Frigidaire FEF366CGSD Manual de usuario

FACTORY PARTS CATALOG

ELECTRIC RANGE

P.O. Box 212378

Augusta, Georgia 30917

PRODUCT NO. BASE MODEL NO. COLOR MARKET

FEF366CGSD FEF366CG WHITE USA

Publication No.

5995319109

980731

-EN/SERVICE /VLM

369

WIRING DIAGRAM # - 316002627

OWNER’S GUIDE # - 316000275

INSTALLATION GUIDE # - 316003025 ELECTRIC - RANGE

FEF366CGSD

03/99 2

Publication number

5995319109 FEF366CGSD

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

# - Fast Moving Parts

* - Non Illustrated Parts 3 3/99

Publication number

FEF366CGSD 5995319109

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

POS. NO PART NO DESCRIPTION

* 316021108 Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 316021110 Screw-8-18x1/2 Tr Sqd black

* 316071902 Gasket-edge

* 316085600 Insulator-shield thermostt

* 316112500 Template, Anti-tip bracket

1 316081601 Shield-backguard,rear wall

2 316015905 Shield-backguard,inner

11 316083721 Trim-wrapper,, textured , white

13A 316095500 Switch-warmer,infinite ,drawer/zone

14 316022504 Light-indicator,250v

14A 316022500 Light/Lamp, warmer,, indicator ,

drawer/zone,125 V

15 316023108 Support-backguard,RH

15A 316023109 Support-backguard,LH

19 316100528 Panel-control,metal ,white

20 # 316101001 Clock/Timer,electronic

20* 316101502 Overlay-clock

23 316100300 Bracket-clock mtg

24# 316005607 Switch-rocker,oven light ,white

31A 316095601 Knob-warmer,white

36 316025106 Knob-control,infinite sw ,white

39* 5303292005 Screw-switch/handle,8-32 x 5/32

40 316025808 Panel-manifold,white

46 316040201 Lens-light/lamp,indicator ,red

54 # 316021500 Switch-infinite, 6" element

54A# 316021501 Switch-infinite, 8" element

03/99 4

Publication number

5995319109 FEF366CGSD

CAUTION: Use the part number on all orders, not the position number.

BODY

# - Fast Moving Parts

* - Non Illustrated Parts 5 03/99

Publication number

FEF366CGSD 5995319109

CAUTION: Use the part number on all orders, not the position number.

BODY

POS. NO PART NO DESCRIPTION

* 3203550 Plug-button

* 316021108 Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 316045000 Clip-wire,harness ,main top

* 316101600 Shield-vent,smoothtop

* 5303051099 Nut,hex ,#10-32

1 316080804 Back-main, short,dipped ,black

3 316081034 Panel-bodyside,white ,RH

3 316081035 Panel-bodyside,white ,LH

5 316107300 Screw-leveling

6 316067902 Rack-oven

7 316007002 Hinge-oven door,(2)

8 3203540 Panel-oven bottom

9 316073800 Pan-broiler

10 3205234 Insert-broiler pan

12 # 316027701 Switch-oven light

13 316026800 Rod-light switch /door

14 316116400 Socket-light

15 5303013071 Light Bulb/Lamp

16 08011086 Lens-light/lamp,glass ,oven

17 316087500 Retainer-lens

18 # 316036300 Latch-door

21 3014099 Spacer-bodyside,(8)

25A 316092400 Shield-warmer,upper

28 3011813 Clip-wire,bodyside

30 5303283574 Bracket-hinge,main top RH

30A 5303283575 Bracket-hinge,main top LH

33A 316095301 Shield-rear wall,lower

37 # 316111200 Probe-oven temp

41 3131570 Cover-hinge cutout

45 316066100 Shield-wire, s/t vent

57 316081101 Cover-access

58 3200847 Insulation,oven bottom

58A 316047708 Insulation, 2" ,oven wrapper

58B 316054200 Insulation, 2" ,oven back

59 316073602 Tube-oven vent

59A 316023601 Tube-oven vent,upper

59B 316040100 Bracket-mounting,vent tube

62 # 5303935061 Terminal Block

63 5301145190 Plate-ground strap

66 # 5303051140 Element-broil

67 # 316075102 Element-bake,lower oven

68 316075300 Support-element, broil

71 316015805 Shield-rear wall

72 5303285692 Cover-light/switch rod

77 316094900 Rail-drawer RH, outer

77A 316094900 Rail-drawer LH, outer

82 5303289913 Shield-insulation

88 316026400 Rod-latch,auto

89 # 316028103 Motor-latch/lock

155 316095201 Shield-drawer,front warmer

170 316107200 Anti-tip bracket

170* 316116000 Screw-Anti tip, 1.75" concrete

03/99 6

Publication number

5995319109 FEF366CGSD

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER

# - Fast Moving Parts

* - Non Illustrated Parts 7 03/99

Publication number

FEF366CGSD 5995319109

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER

POS. NO PART NO DESCRIPTION

* 316021108 Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 316021110 Screw-8-18x1/2 Tr Sqd black

* 316021112 Screw-8-18x1/2 Tr Sqd White

* 316045000 Clip-wire,harness ,main top

* 5303280311 Screw,waf hd sdr ,10-32 x 5/16 ,(2)

* 5309951550 Cleaner-cooktop

1 316094601 Drawer-warmer

2 316092901 Liner,drawer

4 316056201 Panel-drawer,white

10 5303280308 Screw-handle mtg,wafer head ,10-24T x 2

13 316096500 Rail-drawer RH,outer

13A 316096501 Rail-drawer RH,outer

14 3206216 Plug-button,glide

15 # 316010204 Element-surface,radiant , large/8 inch ,

2100W,limit sw incl

15A# 316010203 Element-surface,radiant , small/6 inch ,

1200W,limit sw incl

16 316098105 Main Top,white

18 5303273062 Hinge-main top,RH

18A 5303273063 Hinge-main top,LH

26 316099101 Channel-support,element ,(2)

26A 316099201 Bracket-support, chassis

39 316026106 Handle-drawer,white

44 3131903 Bumper-door/drawer,rubber

48 316100200 Shield-wire,main top

51 80142193 Indicator light

52 316099400 Clip-spring, element mtg,(8)

53 316099300 Bracket-indicator light,hot surface ,

4 hole

80 316109700 Seal-door,warmer drawer

81 # 316093100 Element,warmer drawer

82 316093200 Bracket-mounting,warmer element

83 316093300 Shield-terminal,warmer

84 316093500 Thermo disc,warmer

85 316093600 Rack,warmer drawer

86 316095800 Clip-hold down,warmer element

87 316091900 Base-warmer

87 316091902 Base-warmer

88 316099500 Pin-guide,(2)

03/99 8

Publication number

5995319109 FEF366CGSD

CAUTION: Use the part number on all orders, not the position number.

DOOR

# - Fast Moving Parts

* - Non Illustrated Parts 9 03/99

Publication number

FEF366CGSD 5995319109

CAUTION: Use the part number on all orders, not the position number.

DOOR

POS. NO PART NO DESCRIPTION

* 3203618 Rivet-pop,warning-plate

* 316021110 Screw-8-18x1/2 Tr Sqd black

* 316065301 Plate warning/caution

* 5303271648 Screw,wafer hd sq dr ,8-18AB x 1/2

* 5303280311 Screw,waf hd sdr ,10-32 x 5/16 ,(2)

3 316067804 Trim-oven door,white

4 316089005 Glass-oven door,white ,outer

5 316088700 Glass-oven door,airwash

6 316088401 Shield-wool

7 316076403 Insulation-door

8 316088600 Glass-oven door,inner

9 316066610 Liner-oven door

10 5303280308 Screw-handle mtg,wafer head ,10-24T x 2

12 # 5303131601 Seal-oven door

14 3131361 Reflector,aluminum foil

14A 3131360 Reflector,aluminum foil ,(2)

15 316081403 Bracket-glass mtg

16 316085701 Glass-oven door,heat barrier

39 316091115 Handle-door,white ,oven

39* 316008401 Washer,3/4 x 1/4 ,steel

39* 5303292005 Screw-switch/handle,8-32 x 5/32

52 316081301 Shield-oven door,white ,top

03/99 10

Publication number

5995319109 FEF366CGSD

CAUTION: Use the part number on all orders, not the position number.

WIRING DIAGRAM
