GeekChef GCF20D Manual de usuario
Model No.: GCF20D
User Manual
Espresso Coffee Maker
Toll Free:1-844-801-8880
IMPORTANT:Read the instructions carefully before operating the
appliance and keep them for future reference.
GEEK产品使用说明书统一排版风格
A5 128g铜版纸 双面印 骑马钉 （建议材质）
Model No.: GCF20D
Power : 1350 W
Voltage: 120 V
Pump Pressure: 20 Bar
Capacity of Water Tank: 1.4 L
Safety Instructions
Product Components
How To Use
2
4
5
Cleaning And Maintenance 12
Troubleshooting 14
Limited Warranty 16
TECHNICAL SPECIFICATIONS
TABLE OF CONTENTS
Scan the QR code for more
assistance and support
SAFETY INSTRUCTIONS
2
Read all the safety and operating instructions carefully and retain them for future
reference.
Don't use it outdoors. Keep it away from sources of heat, direct sunlight, humidity
(never dip it into any liquid) and sharp edges. Do not use the appliance with wet
hands. If the appliance is humid or wet, unplug it immediately.
When cleaning or putting it away, switch off the appliance and always pull out the
plug from the socket (pull the plug itself, not the lead) if the appliance is not being
used and remove the attached accessories.
Do not operate the machine without supervisionNever leave the operating
machine unattended. If you leave the room you should always turn the device off.
Remove the plug from the socket.
The device and the mains lead have to beRegularly checked regularly for signs of
damage. If damage is found the device must not be used.
Do not try to repair the appliance on your own. Always contact an authorized
technician. To avoid the exposure to danger, always have faulty cable be
replaced only by the manufacturer, by our customer service or by qualified
person and with a cable for the same type.
In order to ensure your children ‘s safety, please keep all packaging (plastic bags,
boxes, polystyrene etc.) out of their reach.
This device is not intended to be used by individuals (including children) who have
restricted physical, sensory or mental abilities and/or insufficient knowledge and/
or experience, unless they are supervised by and individual who is responsible for
their safety or and have received instructions on how oto use the device. Children
should be supervised at all times in order to ensure that they do not play with
device.
Place the coffee machine on a firm and flat surface. Position it so that it cannot
tip over.
Never apply accessory attachments which are not specified for this appliance.
IMPORTANT SAFETY INSTRUCTIONS
2.
1.
The appliance is designed exclusively for private use and for the envisaged
purpose. This appliance is not fit for commercial use.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Do not touch hot parts of appliance.12.
Do not place the device directly next to a gas or electric cooker or any other
source of heat.
13.
The water tank must only be filled with cold water!14.
SAFETY INSTRUCTIONS
3
SAVE THESE INSTRUCTIONS!
HOUSEHOULD USE ONLY
The appliance is only to be used as described in the user manual.
Do not use the appliance for any commercial purposes.
Any other use is not intended and can result in damages or personal
injuries.
The manufacturer assumes no liability for damages caused by improper use.
15.
16.
17.
18.
This appliance is not intended for use by persons(including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should
be supervised to ensure that they do not play with the appliance.
19.
KNOW YOUR COFFEE MAKER
PRODUCT COMPONENTS
4
1. Water tank cover
2. Water tank
3. Steam control knob
4. Main body
5. Steam wand nozzle
6. ON/OFF switch
7. Warm cup board
8. Single-cup coffee
switch and indicator
9. Double -cup coffee
switch and indicator
Note:
The machine must use ground coffee to make coffee
and coffee drinks (e.g. Cappuccino, Latte and so on).
10. Steam switch and indicator
11. Buoy
12. Drip tray cover
13. Drip tray
14. Measure scoop
15. Single-cup coffee filter
16. Double-cup coffee filter
17. Filter holder
18. Coffee outlet
1
7
8
9
10
11
12
13
2
3
4
5
6
14
17
18
15
16
BEFORE FIRST USE
HOW TO USE
5
Note: If don’t remove the red silicone cap, the machine will be unable
to pump water.
Water tank
Red Silicone Cap
Remove the package from coffee maker and check the accessories according to
the component list.
Remove the tank cover and the water tank, then remove the red silicone cap from
the water tank before using the coffee maker.
1.
2.
Clean all the detachable components.
Pour water into water tank and the water level should not exceed the "MAX"
mark, put back the water tank and close the water cover.
Plug in and press the ON/OFF switch“ ”. At this time, all indicator lamps are
flashing, The machine starts to preheat, when the indicator lights stop blinking
and turns normal on, the preheat is completed, it takes about 1 minutes.
After finished preheat, touch the double cup coffee button, the electromagnetic
pump works, and immediately open the steam knob to the maximum position
counterclockwise Until the steam tube has a continuous outflow of hot water,
close the steam knob (the process may be repeated 1-3 times).
Insert the Filter to the Filter holder .
3.
4.
5.
6.
7.
From position " " to position " ", rotate counterclockwise to install the
filter holder (No coffee powder added) into the funnel holder of the machine,
then touch the double-cup coffee switch " " to let the hot water out to wash
the coffee filter and the cup.
HOW TO USE
6
8.
MAKING THE ESPRESSO
Note:
If too much ground coffee remaining in the edge of the filter,
will easily to cause poor sealing and water leakage.
HOW TO USE
7
Open the lid, take out water tank, and fill cold water into water tank NOT exceed
the “MAX” line. Set up the water tank vertically and align the buckles to the hole
on the back of the machine, press it down and close the lid.
1.
Plug in and press the ON/OFF switch“ ”, all indicators will flash, machine start
preheating, preheating will be finished Within 1 minute, coffee and steam indicators
will stay on.
Remove the filter holder and fill ground coffee into the filter. Evenly press down the
ground coffee into the filter with the measure scoop. Please keep the rim of the filter
clean after each filling.
2.
3.
Ground Coffce
Filter Filter Filter
Ground Coffce Ground Coffce
switch “ ” or double-cup coffee switch“ ”, the machine will start brewing.
HOW TO USE
8
Do not leave the coffee machine unattended during the
coffee making process, as it sometimes requires manual
operation.
Warning: Do not touch the hot surfaces of the machine with hands
to avoid scald, especially brewing outlet, steam nozzle
when use machine.
Install the filter holder into coffee outlet at " " position. Hold the machine by one
hand, using another hand to rotate the filter hold to " " position.
4.
After the coffee is made, remove the filter holder by rotating it clockwise, clean
the coffee grounds in the filter in time, and rinse it with hot water.
7.
Place a cup on the drip tray. After all indicators stop flashing, touch the single-cup
The coffee machine will stop automatically when coffee brewing finished. During
coffee brewing, you can press the coffee button again to stop the operation if you
like.
5.
6.
Warning:
HOW TO USE
9
FROTHING MILK
To prepare a traditional cappuccino or latte, we recommend:
Continue as follows:
Using cold (39°F-50°F), fresh whole milk. The density of the frothed milk will
depend on the milk fat content.
Using stainless steel, circular, rounded milk jugs, narrower at the top, with a spout,
necessary to make cappuccino decorations.
Before starting, it is important to slightly move the Steam Wand outwards in order
to insert the jug directly under it and facilitate the movements required to froth the
milk correctly
1.
2.
3.
It is important to keep the nozzle not at the center but close to the edge of the jug,
with an appropriate angle to produce a stronger vortex.
Put the cup/jug with milk under the steam wand, place the steam nozzle just below
the surface of the milk. If it is inserted too deep, the milk will not be frothed; if it is
not inserted deep enough, big bubbles will be produced and then disappear
immediately.
4.
Use whole, fresh cold milk, and pour 1/3 milk in cup/jug. The volume of milk will
increase after frothing.
Touch steam switch“ ”, it starts preheating, the steam indicator is flashing, when
machine preheating finished the steam indicator lights on.
Put an empty cup under the steam wand, turn the steam control knob counter -
clockwise to the maximum position, release a little water in the steam wand, and
turn the steam control knob clockwise to turn off the steam after the steam comes
out.
1.
2.
3.
OFF
