Owner’s Manual

Automatic Standby Generator

Reference all appropriate documentation.

This manual should remain with the unit.

nNOT INTENDED FOR USE IN CRITICAL LIFE SUPPORT APPLICATIONS.

nONLY QUALIFIED ELECTRICIANS OR CONTRACTORS SHOULD ATTEMPT

INSTALLATION.

nDEADLY EXHAUST FUMES! OUTDOOR INSTALLATION ONLY!

LISTED

CUS

Home Standby Models:

8kW to 20kW

WARNING!

California Proposition 65

Engine exhaust and some of its constituents are known to the state of California to cause cancer,

birth defects, and other reproductive harm.

WARNING!

California Proposition 65

This product contains or emits chemicals known to the state of California to cause cancer,

birth defects, and other reproductive harm.

Use this page to record important information about your generator set.

Record the information found on your unit data label on this page. For the

location of the unit data label, see Section 2 General Information. The

unit has a label plate affixed to the inside partition, to the left of the control

panel console as shown in Figures 2-1, 2-2, and 2-3. For directions on

how to open the top lid and remove the front panel, see Section 3 Opera-

tion. The Unit Identification label provides the following information:

• Model Number

• Serial Number

• Control Panel Part Number

• Voltage Rating of the unit

• Maximum Current Rating of the unit (AMPS)

When contacting an Authorized Service Dealer about parts and service,

always supply the complete model number and serial number of the unit.

Operation and Maintenance: Proper maintenance and care of the gen-

erator ensures a minimum number of problems and keeps operating

expenses at a minimum. It is the operator’s responsibility to perform all

safety checks, to make sure that all maintenance for safe operation is

performed promptly, and to have the equipment checked periodically by

an Authorized Service Dealer. Normal maintenance, service and replace-

ment of parts are the responsibility of the owner/operator and, as such,

are not considered defects in materials or workmanship within the terms

of the warranty. Individual operating habits and usage may contribute to

the need for additional maintenance or service.

When the generator requires servicing or repairs, contact an Authorized

Service Dealer for assistance. Authorized service technicians are factory-

trained and are capable of handling all service needs.

To find your Local AUTHORIZED SERVICE DEALER

AUTHORIZED SERVICE

DEALER LOCATION

To locate the nearest AUTHORIZED

SERVICE DEALER, please call this

number:

1-800-333-1322

or, visit the dealer locator at:

www.generac.com/Service/DealerLocator/

Table of Contents

Section 1 — Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1.1 — General Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.2 — General Safety Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.3 — Exhaust Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.4 — Electrical Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.5 — Fire Hazards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

1.6 — Explosion Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Section 2 — General Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2.1 — The Generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2.2 — Protection Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.3 — Emission Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2.4 — Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.5 — Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Section 3 — Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

3.1 — Control Panel Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

3.2 — Using the Auto/Off/Manual Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3.3 — Interface Menu Displays. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

3.4 — Automatic Transfer Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3.5 — Turning the Generator Off When Operating Under Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3.6 — Manual Transfer Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

3.7 — Side Compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

3.8 — Alarm Response Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.9 — Battery Charger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.10 — Setting the Exercise Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Section 4 — Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

4.1 — Performing Scheduled Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

4.2 — Service Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

4.3 — Checking Engine Oil Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

4.4 — Changing the Engine Air Cleaner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

4.5 — Spark Plugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

4.6 — Valve Lash Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4.7 — Battery Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4.8 — Attention After Submersion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

4.9 — Corrosion Protection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

4.10 — Out of Service Procedure (includes removal and return from service). . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Section 5 — Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Section 6 — Quick Reference Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Also included is Spanish, French Canadian and Portuguese.

iii

This page intentionally left blank.

Automatic Standby Generator Owner’s Manual 1

Section 1 Safety

INTRODUCTION: Thank you for purchasing this compact, high performance, air-cooled, engine-driven stationary automatic standby generator

set. Every effort was made to make sure that the information and instructions in this manual were both accurate and current at the time the man-

ual was written. However, the manufacturer reserves the right to change, alter or otherwise improve this product or manual at any time without

prior notice.

This generator is designed to automatically supply electrical power to operate critical loads during a utility power failure. This unit is factory

installed in an all-weather metal enclosure and is intended exclusively for outdoor installation. This generator will operate using either vapor

withdrawn liquid propane (LP) or natural gas (NG).

NOTE: When properly sized, this generator is suitable for supplying typical residential loads such as Induction Motors (sump pumps,

refrigerators, air conditioners, furnaces, etc.), Electronic Components (computer, monitor, TV, etc.), Lighting Loads and Microwaves.

READ THIS MANUAL THOROUGHLY: The operator is responsible for proper and safe use of this equipment. The manufacturer strongly recom-

mends that the operator read and thoroughly understand the instructions and contents of this owner’s manual before attempting to use the equip-

ment. If any portion of this publication is not understood, contact the nearest Authorized Service Dealer for starting, operating and servicing

procedures.

SAVE THESE INSTRUCTIONS: The manufacturer suggests that this manual and the rules for safe operation be copied and posted near the

unit’s installation site. Safety should be stressed to all operators and potential operators of this equipment.

SAFETY: Throughout this manual, and on tags and decals affixed to the unit, DANGER, WARNING, CAUTION and NOTE blocks are used to

alert personnel to special instructions about a particular operation, function or service that may be hazardous if performed incorrectly or care-

lessly. Observe them carefully. Their definitions are as follows:

INDICATES A HAZARDOUS SITUATION OR ACTION WHICH, IF NOT AVOIDED, WILL RESULT IN DEATH OR SERIOUS

INJURY.

Indicates a hazardous situation or action which, if not avoided, could result in death or serious injury.

Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.

NOTE: Notes contain additional information important to an operation or procedure.

Four commonly used safety symbols accompany the DANGER, WARNING and CAUTION blocks. The type of information each indicates is as

follows:

This symbol points out important Safety Information that, if not followed, could endanger personal safety and/or

property of others.

This symbol points out a potential Explosion Hazard.

This symbol points out a potential Fire Hazard.

This symbol points out a potential Electrical Shock Hazard.

These “Safety Alerts” cannot eliminate the hazards that they signal. Strict compliance with these special instructions, plus common sense are

major accident prevention measures.

2Automatic Standby Generator Owner’s Manual

1.1 — General Safety

Study these safety rules carefully before operating or servicing this equipment. Become familiar with this Owner’s Manual and with the unit. The

generator can operate safely, efficiently and reliably only if it is properly installed, operated and maintained. Many accidents are caused by failing

to follow simple and fundamental rules or precautions.

The manufacturer cannot anticipate every possible circumstance that might involve a hazard. The warnings in this manual, and on tags and

decals affixed to the unit are, therefore, not all-inclusive. If using a procedure, work method or operating technique the manufacturer does not

specifically recommend, ensure that it is safe for personnel. Also make sure the procedure, work method or operating technique utilized does not

render the generator unsafe.

Despite the safe design of this generator, operating this equipment imprudently, neglecting its maintenance or

being careless can cause possible injury or death. Permit only responsible and capable persons to install, operate

and maintain this equipment.

Potentially lethal voltages are generated by these machines. Ensure steps are taken to make the machine safe

before attempting to work on the generator.

Parts of the generator are rotating and/or hot during operation. Exercise care near a running generator.

The installation of this generator must always comply with applicable codes, standards, laws and regulations.

A running generator gives off DEADLY carbon monoxide, an odorless, colorless, poisonous gas. Breathing carbon

monoxide can cause dizziness, throbbing temples, nausea, muscular twitching, headache, vomiting, weakness,

sleepiness, inability to think clearly, fainting, unconsciousness or even death.

The control panel for this unit is intended to be operated by qualified service personnel only.

1.2 — General Safety Hazards

• For safety reasons, this equipment should only be installed, serviced and repaired by a Service Dealer or other competent, qualified electri-

cian or installation technician who is familiar with applicable codes, standards, regulations and product Installation Manual guidelines. The

operator also must comply with all such codes, standards, regulations and product Installation Manual guidelines.

• The engine exhaust fumes contain carbon monoxide, which can be DEADLY. This dangerous gas, if breathed in sufficient concentrations, can

cause unconsciousness or even death. DO NOT alter or add to the exhaust system or do anything that might render the system unsafe or in

noncompliance with applicable codes and standards.

• Install a carbon monoxide alarm indoors, according to manufacturer’s instructions/recommendations.

• Adequate, unobstructed flow of cooling and ventilating air is critical for correct generator operation. Do not alter the installation or permit even

partial blockage of ventilation provisions, as this can seriously affect safe operation of the generator. The generator MUST be installed and

operated outdoors only.

• Keep hands, feet, clothing, etc. away from drive belts, fans, and other moving or hot parts. Never remove any drive belt or fan guard while the

unit is operating.

• When working on this equipment, remain alert at all times. Never work on the equipment when physically or mentally fatigued.

• Inspect the generator regularly, and contact the nearest Dealer for parts needing repair or replacement.

• Before performing any maintenance on the generator, remove the control panel fuse and disconnect the Negative (—) battery cable to pre-

vent accidental startup. When disconnecting battery cables always remove the NEGATIVE (NEG or “—”) cable first, then remove the

POSITVE (POS, or “+”) cable. When reconnecting the cables, connect the POSITIVE cable first, and the NEGATIVE cable last.

• Never use the generator or any of its parts as a step. Stepping on the unit can stress and break parts, and may result in dangerous operating

conditions from leaking exhaust gases, fuel leakage, oil leakage, etc.

Automatic Standby Generator Owner’s Manual 3

1.3 — Exhaust Hazards

• Generator engine exhaust contains DEADLY carbon monoxide, an odorless, colorless, poisonous gas. Breathing carbon monoxide can

cause dizziness, throbbing temples, nausea, muscular twitching, headache, vomiting, weakness, sleepiness, inability to think clearly, fainting,

unconsciousness or even death. If any carbon monoxide poisoning symptom is experienced, move into fresh air and immediately seek med-

ical attention.

• This generator is designed for OUTDOOR installation ONLY. Never operate the generator inside any garage or other enclosed space.

1.4 — Electrical Hazards

• All generators covered by this manual produce dangerous electrical voltages that can cause fatal electrical shock. Utility power delivers

extremely high and dangerous voltages to the transfer switch, as does the standby generator when it is in operation. Avoid contact with bare

wires, terminals, connections, etc. while the unit is running. Ensure all appropriate covers, guards and barriers are in place, secured and/or

locked before operating the generator. If work must be done around an operating unit, stand on an insulated, dry surface to reduce potential

shock hazard.

• Do not handle any kind of electrical device while standing in water, while barefoot, or while hands or feet are wet. DANGEROUS ELECTRI-

CAL SHOCK MAY RESULT.

• This is an Automatic Standby Generator, the generator may crank and start at any time when utility is lost. When this occurs, load circuits are

transferred to the STANDBY (generator) power source. To prevent injury, before working on this generator (for inspection, service or mainte-

nance), always put the generator into the OFF mode and remove the 7.5 Amp fuse from the generator control panel.

• In case of accident caused by electric shock, immediately shut down the source of electrical power. If this is not possible, attempt to free the

victim from the live conductor. AVOID DIRECT CONTACT WITH THE VICTIM. Use a nonconducting implement, such as a dry rope or board,

to free the victim from the live conductor. If the victim is unconscious, apply first aid and get immediate medical help.

• Never wear jewelry when working on this equipment. Jewelry can conduct electricity resulting in electric shock, or may get caught in moving

components resulting in injury.

1.5 — Fire Hazards

• For fire safety, the generator must be installed and maintained properly. Installation MUST always comply with applicable codes, standards,

laws, regulations and product Installation Manual guidelines. Adhere strictly to local, state, and national electrical and building codes. Comply

with regulations the Occupational Safety and Health Administration (OSHA) has established. Also, ensure that the generator is installed in

accordance with the manufacturer’s instructions and recommendations. Following proper installation, do nothing that might alter a safe instal-

lation and render the unit in noncompliance with the aforementioned codes, standards, laws and regulations.

• Keep a fire extinguisher near the generator at all times. Extinguishers rated “ABC” by the National Fire Protection Association are appropriate

for use on the standby generator. Keep the extinguisher properly charged and be familiar with its use. Consult the local fire department with

any questions pertaining to fire extinguishers.

1.6 — Explosion Hazards

• Do not smoke around the generator. Wipe up any fuel or oil spills immediately. Ensure that no combustible materials are left in the generator

compartment, or on or near the generator as FIRE or EXPLOSION may result. Keep the area surrounding the generator clean and free from

debris.

• Gaseous fluids such as natural gas and liquid propane (LP) gas are extremely EXPLOSIVE. Install the fuel supply system according to appli-

cable fuel-gas codes. Before placing the home standby electric system into service, fuel system lines must be properly purged and leak

tested according to applicable code. After installation, inspect the fuel system periodically for leaks. No leakage can be permitted.

4Automatic Standby Generator Owner’s Manual

If this generator is used to power electrical load circuits normally powered by a utility power source, it is

required by code to install a transfer switch. The transfer switch must effectively isolate the electrical system

from the utility distribution system when the generator is operating (NEC 702). Failure to isolate an electrical

system by such means will result in damage to the generator and also may result in injury or death to utility

power workers due to backfeed of electrical energy.

Automatic Standby Generator Owner’s Manual 5

Section 2 General Information

2.1 — The Generator

Figure 2-1: GH-410 Engine 8kW Unit

Figure 2-2: GH-530 Engine 11kW Unit

EXHAUST

NCLOSURE

COMPOSITE BASE

OIL FILTER

OIL FILL CAP BATTERY COMPARTMEN

FUEL

REGULATOR

CIRCUIT

BREAKERS

FUEL INLET

(BACK)

CONTROL

PANEL

OIL

DIPSTICK

AIR FILTER

DATA LABEL

(SEE SAMPLE)

EXHAUST

ENCLOSURE

COMPOSITE BASE OIL FILTER OIL FILL CAP

BATTERY COMPARTMENT

FUEL

REGULATOR

CIRCUIT

BREAKERS

FUEL

INLET

(BACK)

CONTROL

PANEL

OIL

DIPSTICK AIR FILTER

DATA LABEL

(SEE SAMPLE)

EXHAUST

ENCLOSURE

COMPOSITE BASE OIL FILTER OIL FILL CAP

BATTERY COMPARTMENT

FUEL

REGULATOR

CIRCUIT

BREAKERS

FUEL

INLET

(BACK)

CONTROL

PANEL

OIL

DIPSTICK AIR FILTER

DATA LABEL

(SEE SAMPLE)

6Automatic Standby Generator Owner’s Manual

Figure 2-3: GT-990/GT-999 Engines, 13-20kW Unit

2.2 — Protection Systems

The generator may have to run for long periods of time with no operator present to monitor the engine/generator conditions. Therefore, the gen-

erator is equipped with a number of systems to automatically shut down the unit to protect it against potentially damaging conditions. Some of

these systems are as follows:

The control panel contains a display which alerts the operator when a fault condition occurs. The above list is not all inclusive. For more informa-

tion about alarms and control panel operation, see Section 3 Operation.

• Low Oil Pressure Sensor

• High Temperature Sensor

• Overcrank Sensor

• Overspeed Sensor

• RPM Sensor

• Under-frequency Sensor

• Undervoltage Sensor

• Overvoltage Sensor

• Internal Failure Sensor

• Low Battery Voltage Alarm

EXHAUST

ENCLOSURE

COMPOSITE BASE OIL FILTER OIL FILL CAP

BATTERY COMPARTMENT

FUEL

REGULATOR

CIRCUIT

BREAKERS

FUEL

INLET

(BACK)

CONTROL

PANEL

OIL

DIPSTICK AIR FILTER

DATA LABEL

(SEE SAMPLE)

Otros manuales para 8 kW LP

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Inversor de Generac Power Systems

Generac Power Systems

Generac Power Systems 006180-0 Manual de usuario

Generac Power Systems

Generac Power Systems Guardian 5410 Instrucciones de funcionamiento

Generac Power Systems

Generac Power Systems PWRcell X7600 Series Manual de usuario

Generac Power Systems

Generac Power Systems 004270-3 Instrucciones de instalación

Generac Power Systems

Generac Power Systems 05176-0 Instrucciones de instalación

Generac Power Systems

Generac Power Systems 004988-2 Manual de usuario

Generac Power Systems

Generac Power Systems Guardian 04389-2 Instrucciones de instalación

Generac Power Systems

Generac Power Systems Guardian Elite Whisper Test 5261 Manual de usuario

Generac Power Systems

Generac Power Systems PWRcell X7600 Series Manual de usuario

Generac Power Systems

Generac Power Systems 004090-2, 004091-2, 004092-2, 004093-2, 004094-2, 004095-2, 004096-2, 004097-2, 004474-0, 004124-1, 004125-1, 004126-1... Manual de usuario
