GarrettCom Magnum CSG14 Manual de usuario
www GarrettCom com
..
www GarrettCom com
..
Corporate Headquarters
GarrettCom, Inc.
47823 Westinghouse Drive
Fremont, CA 94539-7437
Phone (510) 438-9071
Fax (510) 438-9072
Website: http://www.GarrettCom.com
Magnum CSG14 Gigabit Converter Switches
Installation and User Guide
CSG14 Series Gigabit Converter Switch Installation and User Guide (05/08)
i
www GarrettCom com
..
Magnum™CSG14 Series Gigabit Converter Switch
Installation and User Guide
Part #: 84-00102Z Rev. A
Trademarks
GarrettCom, Magnum, Link-Loss-Learn, S-Ring, Convenient Switch, Converter
Switch are trademarks and Personal Hub is a registered trademark of GarrettCom, Inc.
Ethernet is a trademark of Xerox Corporation
NEBS is a trademark of Telcordia Technologies
UL is a registered trademark of Underwriters Laboratories
CSG14 Series Gigabit Converter Switch Installation and User Guide (05/08)
ii
www GarrettCom com
..
Important: The Magnum CSG14 Series 10/100/1000 Mb/s Converter
Switches contain no user serviceable parts. Attempted service by unauthorized
personnel shall render all warranties null and void. If problems are
experienced with Magnum CSG14 10/100/1000 Mb/s Converter Switch
products, consult Section 5, Troubleshooting, of this User Guide.
Copyright ©2008 GarrettCom, Inc. All rights reserved. No part of this publication may
be reproduced without prior written permission from GarrettCom, Inc.
Printed in the United States of America
CSG14 Series Gigabit Converter Switch Installation and User Guide (05/08)
iii
www GarrettCom com
..
Federal Communications Commission
Radio Frequency Interference Statement
This equipment generates, uses and can radiate frequency energy and if not
installed and used properly, that is in strict accordance with the manufacturer's
instructions, may cause interference to radio communication. It has been tested and
found to comply with the limits for a Class A computing device in accordance with the
specifications in Subpart J of Part 15 of FCC rules, which are designed to provide
reasonable protection against such interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause
interference, in which case the user, at his/her own expense, will be required to take
whatever measures may be required to correct the interference.
CSG14 Series Gigabit Converter Switch Installation and User Guide (05/08)
iv
www GarrettCom com
..
Contacting GarrettCom, Inc
Please use the mailing address, phone and fax numbers and email address listed below:
GarrettCom, Inc.
47823 Westinghouse Drive
Fremont, CA 94539
Phone (510) 438-9071
Fax (510) 438-9072
Website: http://www.GarrettCom.com
CSG14 Series Gigabit Converter Switch Installation and User Guide (05/08)
v
www GarrettCom com
..
TABLE OF CONTENTS Page
1.0 SPECIFICATIONS ............................................................................... 1
1.1 Technical Specifications...................................................................... 1
1.2 Summary of models and descriptions:............................................... 11
2.0 INTRODUCTION ............................................................................... 14
2.1 Inspecting the Package and the Product............................................. 14
2.2 Product Description ........................................................................... 15
2.3 Frame Buffering and Latency............................................................ 22
2.4 Features and Benefits......................................................................... 26
2.5 Applications for CSG14 Series Converter Switches.......................... 29
3.0 INSTALLATION................................................................................. 37
3.1 Locating the Converter Switch Unit .................................................. 37
3.2 MC14-TRAY for Rack Mounting of CSG14 Series Switches ......... 39
3.3 MC14-TR+PS9 and X2 for Rack Mounting Media Converters........ 40
3.4 DIN-Rail mounting option................................................................. 42
3.5 Power Requirements, CSG14 Series Switches .................................. 43
CSG14 Series Gigabit Converter Switch Installation and User Guide (05/08)
v
www GarrettCom com
..
3.6 Powering the CSG14H and CSG14P (DC internal) .......................... 45
3.7 CSG14H and P Series , DC-powered, Installation............................. 47
3.8 Connecting Ethernet Media ............................................................... 48
3.8.1 Connecting Twisted Pair............................................................ 50
3.8.2 Connecting Fiber Optic LC-type, “Small Form factor (SFF)”... 51
3.8.3 Connecting Fiber Optic SC-type, "Snap-In".............................. 51
3.8.4 Connecting Single-Mode Fiber Optic........................................ 52
3.8.5 Power Budget Calculations for CSG14 Series, Fiber Media..... 52
3.8.6 Connections to NICs which support Auto-Neg RJ-45 ports...... 55
4.0 OPERATION....................................................................................... 56
4.1 Triple-Speed Functionality, and Switching ....................................... 56
4.2 Auto-cross (MDIX), Auto-negotiation and Speed-sensing................ 58
4.3 Dual LEDs, Front-panel and Side-panel............................................ 60
5.0 TROUBLESHOOTING...................................................................... 61
5.1 Before Calling for Assistance............................................................ 62
5.2 When Calling for Assistance ............................................................. 64
5.3 Return Material Authorization (RMA) Procedure............................. 65
CSG14 Series Gigabit Converter Switch Installation and User Guide (05/08)
vi
www GarrettCom com
..
5.4 Shipping and Packaging Information................................................. 67
APPENDIX A: WARRANTY INFORMATION......................................... 69
Revisions
Rev A 05/08: Initial release of this user manual for CSG14 Converter Switches
GarrettCom, Inc. reserves the right to change specifications, performance characteristics and/or
model offerings without notice.
CSG14 Series Gigabit Converter Switch Installation and User Guide (05/08)
1
www GarrettCom com
..
1.0 SPECIFICATIONS
1.1 Technical Specifications
Ports Performance
Data Rate: 10Mbps, 100Mbps, 1000Mbps
Network Standards
1000Mb: Ethernet IEEE 802.3ab and 802.3z
1000Base-T, -SX, -LX and -ZX
100Mb: Ethernet IEEE 802.3u, 100BASE-TX, 100BASE-FX
10 Mb: Ethernet IEEE 802.3, 10BASE-T
Auto-sensing for speed: IEEE 802.3z
Packet-Processing Between Domains
Filter and Forward Rate from 1000Mbps ports: 1,488,000 pps max.
Filter and Forward Rate from 100Mbps ports: 148,800 pps max.
Filtering and Forwarding Rate from 10 Mbps ports: 14,880 pps max.
Processing type: Store and Forward, non-blocking
Auto-learning: 1K-address table
Address buffer age-out time: 300 sec.
CSG14 Series Gigabit Converter Switch Installation and User Guide (05/08)
2
www GarrettCom com
..
Packet buffers memory: 64KB, dynamically shared on all domains
Latency (not including packet time): 100 to 10 Mbps: 5μs
10 to 100Mbps: 15μs
Path Delay Value: 50 BT on all ports
Maximum Ethernet Segment (or Domain) Lengths
10BASE-T (Unshielded twisted pair) 100 m (328 ft)
10BASE-FL, Fiber optic 2 km (6,562 ft)
10BASE-FL, Single-mode Fiber optic 10 km (32,810ft)
100BASE-TX (CAT 5 UTP) 100 m (328 ft)
100BASE-FX, half-duplex: (multi-mode) 412 m (1350 ft)
100BASE-FX, full duplex: (multi-mode) 2 km (6,562 ft)
100BASE-FX, half-duplex: (single-mode) 412 m (1350 ft)
100BASE-FX, full duplex: (single-mode) 20 km (65,620 ft)
100BASE-FX, full duplex: (single-mode, long reach) 40 km (131,240 ft)
1000BASE-T (CAT5E OR HIGHER recommended) 100 m (328 ft)
1000BASE-SX, full duplex, multi-mode (62.5um) 220 m (722 ft)
1000BASE-SX, full duplex, multi-mode (50um) 550 m (1804 ft)
1000BASE-LX, full duplex, single-mode (9um) 5 km (16404 ft)
