Gefen HD Digital Audio Switcher Manual de usuario

HD Digital Audio

Switcher

USER MANUAL

www.gefen.com

Technical Support:

Telephone (818) 884-6294

(800) 545-6900

Fax (818) 884-3108

Technical Support Hours:

8:00 AM to 5:00 PM Monday thru Friday.

Write To:

Gefen Inc.

C/O Customer Service

6265 Variel Ave.

Woodland Hills, CA91367-9897

Notice

Gefen Inc. reserves the right to make changes in the hardware, packaging and any

accompanying documentation without prior written notice.

2x1 HD Digital Audio Switcher is a trademark of Gefen Inc.

ASKING FOR ASSISTANCE

TABLE OF CONTENTS

Introduction

Features

Panel Descriptions

Connecting and Operating the 2x1 HD Digital Audio Switcher

RMT2-IR Installation

Speciﬁcations

Warranty

Congratulations on your purchase of the ex•tend•it 2x1 HD Digital Audio Switcher. Your

complete satisfaction is very important to us.

Gefen’s line of HDTV switches, extenders, and splitters are designed to make yourA/V

equipment use more comfortable, more productive and less expensive.

The 2x1 HD Digital Audio Switcher allow access to multiple HDTV devices, using a

single HDTV display while the HDTV extender product line can extend the HD video

signal up to 1640 feet (500 meters).

The ex•tend•it line offers solutions for noise, space and security concerns, data center

control, information distribution, conference room presentation, school and corporate

training environments.

Our Commitment

Gefen will always offer the ﬁnest quality product at the best possible price. Included in

that price is a lifetime of support from a team of outstanding engineers.

The ex•tend•it 2x1 HD Digital Audio Switcher allows two HDTV HD devices to be

switched easily in to one HDTV HD compatible monitor or projector. Simply connect

your HDTV display to the Switcher’s display output and your digital audio to the digital

out. The 2x1 HD DigitalAudio Switcher can also be placed at the end of a long HDMI

cable to regenerate the HD signal.

INTRODUCTION

FEATURES

Features

• Switches easily between any two HDTV sources

• Maintains 480i, 480p, 720p, 720i, and 1080i, 1080p resolutions

• Extends any HDMI compliant device by regenerating the HDMI signal

• Maintains highest HDMI single link video resolution

• Supports DDWG standard for HDMI compliant monitors

• Supports HDCP compliant devices

• Optional RMT-2 remote control

• HDMI cables are used to connect the HDMI inputs and 2x1 HD Digital Audio Switcher

output

• TOSLINK cables are used to connect the TOSLINK inputs and 2x1 TOSLINK Digital

Audio Switcher output

• Installs in seconds

Includes:

(1) HD Digital Audio Switcher

(2) 6’ HDMI cables (m-m)

(2) 6’ TOSlink cables

(1) 5VDC Power Supply

(1) RMT2-IR

PANEL DESCRIPTIONS

Connects to

5VDC power supply

Connects to IR

extender IR eye

Indicates if port 1 or

port 2 is selected Selects port 1

or port 2

Input 2

Input 1 HD Out

SPDIF Out

Optical Out

SPDIF 1

SPDIF 2

OPT 2

OPT 1

Connecting and Operating the 2x1 HD Digital Audio Switcher

How to Connect the 2x1 HD Digital Audio Switcher to your devices

1 Connect the supplied HDMI cables from the HDTV HD sources into the 2x1 HD Digital

Audio Switcher inputs.

2Connect the digital audio cables from your devices into the 2x1 HD DigitalAudio

Switcher inputs. Make sure the digital audio matches the digital video input.

3Connect the cable from your display (monitor or projector) into the HD Out of the

2x1 HD Digital Audio Switcher.

4 Connect your digital audio receiver to the 2x1 HD DigitalAudio Switcher output.

5 Plug the 5VDC power supply into the 2x1 HD Digital Audio Switcher.

How to Operate the 2x1 HD Digital Audio Switcher

1 Use the front panel push button to switch between sources.

2 Alternatively, use the RMT2-IR remote control port to remotely toggle between sources.

RMT2-IR Installation

1. Remove battery cover from the back of the RMT2-IR remote.

2. Verify that dip switches 1 & 2 are in the down (OFF) position.

3. Insert the battery, hold the battery so that you can see the positive side facing up. The

side that is not marked must be facing down.

4. Test the RMT2-IR remote by pressing ONLY one button at a time. The indicator light

on the remote will ﬂash once each time you press a button. WARNING: Do not press

multiple buttons simultaneously and do NOT press buttons rapidly. These actions will

cause the remote to reset and steps 1-4 will have to be repeated.

Note: The RMT2-IR ships with two batteries. One battery is required for operation, the

second battery is complimentary.

The optional IR extender allows you to

relocate your 2x1 HD Digital Audio Switcher

and still have IR control of the 2x1 HD Digi-

tal Audio Switcher

SPECIFICATIONS

Video Ampliﬁer Bandwidth ................................................................................. 1.65 GHz

Input Video Signal ......................................................................................... 1.2 volts p-p

Input DDC Signal .................................................................................... 5 volts p-p (TTL)

Single Link Range ......................................................................................... 1920 x 1200

HD Input/Output Connector Type ............................................................................ HDMI

Power Consumption ................................................................................ 15 Watts (max.)

Power Supply .......................................................................................................... 5VDC

Dimensions ............................................................................... 4”D x 6.125”W x 1.125”H

Shipping Weight ....................................................................................................... 2 Lbs

Gefen Inc. warrants the equipment it manufactures to be free from defects in material

and workmanship.

If equipment fails because of such defects and Gefen Inc. is notiﬁed within two

(2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace

the equipment, provided that the equipment has not been subjected to mechanical,

electrical, or other abuse or modiﬁcations.

Equipment that fails under conditions other than those covered will be repaired at the

current price of parts and labor in effect at the time of repair. Such repairs are warranted

for ninety (90) days from the day of reshipment to the Buyer.

This warranty is in lieu of all other warranties expressed or implied, including without

limitation, any implied warranty or merchantability or ﬁtness for any particular purpose,

all of which are expressly disclaimed.

1. Proof of sale may be required in order to claim warranty.

2. Customers outside the US are responsible for shipping charges to and from Gefen.

3. Copper cables are limited to a 30 day warranty and cable must be free from any

scratches, markings, and neatly coiled.

The information in this manual has been carefully checked and is believed to be

accurate. However, Gefen Inc. assumes no responsibility for any inaccuracies that may

be contained in this manual. In no event will Gefen Inc., be liable for direct, indirect,

special, incidental, or consequential damages resulting from any defect or omission

in this manual, even if advised of the possibility of such damages. The technical

information contained herein regarding 2x1 HD Digital Audio Switcher features and

speciﬁcations is subject to change without notice.

WARRANTY
