Fujitsu PRIMERGY TX150 S4 Manual de usuario

PRIMERGY

PRIMERGY TX150 S4

Server System

Options Guide

Däschlein

Fujitsu Siemens Computers GmbH München

81730 München

e-mail: email: [email protected]

Tel.: (089) 61001155

Fax: 0 700 / 372 00000

U41629-J-Z156-2-76

Sprachen: En

Edition Febru ry 2006

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Fax forms for sending us your comments are included in

the back of the manual.

There you will also find the addresses of the relevant

User Documentation Department.

Certified documentation

according to DIN EN ISO 9001:2000

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2000.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

U41629-J-Z156-2-76 Options Guide

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1 Overview of the documentation . . . . . . . . . . . . . . . . . . 5

1.2 Extensions and conversions . . . . . . . . . . . . . . . . . . . . 7

1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . . . 9

2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

3 Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

4.1 Floorstand model . . . . . . . . . . . . . . . . . . . . . . . . 19

4.1.1 Opening the server . . . . . . . . . . . . . . . . . . . . . . . 19

4.1.2 Removing the front cover . . . . . . . . . . . . . . . . . . . . 20

4.1.3 Removing the hard disk cover . . . . . . . . . . . . . . . . . . 21

4.2 Rack model . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

4.2.1 Opening the server . . . . . . . . . . . . . . . . . . . . . . . 22

4.2.2 Removing the rack front cover . . . . . . . . . . . . . . . . . . 25

5 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 27

5.1 Equipping rules . . . . . . . . . . . . . . . . . . . . . . . . . 27

5.2 Extending/replacing the main memory . . . . . . . . . . . . . 28

6 Accessible drives . . . . . . . . . . . . . . . . . . . . . . . 31

6.1 Installing an accessible 5.25-inch drive . . . . . . . . . . . . . 31

6.2 Installing the hard disks extension box . . . . . . . . . . . . . 34

6.3 Installing a 3.5-inch floppy disk drive . . . . . . . . . . . . . . 36

7 Controllers in the PCI slots . . . . . . . . . . . . . . . . . . 39

7.1 Installing a controller . . . . . . . . . . . . . . . . . . . . . . 40

7.2 PCI slot assembly . . . . . . . . . . . . . . . . . . . . . . . . 42

8 RemoteView components . . . . . . . . . . . . . . . . . . . 43

8.1 RemoteView Service Board S2 LP . . . . . . . . . . . . . . . 43

9 External SCSI interface . . . . . . . . . . . . . . . . . . . . 47

9.1 Installing the external SCSI interface . . . . . . . . . . . . . . 47

10 Conversion standard PS to hot-plug PS . . . . . . . . . . . 49

11 Converting from the floorstand model to the rack model . . 61

Options Guide U41629-J-Z156-2-76

Contents

12 Completion . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

12.1 Floorstand model . . . . . . . . . . . . . . . . . . . . . . . . 67

12.1.1 Attaching the hard disk cover . . . . . . . . . . . . . . . . . . 67

12.1.2 Attaching the front cover . . . . . . . . . . . . . . . . . . . . 68

12.1.3 Closing the server . . . . . . . . . . . . . . . . . . . . . . . . 69

12.2 Rack model . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

12.2.1 Attaching the rack front cover . . . . . . . . . . . . . . . . . . 70

12.2.2 Closing the server . . . . . . . . . . . . . . . . . . . . . . . . 72

13 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

13.1 Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

13.1.1 SCSI version . . . . . . . . . . . . . . . . . . . . . . . . . . 75

13.1.2 SATA version . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

U41629-J-Z156-2-76 Options Guide 5

1Introduction

The PRIMERGY TX150 S4 Server is an Intel-based server for medium-sized

networks and large companies. The server is suitable for use as a file server as

well as an application, information, or Internet server. It is available as a floor-

stand or rack model. The floorstand model can be converted to a rack model

using an optional conversion kit.

1.1 Overview of the documentation

IPRIMERGY manuals are available in PDF format on the ServerBooks

CD which is supplied in the ServerView Suite package for every server

system.

These PDF files can also be downloaded free of charge from the

Internet: at http://manuals.fujitsu-siemens.com you will find an overview

page with the online documentation available on the Internet. You can go

to the PRIMERGY Server documentation by clicking on “industry

standard servers”.

Concept and target groups

This Options Guide shows you how you can expand and upgrade the server.

IThe Operating Manual for the server describes how you install/remove

the hot-plug components.

The activities described in this manual may only be performed by technicians,

service personnel or technical specialists.

Additional documentation about the server

The PRIMERGY TX150 S4 documentation comprises the following additional

manuals:

– „Quick Start Hardware - PRIMERGY TX150 S4“ (poster)

– „Quick Start Software - PRIMERGY ServerView Suite“ (poster)

– “Warranty” manual (print version delivered together with the system, PDF file

available on the ServerBooks CD delivered with the system)

– “Safety” manual (print version always delivered together with the system,

PDF file available on the ServerBooks CD)

6 Options Guide U41629-J-Z156-2-76

Overview of the documentation Introduction

– “Ergonomics” manual (PDF file available on the ServerBooks CD)

– “Helpdesk” (poster with worldwide helpdesk telephone numbers)

– Technical Manual for the system board D2239 (PDF file available on the

ServerBooks CD)

– “BIOS Setup V4.06” manual (PDF file available on the ServerBooks CD)

– "TX150 S4 Server System Operation Guide” (PDF file available on the

ServerBooks CD)

– “ServerView Suite” includes the ServerStart CD, the ServerBooks CD and

the ServerSupport CDs. The PDF version of the user manual “PRIMERGY

- ServerView Suite - ServerStart” is also available on the ServerBooks CD.

IYou can order a supplementary ServerBooks CD by sending an e-

mail to the following address, quoting your server data:

[email protected]

– “MegaRAID 320 Storage Adapters” (PDF file available on the ServerBooks

CD)

– “MegaRAID 320-0X Zero-channel PCI-X RAID Storage Adapter” (PDF file

available on the ServerBooks CD)

– “MegaRAID Device Driver Installation” (PDF file available on the Server-

Books CD)

– “MegaRAID Configuration Software” (PDF file available on the ServerBooks

CD)

– “Global Array Manager Client Software User’s Guide” (PDF file available on

the ServerBooks CD)

– “Global Array Manager Server Software User’s Guide” (PDF file available on

the ServerBooks CD)

– “Integrated Mirroring User’s Guide” (PDF file available on the ServerBooks

CD)

U41629-J-Z156-2-76 Options Guide 7

Introduction Extensions and conversions

Further sources of information:

– Technical Manual on the relevant rack

– Manual on the monitor

– Manual on ServerView Server Management

– Manual on the RemoteView Remote Test and Diagnostics System

– Documentation on boards and drives

– Documentation on your operating system

– Information files on your operating system

(see also “Related publications” on page 89)

1.2 Extensions and conversions

Extension of the main memory

The four slots for the main memory are suitable for DDR2 PC 2-4200 (533 MHz)

(unbuffered) SDRAM memory modules with ECC. The organization in two

memory banks, 1 and 2, permits rapid memory access with two-way inter-

leaving.

If the memory modules are populated in pairs, each pair must consist of

identical memory modules (2-way interleaved mode).

Upgrading the processor

The LGA775 processor socket -Prozessorsteckplatz accomodates one Intel

Pentium 4 or Pentium D desktop processor with 533/800 MT/s (133/200 MHz)

front side and bus clock speeds of up to 3.8 GHz.

Additional accessible drives

Three 5.25-inch bays are available for accessible drives. The top side bay is

already occupied by a CD/DVD ROM drive. Additionally, one 3.5“ floppy disk

drive can be installed.

Hard disks extension box

The two lower 5.25-inch bays for accessible drives can be used to integrate a

hard disks extension box.

8 Options Guide U41629-J-Z156-2-76

Extensions and conversions Introduction

The hard disks extension box enables up to three additional HDD modules to be

integrated. Each HDD module can accommodate a SCSI hard disk drive with

an SCA (Single Connector Attachment) interface and a height of at most 1 inch.

The connection to the SCSI backplane is made without cables via the SCA

interface. This makes it simple to plug in or pull out the HDD modules. If the

server has a RAID controller and the corresponding RAID configuration,

defective HDD modules can also be replaced while the system is operating.

Additional controllers in the PCI slots

The system board offers seven PCI slots:

– 2 x PCI-X 1.1 (64 Bit / 66 MHz / 100 MHz, 3.3 V, length: 2 x 340 mm)

– 3 x PCI (32 Bit / 33 MHz, 5 V, length: 1 x 340 mm, 2 x 245 mm)

– 1 x PCI-Express x1 (0.5 GB/s, length: 167 mm)

– 1 x PCI-Express x4 (2.0 GB/s, length: 167 mm)

The PCI slot 2 (blue) is prepared for Zero Channel RAID (ZCR).

RemoteView Service Board S2 LP

The RemoteView Service Board S2 LP (RSB S2 LP) is a PCI board with a

completely independent system, i.e. it has its own operating system with Web

server and SNMP agents and can optionally be equipped with an external

power supply. The RSB S2 LP permits remote diagnosis for system analysis,

remote system configuration and remote restart even in the event of operating

system failure or hardware faults. It has its own LAN connection and its own

COM port. All the functions of the RSB S2 LP are thus available either via a LAN

or modem.

External SCSI interface

If the internal hard disks are connected via a PCI RAID controller, one channel

of the on-board controller can also be made available for connecting a

peripheral cabinet SX10 via an external SCSI interface.

U41629-J-Z156-2-76 Options Guide 9

Introduction Notational conventions

Conversion standard power supply to hot-plug power supply

The standard power supply can be replaced by a hot-plug power supply. The

hot-plug power supply consists of two power supply modules.

If one power supply module fails, the other power supply module guarantees the

unrestricted operation and the defective power supply module can be replaced

be replaced while the system is operating (hot-plug).

Conversion of the floorstand model to a rack model

The floorstand model can optionally be converted so that the server can be

integrated into the common rack systems.

1.3 Notational conventions

The following notational conventions are used in this manual:

Text in italics indicates commands, menu items or software programs.

„Quotation marks“ indicate names of chapters and terms that are being

emphasized.

Êdescribes activities that must be performed in the order

shown.

VCAUTION! pay particular attention to texts marked with this symbol.

Failure to observe this warning may endanger your life,

destroy the system or lead to the loss of data.

Iindicates additional information, notes and tips.

Table 1: Notational conventions

Otros manuales para PRIMERGY TX150 S4

Tabla de contenidos

Otros manuales de Servidor de Fujitsu

Fujitsu

Fujitsu PRIMERGY BX900 Guía del usuario

Fujitsu

Fujitsu PRIMERGY RX200 S6 Manual de usuario

Fujitsu

Fujitsu SPARC Enterprise M3000 Manual de usuario

Fujitsu

Fujitsu PRIMERGY RX600 S4 Manual de usuario

Fujitsu

Fujitsu SPARC Enterprise T5440 Server Manual de usuario

Fujitsu

Fujitsu PRIMERGY TX150 S2 Manual de usuario

Fujitsu

Fujitsu SPARC Enterprise T5140 Guía de instalación

Fujitsu

Fujitsu PRIMERGY RX4770 M2 Manual de usuario

Fujitsu

Fujitsu BS2000/OSD Manual de usuario

Fujitsu

Fujitsu PRIMERGY TX150 S5 Manual del propietario

Fujitsu

Fujitsu PRIMERGY TX1310 M1 Manual de usuario

Fujitsu

Fujitsu PRIMERGY RX200 S3 Guía

Fujitsu

Fujitsu PRIMEQUEST 1000 Series Manual de usuario

Fujitsu

Fujitsu PRIMERGY RX200 S5 Manual de usuario

Fujitsu

Fujitsu Primergy RX100 S3 Manual de usuario

Fujitsu

Fujitsu PRIMERGY RX900 S2 Manual de usuario

Fujitsu

Fujitsu PRIMERGY RX300 S7 Manual de usuario

Fujitsu

Fujitsu S140 Manual de usuario

Fujitsu

Fujitsu PRIMEQUEST 2800B3 Manual de usuario

Fujitsu

Fujitsu SPARC Enterprise M3000 Guía de instalación

Fujitsu

Fujitsu PRIMERGY BX600 S2 Manual de usuario

Fujitsu

Fujitsu BS2000 SE320 Manual de usuario

Fujitsu

Fujitsu SPARC Enterprise T5140 Manual de usuario

Fujitsu

Fujitsu Primergy RX100 S5 Manual de usuario

Manuales populares de Servidor de otras marcas

HP AlphaServer ES47 Manual de usuario

Dell

Dell PowerEdge R410 Manual de usuario

PowerNAS

PowerNAS CMA Manual de usuario

Supero

Supero FatTwin F617R3-FT Manual de usuario

MSI

MSI P1-109N-L70 Manual de usuario

Dell

Dell PowerEdge XE9640 Manual

Dell

Dell PS4100 Instrucciones de montaje

EtroVISION

EtroVISION EV3151 Manual de usuario

NEC

NEC Express5800/T110j Manual de usuario

HP ProLiant Gen9 Manual de usuario

Compaq

Compaq ProLiant 3000 Manual

Dell

Dell PowerEdge 3YPMN Manual de usuario

iRobo

iRobo IPC2U Manual de usuario

Nortel

Nortel 1000 Con?guration guide Manual de usuario

Asus

Asus AP7500 Manual de operación y mantenimiento

Avid Technology

Avid Technology AirSpeed 5000 Manual de usuario

HP Integrity rx2600 Guía de instalación

Milestone

Milestone Husky IVO 350T Manual de usuario
