Match 19" UPS

OPM_MAE_19X_700_1K5_2GB_V030 1GE DE Match 19” 700-1500: User manual 3.0 (GB)

GE Digital Energy

USER MANUAL

Match 19"

Uninterruptible Power Supply

Uninterruptible Power SupplyUninterruptible Power Supply

Uninterruptible Power Supply

700 - 1500 VA

700 - 1500 VA700 - 1500 VA

700 - 1500 VA

Please read these instructions carefully before installation and start-up of the Match 19” UPS.

Keep this manual in a safe place for future reference.

CONTENTS

1 INTRODUCTION .......................................................................................................2

1.1 Introduction

1.2 Safety Rules

1.3 Transport / Storage

2 INSTALLATION .........................................................................................................2

2.1 Installation Rules

2.2 Installation Procedure

3 OPERATION..............................................................................................................4

3.1 Start-up

3.1.1 Start-up, mains available

3.1.2 Start-up, mains not available

3.2 Use: Normal Operation

3.2.1 Normal operating conditions

3.2.2 Load indication

3.2.3 Auto-off (no-load shutdown)

3.2.4 Battery test

3.2.5 Switching off

3.3 Use: Status and Alarm Indications

3.3.1 Charger on

3.3.2 Normal operation

3.3.3 AVR active

3.3.4 On battery

3.3.5 Battery low

3.3.6 Replace battery

3.3.7 Overload

3.3.8 High temperature

3.3.9 Programmed shutdown

4 COMMUNICATION ...................................................................................................7

4.1 RS232 Port

4.2 Relay Interface Card (option)

4.3 SNMP Interface Card (option)

5 MAINTENANCE.........................................................................................................7

5.1 General

5.2 Fuses

5.3 Batteries

5.3.1 General

5.3.2 Battery replacement

5.4 UPS Configuration Tool

6 TROUBLESHOOTING ..............................................................................................9

7 SPECIFICATIONS...................................................................................................10

liability can be accepted for any error or omission.

OPM_MAE_19X_700_1K5_2GB_V030 2GE DE Match 19” 700-1500: User manual 3.0 (GB)

GE Digital Energy

1.1 Introduction

The General Electric (GE) Digital Energy Match 19” UPS, an uninterruptible power supply, protects

your equipment from all forms of power interference, including complete power failures.

1.2 Safety Rules

CAUTION: RISK OF ELECTRICAL SHOCK. The UPS contains batteries. The appliance

outlets may be electrically live, even when the UPS is disconnected from the mains.

The UPS contains potentially hazardous voltages. Do not open the UPS, there are no user

serviceable parts inside.

All maintenance and service work, except for replacement of the batteries, should be performed

by qualified service personnel.

1.3 Transport / Storage

xNo liability can be accepted for any transport damage when the equipment is shipped in non-

original packaging.

xDuring transport the battery drawer must either be removed or fixed with two screws at the rear

side of the UPS (A, fig. 1).

xStore the UPS in a dry location with the batteries in a fully charged state. Storage temperature

must be within -20 +45 qC. If the unit is stored for a period exceeding 3 months, optimal battery

lifetime is obtained if the storage temperature does not exceed 25°C.

xIf the unit is stored for an extended period of time, the batteries must be recharged periodically.

Be sure that the battery drawer is connected to the UPS. Subsequently connect the unit to a wall

outlet and recharge the batteries for 24 hours:

- if the storage temperature is within -20 and +30°C: every 3 months,

- if the storage temperature is within -20 and +45°C: every month.

The shipping box contains a Match 19” UPS, two IEC male-female power cords, a data cable, a CD ROM

and this manual. After unpacking, inspect the UPS for damage. If you find any damage please

immediately notify the carrier and place of purchase.

IMPORTANT:

Before making any connection and switching on the UPS, please check the following conditions:

xyour mains supply is 220 - 240 Volts and 50 or 60 Hz, and

xthe total power demand of the connected equipment does not exceed the rated output power of

the UPS (indicated on the rating label).

2.1 Installation Rules

xThe UPS is intended to be used in normal domestic and office situations.

xProtect the UPS, according to the wiring rules, with a 16A D-type fuse.

xThe UPS must be powered from a single phase grounded wall outlet. Do not use extension

cords.

xAvoid locations that are excessively humid, near water, near heat sources or in direct sunlight.

xThe ambient temperature should not exceed 40qC. Optimal battery lifetime is obtained if the

ambient temperature does not exceed 30qC.

xIt is important that ventilation air can move freely around and through the unit. Do not block the air

vents.

xDo not plug appliances such as electric heaters, toasters and vacuum cleaners into the UPS.

xBe careful when connecting laser printers: be sure that the demanded power does not exceed the

capacity of the UPS.

xThe sum of the leakage currents of the UPS and the connected loads should not exceed 3.5mA.

1 - Introduction

2 - Installation

OPM_MAE_19X_700_1K5_2GB_V030 3GE DE Match 19” 700-1500: User manual 3.0 (GB)

GE Digital Energy

2.2 Installation Procedure

1. Remove the transport screws (A, fig. 1) and store them in the free holes (B, fig.1). Mount the

Match 19” UPS in the 19” rack. The module must be supported by mounting rails, do not mount it

by using the front brackets only. The front brackets allow mounting of handles (not included).

2. Make sure that the air vents in the side panels of the module are not blocked by the mounting

rails or the side panels of the 19” rack.

3. Switch off your computer, and unplug it from the

socket-outlet.

4. Disconnect the power cord from the computer (rating

250Vac/10A) and connect this cord to the mains

input socket (2, fig. 1) of the UPS. See fig. 2.

5. Using the output cord(s) provided, connect the

computer(s) to the appliance outlet(s) (4, fig. 1) of

the UPS. Spread the loads over the appliance

outlets as equally as possible. If you use a

distribution box to connect more than one appliance

per outlet, please note that the maximum AC-current

rating of each appliance outlet is 10Amps. See fig. 3.

6. Connect the mains cord of the UPS to a working,

grounded AC wall socket outlet. See fig. 4. The

green LED 'on' (7, fig. 6) will blink: power is available

and the batteries are charging. If the LED does not

blink, press 'I' briefly. Probably LED ‘replace battery’

lights up; the LED goes out as soon as the batteries

have been charged.

7. For best results, allow the UPS to recharge the batteries during a period of approx. 2 hours. It is

acceptable to use the UPS without first charging the battery, but the runtime may be reduced.

8. For advanced communication possibilities, the RS232 interface port (3, fig. 1) can be connected

to a computer system and/or optional interface cards (5, fig. 1, 1000/1500VA models only) can be

added. See chapter 4.

321

1000/1500 VA

models

fig. 2

fig. 3

fig. 1

fig. 4

OPM_MAE_19X_700_1K5_2GB_V030 4GE DE Match 19” 700-1500: User manual 3.0 (GB)

GE Digital Energy

Please refer to figure 6.

3.1 Start-up

3.1.1 Start-up, mains available

1 Press keypad 'I' (13, fig. 6) briefly; LED ‘on’ (already blinking) will illuminate continuously now.

2 The equipment connected to the UPS can now be switched on.

3.1.2 Start-up, mains not available

If the mains input is absent (power cord not connected, or mains failure):

1 Press keypad 'I' briefly, and then

2 Press keypad 'I' during 5 seconds until the buzzer sounds.

The LEDs 'on' and 'on battery' (12, fig. 6) will illuminate. The UPS operates on battery: it

discharges the batteries.

3.2 Use: Normal Operation

3.2.1 Normal operation conditions:

xthe mains supply is present,

xthe UPS is on,

xthe load does not exceed the capacity of the UPS and

xthe operating temperature is below alarm level:

3.2.2 Load indication (fig. 5)

1 During normal operation, press keypad 'I' briefly.

2 Yellow LEDs will blink during 3 seconds, the number is load

dependent (in case of overload LED 'alarm' (8, fig. 6) blinks as

well).

3.2.3 Auto-off (no-load shutdown)

If this function is activated, the UPS will switch off during a mains

failure when the load is less than 5% of the maximum load. In this

way unnecessary discharging of the batteries is avoided. The unit will automatically turn on again

when mains power is restored. The default setting of the no-load shutdown function is: activated.

You can change this setting through the RS232 port, using the UPS configuration tool that came

with the unit (CD ROM, see 5.4). Please note that if the UPS is not connected to the mains, and

the batteries are disconnected from the UPS, the unit will return to the default setting.

3.2.4 Battery test

1 During normal operation, press keypad 'I' for one second.

2 The duration of the test is 4 seconds. See also 3.3.6.

3.2.5 Switching off

1 Press keypad ‘0’ (14, fig. 6) briefly.

2 If electric isolation is required, unplug the power cord from the wall outlet.

fig. 5

3 - Operation

OPM_MAE_19X_700_1K5_2GB_V030 5GE DE Match 19” 700-1500: User manual 3.0 (GB)

GE Digital Energy

3.3 Use: Status and Alarm Indications

ostatus indications : the operating mode

!low priority alarms : abnormal operating situations

!! high priority alarms : situations in which the actual output voltage of the UPS is no longer

guaranteed; immediate action should be taken

Indicators on front panel

Situation on alarm avr progr.

shutd.

repl.

batt.

batt. buzzer

o Charger on (3.3.1) - - - -

o Normal operation (3.3.2) 





o Automatic voltage

regulation (3.3.3) 



 - - - -

! On battery (3.3.4) 



 





- - - -*

1x/8 s.

!! Battery low (3.3.5) 



 - - - - 





- - - -*

1x/s.

! Replace battery (3.3.6) 



 





!! Overload (3.3.7) 



 - - - - 





!! High temperature (3.3.8) 



 - - - - - - - -*

1x/s.

o Progr. shutdown

pending (3.3.9) 



 - - - -

o Progr. shutdown in

progress (3.3.9) - - - - 





Operating modes and corresponding indications, see 3.3.1. – 3.3.9.

- - - - = intermitting





 = continuous

* = resettable: press push button ‘I’ > 2 secs.

fig. 6

10 11 12 13 14

OPM_MAE_19X_700_1K5_2GB_V030 6GE DE Match 19” 700-1500: User manual 3.0 (GB)

GE Digital Energy

3.3.1 Charger on

The batteries are charging, see 2.2 step 6.

3.3.2 Normal operation

See 3.2.1.

3.3.3 AVR (Automatic Voltage Regulation) active

The quality of the incoming mains is poor, and the AVR boosts a low incoming voltage or reduces

a high one (see chapter 7).

3.3.4 On battery

The UPS uses the energy stored in the batteries: see chapter 7 ‘Batteries - runtime’.

The UPS will shutdown

xafter the batteries have been discharged (automatic restart), or

xif keypad 'O' is pressed (manual restart required) or

xif a 'UPS shutdown' command is given by the computer (manual restart required).

xif the load is < 5% and the auto-off function is activated (see 3.2.3)

Runtime indication (fig. 7)

During battery operation, press keypad 'I' briefly. The 4 yellow

LEDs indicate during 3 seconds the remaining runtime time for the

actual load.

3.3.5 Battery low (end of runtime)

The batteries are nearly discharged. Controlled shutdown of your

computer equipment should be completed within 1 minute.

3.3.6 Replace battery

The batteries are bad. The alarm only goes out after the next battery test: if the batteries have

either been sufficiently charged (discharged batteries) or replaced by a new set (worn out

batteries).

3.3.7 Overload

The demanded power of the equipment exceeds the UPS's rated output power. If overload

persists during battery operation, the UPS may shut down.

3.3.8 High temperature

Overtemperature shut down during battery operation can occur from:

xextreme environmental temperature,

xlack of proper ventilation,

xoverload situation.

When the pre-alarm sounds, check these conditions to avoid shutdown or damage. If the

temperature rises further, the UPS will

xif it runs on mains: switch off the battery charger

xif it runs on battery: switch off completely. Output voltage is no longer available!

3.3.9 Programmed shutdown

The UPS monitoring software allows you to program a 'sleep period' of the UPS by sending two

commands to the UPS:

xshut down after # minutes (blinking LED), and subsequently:

xshut down during # hours (continuous LED).

The programmed shutdown in progress can be cancelled:

- press keypad 'I' for at least 5 seconds to cancel shutdown and switch UPS on.

- press keypad '0' for at least 5 seconds to cancel shutdown and switch UPS off.

fig. 7

OPM_MAE_19X_700_1K5_2GB_V030 7GE DE Match 19” 700-1500: User manual 3.0 (GB)

GE Digital Energy

4.1 RS232 Port (fig. 8)

The RS 232 Port is a plug-in interface port (9-pin, Sub-D, male) which enables advanced communication

between the UPS and the computer (interface kit required).

We strongly recommend to use only original GE Digital Energy software products in combination with

the interface port.

Pin # Function

1 RS232 input (UPS shutdown)

2 RS232 output

3 No function

4 Plug and Play

5 Common

6 No function

7 Battery low

8 UPS connected

9 Mains failure

4.2 Relay Interface Card (option, 1000/1500VA only)

The card is equipped with potential free change-over contacts for the following alarms:

• mains failure

• battery low

For more information please refer to the user manual that comes with the interface card.

4.3 SNMP Interface Card (option, 1000/1500VA only)

This card allows the data interface to be connected directly to an Ethernet network. When this card is

installed the RS232 communication link is no longer available.

For more information please refer to the user manual that comes with the interface card.

5.1 General

The UPS is virtually maintenance free: take care of proper environmental conditions and keep air inlets-

outlets free of dust.

Please read 2.1.

5.2 Fuses

If the AC input fuse (1, fig. 1) is defect, be sure it is replaced by a compatible fuse from the same make

and type:

FERRAZ TISP 5x20 or LITTLEFUSE 215 5x20 or WICKMANN 19181 5x20

Fuse ratings: see chapter 7.

5.3 Batteries

5.3.1 General

The service life of the battery is up to 6 years, depending on operating conditions.

As a healthy battery is critical to the performance of the UPS, keypad 'I' allows a Quick Battery Test (see

3.2.4). When the condition of the battery is critical, a 'replace battery' alarm will be generated. Replace the

batteries as soon as possible. See 5.3.2.

fig. 8

4 - Communication

5 - Maintenance

OPM_MAE_19X_700_1K5_2GB_V030 8GE DE Match 19” 700-1500: User manual 3.0 (GB)

GE Digital Energy

5.3.2 Battery replacement

-WARNING: first read the safety rules in section 1.2.

- When replacing the batteries, use the same number and voltage(V)/capacity(Ah).

- Proper disposal or recycling of the batteries is required. Refer to your local codes for disposal

requirements.

- Never dispose of batteries in a fire: they may explode.

- Do not open or mutilate batteries: their contents (electrolyte) may be extremely toxic. If exposed to

electrolyte, wash immediately with plenty of water.

- Avoid charging in a sealed container.

- Never short circuit batteries. When working with batteries, remove watches, rings or other metal

objects, and only use insulated tools.

Battery replacement procedure

Refer to the label on the battery drawer.

1. Be sure that the transport screws (A, fig. 1) have

been removed.

2. Remove the front panel of the battery compartment.

Use a screw driver or pen as a lever.

3. Remove the two screws that hold the battery drawer.

4. Disconnect the DC connectors. Use a screwdriver

as a lever.

5. Remove battery drawer. Be careful, heavy weight!

6. Remove clamp (two screws) and replace the

batteries.

7. Reinstall battery clamp, do not pinch or clamp the

wires.

8. Slide in the battery drawer.

9. Connect the DC connectors, a small spark is

normal. Fasten the two screws.

10. Reinstall the front panel.

5.4 UPS Configuration Tool

With the UPS configuration software, that came with the unit on CD ROM, you are able to change the

setting of the 'auto-off' function (3.2.3).

Insert the CD ROM in your computer, and

1. Select RUN from the start menu

2. Type a:\conftool (type for 'a' the appropriate drive letter)

3. Press ENTER

Manuales populares de Unión Postal Universal de otras marcas

Pylontech

Pylontech Victron & Pylontech US5000 Manual de usuario

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manual de usuario

Mecer

Mecer ME-1000-WTU Manual de usuario

Mustek

Mustek PowerMust 530(B) Plus Manual de instalación y operación

Emerson

Emerson Liebert NXL series Manual de usuario

MAKELSAN

MAKELSAN BOXER SERIES Manual de usuario

Block

Block PC-0524-400-0 Manual de usuario

CyberPower

CyberPower CP585LCD Manual de usuario

Eaton

Eaton 3S Instrucciones de montaje

CyberPower

CyberPower Office Tower Series UPS 1000 Manual de usuario

CyberPower

CyberPower BM100 Manual de usuario

Best Power

Best Power 610 Manual de usuario

Best Power

Best Power Unity/I UT3K Manual de usuario

Mustek

Mustek PowerMust 400 Offline Manual de usuario

Xantrex

Xantrex Trace 512 UR-UPS Manual de usuario

Forza

Forza SL-1501UL Manual de usuario

LEGRAND

LEGRAND keor 310081 Manual de usuario

ABB

ABB Conceptpower DPA 500 Manual de usuario
