Garmin NuLink! LIVE 2390 Manual de instrucciones

nüLink!™

2320/2340/2390

quick start manual

2 nüLink!2320/2340/2390QuickStartManual

Getting Started

‹

WARNING

See the Important Safety and Product

Information guide in the product

box for product warnings and other

important information.

When using your device for the rst

time, complete these tasks.

1. Connect the device to vehicle

power (page 3).

2. Mount the device (page 4).

3. Register the device (page 5).

4. Check for updates:

• Software updates (page 5).

• Free map update (page 6).

5. Download the full owner’s manual

(page 6).

Power Cables

The device comes with two power

cables. Each connector ts in only the

matching port.

• The vehicle power cable

➊

connects the mount to vehicle

power. The vehicle power cable

has a right-angle connector.

• The micro-USB cable

➋

connects

the device to a computer. A “B”

is inscribed on the head of the

micro-USB cable.

➊

➋

nüLink!2320/2340/2390QuickStartManual 3

Connecting the Device

to Vehicle Power

‹

WARNING

This product contains a lithium-ion

battery. To prevent the possibility of

personal injury or product damage

caused by battery exposure to

extreme heat, remove the device from

the vehicle when exiting or store it

out of direct sunlight.

Before you use your device on

battery power, you should charge it.

1. Fit the bottom of your device into

the mount.

2. Tilt your device back until it

snaps into place.

3. Plug the vehicle power cable

➊

into the USB connector

➋

on the

mount or device.

➊

➋

4. Plug the other end of the vehicle

power cable into a power outlet in

your vehicle.

4 nüLink!2320/2340/2390QuickStartManual

After the device has been connected

to vehicle power, the following

occurs.

• The device turns on.

• The device acquires satellite

signals. When at least one of the

bars is green, your device has

acquired satellite signals.

NOTE: The device may need a

clear view of the sky to acquire

satellite signals.

• The device charges as you drive.

in the status bar indicates the

status of the internal battery.

Mounting Your Device

Notice

Before mounting the device, see

the Important Safety and Product

Information guide for information

about laws pertaining to windshield

mounting.

1. Remove the clear plastic from the

suction cup.

2. Clean and dry your windshield

and the suction cup with a lint-free

cloth.

3. Press the suction cup to the

windshield.

4. While pressing, ip the lever back

toward the windshield.

5. Snap the mount

➊

onto the

suction cup arm

➋

➊➋

About myDashboard

You can use myDashboard to register

your device, check for software and

map updates, access product manuals

nüLink!2320/2340/2390QuickStartManual 5

and support, and more.

Setting Up myDashboard

1. Connect the micro-USB cable

➊

to the micro-USB port

➋

on the

device (page 2).

➊

➋

2. Connect the micro-USB cable to

the USB port on your computer.

3. Go to www.garmin.com

/dashboard.

4. Follow the on-screen instructions.

Registering the Device

1. From myDashboard, click

2. Follow the on-screen instructions.

3. Keep the original sales receipt, or

a photocopy, in a safe place.

Updating the Software

1. Open myDashboard (page 5).

2. Under Software Updates, click

Update Now.

3. Follow the on-screen instructions.

nüMaps Guarantee™

If you register the device at http

://my.garmin.com within 60 days of

acquiring satellites while driving,

your device could be eligible for one

free map update. Go to www.garmin

.com/numaps for terms and

conditions.

Updating Maps

1. Open myDashboard (page 5).

2. Register the device (page 5).

3. Under Map Updates, click Update

Now.

4. Follow the on-screen instructions.

6 nüLink!2320/2340/2390QuickStartManual

Downloading the Owner’s

Manual

The owner’s manual for your device

is available on the Garmin Web site.

1. Open myDashboard (page 5).

2. Click Manuals.

3. Click Download next to the

manual you want.

4. Save the le to your computer.

Device Overview

➊

➋

➊

Power key

➋

microSD

™

card slot

Turning Off the Device

1. Hold the Power key for four

seconds.

2. Select Off.

Using the Main Menu

➊

➋ ➌

➍ ➐ ➑➎ ➏

• Select

➊

to select a

transportation mode.

• Select

➋

to nd a destination.

• Select

➌

to view the map.

• Select

➍

to stop a route.

• Select

➎

to detour a route

• Touch

➏

to make a call when

connected to a compatible

mobile phone.

• Touch

➐

to adjust the volume.

nüLink!2320/2340/2390QuickStartManual 7

• Touch

➑

to open the menu of

tools and settings.

About Points of Interest

The detailed maps loaded in your

device contain points of interest,

such as restaurants, hotels, and auto

services.

Finding a Point of Interest by

Category

1. From the main menu, select

Where To? > Points of Interest.

2. Select a category.

3. If necessary, select a subcategory.

4. Select a destination.

5. Select Go!.

You can select > Save on

this page to save the location to

a Favorites folder on the device.

Use the Favorites folder to save

the location of your workplace,

home, and other common

destinations.

6. If necessary, select an option.

• Select Drive to calculate a

route you will navigate by

driving.

• Select Walk to calculate a

route you will navigate by

walking.

• Select Public Transit to

calculate a route that combines

public transit and walking.

NOTE: You must have

cityXplorer™ maps loaded to

navigate using public transit.

Go to www.garmin.com to

purchase cityXplorer maps.

7. If necessary, select a route.

8 nüLink!2320/2340/2390QuickStartManual

Your Route on the Map

Notice

The speed limit icon feature is for

information only and does not replace

the driver’s responsibility to abide

by all posted speed limit signs and to

use safe driving judgment at all times.

Garmin will not be responsible for

any trafc nes or citations that you

may receive for failing to follow all

applicable trafc laws and signs.

Your route is marked with a magenta

line on the map. If you depart from

the original route, your device

recalculates the route. A speed limit

icon could appear as you travel on

major roadways.

Using the Map Functions

➊ ➋

➌ ➍

➎➏

➐➑➒ ➓

• Select

➊

to view the next turn.

If a view of a junction exists,

the junction view appears.

• Select

➋

to view the turn list.

• Select

➌

to view trafc

information.

• Select

➍

to zoom in and out.

• Select

➎

to view the Where

Am I? page.

• Select and drag

➏

to view a

different area of the map.

• Select

➐

to return to the Main

menu.

• Select

➑

to change the data

eld.

nüLink!2320/2340/2390QuickStartManual 9

• Select

➒

to view trip

information.

• Select

➓

to change the speed

limit if the speed limit shown

on the map is incorrect or to

report a safety camera.

About the Main Menu

Toolbar

Icon Description

GPS signal status. Select

and hold to view satellite

information.

Bluetooth

technology

status (appears when

connected to a compatible

device.) Select to change

Bluetooth settings.

Transportation mode

indicator. Select to choose a

transportation mode.

Current time. Select to

change time settings.

Icon Description

myGarmin

™

messages.

Select to check messages.

Current temperature. Select

to view weather information.

nüLink!

™

services signal

status.

Battery status.

Using myTrends

As you drive with the device on,

myTrends™ gathers information that

allows the device to predict when you

are traveling to a common destination,

like your workplace or home. When

myTrends is activated, the destination

and estimated time of travel will

appear in the navigation bar on the

map. Trafc information may also

appear in the navigation bar.

myTrends only works for locations

that are saved as Favorites (page 7).

10 nüLink!2320/2340/2390QuickStartManual

When myTrends information

appears in the navigation bar,

select the navigation bar to view

route information.

Disabling myTrends

From the main menu, select

Tools > Settings > Navigation

> Automobile > nüRoute >

myTrends > Disabled.

About nüLink! Services

nüLink! services may not be available

in all areas or countries.

Your device includes a basic nüLink!

subscription, which is activated when

you rst turn on your device. nüLink!

services allow you to receive current

information, such as weather updates,

fuel prices, and ight times.

To use these features, you must have

a current nüLink! subscription, and

your device must be receiving a

nüLink! signal, represented by in

the toolbar.

For more information on nüLink!

services, select Tools > Help, or

refer to the nüLink! 2320/2340/2390

Owner’s Manual (page 6).

Purchasing Additional nüLink!

Services

Select Tools > nüLink! Store.

About Trafc

Notice

Garmin is not responsible for the

accuracy or timeliness of the trafc

information.

Trafc information may not be

available in all areas or countries.

When you are receiving trafc

information, a trafc icon appears in

the upper-left corner of the map page.

The trafc icon ( ) changes color to

indicate the severity of trafc

Otros manuales para nuLink! LIVE 2390

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de GPS de Garmin

Garmin

Garmin G300 for Cessna SkyCatcher Manual de usuario

Garmin

Garmin Montana 700 Series Manual de usuario

Garmin

Garmin Oregon 750 Manual de instrucciones

Garmin

Garmin GNC 420 Instrucciones de instalación y funcionamiento

Garmin

Garmin 300XL Manual de usuario

Garmin

Garmin GPSMAP 79S Manual de usuario

Garmin

Garmin Colorado Series Manual de usuario

Garmin

Garmin DEZL OTR800 Manual de usuario

Garmin

Garmin GPS 19x HVS Manual de usuario

Garmin

Garmin GTN 725 Manual

Garmin

Garmin ECHOMAP ULTRA 100 Series Manual de instrucciones

Garmin

Garmin GPSMAP 66i Manual de usuario

Garmin

Garmin nuvi 205W-Series Manual de usuario

Garmin

Garmin GPS 92 Manual de usuario

Garmin

Garmin nuvi 680 Manual de usuario

Garmin

Garmin GPSMAP 3205 - Marine GPS Receiver Manual de usuario

Garmin

Garmin affordable car navigation Manual de usuario

Garmin

Garmin Oregon 450 Guía de referencia

Garmin

Garmin GPS 17HVS - Receiver Module Guía de referencia

Garmin

Garmin Personal Navigator GPS 100AVD Manual de usuario

Garmin

Garmin GPSMAP 86 Series Manual de usuario

Garmin

Garmin GPSMAP GPSMAP 196 Manual de usuario

Garmin

Garmin approach X40 Manual de usuario

Garmin

Garmin Astro 320 Manual de instrucciones

Manuales populares de GPS de otras marcas

Raven

Raven Cruizer II Manual

Hama

Hama 53118 Manual de usuario

Jigabot

Jigabot EX Manual de usuario

Pointer

Pointer Cellocator CelloTrack XT LTE Guía de instalación

Queclink

Queclink GV55LITE Manual de usuario

Voxson

Voxson Voxtrack GPS500 Manual de instrucciones

Starcom Systems

Starcom Systems Kylos Compact Manual de usuario

Cobra

Cobra Marine MC 600Ci Manual de usuario

Cellocator

Cellocator CelloTrack T Manual de usuario

Enfora

Enfora Mini-MT GSM2228UG001 Manual de usuario

Magellan

Magellan eXplorist 100 Manual de usuario

LTE

LTE G50B Manual de usuario

SkyGolf

SkyGolf SkyCaddie SG1 Manual de usuario

Kenwood

Kenwood DNN9330BT Manual de usuario

Safelet

Safelet Indra Manual de usuario

Bushnell

Bushnell 360100 Manual de usuario

Geneq

Geneq SXBlue Manual de usuario

ORIGO

ORIGO ED308 Manual de usuario

Garmin nuLink! LIVE 2390 Manual de instrucciones

Manuales populares de GPS de otras marcas
