GMA 240

Pilot’s Guide

This manual reﬂects the operation of GMA 240 units with mod level 0 or later.

Some differences in operation may be observed when comparing the information

in this manual to earlier or later Mod status levels.

Garmin International, Inc., 1200 East 151st Street, Olathe, Kansas 66062, U.S.A.

Tel: 913/397.8200 Fax: 913/397.8282

Garmin AT, Inc., 2345 Turner Road SE, Salem, OR 97302, U.S.A.

Tel: 503/391.3411 Fax 503/364.2138

Garmin (Europe) Ltd, Liberty House, Bulls Copse Road, Hounsdown Business Park,

Southampton, SO40 9RB, U.K.

Tel: 44/0870.8501241 Fax: 44/0870.8501251

Garmin Corporation, No. 68, Jangshu 2nd Road, Shijr, Taipei County, Taiwan

Tel: 886/02.2642.9199 Fax: 886/02.2642.9099

Web Site Address: www.garmin.com

Except as expressly provided herein, no part of this manual may be reproduced,

copied, transmitted, disseminated, downloaded or stored in any storage medium,

for any purpose without the express written permission of Garmin. Garmin hereby

grants permission to download a single copy of this manual and of any revision to

this manual onto a hard drive or other electronic storage medium to be viewed for

personal use, provided that such electronic or printed copy of this manual or revision

must contain the complete text of this copyright notice and provided further that

any unauthorized commercial distribution of this manual or any revision hereto is

strictly prohibited.

Garmin® is a registered trademark of Garmin Ltd. or its subsidiaries. These

trademarks may not be used without the express permission of Garmin.

June, 2008 190-00917-00 Rev. A Printed in the U.S.A.

LIMITED WARRANTY

This Garmin product is warranted to be free from defects in materials or

workmanship for one year from the date of purchase. Within this period, Garmin

will, at its sole option, repair or replace any components that fail in normal use.

Such repairs or replacement will be made at no charge to the customer for parts

and labor, provided that the customer shall be responsible for any transportation

cost. This warranty does not cover failures due to abuse, misuse, accident, or

unauthorized alterations or repairs.

THE WARRANTIES AND REMEDIES CONTAINED HEREIN ARE EXCLUSIVE AND IN

LIEUOFALLOTHERWARRANTIESEXPRESSORIMPLIED ORSTATUTORY,INCLUDING

ANY LIABILITY ARISING UNDER ANY WARRANTY OF MERCHANTABILITY OR

FITNESS FOR A PARTICULAR PURPOSE, STATUTORY OR OTHERWISE. THIS

WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, WHICH MAY VARY FROM STATE

TO STATE.

IN NO EVENT SHALL GARMIN BE LIABLE FORANY INCIDENTAL,SPECIAL, INDIRECT

OR CONSEQUENTIAL DAMAGES, WHETHER RESULTING FROM THE USE, MISUSE,

OR INABILITY TO USE THIS PRODUCT OR FROM DEFECTS IN THE PRODUCT. Some

states do not allow the exclusion of incidental or consequential damages, so the

above limitations may not apply to you.

Garmin retains the exclusive right to repair or replace the unit or software, or to

offer a full refund of the purchase price, at its sole discretion. SUCH REMEDY SHALL

BE YOUR SOLE AND EXCLUSIVE REMEDY FOR ANY BREACH OF WARRANTY.

To obtain warranty service, contact your local GarminAuthorized Service Center. For

assistance in locating a Service Center near you, visit the GarminWeb site at “http://

www.garmin.com” or contact Garmin Customer Service at 800-800-1020.

CAUTION: Incorrect aircraft wiring could short the left channel or

both channels to ground if a monaural headset is plugged into

the stereo jacks. If wired incorrectly, fail-safe operation will not

work.

CAUTION: If monaural headsets are plugged into stereo jacks,

power supply current increases, which may cause power supply

fuse damage.

190-00917-00 Rev. A

Garmin GMA 240 Pilot’s Guide

GMA 240 Audio Panel

Pilot’s

Squelch

Knob

Copilot/

Passenger/

Music Volume

Knob

Copilot/

Passenger

Squelch Knob

ON/OFF

and Pilot’s

Volume

Knob

Monitor Mute

Key

Music 1 or 2

Select Key Transceiver

Selection Keys

Com Receiver

Keys Nav Receiver and

AUX Audio Keys

Music On/

Off Key

Intercom

Mute Key and

Radio Mute

Key

Pilot ICS

Isolation

Key

Telephone

Key Music Audio

or Telephone

Input Jack

Volume/Squelch: Rotating the Pilot Volume Knob (left small

knob) controls the ON and OFF function (Full CCW detent is

OFF). The large left knob controls Pilot squelch.

Pulling the right volume knob (small knob) controls music

volume, pushing in controls Copilot and passenger volume.

The large right knob controls Copilot and passenger squelch.

190-00917-00 Rev. A

Garmin GMA 240 Pilot’s Guide

GMA 240 Audio Panel

COM receiver keys. Pressing a COM receiver key selects the receiver,

which is heard in addition to the selected transceiver. Pressing again

deselects the receiver.

Transceiver selection keys. Pressing a COM transceiver key selects the

COM transmitter and associated receiver. One of the transceivers is

always selected as active.

Monitor Mute key. Mutes all other monitored receivers when the active

transceiver receives audio.

Telephone key. Pressing the TEL Key selects the Telephone interface.

Pressing again deselects the telephone.

NAV receiver and AUX keys. Pressing a key selects the Nav receiver or

AUX audio input. Pressing again deselects the audio.

Master Music key. Pressing the MUSIC Key allows the selected music

input to be heard. Pressing again deselects music.

Music Source 1 or 2 selection key and Music Source Annunciators.

Selects Music input 1 or 2. LED 1 or 2 iluminates to indicate which input

is selected.

Music 1/TEL jack. External music device or telephone input.

ICS Key. When selected, music is muted during Intercom operation.

RADIO Key. When selected, music is muted during reception of selected

aircraft radios.

190-00917-00 Rev. A

Garmin GMA 240 Pilot’s Guide

GMA 240 Audio Panel

FEATURES AND OPERATION

The Garmin GMA 240 is a headphones only audio control panel. Pushbutton

keys control audio selection of COM, NAV, telephone (TEL), and intercom.

Two AUX inputs are available for additional avionics or audio devices.

LED annunciators indicate when a key function is selected. Annunciator

brightness is adjusted automatically by photocell dimming. LED-illuminated

key brightness is adjusted by the radio dimming bus control.

In case power is interrupted or the unit is turned off, a fail-safe circuit

connects the Pilot’s headset, microphone, and PTT directly to COM 1 and the

fail-safe alert audio, such as an autopilot disconnect tone.

In addition to radio squelch circuitry, MASQ

(Master Avionics Squelch)

processing further reduces ambient noise from the avionics inputs.

Upon installation, the unit may be conﬁgured in various ways depending

on the aircraft type and the needs of the Pilot. See the conﬁguration list at the

end of this manual. Contact a Garmin-authorized service center for details

and assistance in altering the conﬁguration settings.

MICROPHONES

The GMA 240 Audio Panel can accept up to four (4) microphone inputs,

allowing for a two-person crew and up to two (2) passenger intercom

stations in the aircraft. A push-to-talk (PTT) switch must be pressed to

transmit on a selected Transceiver. The passengers cannot transmit over the

active COM radio, even if equipped with a PTT switch.

Each microphone input has a dedicated VOX circuit to ensure that only

the active microphone is heard when squelch is broken.

190-00917-00 Rev. A

Garmin GMA 240 Pilot’s Guide

GMA 240 Audio Panel

MONO/STEREO HEADSETS

The unit can accommodate up to four (4) headsets (Pilot, Copilot and up

to two (2) passengers). The use of stereo headsets is highly recommended.

If monaural headsets are plugged into stereo jacks, power supply fuses may

be damaged.

When wired correctly, the use of a monaural headset in a stereo jack

shorts the right headset channel to ground. Anyone listening on a monaural

headset hears only the left channel in both ears. If a monaural headset is

used at one of the passenger positions, anyone else listening on a stereo

headset hears audio in the left ear only, unless their headset has a mono/

stereo switch set to mono.

POWER ON/OFF

The GMA 240 may be powered ON and OFF with the avionics master

switch. The unit may also be turned ON and OFF with the Pilot ICS Volume

Knob. Rotate the knob clockwise out of the detent to turn ON. Rotate the

knob counterclockwise into the detent to turn OFF.

During power-up, the unit undergoes a self-test, illuminating all panel

annunciator lights for about two (2) seconds. Once the self-test is complete,

the unit is ready for use with the same keys selected as when the system was

last powered OFF.

TRANSCEIVERS

Pressing

COM1 MIC

COM2 MIC

Key selects the transmitter and receiver

audio for the selected transceiver source. The active COM audio is always

heard on the Pilot headphones. Audio level is controlled by the selected

COM radio volume control.

Either audio source can be selected independently by pressing the

COM1

COM2

receiver keys. When selected this way, they remain active as audio

sources regardless of which transceiver has been selected for microphone

use.

190-00917-00 Rev. A

Garmin GMA 240 Pilot’s Guide

GMA 240 Audio Panel

When a microphone is keyed, the active transceiver’s MIC key LED blinks

approximately once per second indicating the PTT is pressed.

RECEIVERS

Pressing the

NAV1

NAV2

AUX1

, or

AUX2

Key selects the receiver audio

for the selected source. Each audio source can be selected independently by

pressing the appropriate

receiver keys. They remain active as audio sources

until deselected.

Press the MON MUTE Key to mute all monitored receiver audio when

the active transceiver is receiving audio.

INTERCOM

The GMA 240 includes a four-position intercom system (ICS) with

electronic cabin noise de-emphasis and two stereo music inputs. Two

volume controls, one for the Pilot and one for a combined Copilot/passenger

control, set intercom audio level. Music volume is controlled by pulling

the right side (Copilot/passenger) volume control knob and turning it for

the desired audio level.

ICS squelch is adjusted by turning the Pilot side and Copilot/passenger

side

knob. Turning either knob clockwise increases the squelch threshold

level, turning counterclockwise decreases the level.

The intercom system provides two modes of isolation, PILOT and ALL,

controlled by pressing the PILOT ISO Key. In Pilot mode, (PILOT ISO

annunciator is illuminated) the Pilot is isolated from all other occupants of

the aircraft. In ALL mode, (PILOT ISO annunciator is off) everyone hears

all occupants of the aircraft.

The unit can also be conﬁgured for Crew Isolation in place of Pilot

Isolation. When conﬁgured for Crew Isolation, the Pilot and Copilot can

communicate with each other while the passengers are able to communicate

only with each other. In ALL mode, there is no isolation and every occupant

can communicate with every other occupant.

190-00917-00 Rev. A

Garmin GMA 240 Pilot’s Guide

GMA 240 Audio Panel

Press the ICS Key to mute the music during intercom operation.

Press the PILOT ISO Key for Pilot or Crew isolation, depending on

conﬁguration.

Mode Pilot Hears Copilot Hears Passenger Hears

ALL

(PILOT ISO not

Selected)

Selected Radios,

Alerts, Telephone,

Pilot, Copilot,

Passengers, Music

Selected Radios,

Alerts, Telephone,

Copilot, Pilot,

Passengers, Music

Selected Radios,

Alerts, Telephone,

Pilot, Copilot,

Passengers, Music

PILOT (PILOT

ISO Selected)

Selected Radios,

Alerts, Telephone,

Pilot, Music*

Copilot,

Passengers,

Music

Copilot,

Passengers,

Music

CREW (When

Crew Isolation

is conﬁgured

and PILOT ISO

is selected)

Selected Radios,

Alerts, Telephone,

Pilot, Copilot,

Music*

Selected Radios,

Alerts, Telephone,

Copilot, Pilot,

Music*

Passengers,

Music

*A conﬁguration option can allow music for these positions.

ICS Isolation Modes & Telephone Distribution

TELEPHONE

The GMA 240 provides a full-duplex telephone interface. Press the

TEL Key to activate telephone operation. When the telephone is active,

operation depends on the ICS mode. See the ICS Isolation Modes &

Telephone Distribution table. Telephone communication is much like using

the intercom, allowing both parties to talk at once.

190-00917-00 Rev. A

Garmin GMA 240 Pilot’s Guide

GMA 240 Audio Panel

ENTERTAINMENT INPUTS

The GMA 240 provides two stereo entertainment inputs; MUSIC 1 and

MUSIC 2. A MUSIC 1/TEL jack is also located on the GMA 240 front panel.

The MUSIC 1/TEL jack can accept music or telephone sources.

The MUSIC 1 and MUSIC 2 rear inputs may be wired to either a stereo

phone jack in a convenient place, or to an audio device in a ﬁxed mount

(e.g. a GPSMAP 396 dock or a CD player). These inputs are compatible

with popular portable entertainment devices such as MP3 and CD players.

The headphone outputs of these devices are plugged into the MUSIC 1 or

MUSIC 2 jacks.

Press the MUSIC Key to enable the selected music input to be heard.

Press again to disable music audio.

Press the MUSIC 1-2 Key to select either the MUSIC 1 or MUSIC 2 input.

Annunciators above the key indicate which music source is selected.

Either music source may be selected. The selected source is heard by

all unless intercom isolation removes the audio. A music source plugged

into the GMA 240 front panel MUSIC 1 jack will bypass the MUSIC 1 rear

input.

MUSIC is soft-muted under certain conditions. Soft-muting refers to the

temporary reduction of music volume and a gradual return to its original

level. This muting occurs during alerts (unless conﬁgured otherwise),

during selected radio reception if the RADIO Key is selected, during

intercom operation if the ICS Key is selected, and any time the TEL Key is

selected.

Otros manuales para Fishfinder 240 Blue

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de GPS de Garmin

Garmin

Garmin GPSMAP 62stc Manual de usuario

Garmin

Garmin GPS 500 Manual de usuario

Garmin

Garmin Street Pilot 2720 Manual de usuario

Garmin

Garmin aera 500 Manual de instrucciones

Garmin

Garmin Apollo CNX80 Manual de usuario

Garmin

Garmin GPSMAP 696 Manual de usuario

Garmin

Garmin GNS 420AW Manual de usuario

Garmin

Garmin GPSMAP 76S Manual de usuario

Garmin

Garmin Etrex Legend - GPS Receiver Instrucciones de funcionamiento

Garmin

Garmin Zumo 550 - Motorcycle GPS Receiver Manual de usuario

Garmin

Garmin GPSMAP 76Cx Guía de inicio rápido

Garmin

Garmin GHP 20 Marine Autopilot System for... Manual de usuario

Garmin

Garmin DEZLCAM 785 Manual de usuario

Garmin

Garmin GPS 35 LP Manual

Garmin

Garmin GPS 16A Manual de usuario

Garmin

Garmin 3750 Manual de usuario

Garmin

Garmin LIVE 1695 Manual de usuario

Garmin

Garmin GPSMAP 78 series Manual de usuario

Garmin

Garmin GPSMAP 66 Manual de usuario

Garmin

Garmin 400W Series Instrucciones de instalación y funcionamiento

Garmin

Garmin GPSMAP 800 Series Manual de usuario

Garmin

Garmin eTrex Venture Cx, Legend Cx Manual de usuario

Garmin

Garmin Montana 650 Manual de usuario

Garmin

Garmin nüvi 760 Manual de usuario

Manuales populares de GPS de otras marcas

Raven

Raven Cruizer II Manual

Hama

Hama 53118 Manual de usuario

Jigabot

Jigabot EX Manual de usuario

Pointer

Pointer Cellocator CelloTrack XT LTE Guía de instalación

Queclink

Queclink GV55LITE Manual de usuario

Voxson

Voxson Voxtrack GPS500 Manual de instrucciones

Starcom Systems

Starcom Systems Kylos Compact Manual de usuario

Cobra

Cobra Marine MC 600Ci Manual de usuario

Cellocator

Cellocator CelloTrack T Manual de usuario

Enfora

Enfora Mini-MT GSM2228UG001 Manual de usuario

Magellan

Magellan eXplorist 100 Manual de usuario

LTE

LTE G50B Manual de usuario

SkyGolf

SkyGolf SkyCaddie SG1 Manual de usuario

Kenwood

Kenwood DNN9330BT Manual de usuario

Safelet

Safelet Indra Manual de usuario

Bushnell

Bushnell 360100 Manual de usuario

Geneq

Geneq SXBlue Manual de usuario

ORIGO

ORIGO ED308 Manual de usuario
