fi-4220C IMAGE SCANNER

ILLUSTRATED PARTS CATALOGUE

APPR.

TITLE

DRAW.

No.

1/16

Mar.19,02

fi-4220C

IMAGE SCANNER

ILLUSTRATED PARTS CATALOGUE

Rev

PAGE

PFU LIMITED

P4PA03289-B50X/6

See revision record in page 2.

T,Anzai

Apr 12,02 T.Anzai

See revision record in page 2.T.AnzaiT.Anzai

DESCRIPTION

CHECK

DATE

H.Hasegawa

APPR

Y. Ta k a s h i m a

T. Anzai

Mar. 27, 02

DESIG

DESIG.

CUST.

H.Hasegawa

H.Hasegaw

CHECK

fi-4220C IMAGE SCANNER

ILLUSTRATED PARTS CATALOGUE

APPR.

TITLE

DRAW.

No.

2/16

Mar.19,02

The contents of this manual is subject to change without prior notice.

REVISION RECORD

Edition Data published Revised contents

01 March, 2002 First edition

02 April, 2002 Page 10, P/N error corrected

03 Mar. 2003 Page 10, P/N of Pad ASY changed

Rev

PAGE

PFU LIMITED

P4PA03289-B50X/6

See revision record in page 2.

T,Anzai

Apr 12,02 T.Anzai

See revision record in page 2.T.AnzaiT.Anzai

DESCRIPTION

CHECK

DATE

H.Hasegawa

APPR

Y. Ta k a s h i m a

T. Anzai

Mar. 27, 02

DESIG

DESIG.

CUST.

H.Hasegawa

H.Hasegaw

CHECK

fi-4220C IMAGE SCANNER

ILLUSTRATED PARTS CATALOGUE

APPR.

TITLE

DRAW.

No.

3/16

Mar.19,02

HOW TO USE THIS MANUAL

ILLUSTRATION

The illustration gives an exploded view of an assembly, and separate parts and

how they fit together. Each part has a number corresponding to an Index No.

on the parts list.

PARTS LIST

(1) INDEX NO.

The number which corresponds with a parts number in the illustration.

• When the mark ‘*’ precedes the index number, the parts is a

Recommended Spare Parts or a Consumables.

• When a ‘-’ is given in this column, the part (screw or washer) is not

shown in the illustration.

• When blank, and the QUANTITY and SPECIFICATION are given, a

whole of that part is not shown in the illustration or that part is illustrated

for detail breakdown in the other page.

(2) COMPOSITION & QUANTITY

This column shows the relationship among units, assemblies, subassemblies,

and parts. A unit indicated in a column is assembled by the parts or units

indicated in the next right column. The figure is the quantity of the parts

needed to assemble into the higher assembly.

(3) SPECIFICATIONS

This column shows part number of the units, or parts.

(4) DESCRIPTION

The part name, applicable device number, and other information are given

in this column.

OTHERS

The parts other than the parts marked with ‘*’ in INDEX NO. column are

listed in SPARE PARTS LIST REPAIR.

Rev

PAGE

PFU LIMITED

P4PA03289-B50X/6

See revision record in page 2.

T,Anzai

Apr 12,02 T.Anzai

See revision record in page 2.T.AnzaiT.Anzai

DESCRIPTION

CHECK

DATE

H.Hasegawa

APPR

Y. Ta k a s h i m a

T. Anzai

Mar. 27, 02

DESIG

DESIG.

CUST.

H.Hasegawa

H.Hasegaw

CHECK

fi-4220C IMAGE SCANNER

ILLUSTRATED PARTS CATALOGUE

APPR.

TITLE

DRAW.

No.

4/16

Mar.19,02

CONTENTS

A. fi-4220C Page

FIGURE 1 FINAL ASSEMBLY.................................................................................................................................................................................. 5

FIGURE 2 BASE UNIT ............................................................................................................................................................................................ 7

FIGURE 3 UPPER UNIT .......................................................................................................................................................................................... 9

FIGURE 4 PCA, COVER AND CHUTE................................................................................................................................................................ 11

FIGURE 5 FLATBED................................................................................................................................................................................................. 13

B. LIST OF STANDARD FASTENERS

TABLE B.1 LIST OF THE FASTENER ................................................................................................................................................................... 15

FIGURE B.1 TP SCREW .......................................................................................................................................................................................... 15

FIGURE B.2 MACHINE SCREW WITH WASHER.............................................................................................................................................. 15

FIGURE B.3 RETAINING RING (E-RING) ........................................................................................................................................................... 16

FIGURE B.4 PT SCREW .......................................................................................................................................................................................... 16

FIGURE B.5 SCREW................................................................................................................................................................................................. 16

Rev

PAGE

PFU LIMITED

P4PA03289-B50X/6

See revision record in page 2.

T,Anzai

Apr 12,02 T.Anzai

See revision record in page 2.T.AnzaiT.Anzai

DESCRIPTION

CHECK

DATE

H.Hasegawa

APPR

Y. Ta k a s h i m a

T. Anzai

Mar. 27, 02

DESIG

DESIG.

CUST.

H.Hasegawa

H.Hasegaw

CHECK

fi-4220C IMAGE SCANNER

ILLUSTRATED PARTS CATALOGUE

APPR.

TITLE

DRAW.

No.

5/16

Mar.19,02

FIGURE 1. FINAL ASSEMBLY

Rev

PAGE

PFU LIMITED

P4PA03289-B50X/6

See revision record in page 2.

T,Anzai

Apr 12,02 T.Anzai

See revision record in page 2.T.AnzaiT.Anzai

DESCRIPTION

CHECK

DATE

H.Hasegawa

APPR

Y. Ta k a s h i m a

T. Anzai

Mar. 27, 02

DESIG

DESIG.

CUST.

H.Hasegawa

H.Hasegaw

CHECK

fi-4220C IMAGE SCANNER

ILLUSTRATED PARTS CATALOGUE

APPR.

TITLE

DRAW.

No.

6/16

Mar.19,02

INDEX

NO.

CONPOSITION &

QUANTITY SPECIFICATION DESCRIPTION

101

102

103

105

106

107

108

PA03289-D901

PA03289-D903

PA03289-E905

PA03289-K004

BASE UNIT

UPPER UNIT

CHUTE UNIT

(See Fig,4)

PANEL PCA

(See Fig.4)

(See Fig.5)

FIGURE 1. FINAL ASSEMBLY

Rev

PAGE

PFU LIMITED

P4PA03289-B50X/6

See revision record in page 2.

T,Anzai

Apr 12,02 T.Anzai

See revision record in page 2.T.AnzaiT.Anzai

DESCRIPTION

CHECK

DATE

H.Hasegawa

APPR

Y. Ta k a s h i m a

T. Anzai

Mar. 27, 02

DESIG

DESIG.

CUST.

H.Hasegawa

H.Hasegaw

CHECK

fi-4220C IMAGE SCANNER

ILLUSTRATED PARTS CATALOGUE

APPR.

TITLE

DRAW.

No.

7/16

Mar.19,02

FIGURE 2. BASE UNIT

Rev

PAGE

PFU LIMITED

P4PA03289-B50X/6

See revision record in page 2.

T,Anzai

Apr 12,02 T.Anzai

See revision record in page 2.T.AnzaiT.Anzai

DESCRIPTION

CHECK

DATE

H.Hasegawa

APPR

Y. Ta k a s h i m a

T. Anzai

Mar. 27, 02

DESIG

DESIG.

CUST.

H.Hasegawa

H.Hasegaw

CHECK

fi-4220C IMAGE SCANNER

ILLUSTRATED PARTS CATALOGUE

APPR.

TITLE

DRAW.

No.

8/16

Mar.19,02

INDEX

NO.

CONPOSITION &

QUANTITY SPECIFICATION DESCRIPTION

*101

202

203

204

205

206

207

208

*210

*212

214

216

217

*220

221

224

225

226

227

228

*230

232

PA03289-D901

PA49001-0377

PA03277-Y237

PA55001-0011

PA03289-E903

PA70002-0922

PA03289-E906

PA03289-Y041

PA03289-K006

PA03289-Y090

PA03951-0305

PA70002-0924

BASE UNIT

COVER OPEN SENSOR

BUSHING

LAMP INVERTER

OPTICAL UNIT

CCD CABLE F

DUST COVER ASY

WHITE SHEET

LAMP

HK RING L2

SENSOR PTR

SE CABLE F

INDEX

NO.

CONPOSITION &

QUANTITY SPECIFICATION DESCRIPTION

*234

236

*237

238

*240

PA03289-E901

PA03289-Y051

PA03289-0001

PA03289-Y058

PA03289-E902

GUIDE A ASY

PICK SHAFT

PICK ROLLER

PICK GEAR

GUIDE P ASY

FIGURE 2. BASE UNIT FIGURE 2. BASE UNIT

Rev

PAGE

PFU LIMITED

P4PA03289-B50X/6

See revision record in page 2.

T,Anzai

Apr 12,02 T.Anzai

See revision record in page 2.T.AnzaiT.Anzai

DESCRIPTION

CHECK

DATE

H.Hasegawa

APPR

Y. Ta k a s h i m a

T. Anzai

Mar. 27, 02

DESIG

DESIG.

CUST.

H.Hasegawa

H.Hasegaw

CHECK

fi-4220C IMAGE SCANNER

ILLUSTRATED PARTS CATALOGUE

APPR.

TITLE

DRAW.

No.

9/16

Mar.19,02

FIGURE 3. UPPER UNIT

Rev

PAGE

PFU LIMITED

P4PA03289-B50X/6

See revision record in page 2.

T,Anzai

Apr 12,02 T.Anzai

See revision record in page 2.T.AnzaiT.Anzai

DESCRIPTION

CHECK

DATE

H.Hasegawa

APPR

Y. Ta k a s h i m a

T. Anzai

Mar. 27, 02

DESIG

DESIG.

CUST.

H.Hasegawa

H.Hasegaw

CHECK

fi-4220C IMAGE SCANNER

ILLUSTRATED PARTS CATALOGUE

APPR.

TITLE

DRAW.

No.

10/16

Mar.19,02

INDEX

NO.

CONPOSITION &

QUANTITY SPECIFICATION DESCRIPTION

343

344

346

348

350

351

352

*353

*210

*212

*220

*106

PA03289-Y044

PA70002-0923

PA03289-Y531

PA03289-Y005

PA03289-Y003

PA03289-Y006

PA03289-Y004

PA03289-0002

PA03289-0003 03

PA55001-0011

PA03289-E903

PA03289-K006

PA03289-K004

PA03289-K003 02

ROLLER COVER1

BS CABLE

UPPER COVER

PANEL COVER

LED PIPE

FILTER

ADF BUTTON

PAD ASY

LAMP INVERTER

OPTICAL UNIT

LAMP

PANEL PCA

FIGURE 3. UPPER UNIT FIGURE 3. UPPER UNIT

INDEX

NO.

CONPOSITION &

QUANTITY SPECIFICATION DESCRIPTION

*102

*302

304

217

306

307

308

320

208

322

323

324

326

327

328

*330

331

332

333

*336

*337

340

341

PA03289-D903

PA03289-E907

PA03289-Y041

PA03289-Y065

PA03289-Y045

PA03277-Y237

PA03289-Y030

PA03289-Y029

PA03289-Y052

PA03289-Y023

PA03951-0293

PA03289-Y061

PA03951-0310

PA03289-F901

PA03951-0306

PA70002-0926

UPPER UNIT

UPPER ASY

WHITE SHEET

SIDE COVER

ROLLER COVER 2

BUSHING

PULLEY

GEAR

PAD SPRING

PAD PLATE

ADF MOTOR UNIT

COLLAR

ADF BELT

SENSOR ASY B

SENSOR LED

FG CABLE

Otros manuales para FI 4220C - Document Scanner

Tabla de contenidos

Otros manuales de Escáner de Fujitsu

Fujitsu

Fujitsu ScanSnap iX100 Manual de usuario

Fujitsu

Fujitsu Fujitsu fi-5950 Manual de usuario

Fujitsu

Fujitsu ScanSnap S1300i Manual de usuario

Fujitsu

Fujitsu C150-E146-02EN Manual

Fujitsu

Fujitsu M3097DE Guía de configuración

Fujitsu

Fujitsu ScanSnap iScanner fi-6010N Manual de usuario

Fujitsu

Fujitsu ScanSnap FI-4110EOX2 Manual

Fujitsu

Fujitsu S510 - ScanSnap - Document Scanner Manual

Fujitsu

Fujitsu ScanPartner 620C Manual de usuario

Fujitsu

Fujitsu fi-5650C Guía de configuración

Fujitsu

Fujitsu Fi-5110EOX2 - ScanSnap! - Document Scanner Manual de usuario

Fujitsu

Fujitsu FI 6140 - Document Scanner Manual de usuario

Fujitsu

Fujitsu fi-5650C Manual de usuario

Fujitsu

Fujitsu S510M - ScanSnap - Document Scanner Manual

Fujitsu

Fujitsu ScanSnap iX500 Manual de usuario

Fujitsu

Fujitsu i-4990C Manual

Fujitsu

Fujitsu ScanPartner 15C Manual de usuario

Fujitsu

Fujitsu FI-4120C Guía de referencia

Fujitsu

Fujitsu M3092DC Manual de usuario

Fujitsu

Fujitsu SCANSNAP iX1300 Manual de usuario

Fujitsu

Fujitsu PA03630-B055 Manual de usuario

Fujitsu

Fujitsu ScanPartner FI-4110CU Manual

Fujitsu

Fujitsu fi-6000N Guía de configuración

Fujitsu

Fujitsu FI-4860C2 Manual de usuario

Manuales populares de Escáner de otras marcas

Plustek

Plustek Scanner Manual de usuario

Z/I Imaging

Z/I Imaging PhotoScan 2001 Manual de usuario

Renkforce

Renkforce DS100-5M Manual de usuario

Image Access

Image Access WideTEK A2 Manual de usuario

Canon

Canon imageFORMULA CR-120N Manual de usuario

GeoSlam

GeoSlam ZEB Horizon Instrucciones de instalación

Kodak

Kodak i5800 Scanner Manual de usuario

Kodak

Kodak i7300 Manual de usuario

Revopoint

Revopoint POP Manual de usuario

Eddyfi Technologies

Eddyfi Technologies Floormap X Manual de usuario

Faselase

Faselase F6 Manual de usuario

Uniden

Uniden BC340CRS Manual de usuario

Infinite Peripherals

Infinite Peripherals INFINEA TAB M Manual de usuario

Mustek

Mustek PageExpress 4800 Pro Manual de usuario

Optex

Optex 750830 Manual de usuario

Innova

Innova 5210 Manual de usuario

Visioneer

Visioneer CardReader 100 Guía de inicio rápido

Rohde & Schwarz

Rohde & Schwarz TSME6 Manual de usuario
