Frigidaire FRT185BS Manual de usuario

PRODUCT NO. BASE MODEL NO. COLOR VOLTS

FRT185BSB0 FRT185BS stainless (RH) 115

FRT185BSK0 FRT185BS stainless (LH) 115

MARKET

North America

Publication No.

5995387585

030318

-EN/SERVICE /ECL

390

TOP MOUNT

REFRIGERATOR

Model No.

FRT185BS

FACTORY

PARTS CATALOG

ELECTROLUX HOME PRODUCTS,INC.

P.O. Box 212378, Augusta, GA 30917

ENERGY GUIDE - 218791428

OWNER’S GUIDE - 240400108

SERVICE DATA SHEET - 240379010

03/03 2

Publication No. FRT185BS

5995387585

DOOR

# = Fast-moving Parts 3 03/03

* = Non-Illustrated Parts

FRT185BS Publication No.

5995387585

A = FRT185BS (FRT185BSB0)

B = FRT185BS (FRT185BSK0)

POS. NO PART NO DESCRIPTION

1 # 240542109 A B Gasket-frzr door,black ,magnetic

2 # 240542112 A B Gasket-refr door,black ,magnetic

7 240337703 A B Door-dairy,w/o graphics ,clear

11 240412503 A - Door-frzr,stainless ,complete assy

11 240412504 - B Door-frzr,stainless ,complete assy

12 240416304 A B Nameplate,black

13 240312405 A B Door Stop,black ,refr

13A 240312406 A B Door Stop,black ,frzr

15 240412603 A - Door-refr,stainless ,complete assy

15 240412604 - B Door-refr,stainless ,complete assy

18 218668003 A B Handle-door,black

21 240383401 A B Screw,truss hd quad ,#10-16 x .500

21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500

22 240527102 A B Bearing-hinge,black

37A 215870636 A B Trim-handle,2.47" ,black ,w/satin AL band

37A* 218676004 A B Band-decorative,satin aluminum ,handle trim

48 240338101 A B Bin-door,pseudo ,bottom

48A 240337901 A B Bin-door,refr

48B 240338001 A B Bin-door,pseudo ,gallon ,refr

49 240495804 A B Bin-door,pseudo ,frzr

* 218490900 A B Cleaner,stainless steel

DOOR

03/03 4

Publication No. FRT185BS

5995387585

CABINET

# = Fast-moving Parts 5 03/03

* = Non-Illustrated Parts

FRT185BS Publication No.

5995387585

A = FRT185BS (FRT185BSB0)

B = FRT185BS (FRT185BSK0)

POS. NO PART NO DESCRIPTION

1 240355401 A B Cover-fan

2 240367001 A B Knob-damper control

3 5303001028 A B Nut,push-on

4 240367401 A B Damper-fan cover

5 # 5308000010 A B Fan Blade,red ,evaporator fan

8 5300157666 A B Bushing-motor mtg,(2)

9 5303292396 A B Bracket-motor mtg,front

10 240462010 A B Cover-evap coil

10* 240568601 A B Seal-coil cover

10* 240524701 A B Wiring Harness,freezer section

11 5303208309 A B Plug-hole,factory test

13 # 240369701 A B Motor-evap fan

13* 215474201 A B Washer,"slinger" ,nylon ,evap fan shaft

13* 218931001 A B Clamp-motor wiring,nylon ,w/adhesive tape

14 5303292397 A B Bracket-motor mtg,rear

18 240411901 A B Support-evap cover,(2)

21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500

22 215774918 A B Plug-button,black ,upr hinge holes

28 240335501 A B Bolt-roller adj,hex washer head ,1/4-20 x 4.020,(2) ,special

30 240314003 A B Bracket-lower hinge,black

34 240311301 A B Washer,hinge ,nylon ,(2)

35 240313803 A B Bracket-ctr hinge,black

35A 240336801 A B Spacer-hinge,center

36 240516401 A B Pin-center hinge

37 240337603 A B Trim-cabinet corner,black ,(2)

38 240313701 A B Bracket-upper hinge

40 240354404 A B Cover-upper hinge,black

41 5303001609 A B Grommet,shelf mtg ,0.69" ,RH

41* 5308009759 A B Grommet,shelf mtg ,1.25" ,LH

42 240423601 A B Screw-hinge mtg,hex head ,1/4-20 x 0.75

43 240335003 A B Roller Assy,front ,(2)

47 218233300 A B Channel-shelf mtg,side ,(2)

48 5303292395 A B Channel-shelf mtg,center

49 218362500 A B Screw,hex washer head ,8-18AB x 1.250

56 240516501 A B Pin-lower hinge

58 5303001343 A B Screw,hex washer head ,8-15A x 0.500

59 240442703 A B Screw-#10-32 X 3/4,black

72 240368207 A B Grille/Kickplate,black

81 5308016566 A B Screw,hex washer head ,8-15A x 0.625 ,low profile

82 5304418225 A B Roller,compressor base ,rear ,(2)

83 5303316859 A B Rivet,flat head ,1/4 OD x 1-3/4 ,roller pin

89 240326115 A B Cover-access,with label

89* 241500302 A B Screw,hex washer head ,8-18AB x 0.625

92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875

* 5303305345 A B Paint,touch-up ,black

* 218515401 A B Clip

CABINET

03/03 6

Publication No. FRT185BS

5995387585

SHELVES

# = Fast-moving Parts 7 03/03

* = Non-Illustrated Parts

FRT185BS Publication No.

5995387585

A = FRT185BS (FRT185BSB0)

B = FRT185BS (FRT185BSK0)

POS. NO PART NO DESCRIPTION

11 240358002 A B Shelf-freezer,full width

11* 5303299664 A B Spacer,shelf

12 240545001 A B Diffuser,air ,top

13 240362601 A B Diffuser,air ,bottom

14 # 240505801 A B Switch,light/lamp

15 240436702 A B Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature

16 # 241500701 A B Socket-light/lamp

17 240352701 A B Control Box

17*# 240388701 A B Wiring Harness,control box

18 240360801 A B Knob,temp control

21 5304421256 A B Control,temperature

22A 240468201 A B Tube,sensor sleeve ,31 inch ,plastic ,white

23 # 215846606 A B Timer,defrost ,60 Hz ,0.25 W ,120 V ,10 hour/30 min

23* 5303001259 A B Screw-timer mtg,pan hd ,6-20 x 0.438 ,(2)

24 240355210 A B Shelf-"Spill-Safe",fixed

25 240364714 A B Cover-crisper pan

25B 240361201 A B Control-humidity

25C 240361301 A B Damper,humidity cont.

26 240337103 A B Pan-crisper,clear ,(2) ,no graphics

31 240530803 A B Pan-meat,w/o graphics ,clear

34 240385201 A B Container,ice bin

42 240356501 A B Track,meat pan hanger ,RH

42 240365401 A B Track,meat pan hanger ,LH

47 240350643 A B Insert-pan cover,glass

81 5308016566 A B Screw,hex washer head ,8-15A x 0.625 ,low profile

123 215005100 A B Screw,hanger/rlr mtg ,8-10 x 0.438

* 218791428 A B Energy Guide

SHELVES

03/03 8

Publication No. FRT185BS

5995387585

SYSTEM

# = Fast-moving Parts 9 03/03

* = Non-Illustrated Parts

FRT185BS Publication No.

5995387585

A = FRT185BS (FRT185BSB0)

B = FRT185BS (FRT185BSK0)

POS. NO PART NO DESCRIPTION

1 240444401 A B Condenser,dynamic

4 # 218944001 A B Drier-filter,R134a System

6 240496101 A B Wiring Harness,machine compt ,w/electric cord

6* # 240524701 A B Wiring Harness,freezer section

6* # 240388701 A B Wiring Harness,control box

14 # 5303918208 A B Defrost Heater Kit

15 # 5303918274 A B Evaporator Kit

16 5308000110 A B Strap-evap/heater,aluminum ,(2)

17 240434002 A B Trough-drain

20 240518402 A B Insulation,evap block ,foam ,LH/RH

21 # 5303918202 A B Thermostat-defrost,kit

22 240330001 A B Plate-compr mtg

22* 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500

23 218513300 A B Grommet-compr mtg,(4)

25 240491501 A B Screw-comp,hx wshr hd ,1/4-28 x 1.16,shoulder,typ CF

26 240332605 A B Pan-defrost drain

29 # 5303918264 A B Compressor,w/electricals

30 # 218721120 A B Starter,PTC

32 240493301 A B Clamp,elec cont mtg ,compressor ,bale wire

34 240405201 A B Grommet,rubber ,black ,cond tube/wire

41 240433202 A B Screw,hex washer head ,8-18 x 5/16

44 5303001199 A B Clamp-wiring harness,strain relief ,galv steel

45 5308016566 A B Screw,hex washer head ,8-15A x 0.625 ,low profile

55 # 218909901 A B Capacitor,run ,50/60 Hz ,220 VAC ,15 microfarad

57 240542601 A B Clip-wiring harness

58 218897002 A B Screw,hex washer head ,8-32 x 0.375

59 5304430246 A B Bracket-cond motor assy

59* 240346701 A B Tape-foam seal,shroud

59* 240359401 A B Screw-fan shroud,(2)

60 # 240525401 A B Motor-condenser fan

61 # 240524101 A B Fan Blade,galv steel ,condenser fan

82 5304418225 A B Roller,compressor base ,rear ,(2)

83 5303316859 A B Rivet,flat head ,1/4 OD x 1-3/4 ,roller pin

84 240500801 A B Tube-drain,rubber ,lower

85 240493101 A B Tube-connector,suction

* 240396801 A B Clamp,tube/wiring ,nylon ,black/natural

* # 5303918207 A B Heat Exchanger Kit,suction line

* 5303918222 A B Hot Tube Repair Kit,Service

SYSTEM

03/03 10

Publication No. FRT185BS

5995387585

ICE MAKER
