GBC Shredmaster 2230S Manual de usuario

This service manual covers adjustment, disassembly, operation, preventative maintenance, trou-

bleshooting procedures and contains an illustrated parts list for the GBC Shredmaster 2230S-/2250X

shredder. The GBC Shredmaster 2230S/2250X shredders are designed for small offices and low

volume requirements.

Innovative engineering has provided these shredders with the following operating and safety fea-

tures:

1. Automatic Operation - The unit begins to operate when paper actuates the trigger in the shred

der throat area. The motor stops running when the paper has cleared the cutting head and after the

shredder has timed out.

2. Overload Warning - Whenever the capacity of the shredder is exceeded the unit will stop shred

ding and the "Reverse" icon will illuminate.

3. Bin Full - When the shred bag becomes full, the motor automatically turns off and the "Bin full"

icon will illuminate. The shredder will not operate until the shredded material is either compacted or

emptied.

4. Door Ajar

- When the door of the shredder is not fully closed, the "Door Ajar" icon will illuminate.

This is a safety feature that will only allow the shredder to operate when the cabinet door is in the

closed position.

Before attempting any repairs on the 2230S-1/2250X shredder, review the operating instructions first

to gain experience and familiarity with its operation. You will then be better prepared to use the

remaining sections of this manual to troubleshoot and repair the shredder.

2.0 2230S-1/2250X Introduction

2250X

2230S-1

Required

Electrical

Service:

115V AC +/

10%, 60 Hz, 15 Amp

Electrical

Rating:

115V AC

3.4A, @ 60Hz

Duty Cycle:

Continuous

Dimensions:

HxWxD

26.75” x 16.75”x 15”

(67.9 x 42.5 x 38.1 cm)

Weight W/

Cabinet:

38.71 lbs.

Shredding

Speed:

30 FPM @ 1 sheet

Shred Size:

5/32” (4mm)

Throat

Width:

9 1/4” (23.5cm)

Capacity:

12-

14 sheets of 20# Bond

Paper

Noise Level:

68 dB No Load

Shipping Carton

Dimensions:

HxWxD

32.06” x 22.5” x 20”

(81.4 x 57.15 x 50.8 cm)

Required

Electrical

Service:

115V AC +/

10%, 60 Hz, 15 Amp

Electrical

Rating:

115V AC

2.6A, @ 60Hz

Duty Cycle:

Continuous

Dimensions:

HxWxD

26.75” x 16.75”x 15”

(67.9 x 42.5 x 38.1 cm)

Weight W/

Cabinet:

38.71 lbs.

Shredding

Speed:

20 FPM @ 1 sheet

Shred Size:

5/32” X 2 5/32” (4 x 55mm)

Throat

Width:

9 1/4” (23.5cm)

Capacity:

8 sheets of 20# Bond

Paper

Noise Level:

68 dB No Load

Shipping Carton

Dimensions:

HxWxD

32.06” x 22.5” x 20”

(81.4 x 57.15 x 50.8 cm)

2.0 2230S-1/2250X Specifications

3.0 2230S-1/2250X Safety Instructions 6

3.0/4.0 2230S-1/2250X Installation/Operation
