Frigidaire FES387CH Manual de usuario

PRODUCT NO. FACTORY NO. COLOR MARKET

FES387CHSA 37956396G9011 WHITE U.S.A.

ELECTRIC - RANGE

Model No.

FES387CH

Inc.

FACTORY PARTS CATALOG

SLIDE-IN RANGE

WIRING DIAGRAM # - 318045025

OWNER’S GUIDE # - 318200813

TIMER INSTRUCTION GUIDE # - 318130805

INSTALLATION INSTR. # - 318104602

FRIGIDAIRE HOME PRODUCTS

7075 ORDAN DRIVE

MISSISSAUGA, ONTARIO

CANADA, L5T 1K6

TEL: (905) 565-9200 Publication No.

5995323754

990518

-EN/SERVICE

377

HOTSURFACE

WARMING ZONE

OVENLIGHT

LEFTFRONT LEFTREAR RIGHTFRONTRIGHT REAR SURFACESURFACE

BAKE

TIME STOP

TIME CLOC CANCECLEA BROIL

TIMER

ON/OFF

PRE-

HEATBAKE

TEM

SELF-CLEANINGCONVECTIONOVEN

Galler

DUALRADIANT BAKING AND ROASTING

WARM & SER VE

ZONE

OFF HI

MED

Publication No. FES387CHS

5995323754

05/99 2

BACKGUARD

LAP23G0047D

13A

18A

102

64 18

36A

36 42

2424

24B

24B 46

FES387CHS Publication No.

5995323754

# = Functional Part 305/99

* = Non-Illustrated Part

BACKGUARD

POS. NO PART NO DESCRIPTION

13A 316095500 ASwitch-warmer infinite

14 5303051533 ALight/Lamp

18 5303304668 AEnd Cap white RH

18A 5303304671 AEnd Cap white LH

19 318005550 APanel-control

20 # 318012901 AClock/Timer

21 318027804 ATrim-backguard

23 318015020 ABracket-clock mtg

24 # 316005607 ASwitch-rocker white

24B# 316076301 ASwitch-rocker white

36 318016300 AKnob-surface unit white

36A 318165101 AKnob-warmer white

42 318106904 ATrim-vent

46 5308006417 ALens-light/lamp

54 # 318120501 ASwitch-surface unit

64 318112200 APlate

69 5303323134 AScrew mtg 8-32 X 3/16

102 318055601 ABracket-mounting

*5303211311 AScrew, #8 X ½

*08016432 AScrew, 8-18 X 3/8

*5303323145 ANut

*5303311124 AScrew, clock

A= FES387CH (FES387CHSA)

FES387CHS Publication No.

5995323754

05/99 4

BODY

222

170

170A

102

191

LAP23V0072G

58B

142

58A

89 108

141

127

129

128

114

54 15 16

125

76 41

217

107

102

177

FES387CHS Publication No.

5995323754

# = Functional Part 505/99

* = Non-Illustrated Part

BODY

POS. NO PART NO DESCRIPTION

1 5303310527 ABack-main

1A 318070901 A Panel-back

2A 318108600 AShield-oven top

3 5303300143 APanel-bodyside

3A 318160004 APanel-bodyside RH

3B 318160005 APanel-bodyside LH

5 318175503 AScrew-leveling

6 5303310522 ARack-oven

6A 5303311206 ARack, broiler pan

9 5303317977 APan-broiler

10 5303317976 AInsert-broiler pan

12 # 318089910 ASwitch-light

14 5308011085 ASocket-light/lamp

15 3201908 ALamp-oven light

16 3201911 AGlass-oven light lens

17 5304400195 ARetainer-lens

25 318179100 AShield-heat

37 # 316111203 AProbe-oven temp

41 5303310526 ACover-hinge cutout

54 5303310514 AHousing-oven light

56 318002602 ATrim-oven front white

58A 5303310539 AInsulation

58B 5303310538 AInsulation oven back

59 318072502 ATube-oven vent

62 # 5303310518 ATerminal Block

63 5303310517 APlate-ground strap

66 # 5303310513 AElement-broil

67 # 5303310512 AElement-bake

68 5304403015 ASupport-element

70 5303300142 AShield-insulation

71 5303310515 ACover-wiring

76 318124100 AFront-oven

80 5303320846 APlate oven

81 5303301261 ASpring-oven

83 318089609 ALiner-oven

86 5303310524 AChannel-hinge

87 318111800 APlate-mounting

88 5303311160 ARod-latch

89 * 318120702 ASwitch latch

89 # 5304404899 AMotor-latch

102 5303311142 ASupport-oven front

107 318119600 ACover-fan

108# 318073001 AMotor-fan

109 5303311203 AFan blade

111 5303311205 ANut-fan retainer

114 3051827 APlate-filler

125# 5303311202 AMotor-convection

127 5303310542 AAdapter assy

128 5303311163 ABushing

129 5303311164 ASpring

141 # 5303284446 ASwitch

142 318123901 AAir Deflector

170 3203576 AAnti-tip bracket right

170A 3203575 AAnti-tip bracket left

177 5303324040 AGasket-vent

191 5303304030 ABracket

217 316042300 AWarning plate

222 318080000 ACovering plate

263 5303322885 ASpacer

* 5303211311 AScrew #8 X ½

*5303311124 AScrew clock

*5303307980 AScrew, 8-32 X 7/16

A= FES387CH (FES387CHSA)

FES387CHS Publication No.

5995323754

05/99 6

TOP/DRAWER

LAP23T0005C

13A

15C

15A

52 15B

FES387CHS Publication No.

5995323754

# = Functional Part 705/99

* = Non-Illustrated Part

TOP/DRAWER

POS.NO PART NO DESCRIPTION

1 5303310500 ADrawer-utility

2318108000 ALiner-drawer

4 5303311126 APanel-drawer

6318111101 ASupport element

11 5303311125 ABracket-drawer

13 5303311129 AChannel-drawer RH

13A 5303311130 AChannel-drawer LH

15# 318178100 AElement-surface1200W

15A# 318178000 AElement-surface 700/2100W

15B# 318178001 AElement-surface 1000/2100W

15C# 318178103 AElement-drawer 120W

16 318079509 AMain Top

51# 5303297484 ALight-indicator hot surface

52 5303317177 ASpring-element mtg

53 318125930 ABracket indicator light

55 5303317178 ASpacer-element

56 5303317179 AScrew, element 6 X 3/4

70 5303311143 ABracket-slide

71 5303311144 AMagnet & spring assy

72 5303311145 ABracket & wheel assy

*5303211311 AScrew, #8 X ½/

A= FES387CH (FES387CHSA)

Publication No. FES387CHS

5995323754

05/99 8

DOOR

A23CD018

FES387CHS Publication No.

5995323754

# = Functional Part 905/99

* = Non-Illustrated Part

DOOR

POS. NO PART NO DESCRIPTION

1 318043100 ABracket-trim

3 318049206 A Trim-oven door white

3A 318028900 ATrim-oven door

3B 318049020 ATrim-oven door white

4 318041102 AGlass-oven door white

6 318056802 AShield-wool

7 318106001 AInsulation-door

9 318048802 ALiner-oven door

10 5303324305 AScrew 10-24 X 5/8

12 318053103 ASeal-oven door

16 318041603 AGlass-oven door

17 318042102 ASpacer-glass

18 318053001 ASeal-window

20 318014301 ASpacer-handle white

23 5303311215 AHinge-oven door assy.

29 5303310535 ABumper base

31 5303310536 ALatch-door

39 316091119 AHandle-door white

42 5303311194 ATrim-oven door white

54 5303317175 AScrew 8-18 X ½ white

*08016432 AScrew, 8-18 X 3/8

*5303211311 AScrew, #8 X ½

*5303307980 AScrew, 8-32 X 7/16

A= FES387CH (FES387CHSA)

Publication No. FES387CHS

5995323754

05/99 10

WIRING DIAGRAM
