GE IC693CBL300 Manual de usuario

QuickPanel™ Control

Communication Module

Quick Installation Guide

PCIF I/O Adapter

April 2010

GFK-2245A

GFL-002

Warnings, Cautions, and Notes as Used in this Publication

Warning

Warning notices are used in this publication to emphasize that hazardous voltages,

currents, temperatures, or other conditions that could cause personal injury exist in

this equipment or may be associated with its use.

In situations where inattention could cause either personal injury or damage to

equipment, a Warning notice is used.

Caution

Caution notices are used where equipment might be damaged if care is not taken.

Note: Notes merely call attention to information that is especially significant to under-

standing and operating the equipment.

This document is based on information available at the time of its publication. While efforts

have been made to be accurate, the information contained herein does not purport to cover

all details or variations in hardware or software, nor to provide for every possible contingency

in connection with installation, operation, or maintenance. Features may be described herein

which are not present in all hardware and software systems. GE Intelligent Platforms as-

sumes no obligation of notice to holders of this document with respect to changes subse-

quently made.

GE Intelligent Platforms makes no representation or warranty, expressed, implied, or statu-

tory with respect to, and assumes no responsibility for the accuracy, completeness, suffi-

ciency, or usefulness of the information contained herein. No warranties of merchantability

or fitness for purpose shall apply.

* Indicates a trademark of GE Intelligent Platforms, Inc. and/or its affiliates. All other

trademarks are the property of their respective owners.

Contact Information

If you purchased this product through an Authorized Channel Partner, please contact the

seller directly.

General Contact Information

Online technical support and GlobalCare http://www.ge-ip.com/support

Additional information http://www.ge-ip.com/

Solution Provider solutionprov[email protected]

Technical Support

If you have technical problems that cannot be resolved with the information in this guide,

please contact us by telephone or email, or on the web at www.ge-ip.com/support

Americas

Online Technical Support www.ge-ip.com/support

Phone 1-800-433-2682

International Americas Direct Dial 1-780-420-2010 (if toll free 800 option is unavail-

able)

Technical Support Email support.ip@ge.com

Customer Care Email customercare.ip@ge.com

Primary language of support English

Contact Information

Europe, the Middle East, and Africa

Online Technical Support www.ge-ip.com/support

Phone +800-1-433-26 82

EMEA Direct Dial +352-26-722-780 (if toll free 800 option is unavail-

able or if dialing from a mobile telephone)

Technical Support Email support.emea.ip@ge.com

Customer Care Email customercare.eme[email protected]

Primary languages of support English, French, German, Italian, Czech, Spanish

Asia Pacific

Online Technical Support www.ge-ip.com/support

Phone +86-400-820-8 208

+86-21-3217-4826 (India, Indonesia, and Pakistan)

Technical Support Email support.cn.ip@ge.com (China)

support.jp.ip@ge.com (Japan)

support.in.ip@ge.com (remaining Asia customers)

Customer Care Email customercare.apo.ip@ge.com

customercare.cn.ip@ge.com (China)

The PCIF I/O Adapter has been tested and found to meet or exceed the requirements of

U.S. (47 CFR 15), Canadian (ICES-003), Australian (AS/NZS 3548) and European

(EN55022) regulations for Class A digital devices when installed in accordance with guide-

lines noted in this manual.

Note: This device complies with Part 15 of the FCC rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and

(2) This device must accept any interference received that may cause undesired

operation.

Note: This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment

is operated in a commercial environment. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used in accordance

with the instruction manual, may cause harmful interference to radio communica-

tions. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at

his own expense.

Note: This Class A digital apparatus complies with Canadian ICES-003.

The following statements are required to appear for Class 1, Div 2 Hazardous Locations.

1. EQUIPMENT LABELED WITH REFERENCE TO CLASS 1, GROUPS A, B, C, AND

D, DIV 2 HAZARDOUS LOCATIONS IS SUITABLE FOR USE IN CLASS 1, DIVISION

2, GROUPS A, B, C, D, OR NON-HAZARDOUS LOCATIONS ONLY.

2. WARNING - EXPLOSION HAZARD - SUBSTITUTION OF COMPONENTS MAY

IMPAIR SUITABILITY FOR CLASS 1, DIVISION 2.

3. WARNING - EXPLOSION HAZARD - DO NOT DISCONNECT EQUIPMENT

UNLESS POWER HAS BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE

NONHAZARDOUS.

The communication card meets ATEX Group II Category 3 when installed properly in a

QuickPanel Control OI.

6 Installation

Installing a Communication Module

Warning: Always use anti-static precautions when ac-

cessing the mating connector or the interior

of the unit.

Note: The 6” model QuickPanel is shown. Other models are

similar.

1. Disconnect the DC input power terminal block connec-

tor from your QuickPanel Control unit before connect-

ing the Communication Module to the unit.

Installation 7

2. Open the back cover.

3. Attach the Communication Module to the unit by plug-

ging the module into the mating connectors on the back

of the unit.

4. Install the three screws to secure the card in the unit.

5. Close the cover.

Connect your I/O network to external connections on the

module enclosure (see applicable sections for details).

Caution: Be sure to properly align pins in the dual

connector upon insertion to avoid damage to the

card or the QuickPanel Control.

8 Specification s

Series 90-30 Remote I/O Connector

Pin # Signal Direction

1 SHLD N/A

2 DFRAM E + Output

3 DFRAM E - Output

7 GND N/A

8 RUN + Output

9 RUN - Output

12 P ERR + Input

13 P ERR - Input

16 DA TA + Input/Output

17 DA TA - Input/Output

20 R SEL + Output

21 R SEL - Output

24 IOCLK + Output

25 IOCLK - Output

Installation 9

Interconnecting Cable

The cable used should have seven twisted pairs, with an

overall shield and drain wire (Belden 8107 or equivalent).

The final rack on the I/O Bus should be terminated with an

I/O Bus terminator plug, catalog number IC693ACC307.

Interconnecting cables may be standard length GE expan-

sion cables or custom length cables.

Part Number Cable Type

IC693CBL300 1 meter “Wye” cable

IC693CBL301 2 meter “Wye” cable

IC693CBL302 15 meter “point to point” cable

Environmental Specifications

Storage Temperature -20° to 70°C

Operating Temperature 0° to 60°C

Operating Humidity 5 to 90% (non-condensing)
