FS IES3100-8T4F-P Manual de usuario
L2+ MANAGED INDUSTRIAL SWITCH
L2+ MANAGED INDUSTRIAL SWITCH
SWITCH INDUSTRIEL MANAGEABLE L2+
IES3100-8T4F-P
Quick Start Guide V1.0
Quick Start Anleitung
Guide de Démarrage Rapide
PWR1
48-57V DC
PWR2
11
8
12
IES3100-8T4F-P PoE+
CLI
IES3100-8T4F-P PoE+
11
8
12
CLI
EN
1
Introduction
Accessory
Thank you for choosing IES3100-8T4F-P L2+ Managed Industrial Switch. This guide is designed to
familiarize you with the layout of the switch and describes how to deploy it in your network.
IES3100-8T4F-P
Console Cable x1
NOTE: IES3100-8T4F-P switch is equipped with dust plugs.
EN
2
Hardware Overview
Ports Description
SFP
RJ45
SFP port for 1G connection
CLI An RJ45 console port for serial management
10/100/1000BASE-T ports for Ethernet connection
Front Panel Ports
IES3100-8T4F-P PoE+
11
8
12
CLI
RJ45
SFP
CLI
IES3100-8T4F-P PoE+
11
8
12
CLI
RJ45
SFP SYS
PWR
Front Panel LEDs
EN
3
DescriptionLEDs
PWR
State
On
On
On
On
Blinking
Off
Off
Off
Off
Off
Yellow. PoE
Green: Link/Act
Blinking
Blinking
Power is being supplied to power input.
Power is not being supplied to power input.
The system is ready for operation.
No supply voltage or the system is not ready for
operation.
A PoE terminal device is connected and
receiving power via PoE.
No PoE port is available or power over
Ethernet function is disabled.
The port is linked.
The port is linked.
The port is transmitting the data.
The port is transmitting the data.
The port is not linked.
The port is not linked.
SYS
RJ45
SFP
Upper Panel
PWR1
48-57V DC
PWR2
Grounding Point Terminal Block Connector
EN
4
Back Panel
DIN Rail Mounting Clip
NOTE: It is recommended to use Internet Explorer 8.0 or above to access the switch. If the
web interface of the Industrial Managed Switch is not accessible, please turn off the
anti-virus software or firewall and then try it again.
Installation Requirements
Before you begin the installation, make sure that you have the following:
Workstations running Windows XP/2003/2008/Vista/7/8/10, MAC OS X or later, Linux, UNIX, or
other platforms compatible with TCP/IP protocols.
Workstations are installed with Ethernet NIC (Network Interface Card).
Serial Port Connection (Terminal)
The above Workstations come with COM Port (DB9) or USB-to-RS232 converter.
The above Workstations have been installed with a terminal emulator, such as HyperTerminal
included in Windows XP/2003.
Serial cable -- one end is attached to the RS232 serial port, while the other ends to the RJ45 console
port of the switch.
Ethernet Port Connection
Network cables -- Use standard network (UTP) cables with RJ45 connectors.
The above PC is installed with Web browser.
EN
5
1. Grip the top of the DIN rail mounting clip onto the edge of the DIN rail.
2. Press the bottom of the clip onto the other side of the DIN rail.
3. Push the bottom of the clip outwards to remove it easily.
Mounting the Switch
DIN-Rail Mounting
Mounting the unit Releasing the unit
1. Connect one end of the grounding cable to a proper earth ground.
2. Secure the grounding lug to the grounding point on the switch upper panel with the screw and
washers.
Grounding the Switch
PWR1
48-57V DC
PWR2
PWR1
48-57V DC
PWR2
EN
6
Connecting the SFP Ports
1. Connect an Ethernet cable to the RJ45 port of a camera, outdoor AP, computer or another network
device.
2. Connect the other end of the Ethernet cable to the RJ45 port of the switch.
Connecting the RJ45 Ports
PWR1
48-57V DC
PWR2
11
8
12
IES3100-8T4F-P PoE+
CLI
PWR1
48-57V DC
PWR2
11
8
12
IES3100-8T4F-P PoE+
CLI
CAUTION: The earth connection must not be removed unless all supply connections have
been disconnected.
1. Remove the dust plugs first.
EN
7
Connecting the Console (CLI) Port
1. Insert the RJ45 connector into the RJ45 console port on the front of the switch.
2. Connect the DB9 female connector of the console cable to the serial port on the computer.
The upper panel of the switch indicates a DC inlet power socket and consists of one terminal block
connector within 5 contacts. Please follow the steps below to insert the power wire.
Connecting the Power
PWR1
48-57V DC
PWR2
PWR1
48-57V DC
PWR2
2. Plug the compatible SFP transceiver into the SFP port.
3. Connect a fiber optic cable to the fiber transceiver. Then connect the other end of the cable to
another fiber device.
PWR1
48-57V DC
PWR2
11
8
12
IES3100-8T4F-P PoE+
CLI
EN
8
Single DC (48-57VDC) Input
1. Insert positive/negative DC power wires into Contacts 1 and 2 for PWR1.
2. Tighten the wire-clamp screws for preventing the wires from loosening.
Dual Redundant DC (48-57VDC) Input
1. Insert positive/negative DC power wires into Contacts 1 and 2 for PWR1 and Contacts 5 and 4 for
PWR2.
2. Tighten the wire-clamp screws for preventing the wires from loosening.
Positive
Negative
Requiring good ground connection
NameNo. Description
+1
2
3
1
V1+ V1-
PWR1 PWR2
V2- V2+
2 3 4 5
1
V1+ V1-
PWR1 PWR2
V2- V2+
2 3 4 5
EN
9
NOTE: The wire gauge for the terminal block should be in the range from 12 to 16 AWG.
Pin 2 / 4
Positive (+) Pin Negative (-) Pin
Pin 1 / 5
Step1: Connect a computer to the console port of the switch with the console cable.
Step2: Start the terminal simulation software, such as HyperTerminal on the computer.
Step3: Set the parameters of the HyperTerminal: Baud rate to 115200, Data bits to 8, Parity to None,
Stop bits to 1.
Configuring the Switch
Configuring the Switch Using the Console Port
x
Quick Connect
Protocol: Serial
Flow Control
DTR/DSR
RTS/CTS
XON/XOFF
Save sessionShow quick connect on startup
The port may be manually entered or selected from the list.
Open in a tab
Cancel
COM3
115200
8
None
1
Port:
Baud rate:
Data bits:
Parity:
Stop bits:
Name of pipe:
Connect
Step4: After setting the parameters, click Connect to enter.
