GENERAL

1.1 INFORMATION ABOUT THIS INSTRUCTIONS MANUAL

These instructions are only intended for use with gas supply panel product type:

• MTLX – gas supply panel for one cylinder

• MTLT – gas supply panel for three cylinders

Gas supply panels of this type are suitable to take gas out of gas cylinder or bundle and reduce the pressure.

With MTLT and its three gas cylinders the gas ﬂow is longer guaranteed and cylinder change is possible

without interrupting the gas ﬂow.

These gas supply panels were installed as permanently wall assembly.

These instructions enable you to operate the system safely and eciently. These instructions form an integral

part of the system and must always be kept with the system and within easy reach of sta at all times.

Prior to commencing any work, the sta must read these instructions carefully and understand the contents.

Observance of all the safety information and instructions for operation that are contained in these instructions

is essential to ensure work safety.

Local accident prevention regulations and general safety regulations governing the use of the system must

also be observed. Illustrations in these instructions serve to ensure a basic understanding of the system and

may dier from the actual version.

1.2 INFORMATION ABOUT THIS GAS SUPPLY PANEL

Gas supply panels of this type are only suitable for gases deﬁned as standard gas. The maximum working

pressure for these panels is 300 bar.

Standard gases are industrial, inert, ﬂammable and oxidizing gases and/ or their mixtures. Not allowed are the

components for corrosive and/ or toxic gases and/or their mixtures.

Single stage gas supply panels consists of valves and a pressure regulator with metal diaphragm, created

and approved as ISO7291 including oxygen shock test.

The MTLX – gas supply panel for one gas cylinder consists of one inlet pressure shut-o valve, one pres-

sure regulator with inlet and outlet pressure gauge. At the version with inert gas purging there is also outlet

pressure purge gas valve.

The MTLT – gas supply panel for three gas cylinder consists of four inlet pressure shut-o valves (three to

shut-o direct and separate at gas cylinder, one to shut-o complete inlet pressure), one pressure regulator

with inlet and outlet pressure gauge. At the version with inert gas purging there is also outlet pressure purge

gas valve.

1.3 EXPLANATION OF SYMBOLS

SAFETY INFORMATION Safety information is highlighted by symbols in these instruc-

tions. This safety information is preceded by signal words that

deﬁne the extent of risk.

DANGER!

This combination of symbol and signal word indicates an im-

mediately dangerous situation that will cause death or severe

injury if not avoided.

WARNING!

This combination of symbol and signal word indicates a pos-

sibly dangerous situation that can cause death or severe injury

if not avoided.

BEWARE!

This combination of symbol and signal word indicates a pos-

sibly dangerous situation that can cause minor injury if not

avoided.

NOTE!

This combination of symbol and signal word indicates a pos-

sibly dangerous situation that can cause property and environ-

mental damage if not avoided.

5/46

TIPS AND RECOMMENDATIONS

This symbol highlights useful tips and recommendations, to-

gether with help for ensuring ecient and trouble-free opera-

tion.

SPECIAL SAFETY

INFORMATION

The following symbols are used in the safety information to

draw your attention to particular risks.

DANGER!

This combination of symbol and signal word indicates an im-

mediately dangerous situation involving electrical current. Ig-

noring such a warning could result in severe or fatal injuries.

1.4 LIMITATIONS OF LIABILITY

All of the information and notes in these instructions have been compiled in accordance with applicable

standards and regulations. They reﬂect best engineering practice and our years of experience.

The manufacturer accepts no liability for damages in the following instances:

• Failure to observe these instructions

• Utilization of the system for any other than the intended purpose

• Operation by untrained sta

• Unauthorized modiﬁcations

• Technical modiﬁcations

• Use of unlicensed spare parts

• Working with the gas supply panel when any safety device is broken or not functional mounted or safety

devices don’t work correctly

• Improper control of components, connections and gaskets, which are wearing parts.

• Incorrect reparations

• Violation of temperature limits, which are dedicated in the datasheet during operation or storage

• In case of disaster or force majeure

The actual scope of supply may dier from the explanations and illustrations in these instructions following

the incorporation of new technical changes.

The obligations stipulated in the supply agreement, our general terms and conditions of business, the

manufacturer’s terms and conditions of supply and the statutory regulations in force at the time of contract

conclusion apply.

1.5 COPYRIGHT

The contents of these instructions are protected by copyright. They may be used in connection with the

operation of the system. Any other use above and beyond the aforementioned is only permitted with the

written consent of the manufacturer.

1.6 SPARE PARTS

WARNING!

• Risk of injury from using incorrect spare parts!

• The use of incorrect or defective spare parts can result in risks for the operating sta and in damages,

malfunctions or total failure of the system.

• Only use original spare parts from the manufacturer or spare parts authorized by the manufacturer.

• Always consult the manufacturer if in doubt.

Loss of warranty

• The manufacturer’s warranty lapses if unauthorized spare parts are used.

6/46

1.7 WARRANTY PROVISION

The warranty provisions are included in the manufacturer’s general terms and conditions of business. See

chapter VI. Warranty Claims.

1.8 CUSTOMER SERVICE

GCE GmbH

Weyherser Weg 8

36043 Fulda

Please do not hesitate to provide us with information and experiences gained through use; we welcome any

valuable input that will help to improve our products.

SAFETY

This section provides an overview of all the important safety aspects to ensure the protection of your sta

and the safe and trouble-free operation of the equipment. Further safety information relating to speciﬁc

tasks can be found in the sections on the individual life cycle phases.

2.1 INTENDED USE

The gas supply panel are only usable for the deﬁned standard gases and pressures observing the given

temperature range. The maximum ﬂow is 20 m3/h.

Intended use also includes compliance with all the information in these instructions and compliance with

reparation, maintenance working, type label and data sheets.

Any use other than, or above and beyond, the intended use constitutes improper use.

WARNING!

• Danger from improper use!

• Improper use of the system can produce dangerous situations.

• Never use the panel with liquid ﬂuids.

2.1.1 STRUCTURAL CHANGES AT THE GAS SUPPLY PANEL

Without written approval of supplier no extensions, additions or alternations are allowed on the gas supply

panel.

Components which are not in perfect condition have to be changed immediately.

Cleaning of gas supply panel and disposal of residues

Used components which are ready for reparation has to be purged with an inert gas before.

Noise Generation

In some cases when speciﬁc inﬂuence quantities collaborate together, e.g. ﬂow and pressure range can

cause noise generation or the gas itself. If this happens please contact supplier.

2.2 FUNDAMENTAL RISKS

The following section addresses the residual risks that may arise, even if the system is used properly.

Observance of the safety information included below and in other sections of these instructions is

mandatory in order to reduce the risk of injury and property damage and to avoid dangerous situations.

7/46

DANGER!

• Gases can be life threatening!

Gases can supersede the oxygen in air. This can result in death by asphyxiation. Oxygen produces a

strongly oxidizing eect.

Therefore:

• Sucient ventilation is absolutely essential.

• Installation only through certiﬁed company.

• Observe ATEX-directive

ATTENTION!

• Risk of injury from environment!

There can be malfunctions on component due to condensation and/ or icing.

Therefore:

• Observe suitable temperatures.

• Protect component from liquids from outside

• Protect component from dust from outside

• Protect component from weather conditions

• Grounding has to be mounted properly

WARNING!

• Risk of injury from using oil and grease!

Oil and grease must never be used in gas regulating systems. Oil and grease are highly inﬂammatory and

can react violently to certain pressurized gases.

Therefore:

• Never use oil and grease

WARNING!

• Risk of injury from residual energy stored in the system!

If handled incorrectly, pressurized components can move uncontrollably and cause severe injury. If han-

dled incorrectly or defective, pressurized components can leak gas under high pressure and cause severe

or even fatal injuries.

Before starting work with these components:

• Installation only through certiﬁed company.

• Always wear protective goggles when working.

• Make sure the equipment is depressurized. Also make sure the residual energy is discharged.

• Always ensure that gas cannot leak unintentionally.

• Make sure that defective components that are pressurized during operation are immediately replaced by

trained sta.

WARNING!

• Danger of accident!

Due to wrong installation there can be serious or even mortal injuries.

Therefore:

• During installation the component should be kept safe

• Never throw the component

Pressurised components are only for intended use.

If there are mechanical damages at tubing or components the whole system has to be put in a safe condition.

Aected area has to be blocked. Troubles which could inﬂuence safety, have to be eliminated through qualiﬁed

sta or supplier.

Especially with gases failure in pressure regulator could happen. Indications for defective regulator is no ﬂow

or immediately rising outlet pressure. In this case system has to be shut-o and the relevant department for

maintenance has to be informed. Never close exhaust piping.

8/46

2.3 OPERATOR’S RESPONSIBILITY

Operator

The operator is the person who operates the system for commercial or business purposes or who provides

the system for use/application by a third party, and who bears legal product responsibility for protecting the

user, sta or third parties during operation.

Operator’s duties

The system is used for commercial purposes. The operator of the system is therefore subject to legal work

safety obligations.

Compliance with the safety, accident prevention and environmental protection regulations that apply for the

use of the system is mandatory, in addition to the safety information in these instructions.

The following applies in particular:

• The operator must be aware of the applicable work safety regulations and must perform a risk assessment

to identify risks that may occur as a result of the speciﬁc working conditions at the site where the system

is operated. The operator must use this assessment as the basis for compiling instructions for operating

the system.

• During the entire period in which the system is operated, the operator must ensure that these operating

instructions comply with the latest regulations, and must update the instructions if necessary.

• The operator must assign clear and speciﬁc responsibility for installation, operation, troubleshooting,

maintenance and cleaning.

• The operator must ensure that all members of sta who work with the system have read and understood

these instructions. The operator must also ensure that these members of sta are trained at regular inter-

vals and are aware of the risks.

• The operator must provide the sta with the requisite protective equipment and bindingly obligate the

sta to wear the necessary protective equipment.

In addition, the operator is responsible for ensuring full technical reliability of the system at all times. As such,

the following applies:

• The operator must ensure compliance with the maintenance intervals speciﬁed in these instructions.

• The operator must ensure that all safety equipment is regularly inspected for functional reliability and

completeness.

2.4 PERSONNEL REQUIREMENTS

2.4.1 QUALIFICATIONS

The various tasks described in these instructions constitute diering requirements in respect of the qualiﬁca-

tions of the sta charged with performing these tasks.

WARNING!

• Danger if sta is insuciently qualiﬁed!

• Insuciently qualiﬁed sta is not able to assess the risks associated with the system and expose both

themselves and others to the risk of severe or fatal injury.

• Ensure that all works are only performed by sta qualiﬁed for the speciﬁc task.

• Keep insuciently qualiﬁed people out of the work area.

The works must always be assigned only to individuals who can be trusted to perform the works reliably.

People with impaired reactions, e.g. as a result of drugs, alcohol or medication, must not be allowed to

perform works.

These instructions deﬁne the qualiﬁcations below that are necessary for the respective tasks:

Gas engineer:

Have a professional training, skills and experience and the knowledge of the pertinent standards and regula-

tions to perform works on gas systems and to identify potential hazards. Gas engineers are trained speciﬁ-

cally for the site where they work and are familiar with all relevant standards and regulations.

Technician

Have the professional training, skills and experience and the knowledge of the pertinent standards and regu-

lations to perform the assigned works and to identify and avoid potential hazards.

9/46

2.4.2 UNAUTHORIZED PERSONNEL

WARNING!

• Risks associated with unauthorized personnel in the hazard and work areas can be life threatening!

• Unauthorized individuals without the qualiﬁcations described in this section are not familiar with the risks

in the work area. As such, they are in danger of severe or even fatal injury.

• Keep unauthorized personnel away from the hazard and work area.

• If in doubt, approach individuals and instruct them to leave the hazard and work area.

• Stop any work while unauthorized individuals are in the hazard and work area.

2.4.3 TRAINING

The operator must train the sta at regular intervals. A training log must be maintained for purposes of better

tracking and must contain the following information, at least:

• Date of training

• Names of trained sta

• Contents of the training session

• Name of trainer

• Signatures of the sta members in training and of the trainer

2.5 PERSONAL PROTECTIVE EQUIPMENT

Personal protective equipment protects sta from safety and health hazards while working.

Various tasks on and associated with, the system necessitate the use of personal protective equipment,

which is described in more detail in the individual sections of these instructions.

BREATHING APPARATUS

To protect against harmful gases, vapors, dust and similar materials and media.

Breathing apparatus (e.g. compressed air respirator) must be used when an oxy-

gen content of at least 17% in the ambient air is not guaranteed or when the limit of

a hazardous substance in the ambient air is exceeded more than 100-fold. Breath-

ing apparatus may only be worn by people who have been specially trained in

the use.

BREATHING APPARATUS, DEPENDENT ON AIR CIRCULATION

To protect against harmful gases, vapors, dust and similar materials and media.

Breathing apparatus must be worn if a permissible limit is exceeded 100-fold. The

breathing apparatus may only be used when the oxygen content in the ambient

air measures at least 17%.

PROTECTIVE GOGGLES

To protect the eyes against airborne parts and splashes of liquid.

CHEMICAL-RESISTANT GLOVES

To protect the hands from aggressive substances.

Make sure the protective gloves are leak-proof before wear, Before taking the

gloves o, clean them and then store them in a well ventilated location.

PROTECTIVE GLOVES

To protect the hands against abrasion, scrapes, pricks or deeper injuries and con-

tact with hot or cold surfaces.

WEAR HEARING PROTECTION

To protect the hands against abrasion, scrapes, pricks or deeper injuries and con-

tact with hot or cold surfaces.

10/46

2.6 BEHAVIOR IN CASE OF FIRE OR ACCIDENT

Preventive Measure

• Always be prepared for ﬁres and accidents!

• Always keep ﬁrst aid equipment (kit, blankets, etc.) and ﬁre extinguishing equipment in working order and

close to hand.

• Familiarize the sta with accident reporting, ﬁrst aid and emergency procedures.

• Keep the access routes free for emergency service vehicles.

Measures in the event of ﬁre or accident

• If there is no risk to your own safety, remove people from the danger zone.

• Administer ﬁrst aid if necessary.

• Notify the ﬁre brigade and/or emergency service.

• In the event of ﬁre: If there is no risk to your own safety, use ﬁre extinguishing equipment to ﬁght the ﬁre

until the ﬁre brigade arrives.

• Inform the person responsible at the location.

• Make sure the access routes are free for emergency service vehicles.

• Direct the emergency service vehicles.

2.7 ENVIRONMENTAL PROTECTION

NOTE!

• Risk of environmental pollution from incorrect handling of environmentally hazardous substances!

• The environment can suer substantial damage if environmentally hazardous substances are handled,

and especially disposed of, incorrectly.

• Always observe the information below on handling environmentally hazardous substances and their dis-

posal.

• Take immediate measures if environmentally hazardous substances are accidentally released into the

environment. If in doubt, notify the responsible local authorities about the damage and enquire about the

suitable measures to be taken.

2.8 SIGNAGE

WARNING!

• Danger from illegible signs!

• Labels and signs can gather dirt or become otherwise illegible over time, thus preventing the recognition

of risks and compliance with the requisite operating information. This could result in injury.

• Make sure all safety, warning and operation information is legible at all times.

• Immediately replace any damaged signs or labels.

2.8.1 SIGNS THAT GIVE ORDERS

• No signs

2.8.2 SIGNS INDICATING BANS

• No signs

2.8.3 WARNING SIGNS

Gas Bottles

Hazard

Explosion -

Hazardous Area

Warning of Toxic

Substances

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Controladores de GCE

GCE

GCE DINCONTROL Manual de usuario

GCE

GCE UNISET Manual de usuario

GCE

GCE ECOSAVER+ Manual de usuario

GCE

GCE MediVital E Manual de usuario

GCE

GCE S 400 Manual de usuario

GCE

GCE mediline MEDIREG II Manual de usuario

GCE

GCE MediVitop Manual de usuario

GCE

GCE MEDIEVAC+ Manual de usuario

GCE

GCE MEDISELECT II Manual de usuario

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario
