 2-2. Smart A/C Module (SACM)

(000100a)

Consult Manual. Read and understand manual

completely before using product. Failure to

completely understand manual and product

could result in death or serious injury.

WARNING

T1N1N2

0 DC GROUND

194 +12 VDC

23 TRANSFER

006783

Tabla de contenidos

Otros manuales de Cambiar de Generac Power Systems

Generac Power Systems

Generac Power Systems GenReady Series 005448-2 Guía de instalación

Generac Power Systems

Generac Power Systems CTTS Series Manual de usuario

Generac Power Systems

Generac Power Systems RTS Series Manual de usuario

Generac Power Systems

Generac Power Systems HTS Wn Manual de usuario

Generac Power Systems

Generac Power Systems TRANSFER SWITCH Manual de instrucciones

Generac Power Systems

Generac Power Systems TMS200 Manual de usuario

Generac Power Systems

Generac Power Systems GTS Series Manual de usuario

Generac Power Systems

Generac Power Systems RXSW400A3CUL Manual de usuario

Generac Power Systems

Generac Power Systems GenTran 6294 Manual de usuario

Generac Power Systems

Generac Power Systems GenTran 6333 Hoja de instrucciones

Generac Power Systems

Generac Power Systems GenTran 6295 Manual de usuario

Generac Power Systems

Generac Power Systems 004945-1 Manual de usuario

Generac Power Systems

Generac Power Systems 006852 Manual de usuario

Generac Power Systems

Generac Power Systems GenTran 6375 Manual de usuario

Generac Power Systems

Generac Power Systems RTSG300A3 Manual de usuario

Generac Power Systems

Generac Power Systems 004635-3 Manual de usuario

Generac Power Systems

Generac Power Systems ILC Manual de usuario

Generac Power Systems

Generac Power Systems RTS Manual de usuario

Generac Power Systems

Generac Power Systems 5464 Manual de usuario

Generac Power Systems

Generac Power Systems GenTran 6295 Hoja de instrucciones

Generac Power Systems

Generac Power Systems OG 2697 Hoja de instrucciones

Generac Power Systems

Generac Power Systems SnapRS Manual de usuario

Generac Power Systems

Generac Power Systems 09227-0 Manual de usuario

Generac Power Systems

Generac Power Systems Automatic Transfer Switch Manual de usuario

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
