Generac Power Systems Automatic Standby Generator Manual de usuario

Owner’s Manual

Automatic Standby Generator

Reference all appropriate documentation.

This manual should remain with the unit.

nNOT INTENDED FOR USE IN CRITICAL LIFE SUPPORT APPLICATIONS.

nONLY QUALIFIED ELECTRICIANS OR CONTRACTORS SHOULD ATTEMPT

INSTALLATION.

nDEADLY EXHAUST FUMES! OUTDOOR INSTALLATION ONLY!

LISTED

CUS

8 kW to 22 kW

To locate in Spanish, go to http://www.generac.com/service‐support/product‐support‐lookup

To locate in French, go to http://www.generac.com/service‐support/product‐support‐lookup

WARNING!

California Proposition 65

Engine exhaust and some of its constituents are known to the state of California to cause cancer,

birth defects, and other reproductive harm.

WARNING!

California Proposition 65

This product contains or emits chemicals known to the state of California to cause cancer,

birth defects, and other reproductive harm.

Use this page to record important information about your generator set.

Record the information found on your unit data label on this page. For the location of

the unit data label, see Section 2 General Information. The unit has a label plate

affixed to the inside partition, to the left of the control panel console as shown in Fig-

ures2-1,2-2,and 2-3. Fordirections onhow to open the top lid and remove the front

panel, see Section 3 Operation. The Unit Identification label provides the following

information:

• Model Number

• Serial Number

• Control Panel Part Number

• Voltage Rating of the unit

• Maximum Current Rating of the unit (AMPS)

WhencontactinganindependentAuthorizedServiceDealerabout parts andservice,

always supply the complete model number and serial number of the unit.

Operation and Maintenance: Proper maintenance and care of the generator

ensures a minimum number of problems and keeps operating expenses at a mini-

mum.Itis the operator’sresponsibility to performallsafety checks,to make surethat

allmaintenancefor safeoperation is performedpromptly, and to have the equipment

checked periodically by an independent Authorized Service Dealer. Normal mainte-

nance, service and replacement of parts are the responsibility of the owner/operator

and, as such, are not considered defects in materials or workmanship within the

terms of the warranty. Individual operating habits and usage may contribute to the

need for additional maintenance or service.

Whenthegeneratorrequiresservicingorrepairs, contactanindependentAuthorized

ServiceDealerforassistance.Authorized service techniciansarefactory-trainedand

are capable of handling all service needs.

To find your Local Independent AUTHORIZED SERVICE DEALER

INDEPENDENT AUTHORIZED

SERVICE

DEALER LOCATION

To locate the nearest INDEPENDENT

AUTHORIZED SERVICE DEALER, please

call this number:

1-800-333-1322

or, visit the dealer locator at:

www.generac.com/Service/Dealer Locator/

Table of Contents

iii

Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv

Section 1 — Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1.1 — General Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.2 — General Safety Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.3 — Exhaust Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.4 — Electrical Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.5 — Fire Hazards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.6 — Explosion Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Section 2 — General Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2.1 — The Generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2.2 — Protection Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.3 — Emission Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.4 — Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.5 — Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Section 3 — Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

3.1 — Control Panel Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

3.2 — Using the Auto/Off/Manual Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3.3 — Interface Menu Displays. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3.4 — Automatic Transfer Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3.5 — Turning the Generator Off When Operating Under Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3.6 — Manual Transfer Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3.7 — Side Compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.8 — Battery Charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.9 — Setting the Exercise Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Section 4 — Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

4.1 — Performing Scheduled Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

4.2 — Service Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

4.3 — Checking Engine Oil Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

4.4 — Changing the Engine Air Cleaner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.5 — Spark Plugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.6 — Valve Lash Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

4.7 — Battery Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

4.8 — Attention After Submersion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4.9 — Corrosion Protection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

4.10 — Out of Service Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Section 5 — Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Section 6 — Quick Reference Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

FREQUENTLYASKEDQUESTIONS

ThislistofFrequentlyAskedQuestions(FAQs)arethefrequentlyaskedquestions

thatpertaintoALLHomeStandbymodels.

Somequestionsmaynotbeapplicabletothemodel(s)coveredinthispublication.

PleasereviewtheSafetySectionofyourproduct’sOwnersorInstallationManualbeforeoperatingyourHome

StandbyGenerator.

INSTALLATION

Q: What are the installation clearance requirements for standby generators?

A: All standby generator clearance requirements are dictated by the National Fire Protection Association

(NFPA) code 37. See detailed instructions in your Manual for clearance requirements.

Q: How do I activate my home standby generator?

A: Products with a digital control panel require an activation code before the unit can be operated in the auto-

matic mode. (The unit will only run in the manual mode if not activate). To get an activation code, register the

product on either generac.com or activategen.com. The confirmation page (last page of the registration) will

show the five-digit activation code at the top of the screen. For any questions or issues, calls can be trans-

ferred to our activation line (888) 922-8482.

Q: How do I size the correct gas line for my home standby generator installation?

A: Generac is not able to size the gas line for you. However, Generac is able to give the fuel consumption and

required water column which will help the gas installers to provide the correct size needed for installation.

These are unique to each model. Consult your owner’s manual for details. Because there are so many fac-

tors that can affect gas pressure, such as having the line that is not dedicated and the distance that the line

is run, your installation will require an on-site inspection and recommendation by a gas professional.

Q: How do I set the exercise time?

A: For all units, 6 kW and 8 – 22 kW, the exercise time can be set from the control board on the “edit” screen.

Simply select the date and time using the up and down arrow keys. The generator time and exercise time

are in military time, so if you would like the generator to exercise at 1 PM, set the exercise time for 1300

hours. Exercise time options can be set for bi-weekly and monthly exercise.

Q: How do I calculate fuel consumption conversion?

A: To size a gas line for a generator, most gas companies/ plumbers will need two pieces of information – water

column and BTUs. All water column/ fuel pressure and BTU information is available in your owner’s manual.

TROUBLESHOOTING

Q: What is the best way to troubleshoot my home standby generator?

A: We are limited as to the troubleshooting we are able to do without potentially damaging the product or void-

ing the warranty of the product (if applicable). Contact your dealer for service if issues persist.

Q: How do I find an authorized service dealer?

A: Authorized service dealers can be located on our website at www.generac.com.

MAINTENANCE&OILINFORMATION

Q: Can I perform maintenance myself?

A: Always check your owner’s manual to confirm specific maintenance intervals for your particular model. Any-

one can perform maintenance, but we recommend a sale or service dealer, as some aspects are very tech-

nical. Dealers can also make sure everything else is in order. Most units with an OHVI engine will require

maintenance every two years or after 200 hours of use.

Q: Are there maintenance kits available for my home standby generator?

A: Maintenance kits and parts can be purchased from any sales or service dealer, through our part distributors

(GPCs) or online at ordertree.com. Only Generac-brand maintenance parts should be used. We don’t rec-

ommend and don’t have cross-reference numbers for other brands like Fram or Napa.

Q: What kind of oil and coolant do I need to use?

A: Air-cooled units will come with some SAE 30 wt. oil from the factory. You will want to check the level and add

more if necessary during the installation. Liquid-cooled units are shipped with oil and coolant. No additional

oil needs to be added during installation.

Q: What is the recommended oil to use?

A: Always check the manual for each specific model as oil recommendations change depending on the model.

Our oil recommendations are based on climate or temperature. Cold weather kits are required when the

ambient temperature falls below 32 degrees F. These kits include the recommended synthetic oil.

Q: Why use synthetic oil?

A: Oil recommendations are based on temperature, but synthetic oil is a good option because it doesn’t

degrade or “sludge” like standard oil. It also has better lubrication properties and stands up better to high

temperatures in the engine.

Q: What is the break-in period for my home standby generator?

A: Current model air-cooled units do not require a break-in period. They can be switched to synthetic or any

weight oil immediately. Please check your owner’s manual to see if this was required for the particular unit.

OPERATION

Q: How do I open an air-cooled standby generator?

A: Air-cooled home standby generators manufactured in 2008 or later require a key to unlock its two locks

before opening the lid. The unit is locked when shipped. To open the lid for the first time, the customer may

need to apply heavy pressure on the lid above each lock while turning the key at the same time.

Q: How long can I continuously operate my home standby generator?

A: During an outage, we recommend the generator be shut down every 24 hours to inspect the air filter and oil

level. Let the engine cool for approximately 15 minutes to get an accurate reading on the dipstick. A com-

plete oil change will need to be performed after every 200 hours of operation for air-cooled units, or every

100 hours of operation for liquid-cooled units.

GENERAL

Q: Are extended warranties available?

A: Extended limited warranties are available for our home standby and commercial generators. (This does not

include the CorePower™ Series, EcoGen, portables or power washers. It must be purchase from an autho-

rized sales/ service dealer within the first year of ownership. Talk with your dealer for more details.

Q: What constitutes a voided warranty?

A: The following are examples of installations that will void the warranty on an automatic standby generator:

Generators used where no utility power is present (ie. Hunting cabins) Generators used to charge back-up

battery systems for alternative energy sourced (This does not include the EcoGen Series) Improper installa-

tions (clearance requirements, wiring, etc.) Modifications to the original design (extending the exhaust,

indoor installations, etc.)

Q: If I have my contractor replace a part, how will they get reimbursed?

A: Any service work performed by someone Generac has not authorized to perform warranty work cannot be

claimed and will not be covered under warranty. This includes any repair work performed by an electrical

contractor who is not affiliated with a service dealership. Regular maintenance, such as changing the oil and

filter, can be done by anyone and is not covered under warranty.

Q: What is an automatic standby generator?

A: An automatic standby generator is a back-up electrical system that operates whether you are home or away.

Within seconds of an outage, it automatically supplies power directly to your home’s electrical circuit breaker

box. It operates on natural gas or liquid propane gas and sits outside, just like a central air conditioning unit.

Automatic Standby Generator Owner’s Manual 1

Section 1 Safety

INTRODUCTION:Thank you for purchasing this compact, high performance, air-cooled, engine-driven stationary automatic standby generator

set. Every effort was madeto make sure that the information and instructions in this manual were both accurate and current at the time the man-

ual was written. However, the manufacturer reserves the right to change, alter or otherwise improve this product or manual at any time without

prior notice.

This generator is designed to automatically supply electrical power to operate critical loads during a utility power failure. This unit is factory

installed in an all-weather metal enclosure and is intended exclusively for outdoor installation. This generator will operate using either vapor

withdrawn liquid propane (LP) or natural gas (NG).

NOTE: When properly sized, this generator is suitable for supplying typical residential loads such as Induction Motors (sump pumps,

refrigerators, air conditioners, furnaces, etc.), Electronic Components (computer, monitor, TV, etc.), Lighting Loads and Microwaves.

READ THIS MANUAL THOROUGHLY: The operator is responsible for proper and safe use ofthis equipment. The manufacturer strongly recom-

mends that the operator read and thoroughlyunderstand the instructions andcontents of this owner’s manual before attempting touse the equip-

ment. If any portion of this publication is not understood, contact the nearest Authorized Service Dealer for starting, operating and servicing

procedures.

SAVE THESE INSTRUCTIONS: The manufacturer suggests that this manual and the rules for safe operation be copied and posted near the

unit’s installation site. Safety should be stressed to all operators and potential operators of this equipment.

SAFETY: Throughout this manual, and on tags and decals affixed to the unit, DANGER, WARNING, CAUTION and NOTE blocks are used to

alert personnel to special instructions about a particular operation, functionor service that may be hazardous if performed incorrectly or care-

lessly. Observe them carefully. Their definitions are as follows:

INDICATES A HAZARDOUS SITUATION OR ACTION WHICH, IF NOT AVOIDED, WILL RESULT IN DEATH OR SERIOUS

INJURY.

Indicates a hazardous situation or action which, if not avoided, could result in death or serious injury.

Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.

NOTE: Notes contain additional information important to an operation or procedure.

Four commonly used safety symbols accompany the DANGER, WARNING and CAUTION blocks. The type of information each indicates is as

follows: This symbol points out important Safety Information that, if not followed, could endanger personal safety and/or

property of others.

This symbol points out a potential Explosion Hazard.

This symbol points out a potential Fire Hazard.

This symbol points out a potential Electrical Shock Hazard.

These “Safety Alerts” cannot eliminate the hazards that they signal. Strict compliance with these special instructions, plus common sense are

major accident prevention measures.

2Automatic Standby Generator Owner’s Manual

1.1 — General Safety

Study these safety rules carefully before operating or servicing this equipment. Become familiar with this Owner’s Manual and with the unit. The

generator can operate safely, efficiently and reliably only if itis properly installed,operatedand maintained. Many accidents are caused by failing

to follow simple and fundamental rules or precautions.

The manufacturer cannot anticipate every possible circumstance that might involve a hazard. The warnings in this manual, and on tags and

decals affixed to the unit are, therefore, not all-inclusive.If using a procedure, work method or operating technique the manufacturer does not

specifically recommend, ensure that itis safe for personnel. Alsomake sure the procedure,work method or operating techniqueutilized doesnot

render the generator unsafe.

Despite the safe design of this generator, operating this equipment imprudently, neglecting its maintenance or

being careless can cause possible injury or death. Permit only responsible and capable persons to install, operate

and maintain this equipment.

Potentially lethal voltages are generated by these machines. Ensure steps are taken to make the machine safe

before attempting to work on the generator.

Parts of the generator are rotating and/or hot during operation. Exercise care near a running generator.

The installation of this generator must always comply with applicable codes, standards, laws and regulations.

A running generator gives off DEADLY carbon monoxide, an odorless, colorless, poisonous gas. Breathing carbon

monoxide can cause dizziness, throbbing temples, nausea, muscular twitching, headache, vomiting, weakness,

sleepiness, inability to think clearly, fainting, unconsciousness or even death.

The control panel for this unit is intended to be operated by qualified service personnel only.

1.2 — General Safety Hazards

• For safety reasons, this equipment should only be installed, serviced and repaired by a Service Dealer or other competent, qualified electri-

cian or installation technician who is familiar with applicable codes, standards, regulations and product Installation Manual guidelines. The

operator also must comply with all such codes, standards, regulations and product Installation Manual guidelines.

• Theengineexhaustfumescontain carbon monoxide, whichcanbeDEADLY.Thisdangerousgas,ifbreathedin sufficientconcentrations,can

cause unconsciousness or even death. DO NOT alter or add to the exhaust system or do anything that might render the system unsafe or in

noncompliance with applicable codes and standards.

• Install a carbon monoxide alarm indoors, according to manufacturer’s instructions/recommendations.

• Adequate,unobstructed flowof coolingand ventilating air is critical for correct generator operation.Do not alter the installation or permit even

partial blockage of ventilation provisions, as this can seriously affect safe operation of the generator. The generator MUST be installed and

operated outdoors only.

• Keep hands, feet, clothing,etc. away from drive belts, fans, andother moving or hot parts. Never removeany drive belt or fanguardwhile the

unit is operating.

• When working on this equipment, remain alert at all times. Never work on the equipment when physically or mentally fatigued.

• Inspect the generator regularly, and contact the nearest Dealer for parts needing repair or replacement.

• Before performing any maintenance on the generator, remove the control panel fuse and disconnect the Negative (—) battery cable to pre-

vent accidental startup. When disconnecting battery cables always remove the NEGATIVE (NEG or “—”) cable first, then remove the

POSITVE (POS, or “+”) cable. When reconnecting the cables, connect the POSITIVE cable first, and the NEGATIVE cable last.

• Never use the generator or any of its parts asa step. Stepping on the unit canstress and break parts, and may result in dangerous operating

conditions from leaking exhaust gases, fuel leakage, oil leakage, etc.

Automatic Standby Generator Owner’s Manual 3

1.3 — Exhaust Hazards

• Generator engine exhaust contains DEADLY carbon monoxide, an odorless, colorless, poisonous gas. Breathing carbon monoxide can

causedizziness, throbbing temples, nausea, musculartwitching, headache,vomiting,weakness, sleepiness, inability to thinkclearly, fainting,

unconsciousness or even death. If any carbon monoxide poisoning symptom is experienced, move into fresh air and immediately seek med-

ical attention.

• This generator is designed for OUTDOOR installation ONLY. Never operate the generator inside any garage or other enclosed space.

1.4 — Electrical Hazards

• All generators covered by this manual produce dangerous electrical voltages that can cause fatal electrical shock. Utility power delivers

extremely high and dangerous voltages to the transfer switch, as does the standby generator when it is in operation. Avoid contact with bare

wires, terminals, connections, etc. while the unit is running. Ensure all appropriate covers, guards and barriers are in place, secured and/or

locked before operating the generator. If work must be done around an operating unit, stand on an insulated, dry surface to reduce potential

shock hazard.

• Do not handle any kind of electrical device while standing in water, while barefoot, or while hands or feet are wet. DANGEROUS ELECTRI-

CAL SHOCK MAY RESULT.

• This is an Automatic StandbyGenerator, the generator may crank and start atany time when utility islost. When this occurs, loadcircuits are

transferred to the STANDBY (generator) power source. To prevent injury, before working on this generator (for inspection, service or mainte-

nance), always put the generator into the OFF mode and remove the 7.5 Amp fuse from the generator control panel.

• In case of accident caused by electric shock, immediately shut down the source of electrical power. If this is not possible, attempt to free the

victimfrom the live conductor.AVOID DIRECTCONTACT WITH THE VICTIM. Use a nonconducting implement, such asa dry rope or board,

to free the victim from the live conductor. If the victim is unconscious, apply first aid and get immediate medical help.

• Never wear jewelry when working on this equipment. Jewelry can conduct electricity resulting in electric shock, or may get caught in moving

components resulting in injury.

1.5 — Fire Hazards

• For fire safety, the generator must be installed and maintained properly. Installation MUST always comply with applicable codes, standards,

laws,regulations andproduct InstallationManual guidelines. Adhere strictly to local, state,and national electrical and buildingcodes.Comply

with regulations the Occupational Safety and Health Administration (OSHA) has established. Also, ensure that the generator is installed in

accordance with the manufacturer’s instructions and recommendations. Following proper installation, do nothing that might alter a safe instal-

lation and render the unit in noncompliance with the aforementioned codes, standards, lawsand regulations.

• Keepa fireextinguishernear thegenerator atall times.Extinguishers rated“ABC” by the National Fire Protection Association are appropriate

for use on the standby generator. Keep the extinguisher properly charged and be familiar with its use. Consult the local fire department with

any questions pertaining to fire extinguishers.

1.6 — Explosion Hazards

• Do not smoke around the generator. Wipe up any fuel or oil spills immediately. Ensure that no combustible materials are left in the generator

compartment, or on or near the generator as FIRE or EXPLOSION may result. Keep the area surrounding the generator clean and free from

debris.

• Gaseous fluids such as natural gas and liquid propane (LP) gas are extremely EXPLOSIVE. Install the fuel supply system according to appli-

cable fuel-gas codes. Before placing the home standby electric system into service, fuel system lines must be properly purged and leak

tested according to applicable code. After installation, inspect the fuel system periodically for leaks. No leakage can be permitted.

4Automatic Standby Generator Owner’s Manual

If this generator is used to power electrical load circuits normally powered by a utility power source, it is

required by code to install a transfer switch. The transfer switch must effectively isolate the electrical system

from the utility distribution system when the generator is operating (NEC 702). Failure to isolate an electrical

system by such means will result in damage to the generator and also may result in injury or death to utility

power workers due to backfeed of electrical energy.

Otros manuales para Automatic Standby Generator

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Inversor de Generac Power Systems

Generac Power Systems

Generac Power Systems 005030-0 (15kW) Manual de usuario

Generac Power Systems

Generac Power Systems Guardian Elite Whisper Test 5261 Manual de usuario

Generac Power Systems

Generac Power Systems PWRcell XVT076A03 Manual de usuario

Generac Power Systems

Generac Power Systems Guardian 004988-1 Manual de usuario

Generac Power Systems

Generac Power Systems SD600 Manual de usuario

Generac Power Systems

Generac Power Systems MGG155 Manual de usuario

Generac Power Systems

Generac Power Systems SG050 Manual de usuario

Generac Power Systems

Generac Power Systems MMG120 Manual de usuario

Generac Power Systems

Generac Power Systems Guardian Elite QT02516 Manual de usuario

Generac Power Systems

Generac Power Systems 004701-0 Manual de usuario

Generac Power Systems

Generac Power Systems 15 kW EcoGen Hoja de instrucciones

Generac Power Systems

Generac Power Systems Guardian 5410 Instrucciones de funcionamiento

Generac Power Systems

Generac Power Systems 8 KVA Manual de usuario

Generac Power Systems

Generac Power Systems Guardian 004721-0 Manual de usuario

Generac Power Systems

Generac Power Systems 004702-0, 004703-0, 004704-0, Manual de usuario

Generac Power Systems

Generac Power Systems 04077-01, 04109-1, 04079-1, 00 Guía

Generac Power Systems

Generac Power Systems 004702-0, 004703-0, 004704-0, Manual de usuario

Generac Power Systems

Generac Power Systems CorePower?/ES Generators Hoja de instrucciones

Generac Power Systems

Generac Power Systems 4000XL 9777-2 Manual de usuario

Generac Power Systems

Generac Power Systems 005914-0 Guía de instalación

Generac Power Systems

Generac Power Systems 05176-0 Instrucciones de instalación

Generac Power Systems

Generac Power Systems QuietSource 005031-2 Manual de usuario

Generac Power Systems

Generac Power Systems Guardian Elite QT04524 Manual de usuario

Generac Power Systems

Generac Power Systems Guardian 005324-0 Manual de usuario

Manuales populares de Inversor de otras marcas

Fourgroup

Fourgroup Easy Manual de usuario

Velleman

Velleman PI300M Manual de usuario

Sungrow

Sungrow SG350HX-US Manual de usuario

WilTec

WilTec 61897 Manual de usuario

SMA

SMA SUNNY BOY STORAGE 2.5 Manual de usuario

Simplicity

Simplicity LANDLORD 316 Manual de usuario

Santak

Santak SMAX 3000 Manual de usuario

ATON

ATON RA.Store-3 Manual de usuario

ZIEHL-ABEGG

ZIEHL-ABEGG FXET4AMQ Manual de usuario

Tektronix

Tektronix CFG250 Manual de usuario

Champion

Champion 200989 Manual de usuario

Vanner

Vanner 20-500 Series Manual de usuario

GE GEP Manual de usuario

Astrel Group

Astrel Group Power Reducer Guía rápida

MULTIQUIP

MULTIQUIP GDP-5H Guía

GoWISE

GoWISE PS1007 Manual de usuario

Promate

Promate PM13500D ES Manual de usuario

Mastervolt

Mastervolt WHISPER 3.5M3000 RPM Manual de usuario
