FujiFilm GFX 50s Manual de usuario

New Features Guide

Version 4.30

Features added or changed as a result of rmware updates may no

longer match the descriptions in the documentation supplied with

this product. Visit our website for information on the updates avail-

able for dierent products:

https://fujifilm-x.com/support/download/firmware/cameras/

BL00005183-201 EN

Contents

GFX 50S rmware version 4.30 adds or updates the features

listed below. For the latest manuals, visit the following

website.

http://fujifilm-dsc.com/en/manual/

No. Description GFX 50S

See

PVer.

1A ZFOCUS BKT item has been added to drive

modes. 7, 81 1, 8 3.00

The camera now displays the color temperature

selected via the color temperature option in the

white balance menu.

12, 14 2, 3 4.00

The camera now displays an external power sup-

ply icon when drawing power from an optional

AC-15V AC power adapter.

12, 14 2, 3 4.00

An EEYE SENSOR + LCD IMAGE DISP. op-

tion has been added to the displays accessible via

the VIEW MODE button.

16 4 2.00

The focus stick can be used to change focus areas

when the display is zoomed in during checking

focus.

69 5 4.00

6The focus stick can be used to change focus areas

when the display is zoomed in during MF assist. 73 6 4.00

AUTO1, AUTO2, and AUTO3 ISO sensitivity op-

tions are now available when the sensitivity dial is

rotated to C(command).

74 7 4.00

The maximum number of pictures that can be

stored in a single folder has changed from 9,999

to 999.

82 8 4.00

gCLASSIC Neg. and XETERNA/CINEMA

options have been added to HIMAGE QUALITY

SETTING > FILM SIMULATION in the shooting

menu.

88 9 4.00

No. Description GFX 50S

See

PVer.

A SMOOTH SKIN EFFECT item has been added

to HIMAGE QUALITY SETTING in the shoot-

ing menu.

89 10 4.00

A LOW LIGHT PRIORITY AF-S item has been

added to GAF/MF SETTING in the shooting

menu.

98 10 4.00

Improved the performance of GAF/MF

SETTING> FACE/EYE DETECTION SETTING

in the shooting menu.

100 11 4.00

13 A FOCUS BKT item has been added to

ASHOOTING SETTING in the shooting menu. 106

3.00

The ASHOOTING SETTING > FOCUS BKT

item in the shooting menu now oﬀers a choice of

MANUAL and AUTO focus bracketing options.

106 4.00

A FLICKER REDUCTION option has been add-

ed to ASHOOTING SETTING in the shooting

menu.

109 15 3.10

The 35mm FORMAT MODE option in the

shooting menu has been moved to the top level

of the ASHOOTING SETTING menu. 35mm

FORMAT MODE can now be used even without

a mount adapter.

111 15 3.30

The procedure for rating pictures has changed. As

a result, the content of the playback information

displays has changed and a RATING item has

been added to the playback menu.

120,

121,

136

16,

17, 18 4.00

18 A SIMULTANEOUS DELETE(RAW SLOT1/JPG

SLOT2) item has been added to playback menu. 130 18 3.30

The options available for DSCREEN SET-UP>

EVF BRIGHTNESS> MANUAL in the setup

menu now range from +5 to −7.

153 19 2.00

20 An EVF COLOR ADJUSTMENT option has been

added to DSCREEN SET-UP in the setup menu. 153 19 3.30

No. Description GFX 50S

See

PVer.

21 An LCD COLOR ADJUSTMENT option has been

added to DSCREEN SET-UP in the setup menu. 153 19 3.30

LARGE INDICATORS MODE(EVF) and LARGE

INDICATORS MODE(LCD) options have been

added to DSCREEN SET-UP in the setup menu.

159 20, 21 3.10

A LARGE INDICATORS DISP. SETTING option

has been added to DSCREEN SET-UP in the

setup menu.

159 22 3.10

An oS.S. OPERATION option has been add-

ed to DBUTTON/DIAL SETTING in the setup

menu.

164 23 2.00

A SHOOTWITHOUT CARD option has been added

BUTTON/DIAL SETTING in the setup menu.

165 23 2.00

An APERTURE SETTING option has been added

BUTTON/DIAL SETTING in the setup menu.

166 24 4.30

27 A SELECT FOLDER option has been added to

DSAVE DATA SET-UP in the setup menu. 171 24 3.20

ACCESS POINT SETTINGS and IP ADDRESS

options have been added to DCONNECTION

SETTING> WIRELESS SETTINGS in the setup

menu.

172 25 1.10

Thecontentsof the setup menuDCONNECTION

SETTING> PC CONNECTION SETTING

item have been moved to DCONNECTION

SETTING> WIRELESS SETTINGS> ACCESS

POINT SETTINGS.

173 25 1.10

30 An INFORMATION option has been added to

DCONNECTION SETTING in the setup menu. 174 25 1.10

No. Description GFX 50S

See

PVer.

A WIRELESS FIXED option has been added

to DCONNECTION SETTING> PC SHOOT

MODE in the setup menu.

174

1.10

The DCONNECTION SETTING> PC SHOOT

MODE option in the setup menu has changed to

PC CONNECTION MODE.

174 2.00

The software that can be used with the

CONNECTIONSETTING> PC CONNECTION

MODE option in the setup menu has changed.

174 4.00

The procedure for adjusting aperture has been

changed to accommodate lenses not equipped

with aperture rings.

189 28, 29 4.30

35 Third-party studio ﬂash commanders compatible

with the FUJIFILM ﬂash system can now be used. 198 30 2.00

In addition to the instax SHARE printers listed in

“Accessories from FUJIFILM”, the camera now sup-

ports the SP-3.

220 30 2.00

The camera can now be used to update the ﬁrm-

ware not only for lenses but also for such option-

al accessories as shoe-mounted ﬂash units and

mount adapters.

232 — 1.10

Changes and Additions

Changes and additions are as follows.

GFX 50S Owner’s Manual: P7 Ver. 3.00

The Drive Button

Pressing the drive button displays the fol-

lowing drive mode options.

Mode

BSTILL IMAGE (single frame)

ICONTINUOUS (burst mode)

OAE BKT (exposure bracketing)

WISO BKT (sensitivity bracketing)

XFILM SIMULATION BKT

(lm simulation bracketing)

Mode

VWHITE BALANCE BKT

(white balance bracketing)

YDYNAMIC RANGE BKT

(dynamic range bracketing)

ZFOCUS BKT (focus bracketing) 8

jMULTIPLE EXPOSURE

FMOVIE

GFX 50S Owner’s Manual: P12 Ver. 4.00

The Electronic Viewnder

1.0

GRIP

-1

-2

-3

-4

-5

01/01/2017 12:00 AM

GWhen a color temperature is selected for white balance

(GFX 50S Owner’s Manual P92), the chosen value now ap-

pears in the display.

kThe camera now displays an external power supply icon

when drawing power from an optional AC-15V AC power

adapter.

GFX 50S Owner’s Manual: P14 Ver. 4.00

The LCD Monitor

GRIP

01/01/2017 12:00 AM

OWhen a color temperature is selected for white balance

(GFX 50S Owner’s Manual P92), the chosen value now ap-

pears in the display.

jThe camera now displays an external power supply icon

when drawing power from an optional AC-15V AC power

adapter.

GFX 50S Owner’s Manual: P16 Ver. 2.00

Choosing a Display Mode

Press the VIEW MODE button to cycle

through the following display modes:

• EEYE SENSOR: Putting your eye to the

viewnder turns the viewnder on and

the LCD monitor o; taking your eye

away turns the viewnder o and LCD

monitor on.

• EVF ONLY: Viewnder on, LCD monitor o.

• LCD ONLY: LCD monitor on, viewnder o.

• EVF ONLY + E: Putting your eye to the viewnder turns the view-

nder on; taking it away turns the viewnder o. The LCD mon-

itor remains o.

• EEYE SENSOR + LCD IMAGE DISP.: Putting your eye to the viewnder

during shooting turns the viewnder on, but the LCD monitor is

used for the display of images once you remove your eye from

the viewnder after shooting.

GFX 50S Owner’s Manual: P69 Ver. 4.00

Focus-Point Selection

Checking Focus

To zoom in on the current focus area for precise

focus, press the control to which focus zoom

has been assigned (at default settings, the cen-

ter of the rear command dial). Press the control

again to cancel zoom.

Normal display Focus zoom

In focus mode S, zoom can be adjusted by rotating the rear command

dial. Focus area selection using the focus stick is available during focus

zoom. Focus zoom is not available in focus mode Cor when GAF/MF

SETTING> PRE-AF is on or an option other than rSINGLE POINT is

selected for AF MODE.

To assign focus zoom to a control, select FOCUS CHECK for

DBUTTON/DIAL SETTING> FUNCTION (Fn) SETTING.
