Frigidaire FGB24S5D C Manual de usuario

FGB24S5DC.eps LA00CP74431-2.eps LA00BR74431-1.eps LA00B74431-1.eps

LA20D74431-1.eps 318046312.eps

Product No. FGB24S5DCA

37454432E40S1

Series 24" single

Color stainless

Market North America

Wiring Diagram 318046312

Owner's Guide 318200953

Installation Instructions 318201551

Service Data Sheet 318047410

Timer Guide 318200191

ELECTROLUX HOME PRODUCTS, INC.

P.O. Box 212378, Augusta, GA 30917

Publication No.

5995420576

04/11/01

(EN/SERVICE/ECL)

377

SINGLE GAS WALL

OVEN

Model No.

FGB24S5D

Publication No: 5995420576 FGB24S5DCA

11/04 2

CONTROL PANEL

FGB24S5DCA Publication No: 5995420576

# Functional Parts 3 11/04

* Non-Illustrated Parts

CONTROL PANEL

POS. NO PART NO. DESCRIPTION

18 5303280338 End Cap, black, RH

18A 5303280339 End Cap, black, LH

19 318234108 Panel, control, black

20 # 318185431 Clock/Timer, electronic, black

20* 316220805 Overlay, clock, black, ES300

21 5303308451 Trim, splasher, black

23 318015034 Bracket, clock/timer

24 # 316005602 Switch, rocker, black

42 318027101 Trim, center vent, black

53 318056901 Deflector trim, black

99 5303311528 Screw, oval hd sq dr, 6-20AB x 0.625, black

100 318112200 Plate, mounting, rocker switch

* 08002868 Screw, 10-24 x 0.500, probe, thrm brkt, shield, drwr, box

* 5303323130 Screw, 8 x 1/4

Publication No: 5995420576 FGB24S5DCA

11/04 4

BURNER

FGB24S5DCA Publication No: 5995420576

# Functional Parts 5 11/04

* Non-Illustrated Parts

BURNER

POS. NO PART NO. DESCRIPTION

9 3201885 Nut, Keps, 10-24

14 # 5303210167 Regulator, pressure

17 # 5303210798 Valve, safety

18 # 5303210787 Burner, oven

19 # 318177710 Ignitor, oven burner

20 3203676 Baffle, oven burner

22 5303271092 Tubing, valve

23 # 5303283132 Burner, broiler

24 # 5303210786 Mixer Elbow, bake

24A# 5303210807 Mixer Elbow, broiler

25 5303326220 Baffle, broil burner

26 # 316119302 Ignitor, broiler

28 # 5303295305 Valve, shut off

30 5303305657 Elbow, fitting

36 318177801 Tubing, safety valve, upper

58 318123600 Shield, broiler

* 3051070 Screw, hex washer head, 10-24 x 0.438, special

* 08002868 Screw, 10-24 x 0.500, probe, thrm brkt, shield, drwr, box

* 5303311306 Screw, 8-18 x 0.375

* 5303311549 Screw, burner mtg

Publication No: 5995420576 FGB24S5DCA

11/04 6

BODY

FGB24S5DCA Publication No: 5995420576

# Functional Parts 7 11/04

* Non-Illustrated Parts

BODY

POS. NO PART NO. DESCRIPTION

2 318145003 Wrapper, base

2A 318102401 Cover, mid top

4 318161500 Box, oven burner

6 5303299366 Rack, oven

8 318121400 Panel, oven bottom

9 5303317977 Pan, broiler

10 5303317976 Insert, broiler pan

12 # 318089913 Switch, light

12* 5303271097 Bracket, light switch

14 318224000 Receptacle, oven light

15 5303013071 Bulb/Lamp, oven light

16 3201911 Cover, oven light, glass

17 5304400195 Retainer, light cover

25 318179000 Shield, insulation, base

33 318187301 Shield, housing

36 3203725 Flue

37 # 316217002 Probe, oven temp

39 318144003 Cord, Service

41 5303310526 Cover, hinge cutout

54 318222400 Housing, oven light

55 5303326219 Shield, flue

56 318145508 Trim, bodyside

* 5303320422 Screw, 6-20 x 5/16, black, (6)

57 318071130 Shield, rear wall

58 318133735 Insulation, oven bottom

58A 318133736 Insulation, oven back

58B 318133760 Insulation, top & sides

58C 318133739 Insulation

58D 318133732 Insulation

58E 318133733 Insulation

58F 318133734 Insulation, flue

58G 5303326119 Insulation, flue

70A 5303210843 Shield, insulation

72 5303210685 Wrapper, shield

76 318056139 Front, oven

80 318192400 Spring, oven

81 5303323710 Bracket, oven

83 318089411 Liner, oven assy

86 5303310524 Receptacle, hinge

87 5303308443 Bracket, safety valve

88 5303311222 Rod, latch

* 5303311528 Screw, oval hd sq dr, 6-20AB x 0.625, black

89 # 318095937 Motor, latch assy, w/brkt & switch

89* 318120711 Switch

* 3201861 Screw, 6 x 0.375, (4)

97 318066803 Wrapper, back & sides

98 318029400 Trim, side, inner, RH

98A 318029401 Trim, side, inner, LH

99 5303299686 Support, adjustable

100 5303302715 Shield, flue, bottom

102 3203688 Support, oven front

Publication No: 5995420576 FGB24S5DCA

11/04 8

BODY

FGB24S5DCA Publication No: 5995420576

# Functional Parts 9 11/04

* Non-Illustrated Parts

BODY

POS. NO PART NO. DESCRIPTION

103 5303316735 Trim, base, black, lower

104 318170210 Flue

108# 318073001 Motor, fan

* 08016432 Screw, truss head, 8-18 x 0.375

117 5303302718 Bracket, thermo protect

119# 5303326252 Switch, thermal

121 318145001 Wrapper, base

122 5303210844 Shield, heat, lower

123 318071421 Shield, insulation, top & sides

128 5303311163 Bushing

129 5303311164 Spring

132 3201437 Strain relief

187 318013501 Tube, latch rod

227 5303323958 Retainer, oven bottom

234 5303210851 Shield, burner box

235 5303326207 Bracket

236 318108900 Shield, insulation, 1.25x1.0x12.9

239 5303326183 Angle, burner box

240 318119301 Shield, bodyside

* 318232518 Wiring Harness, main

* # 318003606 Thermostat, safety

* 318147411 Bumper, door, (2)

* 08002868 Screw, 10-24 x 0.500, probe, thrm brkt, shield, drwr, box

* 08011955 Screw, 10-24 x 0.375, square drive

* 5303211311 Screw, 8 x 0.500

* 5303300195 Screw, 10-32 x 0.375, terminal block, (2)

* 5303302745 Screw, 10-16x1-1/8, square drive

* 5303323130 Screw, 8 x 1/4

* 5303323277 Screw, 8-18 X 13/32

Publication No: 5995420576 FGB24S5DCA

11/04 10

DOOR/DRAWER
