Fujitsu BS2000 SE700 Manual de usuario

Edition September 2015

English

SE700 / SE500 / SE300

Quick Guide

FUJITSU Server BS2000

User Guide

Valid for:

M2000 V6.0A / V6.1A

X2000 V6.0A / V6.1A

HNC V6.0A / V6.1A

Comments…Suggestions…Corrections…

The User Documentation Department would like to know your

opinion on this manual. Your feedback helps us to optimize our

documentation to suit your individual needs.

Feel free to send us your comments by e-mail to:

manuals@ts.fujitsu.com

Certified documentation

according to DIN EN ISO 9001:2008

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system which

complies with the requirements of the standard

DIN EN ISO 9001:2008.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

This manual is printed

on paper treated with

chlorine-free bleach.

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

The Xen® mark is a trademark of Citrix Systems, Inc., which manages the mark on behalf of the Xen open source

community. The Xen® mark is registered with the U.S. Patent and Trademark Office, and may also be registered in

other countries.

Novell and SUSE are registered trademarks of Novell, Inc. in the USA and other countries.

Linux is a registered trademark of Linus Torvalds.

Windows® is a registered trademark of Microsoft Corporation.

The Linux-based basic software M2000, X2000, and HNC which is installed on the Management Unit, Server Unit

x86, and HNC contains Open Source Software. The licenses for this can be found in the LICENSES directory on the

relevant installation DVD.

U41857-J-Z125-1-76

Dokuschablonen 19x24 Version 7.4de für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010

10. September 2015 Stand 12:31.06 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303905_Kurz\se_kurz_e\se_kurz.ivz

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1 Objective and target groups of this manual . . . . . . . . . . . . . . . . . . . . . . 7

1.2 Summary of contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.4 Names and abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

2 Architecture of the SE servers and networks . . . . . . . . . . . . . . . . . . . . 11

2.1 Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.2 Architecture of SE servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.3 Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2.4 Operating the SE Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2.4.1 Calling the SE Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2.4.1.1 Logging in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

2.4.1.2 Logging out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

2.4.2 Working with the SE Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

2.4.2.1 Main window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

2.4.2.2 Terminal window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

2.4.2.3 Calling an object or function in the SE Manager . . . . . . . . . . . . . . . . . . 22

2.4.2.4 Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

2.4.2.5 Authorizations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

2.4.2.6 Calling the online help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Contents

U41857-J-Z125-1-76

3 Power-on, starting up BS2000, shutdown . . . . . . . . . . . . . . . . . . . . . . 25

3.1 Powering on the Management Unit remotely . . . . . . . . . . . . . . . . . . . . 25

3.2 Powering on the Management Unit via the local console . . . . . . . . . . . . . . 28

3.3 Powering on Server Units and other units . . . . . . . . . . . . . . . . . . . . . . 29

3.4 Starting up BS2000 (SU /390) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

3.5 Starting up BS2000 (SU x86) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

3.6 Opening and terminating BS2000 dialog . . . . . . . . . . . . . . . . . . . . . . . 38

3.7 Shutting down BS2000 via the BS2000 console . . . . . . . . . . . . . . . . . . . 40

3.8 Powering off Server Units and other units . . . . . . . . . . . . . . . . . . . . . . 41

3.9 Messages on the BS2000 console . . . . . . . . . . . . . . . . . . . . . . . . . . 42

4 Setting the system time or configuring the NTP . . . . . . . . . . . . . . . . . . 43

5 Application Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

5.1 Powering the Application Unit on and off via the iRMC . . . . . . . . . . . . . . . 45

5.2 Embedding an application or link in the SE Manager . . . . . . . . . . . . . . . . 47

Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

U41857-J-Z125-1-76 5

Dokuschablonen 19x24 Version 7.4de für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010

10. September 2015 Stand 12:30.45 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303905_Kurz\se_kurz_e\se_kurz.k01

1 Introduction

With the completely newly developed FUJITSU Server BS2000 SE Series, FUJITSU now

offers a server infrastructure which consists of three server lines. Under the umbrella of this

SE infrastructure, multiple application scenarios are possible in various combinations for

both mainframe applications and applications of the open world. This new platform stands

out on account of the unrivaled performance scalability (scale-up and scale-out), and

ensures that users can manage their application workloads securely, quickly and efficiently

across technological boundaries with maximum availability.

One major aim in developing the SE series was to provide a uniform management strategy

which offers customers significant added value through maximum integration, and

guarantees extremely cost-effective operation of their IT.

The new SE server line succeeds the tried and tested S and SQ server lines, integrating

the advantages of both lines in an optimal manner. The heart of the SE series is formed by

the /390-based Server Units, the x86-based Server Units, the Net Unit, and the

Management Unit (MU). All components are integrated into a standard 19" rack and are

supplied to customers ready to use. With its newly developed processors and appreciably

higher system performance, the new generation of the SE series offers enhanced

configuration options, maximum availability and, not least of all, significantly reduced power

consumption.

Depending on requirements, the SE server contains all the system components needed for

operation as an overall application:

– Server Unit /390 for BS2000 guest systems

– Server Unit x86 with BS2000, Linux or Windows guest systems

– Application Units x86 for operating Native or hypervisor systems (e.g. Linux, Windows,

VMware, OVM, etc.)

– Shareable tape and disk periphery

– A high-speed, server-internal infrastructure to connect the components with each other

and with the customer's IP and FC networks.

Introduction

6 U41857-J-Z125-1-76

The SE server offers the following advantages:

– Cross-system administration with state-of-the-art, browser-based GUI (SE Manager) as

a single point of operation

– Joint system monitoring of all components

– Uniform redundancy strategy

– Joint service process

– All options for consolidation through virtualization

– SE components and infrastructure are

–

SE servers consequently enable flexible and application-specific implementation which

fulfills high SLAs through the use of high-end components and an end-to-end redundancy

concept, and nevertheless permits cost-effective operation of the overall system with few

resources thanks to its uniformity.

Intel x86-based server systems with their VMware, Linux or Windows system platforms also

profit from the concepts for stable system operation tested on the mainframe:

– Selection of high-quality server components

– Redundant hardware components

– Prepared operating concepts which also include high availability

– Comprehensive tests before release

– Comprehensive service concept.

The management interface which is uniform for all SE servers, the SE Manager, permits a

view of all the system components involved and, from this higher-level perspective, enables

the resources to be optimized through efficient distribution of the application to the systems

which are currently utilized least.

SE servers consequently permit particularly stable system operation which includes not

only the mainframe platforms which have to date been known to be particularly failsafe, but

also other Server Units and the infrastructure and peripherals employed by the SE server.

This can be achieved with fewer resources for administration and system operation than for

separate operation of different IT systems.

Introduction Objective and target groups of this manual

U41857-J-Z125-1-76 7

Dokuschablonen 19x24 Version 7.4de für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010

10. September 2015 Stand 12:30.45 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303905_Kurz\se_kurz_e\se_kurz.k01

1.1 Objective and target groups of this manual

This Quick Guide is intended for people who operate an SE server:

●As administrator you manage the entire SE server with all its components and the

operating systems which run on it. You need a good knowledge of the BS2000, Linux

and Windows operating systems and of the network and peripherals.

As administrator you can also manage the integration of the optional Application Units

on which an open operating system (by default Linux) runs in Native mode or in a

virtualized manner (e.g. under VMware® vSphere 5).

●For other users, roles are provided with a customized selection of functions (e.g.

operator, AU administrator, etc.) to permit the assigned tasks to be performed.

This Quick Guide assumes the following:

●Customer Support provides the customer with the SE server.

●The desired BS2000 operating mode is set on each Server Unit.

●A BS2000 system is configured and fully operational.

●All necessary BS2000 devices are configured.

1.2 Summary of contents

Chapter 2 contains fundamental information which is relevant for all readers.

The chapters below describe fundamental functions which enable you to ensure the SE

server is ready to operate. Detailed knowledge, as described in the “Operation and

Administration” manual [5], is not required.

Detailed information on the data displayed, the dialog boxes, and operation of the SE

Manager is provided in the online help of the SE Manager.

Further information is provided in related publications for the SE servers in the chapter

„Related publications“ auf Seite 49.

Summary of contents Introduction

8 U41857-J-Z125-1-76

README file

For information on any functional changes or extensions to this manual, please refer to the

product-specific Readme file.

In addition to the product manuals, Readme files for each product are available to you

online at http://manuals.ts.fujitsu.com. You will also find the Readme files on the Softbook

DVD.

Information under BS2000

When a Readme file exists for a product version, you will find the following file on the

BS2000 system:

SYSRME.<product>.<version>.<lang>

This file contains brief information on the Readme file in English or German (<lang>=E/D).

You can view this information on screen using the /SHOW-FILE command or an editor.

The /SHOW-INSTALLATION-PATH INSTALLATION-UNIT=<product> command shows the user

ID under which the product’s files are stored.

Additional product information

Current information, version and hardware dependencies and instructions for installing and

using a product version are contained in the associated Release Notice. Release Notices,

in particular those relating to BS2000 OSD/XC, M2000, X2000, and HNC, are available at

http://manuals.ts.fujitsu.com.

Introduction Notational conventions

U41857-J-Z125-1-76 9

Dokuschablonen 19x24 Version 7.4de für FrameMaker V7.x vom 09.02.2010 © cognitas GmbH 2001-2010

10. September 2015 Stand 12:30.45 Pfad: P:\FTS-BS\Server\SE-Server\SE-Doku\1303905_Kurz\se_kurz_e\se_kurz.k01

1.3 Notational conventions

The following notational conventions are used in this manual:

[ ] The titles of related publications in the text are abbreviated. The complete title of

each publication which is referred to by a number is listed in the Related

Publications chapter after the associated number.

IThis symbol indicates important information and tips which you should bear

in mind.

V This symbol and the word CAUTION! precede warning information. In the

interests of system and operating security you should always observe this

information.

ÊThe action which you must perform is indicated by this symbol.

italics Texts from the SE Manager (e.g. menu name, tab)

monospace System inputs and outputs

monospaced

semibold

Statements which are entered via the keyboard are displayed in this font.

<abc> Variables which are replaced by values.

[Key symbols] Keys are displayed as they appear on the keyboard. When uppercase letters

need to be entered, the Shift key is specified, e.g. [SHIFT] - [A] for A. If two

keys need to be pressed at the same time, this is indicated by a hyphen

between the key symbols.

Names and abbreviations Introduction

10 U41857-J-Z125-1-76

1.4 Names and abbreviations

Because the names are used frequently, for the sake of simplicity and clarity the following

abbreviations are employed:

●SE server for the FUJITSU Server BS2000 SE Series (Server Units /390 and x86) with

the following models:

●SE300 for FUJITSU Server BS2000 SE300 (with SU300, optionally AUs)

●SE500 for FUJITSU Server BS2000 SE500 (with SU500, optionally SU300 and

AUs)

●SE700 for FUJITSU Server BS2000 SE700 (with SU700, optionally SU300 and

AUs)

●SU for the Server Unit irrespective of the unit type

A distinction is made between SUs depending on the unit type:

●SU /390 for Server Unit /390 (type of Server Unit with one or more /390 processors)

●SU x86 for Server Unit x86 (type of Server Unit with one or more x86 processors)

A distinction is made between the following SUs according to models:

●SU300 for the Server Unit of the unit type SU x86 in SE300, optionally in SE500 and

SE700

●SU500 for the Server Unit of the unit type SU /390 in SE500

●SU700 for the Server Unit of the unit type SU /390 in SE700

●MU for the Management Unit. The MU permits central, user-friendly and cross-system

management on the SE server.

●AU for the Application Unit (with x86-based hardware)

●HNC (High Speed Network Connect) connects the SU /390 with the LAN and as a net

client also permits access to the Net-Storage. HNC designates both Linux-based basic

software and the hardware unit itself on which this basic software executes.

●BS2000 server as the generic term for all SE servers and the existing S and SQ

servers. BS2000 servers are operated with the relevant BS2000 operating system.

●BS2000 for the BS2000 OSD/BC operating system in compound nouns, e.g. BS2000

system.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Servidor de Fujitsu

Fujitsu

Fujitsu PRIMERGY TX1320 M4 Manual de usuario

Fujitsu

Fujitsu FUTRO S9010 Manual de usuario

Fujitsu

Fujitsu Primergy TX120 Manual de usuario

Fujitsu

Fujitsu BS2000 SE Series Manual de usuario

Fujitsu

Fujitsu PRIMERGY BX620 S6 Manual del propietario

Fujitsu

Fujitsu PRIMERGY RX300 S7 Manual de usuario

Fujitsu

Fujitsu SPARC Enterprise M3000 Manual de usuario

Fujitsu

Fujitsu PRIMERGY TX2560 M1 Manual de usuario

Fujitsu

Fujitsu PRIMERGY TX120 S3 Manual de usuario

Fujitsu

Fujitsu SPARC Enterprise M4000 Guía de instalación

Fujitsu

Fujitsu Primergy RX300 S4 Manual de usuario

Fujitsu

Fujitsu SPARC Enterprise M3000 Guía de instalación

Fujitsu

Fujitsu PRIMERGY TX120 S3 Manual de usuario

Fujitsu

Fujitsu PRIMEQUEST 1000 Series Manual de usuario

Fujitsu

Fujitsu 1FINITY L100 Manual de usuario

Fujitsu

Fujitsu PRIMERGY TX300 S5 Manual del propietario

Fujitsu

Fujitsu PRIMERGY RX600 S6 Manual del propietario

Fujitsu

Fujitsu PRIMEPOWER 900 Manual de usuario

Fujitsu

Fujitsu PRIMERGY TX200 S7 Manual de usuario

Fujitsu

Fujitsu primergy h250 Manual de usuario

Fujitsu

Fujitsu PRIMERGY RX300 S8 Manual de usuario

Fujitsu

Fujitsu PRIMERGY 10/40GbE Connection Blade 18/8+2 Manual de lista de piezas

Fujitsu

Fujitsu PRIMERGY CX2550 M2 Manual de usuario

Fujitsu

Fujitsu BX630 - PRIMERGY - S2 Dual Manual del propietario

Manuales populares de Servidor de otras marcas

HP AlphaServer ES47 Manual de usuario

Dell

Dell PowerEdge R410 Manual de usuario

PowerNAS

PowerNAS CMA Manual de usuario

Supero

Supero FatTwin F617R3-FT Manual de usuario

MSI

MSI P1-109N-L70 Manual de usuario

Dell

Dell PowerEdge XE9640 Manual

Dell

Dell PS4100 Instrucciones de montaje

EtroVISION

EtroVISION EV3151 Manual de usuario

NEC

NEC Express5800/T110j Manual de usuario

HP ProLiant Gen9 Manual de usuario

Compaq

Compaq ProLiant 3000 Manual

Dell

Dell PowerEdge 3YPMN Manual de usuario

iRobo

iRobo IPC2U Manual de usuario

Nortel

Nortel 1000 Con?guration guide Manual de usuario

Asus

Asus AP7500 Manual de operación y mantenimiento

Avid Technology

Avid Technology AirSpeed 5000 Manual de usuario

HP Integrity rx2600 Guía de instalación

Milestone

Milestone Husky IVO 350T Manual de usuario
