Generac Power Systems GP17500E Manual de usuario

1 of 2

GP SERIES

Commercial/Residential

Portable Generators

GP17500E

Model 5735

UPC Number: 696471057355

Emissions Certification: 49-State

A/C Rated Output Watts 17,500

A/C Maximum Output Watts 26,250

customer connectionsfeatures

Outlets

A(1) Duplex 5-20R GFCI

B(1) Duplex 5-20R 120V

C(2) L5-30R

D(1) L14-30R

E(1) 12VDC

F(1) 14-50R

Circuit Breakers

M(2) 20A

N(4) 30A

O(1) 50A

Other Features

HHour Meter

IIdle Control Switch

FUNDERNEATH PANEL

DNC

120V/240V

CIRCUIT BREAKERS - PUSH TO RESET

CONTROL

30A

10A

12Vdc

30A 30A

OFF

30A 30A

20A

120V

IDLE

20A

GFCI

30A

120V

30A

120V

20A

GFCI

TEST

RESET

HIME

GP17500E

• GENERAC OHVI ENGINE, FULL PRESSURE

LUBRICATION

• HIGH PERFORMANCE ALTERNATOR

• LARGE CAPACITY FUEL TANK FOR EXTENDED

RUN TIME

• IDLE CONTROL

• CIRCUIT BREAKER PROTECTED OUTLETS

• BUILT-IN LIFTING EYE

• HEAVY DUTY, FIXED HANDLES

• 12.3" PNEUMATIC WHEELS

• 1.25" HARDENED STEEL TUBE CRADLE

• LOW TONE MUFFLER

2 of 2

GP17500E

Generac Power Systems, Inc. • P.O. Box 8, Waukesha, WI 53187 • generac.com

GP17500E

specifications

Product Series GP17500E Start Switch Type 3-Position

Model 5735 Switch Location On Engine

Configuration/Emissions 49-State Single-Point Lifting Eye Yes

A/C Rated Output Watts: 17,500 Fuel Gauge Built-in Tank

A/C Maximum Output Watts: 26,250 Fuel Tank Capacity (Gal) 16

A/C Voltage 120/240VAC Fuel Tank Capacity (Ltrs) 60.56

A/C Frequency 60 Hz Run Time at 50% (Hours) 10

Rated 120/240 VAC Amperage 72.9 Cord Set N/A

Max 120/240 VAC Amperage 109.4 Handle Style Fixed

Neutrals Not bonded to ground (Floating) Wheel type 12.3" Pneumatic Wheels

Engine Displacement 992cc Maintenance Kit Included

Engine Type OHVI Warranty - Residential 2 Year

Engine RPM 3600 Warranty - Commercial 1 Year

Recommended Oil SAE 30

Lubrication Method Full Pressure

Choke Type Manual Lever

Fuel Shut Off Manual Lever

Idle Control Yes

Starting Method Electric

Battery Included

Battery Size 12VDC 365 CCA

Low Oil Shutdown Method Low Pressure

dimensions and weights

Length (L) 48.5

Width (W) 31

Height (H) 38.5

Carton Length 49.25

Carton Width 23.25

Carton Height 31

Unit Weight (lbs) 390

Shipping Weight (lbs) 513
