GE ADT521PGFBS Manual

27-1/2"

24"*

MAX. 23-3/4"

3/ "

33- 8 MIN.

adj

34-5/8"AX

4"(toekick)

29-7/8"

*Add 2.4" for handle.

Dimensions and Installation Information (in inches)

For answers to your Monogram,® Cafe™Series,

Profile™Series or GE®appliance questions, visit

our website at geappliances.com or call GE

Answer Center®service, 800.626.2000.

As an ENERGY STAR®

partner, GE has determined

that this product meets the

ENERGY STAR guidelines

for energy efficiency.

ADT521PGF

GE Artistry™Series Dishwasher with Top Controls

Specification Revised 8/13 350243

Listed by

Underwriters

Laboratories

•The rough cabinet opening must be at least 24" deep,

24" wide and approximately 34-1/2" high from floor to

underside of the countertop.

5" 5"

Figure A

Floor MUST be Even

With Room Floor

Cabinets

Square

and

Plumb

This Wall Area

must be Free

of Pipes or

wires

24"

Min.

24"

Min.

33-1/2" to 34-3/4"

Underside of

Countertop

to Floor

Plumbing and Electric Service

Must Enter Inside This Area

Electrical Rating

Voltage AC.......................................................... 120

Hertz..................................................................... 60

Total connected load amperage............. 7.1

Calrod®heater watts......................... 415/800

For use on adequately wired 120-volt,

15-amp circuit having 2-wire service

with a separate ground wire. This appliance

must be grounded for safe operation.

Installation Information: Before installing,

consult installation instructions packed with

product for current dimensional data.

ADT521PGFBS_ADT521PGFWS

Features and Benefits

• GE’s most advanced wash system - Consistently clean and dry dishes are ensured with

GE’s most advanced wash system, featuring 65% more wash power.*

*Wash power delivered to each rack. Compared to previous GE models.

• Piranha™Hard Food Disposer with Removable Filter - To ensure consistently clean

items, this stainless steel blade rotates at 3,600 RPM to pulverize food particles and

helps to prevent large particles from clogging the wash arms

• Steam PreWash - Loosens tough soils before any cycle virtually eliminating the need

for soaking or pre-rinsing dishes

• Sanitize option (NSF Residential) - High-temperature rinse sanitizes and reduces 99.99%

of bacteria found on dishes

• SpaceMaker®Silverware Basket - Enjoy table-ready silverware and loading flexibility

with this unique basket that can be placed on the rack or onto the door

• Pearlescent dark gray nylon racks with ball tip tines - Offer durability and secure dishes

• 2/4/8-Hour Delay Start - Wash dishes at your convenience

• Model ADT521PGFWS - White

• Model ADT521PGFBS - Black

ADT521PGF

GE Artistry™Series Dishwasher with Top Controls

Specification Revised 8/13 350243
