Fujitsu S120 Series Manual de usuario

U41182-J-Z126-1-74 1

1Introduction

The range of BS2000/OSD servers has been extended by the addition of the S120 series.

The spectrum of user facilities of the new models lies betweeen that of the S115 and the

S135. They are powerful systems for scientific and commercial applications.

The S120 Business Server (or cluster) has a modular structure and can easily be upgraded

on site.

The main memory can be expanded by up to 2 Gbytes.

The input/output system consists of 1 I/O processor. Up to 64 channels can therefore be

configured for connecting peripheral devices with type-2, type-S or type-F channel inter-

faces. LAN networking is possible via the 3970-SKP servive/console processor, a connec-

tion to the TRANSDATA network world via front-end processors.

The service processor (SVP) and the external 3970-SKP service/console processor

support common operation,monitoring,diagnosis andmaintenanceofthecomputer as well

as TELESERVICE.

Like all computers in the 7.500 system family and the S1xx server series, the S120

Business Server uses the BS2000 operating system in either dialog, online teleprocessing

(OLTP) or batch mode. This offers the portability and compatibility of BS2000 programs.

1.1 Objectives and target group

This manual provides you with all the information you require to operate the S120 Business

Server via the service/console processor, and is thus intended for operators and system

managers.

Knowledge of BS2000 system operation and management as well as basic knowledge of

SINIX are required.

Further manuals with information on the operation of BS2000, SINIX and TELESERVICE

are listed under “Related publications” at the back of this manual.

2U41182-J-Z126-1-74

Summary of contents Introduction

1.2 Summary of contents

This operating manual covers the hardware operating functions of the S120 Business

Server with the 3970-SKP service/console processor.

The chapters “Overview”, “Controls and indicators” and “Standard processing in SVP

mode” provide information on hardware and the operating concept. You should read these

chapters first.

The chapter entitled “Troubleshooting” provides valuable assistance in recognizing and

solving problems.

Document references in the text are given in abbreviated form between quotation marks.

The full title to which the specified number refers is listed under that number at the back of

the manual in the related publications section, accompanied by a brief description.

A keyword index at the end of the manual helps you to find the relevant information quickly.

1.3 Notational conventions

Some text passages are marked using the following symbols:

Information that is particularly important for the function of the product.

Important instructions, e.g. warnings.

Reference to the “SINIX-2000 V7.5/V8.0” [1] manual.

ÊThe input symbol indicates actions which must be carried out (e.g. keyboard input).

Ë This character represents a blank in keyboard input.

[ ... ] References to relevant literature or optional parameters in commands are given in

square brackets.

This typewriter font is used for names, commands and messages (e.g. the

/DETË*CHA(xx) command).

U41182-J-Z126-1-74 3

2 Important instructions

This chapter lists selected notes from the manufacturer and information on RFI

suppression.

You should pay particular attention to the safety instructions in section 2.3.

2.1 Manufacturer instructions

This product complies with the EC guideline 89/336/EEC "Electronic Compati-

bility". The product bears the EC certificate.

2.2 RFI suppression

WARNING: This is a class A equipment. This equipment may cause interference to

radio and television reception in a residential installation. If it does cause inter-

ference, the user may be requested to take appropriate corrective measures at his

or her own cost.

The devices generate and emit high-frequency energy.

If the devices are installed and used other than as instructed in the manual, failures in the

devices or other electric systems may occur. If failures of this type occur it is the task of the

user to carry out measurements and implement measures to solve the problem. Only the

cables supplied with the system or recommended by Fujitsu Siemens Computers may be

used.

All other devices which are connected to the present product must be radio interference

suppressed in accordance with BMPT Order No. 1046/84 and Order No. 243/91 or EU

Directive 89/336/EEC. Products which satisfy this requirements are provided with an appro-

priate certificate by the manufacturer and bear the CE mark or the interference suppression

symbol.

4U41182-J-Z126-1-74

Safety instructions Important instructions

2.3 Safety instructions

This device fulfills the prevailing safety requirements for information technologyequipment,

including electrical office machines.



In emergencies (e.g. damaged housing, operating elements or network cables,

intrusion of liquid or foreign objects), switch off the device immediately (UNIT

EMERGENCY POWER OFF) and contact our service department.

Figure 1: UNIT EMERGENCY POWER OFF switch on the S120



The systems may only be installed by authorized trained personnel.



The cables must be laid in such a way that there is no danger of anyone tripping over

them and they cannot be damaged.



Data transmission lines must not be connected or disconnected during electrical

storms.



Ensure that no foreign bodies (e.g. necklaces, paperclips etc.) or liquids find their way

into the device (danger of electric shock, short circuit).

UNIT

EMERGENCY

POWER

OFF

S120 Business Server

U41182-J-Z126-1-74 5

Important instructions Safety instructions



Repairs to the device may only be carried out by authorized and trained personnel. All

areas which are secured by locks or can only be opened using tools are maintenance

areas and may only be accessed by trained personnel.

Unauthorized opening of the maintenance area and improper repairs can be dangerous

for the user (electric shock, danger of fire).

Eine Dokuschablone von Frank Flachenecker

by f.f. 1992

U41182-J-Z126-1-74 7

3Overview

This chapter provides information on the configuration levels and the configuration of the

S120 Business Server series and the concept of system operation.

Figure 2: S120 Business Server with additional cabinet

The S120 Business Server consists of a cabinet plus an additional cabinet for channel

expansions.

S120 Business Server

8U41182-J-Z126-1-74

Configuration levels of the S120 Business Server Overview

3.1 Configuration levels of the S120 Business Server

The S120 Business Server series consists of four models. Upgrading of the individual

models can easily be carried out on site, so that system downtime is not extended due to

hardware installation.

The S120 models can have multiple channel groups. Thus a reconfiguration is possible for

these models if there is a partial failure.

Figure 3: Hardware overview of the S120 Business Server system with 3970-SKP

Model Number of processors Performance factor

S120–B 1processingunit 1.0

S120–C 1processingunit 1.4

S120–D 1 processing unit 1.7

S120–E 1 processing unit 2.0

ATOP

TELESERVICE V.24

S120

I/O channel

on/off facility

SKP

LAN

Printer

internal LAN

Remote operator terminal

Radio-controlled

clock / GTS

U41182-J-Z126-1-74 9

Overview Concept of system operation

3.2 Concept of system operation

System operation is described in the chapter “Basics of system operation“ of the

“SINIX-2000 V7.5/V8.0“ [1] manual.

The following section lists the most important hardware and software components for S120

operation.

3.2.1 Hardware

Figure 4: Hardware of the system S120 Business Server

Radio-controlled clock/ serial

V.24 SVP

S120

I/O channel

SKP

LAN

Console

ATOP serial

CPU

on/off facility

internal LAN

serial

Secondary

console

GTS

Remote operator terminal

10 U41182-J-Z126-1-74

Concept of system operation Overview

The following hardware and software components are important for the operation of S120:



Service processor (SVP) in the S120 CPU.

This is responsible for the following tasks in the S120 CPU:

– initialization

– monitoring

– controlling

– hardware diagnosis



The service/console processor (3970-SKP) with the SINIX operating system.

Operation of the S120 system is handled via a local PC, the 3970-SKP service/console

processor. S120 and 3970-SKP communicate with one another in three ways:

– serial line (V.24)

– type-S I/O channel

– internal LAN connection

The following components can be operated via the local 3970-SKP screen and remote

secondary consoles:

– the SINIX system of the 3970-SKP

– the SVP of the S120

– the BS2000 running on the S120

– consoles for up to 7 VM2000 guest systems

– BS2000 applications via 9750 emulation



Automatic Operator (ATOP).

The ATOP is a device which is connected to the 3970-SKP via a serial line. It makes the

following functions possible:

– automatic switching on and off of the S120

– automatic operation of the BS2000 system

The customer can program the ATOP to specify which operating functions should

be executed for which conditions.

Examples:

– automatic shutdown of the system in the case of fan failure.

– automatic command entry in reaction to certain BS2000 console messages.



It is possible to connect a radio-controlled clock or Global Time Server (GTS).



On/off facility makes it possible to switch the S120 on and off from the 3970-SKP.
