Garmin 3700 Manual de instrucciones
nüvi
®
3700 series for Volvo
®
cars
quick start manual
June 2010 190-01265-01 Rev. A Printed in Taiwan
for use with these nüvi models:
3760, 3790
2 nüvi 3700 series for Volvo cars Quick Start Manual
Getting Started
‹
WARNING
See the Important Safety and Product
Information guide in the product
box for product warnings and other
important information.
When using your device for the rst
time, complete the following tasks.
1. Power your device (page 2).
2. Mount your device (page 3).
3. Congure your device (page 3).
4. Acquire satellites (page 4).
5. Understand the Main menu
(page 4).
Powering the Device
Connect your device to the vehicle
mount.
Your device charges as you drive.
Power Connection
Your device can be powered three
ways.
Vehicle mount
micro-B cable (page 11)
AC adapter
If you do not plan to use your device
while it is connected to a power
source, press the Power button to
lock the device. For more about
locking the device, go to page 10.
•
•
•
nüvi 3700 series for Volvo cars Quick Start Manual 3
Mounting Your Device
‹
WARNING
This product contains a lithium-ion
battery. To prevent the possibility of
personal injury or product damage
caused by battery exposure to
extreme heat, remove the device from
the vehicle when exiting or store it
out of direct sunlight.
1. Fit the bottom of your device into
the cradle.
2. Tilt your device back until it
snaps into place. Your device
should turn on automatically if
the vehicle is running. Follow the
on-screen instructions.
Conguring your Device
1. Connect your device to the
vehicle mount.
2. Your device should turn on
automatically if it is plugged in
and the vehicle is running.
3. Follow the on-screen instructions.
Front Cover
microSD
slot
Micro-B connector
Power button
Speaker
(on back cover)
Microphone
4 nüvi 3700 series for Volvo cars Quick Start Manual
Acquiring Satellites
The bars indicate satellite
strength.
1. Go outdoors to an open area, away
from tall buildings and trees.
2. If necessary, turn on your device.
Acquiring satellite signals can take
a few minutes. When at least one of
the bars is green, your device has
acquired satellite signals.
Main Menu
➊➋
➌ ➍
➐ ➑ ➒➎ ➏
➊
GPS satellite strength.
➋
Touch to select a transportation
mode.
➌
Touch to nd a destination.
➍
Touch to view the map.
➎
Touch to stop a route.
➏
Touch to detour a route.
➐
Touch to make a call when
connected to a compatible
mobile phone. Go to www
.garmin.com/bluetooth for
information.
➑
Touch to adjust the volume.
➒
Touch to open the menu of tools
and settings.
nüvi 3700 series for Volvo cars Quick Start Manual 5
Finding Points of Interest
1. From the Main menu, touch
Where To? > Points of Interest.
2. Select a category and a
subcategory, if necessary.
3. Select a destination.
4. Touch Go!.
Finding a Volvo®Dealership
1. From the Main menu, touch
Where To? > Volvo Dealers
2. Select a dealership.
3. Touch Go!.
Finding a Place by Spelling
the Name
1. From the Main menu, touch
Where To? > Points of Interest >
Spell Name.
2. Enter the name of your
destination.
3. Touch Done.
4. Select a destination.
5. Touch Go!.
Searching Near Another
Location
1. From the Main menu, touch
Where To? > > Near.
2. Select an option.
6 nüvi 3700 series for Volvo cars Quick Start Manual
Following Your Route
Your route is marked with a magenta
line on the map. If you depart from
the original route, your device
recalculates the route. A speed limit
icon could appear as you travel on
major roadways.
➍
➌
➐
➏
➎
➊ ➋
➑
➊
Touch to view the Next Turn
page. If a view of the junction
exists, the Junction View page
appears.
➋
Touch to view the Turn List
page.
➌
Touch to zoom in and out.
➍
Touch to return to the Main
menu.
➎
Touch to change the data eld.
➏
Touch to view the Where Am I?
page.
➐
Touch and drag the map to view
a different area of the map.
➑
Touch to view the Trip
Computer page.
Adding a Stop
Before you can add a stop, you must
be navigating a route.
1. Touch to return to the Main
menu.
2. Touch Where To?.
3. Search for the extra stop.
4. Select the stop from the search
results.
5. Touch Go!.
6. Touch Add to Current Route.
nüvi 3700 series for Volvo cars Quick Start Manual 7
Taking a Detour
Before you can take a detour, you
must be navigating a route.
1. Touch to return to the Main
menu.
2. Touch Detour.
If the route you are currently taking is
the only reasonable option, the device
might not calculate a detour.
Orienting the Screen
Rotate your device to view in
horizontal (landscape) or vertical
(portrait) mode.
NOTE: When mounted in landscape
mode, the device cannot be rotated
more than 90 degrees.
Adjusting the Screen
Brightness
1. Touch Tools > Settings > Display
> Brightness.
2. Touch and move the scroll bar to
adjust screen brightness.
About the Transportation
Modes
Automobile
Pedestrian
Bicycle
Your device has different
transportation modes for navigation.
Routing is calculated differently
based on your mode. For example,
in Pedestrian transportation mode
with cityXplorer™maps loaded, your
device calculates a route that uses a
combination of public transit options,
such as riding a bus or subway, and
walking. cityXplorer maps are not
included with your device.
8 nüvi 3700 series for Volvo cars Quick Start Manual
Go to www.garmin.com to purchase
cityXplorer maps.
Changing Your Transportation
Mode
1. From the Main menu, touch the
transportation mode icon.
2. Select a mode, and touch Save.
About Trafc
NOTICE
The trafc receiver and the device
must be in data range of an FM
station transmitting TMC data to
receive trafc information. Trafc
information is not available in all
areas or countries.
The FM Trafc Message Channel
(TMC) trafc receiver is an option for
your nüvi 3700. Contact your Volvo
dealer for more information.
If a severe trafc delay occurs on
your route, the device automatically
recalculates the route. The trafc
icon changes color to indicate the
severity of trafc conditions on your
route or on the road you are traveling.
For more information on FM Trafc,
go to www.garmin.com/volvo.
NOTE: Garmin and Volvo are not
responsible for the accuracy of the
information.
About Voice Command
NOTE: The Voice Command menu
is only active if your selected text
language is supported.
The Voice Command feature is
available on some nüvi models. Voice
Command allows you to use your
device by speaking the words you see
on the screen or by speaking certain
commands. The Voice Command
menu provides a list of available
commands to use.
nüvi 3700 series for Volvo cars Quick Start Manual 9
Activating Voice Command
Speak Voice Command.
The voice command menu
appears.
Tips for Using Voice
Command
Talk in a normal voice directed at
the device to speak a command
exactly as it appears on the screen.
Respond to voice prompts from
the device as needed.
Speak numbers to enter numbers.
Speak Exit to exit Voice
Command.
Navigating with Voice
Command
1. Speak your wakeup phrase.
The voice command menu
appears.
2. Speak Find by Name.
•
•
•
•
3. Listen for the voice prompt and
speak the name of the place.
The device repeats the name of the
place as it is searching.
A list of locations appears.
4. Speak the line number of the
location you want.
5. Speak Yes to navigate to the
location, or speak No to go back
to the list of found locations.
Hands-free Features
Hands-free calling is available on
some nüvi models.
Pairing Your Phone
Before you can pair, your phone and
the device must be turned on and near
each other.
1. Enable the Bluetooth®component
on your phone.
2. From the main menu, touch
Tools > Settings > Bluetooth.
10 nüvi 3700 series for Volvo cars Quick Start Manual
3. Touch the button below Bluetooth
> Enabled >OK.
4. Touch the button below Phone.
5. Touch OK.
6. Select your phone, and touch OK.
7. Enter the Bluetooth PIN (1234)
for your device in your phone.
Placing and Ending Calls
1. Touch > Dial.
2. Enter the number.
3. Touch Dial.
4. Touch > End Call to end a
call.
Answering a Call
When you receive a call, the
Incoming Call window opens.
1. Touch Answer.
TIP: Touch Ignore to stop your
phone from ringing.
2. Speak normally.
The internal microphone is in the
front of the device.
About Sleep Mode
You can use sleep mode to conserve
battery power when your device is
not in use. Sleep mode uses very little
power, and a battery charge lasts for
weeks when your device is in sleep
mode.
Press the Power button to put the
device in sleep mode.
Press and quickly release the
Power button and double-tap
to wake up the device.
Resetting the Device
You can reset your device if it stops
functioning.
Press and hold the power button
for 10 seconds.
•
•
