Frigidaire FFGF3051L S Manual de usuario

frigidaire.com

Drop-In Cooktop

FPEC3085K S

30" Electric30" Gas

Signature Features

Ready-Select® Controls

Select options or control cooking

temperature with our easy-to-use

controls.

Product Dimensions

Height (Max.) 47-1/2"

Width 29-7/8"

Depth (Including Handle) 28-1/2"

More Easy-To-Use Features

Black Matte Finish with

Cast Iron Grates

A premium finish to complement

the durable burner grates.

Even Baking Technology

Our latest technology ensures even

baking every time.

Store-More™ Storage Drawer

Our convenient drawer gives you extra

storage space in your kitchen.

Quick Clean

For a quick, light oven cleaning.

Extra-Large Window

Our extra-large oven window lets you

easily see what’s inside.

Delay Start Baking Option

Delay Clean

Set the oven to begin cleaning on

your schedule.

Hi /Lo Broil Option

Offers two-position broiling and

variable temperature control for

more control.

Auto Shut-O

As an extra safety measure, the oven will

automatically shut off after 12 hours.

Timed Cook Option

Attractive Stainless Steel Exterior

LP Gas Conversion Option

Available in:

Sealed Gas Burners

Enjoy easier cleanup and a burner

that stays looking great.

One-Touch Self Clean

Start the self-cleaning cycle with

just the touch of a button.

Large Capacity

Our large capacity oven gives you

room to cook more at once.

Burners

Right Front

Right Rear

Left Front

Left Rear

BTU

9,500

Stainless

(S)

Freestanding Range

FFGF3051L S

Specifications

subject to change.

Accessories information available

on the web at frigidaire.com

30" Gas Freestanding Ranges (4 Burners)

Frigidaire Baseline

36"

(Adjustable)

1 For use on adequately wired 120V, dedicated circuit having

2-wire service with a separate ground wire. Appliance must be

grounded for safe operation.

Features

Oven Control / Timing System

Surface Type

Sealed Gas Burners

Grates

Window

Exterior Door Finish

Handle Design

Exterior Finish (Side Panels)

Convection System

Oven Cleaning System

Drawer Functionality

Oven Controls

Bake

Broil

Add-a-Minute

Delay Bake

Self-Clean

Quick Clean Option

Delay Clean

Kitchen Timer

Timed Cook Option

Auto Oven Shuto

Cooktop Features

Right Front Burner (BTU)

Right Rear Burner (BTU)

Left Front Burner (BTU)

Left Rear Burner (BTU)

Center Extra Zone Burner (BTU)

Oven Features

Capacity (Cu. Ft.)

Oven Light

Rack Conﬁguration

Even Baking System

Broiling System

Bake Burner / Broil Burner (BTU)

Optional Accessories

LP Gas Conversion Kit

Speciﬁcations

Oven Interior ( H x W x D )

Power Supply Connection Location

Gas Supply Connection Location

Voltage Rating

Connected Load

(kW Rating) @ 120 Volts 1

Amps @ 120 Volts

Shipping Weight (Approx.)

Ready-Select® Controls

Black Porcelain

Yes

Cast Iron with

Black Matte Finish

Extra-Large

Stainless Steel

Black

Self Clean

Storage

Yes

Low and High

Yes

12 Hours

9,500

5.0

2 Standard

Yes

Vari-Broil™ Hi / Lo

18,000 / 18,000

PN # GRLP3

17-5/8" x 24-3/8" x 19-3/4"

Left Bottom Rear

Right Bottom Rear

120V / 60 Hz / 15A

1.8

150 Lbs.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Freestanding Range

FFGF3051L S 30" Gas

Cutout Dimensions

Height (Standard)

Width (Min.)

Depth (Min.)

36"

30"

24"

Product Dimensions

A - Height (Max.)

B - Width

C - Depth (Including Handle)

Depth with Door Open 90˚

47-1/2"

29-7/8"

28-1/2"

46-5/8"

NOTE: For planning purposes only. Always consult local and national electric and gas codes.

Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.

Specifications

subject to change.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

General Installation Guidelines

with Side-by-Side Refrigerator

Top

Use these dimensions and clearance instructions for planning purposes only. For detailed installation

instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.

Front

Top

Front

Specifications

subject to change.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Use these dimensions and clearance instructions for planning purposes only. For detailed installation

instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.

Front

Top

Front

Top

General Installation Guidelines

with Top Mount Refrigerator
