GPSMAP®67

Quick Start Manual

Getting Started

WARNING

See the Important Safety and Product

Information guide in the product box for

product warnings and other important

information.

GPSMAP 67 Device Overview

GNSS antenna

Status LED

Power button

Buttons

USB port (under weather cap)

Flashlight

microSD® card slot (under weather

cap)

Mounting spine

Charging the GPSMAP 67 Device

NOTICE

To prevent corrosion, thoroughly dry

the USB port, the weather cap, and

the surrounding area before charging or

connecting to a computer.

NOTE: The device does not charge when

it is outside the approved temperature

range (page10).

1Lift the weather cap .

2 Quick Start Manual

2Plug the small end of the power

cable into the charging port on the

device.

3Plug the other end of the power cable

into a compatible AC power adapter.

4Plug the AC power adapter into a

standard wall outlet.

The device displays the current

battery charge level.

Turning On the Device

Press and hold .

Buttons

FIND

Select to open the search

menu.

Hold to mark your current

location as a man overboard

(MOB) location and activate

navigation.

MARK Select to save your current

location as a waypoint.

QUIT

Select to cancel or return to

the previous menu or page.

Select to scroll through the

main pages.

Quick Start Manual 3

ENTER

Select to choose options and

acknowledge messages.

Select to control the current

activity recording (from the

Map, Compass, Altimeter, and

Trip Computer pages).

Select to open the options

menu for the page that is

currently open.

Select twice to open the main

menu (from any page).

PAGE Select to scroll through the

main pages.

Select , , , or to select

menu options and move the

map cursor.

Select to zoom in on the map.

Select to zoom out on the map.

Adjusting the Backlight

1Select to open the status page.

2Use and to adjust the

brightness.

Acquiring Satellite Signals

It may take 30 to 60 seconds to acquire

satellite signals.

1Go outdoors to an open area.

2If necessary, turn on the device.

3Wait while the device searches for

satellites.

flashes while the device determines

your location.

in the status bar shows the

satellite signal strength.

When the device acquires satellite

signals, it automatically starts recording

your path as an activity.

GPS and Other Satellite Systems

Using GPSand another satellite system

together offers increased performance

in challenging environments and faster

position acquisition than using GPS only.

However, using multiple systems can

reduce battery life more quickly than

using GPS only.

Your device can use these Global

Navigation Satellite Systems (GNSS).

Multi-band systems use multiple

frequency bands and allow for

more consistent track logs, improved

positioning, improved multi-path errors,

and fewer atmospheric errors when using

the device in challenging environments.

4 Quick Start Manual

GPS: A satellite constellation built by the

United States.

GPS multi-band: A satellite constellation

built by the United States, using the

enhanced L5 signal.

GLONASS: A satellite constellation built

by Russia.

GALILEO: A satellite constellation built by

the European Space Agency.

GALILEO multi-band: A satellite

constellation built by the European

Space Agency, using the enhanced L5

signal.

QZSS multi-band: A satellite

constellation built by Japan, using the

enhanced L5 signal.

IRNSS (NavIC): A satellite constellation

built by India, using the enhanced L5

signal.

Turning On Expedition Mode

You can use expedition mode to prolong

the battery life. In expedition mode, the

screen shuts off, the device enters low

power mode, and the device collects

fewer GPS track points.

1Select Setup > Expedition Mode.

2Select an option:

• To enable the device to prompt

you to turn on expedition mode

when you turn off the device,

select Prompted.

• To automatically turn on

expedition mode after two

minutes of inactivity, select Auto.

• To never turn on expedition mode,

select Never.

In expedition mode, the green LED

flashes occasionally.

Connected Features

Connected features are available for

your GPSMAP 67 device when you

connect the device to a wireless network

or a compatible smartphone using

Bluetooth® technology. Some features

require you to install the Garmin Connect™

app or Garmin Explore™ app on your

smartphone. Go to garmin.com/apps for

more information.

Bluetooth sensors: Allows you to connect

Bluetooth compatible sensors, such

as a heart rate monitor.

Connect IQ™: Allows you to extend your

device features with widgets, data

fields, and apps using the Connect IQ

app.

Quick Start Manual 5

EPO Downloads: Allows you to download

an extended prediction orbit file to

quickly locate GPS satellites and

reduce the time it takes to get

an initial GPS fix using the Garmin

Connect app or when connected to a

Wi‑Fi® network.

BirdsEye imagery: Allows you to

download BirdsEye Satellite Imagery

directly to your device when

connected to a Wi‑Fi network.

Garmin Explore: The Garmin Explore app

syncs and shares waypoints, tracks,

and routes with your device. You

can also download maps to your

smartphone for offline access.

Live Geocache Data: Provides paid or

subscription-free services to view live

geocache data from www.geocaching

.com using the Garmin Connect app

or when connected to a Wi‑Fi network.

LiveTrack: Allows friends and family to

follow your activities in real time. You

can invite followers using email or

social media, allowing them to view

your live data on a Garmin Connect

tracking page.

Phone notifications: Displays phone

notifications and messages on your

GPSMAP 67 device using the Garmin

Connect app.

Software Updates: Allows you to receive

updates for your device software

using the Garmin Connect app or

when connected to a Wi‑Fi network.

Active Weather: Allows you to view

current weather conditions and

weather forecasts using the Garmin

Connect app or when connected to a

Wi‑Fi network.

Pairing a Smartphone with Your Device

1Bring your compatible smartphone

within 10m (33ft.) of your device.

2From the main menu on your device,

select Setup > Bluetooth.

3On your compatible smartphone,

enable Bluetooth technology, and

open the Garmin Connect or Garmin

Explore app.

4From the app, select the devices

option and follow the on-screen

instructions to pair your device.

Navigation

Waypoints

Waypoints are locations you record and

store in the device. Waypoints can mark

where you are, where you are going,

6 Quick Start Manual

or where you have been. You can add

details about the location, such as name,

elevation, and depth.

Creating a Waypoint

You can save your current location as a

waypoint.

1Select MARK.

2If necessary, select a field to make

changes to the waypoint.

3Select Save.

Navigating to a Waypoint

1Select FIND > Waypoints.

2Select a waypoint.

3Select Go.

By default, your route to the waypoint

appears as a straight, colored line on

the map.

Routes

A route is a sequence of waypoints or

locations that leads you to your final

destination.

Creating a Route

1Select Route Planner > Create Route

> Select First Point.

2Select a category.

3Select the first point in the route.

4Select Use.

5Select Select Next Point to add

additional points to the route.

6Select QUIT to save the route.

Navigating a Saved Route

1Select FIND > Routes.

2Select a route.

3Select Go.

By default, your route appears as a

straight, colored line on the map.

Recordings

Your device records your path as an

activity. Activities contain information

about points along your recorded path,

including time, location, and elevation for

each point.

Viewing the Current Activity

By default, the device automatically

starts recording your path as an activity

when it is turned on and has acquired

satellite signals. You can pause and start

recording manually.

1Select Recording Controls.

2Select and to view an option:

• To control the current activity

recording, select .

Quick Start Manual 7

• To view data fields for the activity,

select .

• To view the current activity on the

map, select .

• To view the elevation plot for the

current activity, select .

Map

represents your location on the map.

As you travel, moves and displays

your path. Depending on your zoom level,

waypoint names and symbols may appear

on the map. You can zoom in on the

map to see more detail. When you are

navigating to a destination, your route is

marked with a colored line on the map.

Changing the Map Orientation

1From the map, select MENU.

2Select Map Setup > Orientation.

3Select an option:

• Select North Up to show north at

the top of the page.

• Select Track Up to show your

current direction of travel at the

top of the page.

• Select Automotive Mode to show

an automotive perspective with

the direction of travel at the top.

Compass

When navigating, points to your

destination, regardless of the direction

you are moving. When points toward

the top of the electronic compass,

you are traveling directly toward your

destination. If points any other

direction, turn until it points toward the

top of the compass.

Calibrating the Compass

Before you can calibrate the electronic

compass, you must be outdoors, away

from objects that influence magnetic

fields, such as cars, buildings, or

overhead power lines.

The device has a 3-axis electronic

compass. You should calibrate the

compass after moving long distances or

experiencing temperature changes.

1From the compass, select MENU.

2Select Calibrate Compass > Start.

3Follow the on-screen instructions.

Trip Computer

The trip computer displays your current

speed, average speed, trip odometer,

and other helpful statistics. You can

customize the trip computer layout,

dashboard, and data fields.

8 Quick Start Manual

Device Information

Product Updates

On your computer, install Garmin

Express™ (www.garmin.com/express). On

your phone, install the Garmin Explore

app.

This provides easy access to these

services for Garmin® devices:

• Software updates

• Map updates

• Data uploads to Garmin Explore

• Product registration

Setting Up Garmin Express

1Connect the device to your computer

using a USBcable.

2Go to garmin.com/express.

3Follow the on-screen instructions.

Installing a Memory Card

You can install a microSD memory card,

up to 32 GB, for additional storage or

pre-loaded maps.

1Lift the weather cap on the side of the

device .

2Insert the memory card with the

gold contacts facing the front of the

device.

Attaching the Carabiner Clip

1Position the carabiner clip in the

slots on the mounting spine of the

device.

Quick Start Manual 9

2Slide the carabiner clip up until it

locks in place.

Removing the Carabiner Clip

Lift up on the bottom of the carabiner

clip, and slide the carabiner clip off

the mounting spine.

Specifications

Operating temper‐

ature range

From -20° to 60°C

(from -4° to 140°F)

Charging tempera‐

ture range

From 0° to 40°C

(from 32° to 104°F)

Compass-safe

distance 17.5cm (7in.)

Wireless

frequency/

protocol

2.4GHz @ 14.9dBm

nominal

Getting More Information

You can find more information about this

product on the Garmin website.

• Go to support.garmin.com for

additional manuals, articles, and

software updates.

• Go to buy.garmin.com, or contact

your Garmin dealer for information

about optional accessories and

replacement parts.

Getting the Owner's Manual

The owner's manual includes instructions

for using device features and accessing

regulatory information.

Go to garmin.com/manuals

/gpsmap67.

10 Quick Start Manual

Otros manuales para GPSMAP 67

Tabla de contenidos

Otros manuales de GPS de Garmin

Garmin

Garmin nuvi 350 Manual de usuario

Garmin

Garmin GPS 500 Manual de usuario

Garmin

Garmin GPSMAP 4008 - Marine GPS Receiver Guía de referencia

Garmin

Garmin GPSMAP 178 Sounder Manual de usuario

Garmin

Garmin Fishfinder 80 Manual

Garmin

Garmin approach X40 Manual de usuario

Garmin

Garmin GNC 530W Manual de usuario

Garmin

Garmin GPSMAP 620 Manual de usuario

Garmin

Garmin Skoda Navigation Manual de usuario

Garmin

Garmin nuvi 2457LMT Manual de usuario

Garmin

Garmin Edge 810 Manual de instrucciones

Garmin

Garmin ECHOMAP UHD2 5X Manual de usuario

Garmin

Garmin GPS 10x Manual

Garmin

Garmin GPS 92 Manual de usuario

Garmin

Garmin GPS Kit nuvi 510 Manual de instrucciones

Garmin

Garmin nuvi 150T series Manual de instrucciones

Garmin

Garmin GNS 480 Instrucciones de funcionamiento

Garmin

Garmin GPSMAP 2008 Manual de usuario

Garmin

Garmin StreetPilot III Manual de usuario

Garmin

Garmin StreetPilot 2730 Guía de configuración

Garmin

Garmin 500W Series Manual de usuario

Garmin

Garmin nuvi 200W Manual de usuario

Garmin

Garmin 400/500 Manual de usuario

Garmin

Garmin TACX NEO BIKE PLUS Manual de usuario

Manuales populares de GPS de otras marcas

Raven

Raven Cruizer II Manual

Hama

Hama 53118 Manual de usuario

Jigabot

Jigabot EX Manual de usuario

Pointer

Pointer Cellocator CelloTrack XT LTE Guía de instalación

Queclink

Queclink GV55LITE Manual de usuario

Voxson

Voxson Voxtrack GPS500 Manual de instrucciones

Starcom Systems

Starcom Systems Kylos Compact Manual de usuario

Cobra

Cobra Marine MC 600Ci Manual de usuario

Cellocator

Cellocator CelloTrack T Manual de usuario

Enfora

Enfora Mini-MT GSM2228UG001 Manual de usuario

Magellan

Magellan eXplorist 100 Manual de usuario

LTE

LTE G50B Manual de usuario

SkyGolf

SkyGolf SkyCaddie SG1 Manual de usuario

Kenwood

Kenwood DNN9330BT Manual de usuario

Safelet

Safelet Indra Manual de usuario

Bushnell

Bushnell 360100 Manual de usuario

Geneq

Geneq SXBlue Manual de usuario

ORIGO

ORIGO ED308 Manual de usuario
