Garmin GLO sensor Manual de usuario

GLO™ GLONASS and GPS Sensor

Instructions

May 2012 190-01492-90_01 Printed in Taiwan

DRAFT







This product contains a lithium-ion battery.

See page 5 for important battery safety

information.

 With your thumbnail, slide the battery

cover release tab ➊ toward the end of

the sensor.

➌➊

➋

 Remove the battery cover ➋.

 Locate the metal contacts on the end

of the lithium-ion battery.

 Insert the battery ➌ so the metal

contacts on the battery align with

the metal contacts inside the battery

compartment.

 Press the battery down into place.

 Replace the battery cover by inserting

the tabs into the notches and pressing

the battery cover closed.

The release tab locks the cover in

place.



You can purchase a replacement battery

(010-10840-00) at http://buy.garmin.com.



You can use the sensor while you are

charging it.

 Plug the small end of the power cable

into the mini-USB connector on the

end of the sensor.

 Plug the other end of the power cable

into an appropriate source of power for

the cable type.

It takes about three hours to charge the

battery. A fully charged battery lasts about

12 hours.

DRAFT



 Hold to turn on the sensor.

 Turn on the other device and enable

the Bluetooth component.

You can refer to the device’s

documentation for specic instructions

about enabling Bluetooth wireless

technology.

 Bring the sensor within 30 feet (10

meters) of the mobile device.

 Using the mobile device, pair the

sensor with the mobile device.

The sensor PIN is .

The blue LED ashes slowly or is on solid

when the sensor is connected to the other

device.

If the sensor has not established a

Bluetooth connection for several minutes,

it turns off automatically.



 

Rapid ashing

blue

Power on, Bluetooth on

Solid blue Bluetooth connection to the

mobile device established,

satellites not acquired

Slow ashing

blue

Bluetooth connection to the

mobile device established,

satellites acquired



 

Flashing yellow/green Charging

Solid yellow/green Battery is charged

Flashing orange Low battery

Solid orange Faulty battery or

system error



 Ensure that the blue LED on the

sensor is slowly ashing blue or

on solid blue, indicating a wireless

connection.

 Place the sensor where it has a clear

view of the sky.

Acquiring satellite signals may take a few

minutes.

DRAFT





Set your mobile device’s auto-off and

other power management settings

to be suitable for your navigation

experience. Refer to the mobile device’s

documentation for instructions.



Made for iPod® touch (4th generation),

iPod touch (3rd generation), iPhone® 4S,

iPhone 4, iPhone 3GS, iPad® 2, and iPad.

"Made for iPod, iPhone, iPad” means

that an electronic accessory has been

designed to connect specically to iPod,

iPhone, or iPad, respectively, and has

been certied by the developer to meet

Apple performance standards. Apple is

not responsible for the operation of this

device or its compliance with safety and

regulatory standards. Please note that the

use of this accessory with iPod, iPhone, or

iPad may affect wireless performance.

The GLO sensor is also compatible with

many Android®, Windows® or Blackberry®

smartphones, tablets and notebook

computers.

When using the GLO GPS/GLONASS

sensor with an Android device, you

may need to use an application to allow

the sensor to properly communicate

with the Android system over Bluetooth

technology. The application will allow the

Android system to accept non-system (or

mock) GPS/GLONASS signals.



• Go to http://my.garmin.com.

• Keep the original sales receipt, or a

photocopy, in a safe place.



: Rugged, but not water-resistant

: Rechargeable lithium-ion

battery, 12 hours (typical use)

: 10 Hz, but not all mobile

devices support a 10 Hz update rate.

:

12–28 Vdc (*available in some packages)

: -4°F to 140°F

(-20°C to 60°C)

: 32°F to 113°F

(0°C to 45°C)

DRAFT



: -4°F to 140°F (-20°C to

60°C)



: -4°F to 68°F (-20°C to

20°C)











When installing the device in a vehicle,

place the device securely so it does not

obstruct the driver’s view of the road ➊ or

interfere with vehicle operating controls,

such as the steering wheel, foot pedals,

or transmission levers. Do not place

unsecured on the vehicle dashboard

➋. Do not place the device in front of or

above any airbag ➌.

➋

➌

➊



If these guidelines are not followed, the

batteries may experience a shortened life

span or may present a risk of damage to

the unit, re, chemical burn, electrolyte

leak, and/or injury.

• Do not leave the unit exposed to a

heat source or in a high temperature

location, such as in the sun in an

unattended vehicle. To prevent the

possibility of damage, remove the

device from the vehicle or store it out

of direct sunlight, such as in the glove

box.

• Do not use a sharp object to remove

the batteries.

• Do not puncture or incinerate the

device or battery.

• Keep the batteries away from children.

• Do not disassemble, puncture, or

damage the batteries.

• If using an external battery charger,

only use the Garmin accessory

approved for your product.

• Only replace the battery with the

correct replacement battery. Using

another battery presents a risk of

DRAFT

re or explosion. To purchase a

replacement battery, see your Garmin

dealer or the Garmin website.

• When storing the device for an

extended time, store within the

following temperature range: from -22°

to 140°F (from -30° to 60°C).

• Do not operate the device outside of

the following temperature range: from

14° to 140°F (from -10° to 60°C).

• Contact your local waste disposal

department to dispose of the device/

battery in accordance with applicable

local laws and regulations.



Use this unit only as a navigational aid.

Do not attempt to use the unit for any

purpose requiring precise measurement

of direction, distance, location, or

topography. This product should not be

used to determine ground proximity for

aircraft navigation.



Information about Garmin’s product

recycling program and WEEE, RoHS,

REACH, and other compliance programs

can be found at www.garmin.com

/aboutGarmin/environment.



Hereby, Garmin, declares that this

product is in compliance with the

essential requirements and other relevant

provisions of Directive 1999/5/EC. To view

the full Declaration of Conformity, go to

www.garmin.com/compliance.



This device complies with part 15 of the

FCC Rules. Operation is subject to the

following two conditions: (1) this device

may not cause harmful interference,

and (2) this device must accept any

interference received, including

interference that may cause undesired

operation.

This equipment has been tested and

found to comply with the limits for a

Class B digital device, pursuant to

part 15 of the FCC rules. These limits

are designed to provide reasonable

protection against harmful interference in

a residential installation. This equipment

generates, uses, and can radiate radio

frequency energy and may cause harmful

DRAFT

interference to radio communications if

not installed and used in accordance with

the instructions. However, there is no

guarantee that interference will not occur

in a particular installation. If this equipment

does cause harmful interference to radio

or television reception, which can be

determined by turning the equipment off

and on, the user is encouraged to try to

correct the interference by one of the

following measures:

• Reorient or relocate the receiving

antenna.

• Increase the separation between the

equipment and the receiver.

• Connect the equipment into an outlet

that is on a different circuit from the

GPS unit.

• Consult the dealer or an experienced

radio/TV technician for help.

This product does not contain any user-

serviceable parts. Repairs should only be

made by an authorized service center.

Unauthorized repairs or modications

could result in permanent damage to the

equipment, and void your warranty and

your authority to operate this device under

Part 15 regulations.



Category I radiocommunication devices

comply with Industry Canada Standard

RSS-210. Category II radiocommunication

devices comply with Industry Canada

Standard RSS-310. This device complies

with Industry Canada license-exempt RSS

standard(s). Operation is subject to the

following two conditions: (1) this device

may not cause interference, and (2) this

device must accept any interference,

including interference that may cause

undesired operation of the device.



Garmin’s standard limited warranty applies

to this accessory. For more information,

go to www.garmin.com/support/warranty

.html.

DRAFT

Garmin® and the Garmin logo are trademarks of Garmin Ltd.

or its subsidiaries, registered in the USA and other countries.

GLO™ is a trademark of Garmin Ltd. or its subsidiaries. These

trademarks may not be used without the express permission of

Garmin.

The Bluetooth® word mark and logos are owned by the Bluetooth

SIG, Inc. and any use of such marks by Garmin is under license.

iPad, iPhone, iPod, and iPod touch are trademarks of Apple

Inc., registered in the USA and other countries. Android™ is a

trademark of Google Inc. Windows® is a registered trademark of

Microsoft Corporation in the United States and other countries.

BlackBerry is registered with the U.S. Patent and Trademark

Ofce and may be pending or registered in other countries.





1200 East 151st Street,

Olathe, Kansas 66062, USA



Liberty House, Hounsdown Business Park

Southampton, Hampshire, SO40 9LR UK



No. 68, Zhangshu 2nd Road, Xizhi Dist.

New Taipei City, 221, Taiwan (R.O.C.)

815 69 555

00 46 7744 52020

00 331 55 69 33 99

43 (0) 3133 3181 0

0800-0233937

00 34 902 007 097

00 358 9 6937 9758

1-866-429-9296

0180 5 / 42 76 46 - 880

00800 4412 454

+44 2380 662 915

00 32 2 672 52 54

913-397-8200

1-800-800-1020

00 39 02 3669 9699

00 35 1214 447 460

00 45 4810 5050

0808 238 0000

+44 870 850 1242

DRAFT

Tabla de contenidos

Otros manuales de GPS de Garmin

Garmin

Garmin Drive 40 Manual de usuario

Garmin

Garmin GPS 500 Manual de usuario

Garmin

Garmin nuvi 3450 Manual de instrucciones

Garmin

Garmin StreetPilot I2 - Automotive GPS Receiver Manual de usuario

Garmin

Garmin NUVI R NVI 200 Manual de usuario

Garmin

Garmin nuvi 205W-Series Manual de usuario

Garmin

Garmin G3X Touch Manual

Garmin

Garmin aera 795 Manual de usuario

Garmin

Garmin iQue 3200 Guía del usuario

Garmin

Garmin REACTOR 40 MECHANICAL Manual de usuario

Garmin

Garmin zumo 350LM Manual de usuario

Garmin

Garmin GLO 2 Manual de usuario

Garmin

Garmin Astro Manual de usuario

Garmin

Garmin nuvi 500-Series Manual de usuario

Garmin

Garmin eTrex Mariner Manual de usuario

Garmin

Garmin GMA 35 Manual de usuario

Garmin

Garmin GPSMAP 4010 Manual de usuario

Garmin

Garmin GPS 60 - Hiking GPS Receiver Manual de usuario

Garmin

Garmin ECHOMAP Ultra 122sv Manual de usuario

Garmin

Garmin StreetPilot I2 - Automotive GPS Receiver Guía de configuración

Garmin

Garmin GPSMAP 76 series Manual de usuario

Garmin

Garmin NUVI 2300 series Manual de instrucciones

Garmin

Garmin Fishfinder 80 Manual de usuario

Garmin

Garmin GPS 35 PC Manual de usuario

Manuales populares de GPS de otras marcas

Raven

Raven Cruizer II Manual

Hama

Hama 53118 Manual de usuario

Jigabot

Jigabot EX Manual de usuario

Pointer

Pointer Cellocator CelloTrack XT LTE Guía de instalación

Queclink

Queclink GV55LITE Manual de usuario

Voxson

Voxson Voxtrack GPS500 Manual de instrucciones

Starcom Systems

Starcom Systems Kylos Compact Manual de usuario

Cobra

Cobra Marine MC 600Ci Manual de usuario

Cellocator

Cellocator CelloTrack T Manual de usuario

Enfora

Enfora Mini-MT GSM2228UG001 Manual de usuario

Magellan

Magellan eXplorist 100 Manual de usuario

LTE

LTE G50B Manual de usuario

SkyGolf

SkyGolf SkyCaddie SG1 Manual de usuario

Kenwood

Kenwood DNN9330BT Manual de usuario

Safelet

Safelet Indra Manual de usuario

Bushnell

Bushnell 360100 Manual de usuario

Geneq

Geneq SXBlue Manual de usuario

ORIGO

ORIGO ED308 Manual de usuario
