Frigidaire FEB766CJ Manual de usuario

PRODUCT NO. FACTORYNO. COLOR MARKET

FEB766CJSA 38254731E0011 WHITE USA

FEB766CJBA 38254731E0061 BLACK USA

FEB766CJTA 38254731E0031 ALMOND USA

ELECTRICWALLOVEN

Model No.

FEB766CJ

Inc.

FACTORY PARTS CATALOG

ELECTRIC WALL OVEN

WIRINGDIAGRAM#-318046208

OWNER’S GUIDE # - 318200912

INSTALLATIONINSTR. # - 318201507

TIMER INSTRUCTIONGUIDE#- 318130806

FRIGIDAIREHOMEPRODUCTS

7075 ORDAN DRIVE

MISSISSAUGA,ONTARIO

CANADA, L5T 1K6

TEL: (905) 565-9200 PublicationNo.

5995336939

000419

-EN/SERVICE

377

PublicationNo. FEB766CJ

5995336939

04/00 2

CONTROLPANEL

LA00CP82731-2

18A

FEB766CJ PublicationNo.

5995336939

# = Func tional Part 304/00

* = Non-Illustrated Part

POS. NO PART NO DESCRIPTION

18 5303311208 AEnd Cap white

18 5303311231 BEnd Cap black

18 5303311225 CEndCap almond

18A 5303311209 AEnd Cap white

18A 5303311232 BEnd Cap black

18A 5303311226 CEndCap almond

19 318030013 APanel-control

19 318030012 BPanel-control

19 318030018 CPanel-control

20 # 318010900 ABCClock/Timer

21 5303311212 ATrim-canopy white

21 5303301310 BTrim-canopy black

21 5303311227 CTrim-canopyalmond

23 318111602 ABCBracket-timer

42 5303318709 ATrim-vent white

42 5303316983 BTrim-vent black

42 5303318712 CTrim-ventalmond

78 5303302394 ACover vent white

78 5303302396 BCover vent black

78 5303302395 CCoverventalmond

80 # 318111500 ABCRelay

99 5303316956 AScrew white 6-32 X 3/8

99 5303307406 BScrew black 6-32 X 3/8

99 5303317307 CScrew almond 6-32 X 3/8

*3201861 ABCScrew, 6 X 3/8

*5303211311 ABCScrew, #8 X ½

CONTROLPANEL

A = FEB766CJ (FEB766CJSA)

B = FEB766CJ (FEB766CJBA)

C = FEB766CJ (FEB766CJTA)

FEB766CJ PublicationNo.

5995336939

04/00 4

CAVITY/ELEMENTS

264

101

124

103

LA00B82731-2

66 68

58B

58A

187

108

119

127

37 12

129

128

185

99 98A

185

15 16

150A

150

131

132

132A

102A

102

188

FEB766CJ PublicationNo.

5995336939

# = Func tional Part 504/00

* = Non-Illustrated Part

CAVITY / ELEMENTS

POS. NO PART NO DESCRIPTION

1318066700 ABCBack-Main

2318102001 ABCShield oven

2A 318071501 ABCShield oven top

6 5303299719 ABCRack-oven

6B 318025202 ABCShelf-oven

9 5303317977 ABCPan-broiler

10 5303317976 ABCInsert-broilerpan

12 # 318089910 ABCSwitch-light

14 5308011085 ABCSocket-light/lamp

15 3201908 ABCLamp-oven light

16 3201911 ABCGlass-oven light lens

17 5304400195 ABCRetainer-lens

37 # 316111203 ABCProbe-oven temp

41 5303310526 ABCCover hinge cut-out

54 5303310514 ABCHousing-oven light

56 5303302711 ATrim-bodyside white

56 5303298951 BTrim-bodyside black

56 5303302712 CTrim-bodysidealmond

58A 5303311218 ABCInsulation

58B 5303311219 ABCInsulationventtube

59 318072510 ABCTube-oven vent

62 # 5303310518 ABCTerminalblock

66 # 5303322963 ABCElement-broil

67 # 5303299718 ABCElement-bake

68 5304403015 ABCSupport-element

70 5303300142 ABCShield-insulation

71 318071102 ABCShield-wire

76 318056104 ABCFront-oven

80 5303301261 ABCSpring-oven

81 5303320846 ABCPlate-oven mtg

82 318071801 ABCShield-ovenbottom

83 318089517 ABCLiner-oven assy

86 5303310524 ABCSupportdoor-hinge

88 5303311222 ABCRod-latch

89 # 318095913 ABCMotor-latch/lock

89* 318120710 ABCSwitch-latch

98 318029900 ABCTrim-side RH

98A 318029901 ABCTrim-side LH

99 318055420 ABCSupport-adjustable

101 318039512 ABracket-trim

101 318039511 BBracket-trim

101 318039513 CBracket-trim

102 318070700 ABCCap top panel RH

102A 318070701 ABCCap top panel LH

103 318028701 ATrim-base white

103 318028700 BTrim-base black

103 318028702 CTrim-basealmond

108# 318073001 ABCMotor-fan

119# 318004900 ABCSwitchthermal

124 318076902 ABCBox vent

127 5303310542 ABCAdapter assy

128 5303311163 ABCBusing

129 5303311164 ABCSpring

131 318102202 ABCCover-controlhousing

132 318101700 ABCEnd-cover

132A 318101701 ABCEnd-cover

150 318072207 ABCBracket-support

150A 318072206 ABCBracket-support

185 318014700 ABCSpacer-oven shield

187 318013501 ABCTube, rod latch

188 08007817 ABCSpacer

264 318143811 BHiddenwires

*5303323139 ABCScrew, 10-24 X 29/32

*318078511 ABCBx & wires assy

*5303300265 ABCScrew, 8-18 X ½ chrome

*318028801 ATrimbase (white)use onmodelsundercounteronly

*318028800 BTrimbase (black)use onmodelsundercounteronly

*318028802 CTrimbase(almond)useonmodelsundercounteronly

*5303302745 ABCScrew, 10-16 X 1 1/8 (black)

*5303935083 AScrew, 10-16 X 1 1/4 (white)

*5303324188 CScrew, 10-16 X 1 1/4 (almond)

A = FEB766CJ (FEB766CJSA)

B = FEB766CJ (FEB766CJBA)

C = FEB766CJ (FEB766CJTA)

FEB766CJ PublicationNo.

5995336939

04/00 6

DOOR

LA00D82731-2

FEB766CJ PublicationNo.

5995336939

# = Func tional Part 704/00

* = Non-Illustrated Part

DOOR

POS. NO PART NO DESCRIPTION

3 318026110 ATrim-oven door white

3 318026600 BTrim-oven door black

3 318026111 CTrim-oven door almond

4 318051601 AGlass-oven door

4 318051600 BGlass-oven door

4 318051602 CGlass-oven door

6 318073502 ABCShield-air wash

7 5303311214 ABCInsulation

9 318048503 ABCLiner-doorbaffle

10 5303311217 ABCScrew, 10-24 X 2 3/16, han dle-door

12 # 318053100 ABCSeal-oven door

16 318042300 ABCGlass-oven door

17 318042000 ABCSpacer-glass

18 318053000 ABCSeal-rope

20 318014301 ASpacer-handle, white

20 318014300 BSpacer-handle, black

20 318014302 cSpacer-handle, almond

22 5303310511 ABCRetainer-glass

23 5303310506 ABCHinge-oven door ass.

29 5303210003 ABCSpacer-door

31 318065102 ABCLatch-door

39 316091107 AHandle-doorwhite

39 316091106 BHandle-doorblack

39 316091108 CHandle-dooralmond

54 5303308456 ABCScrew, 8-18 X 17/32 black

59 3202113 ABCButton-plug

*5303307980 ABCScrew,8-32 x 7/16

*5303300414 ABCSpacer,cork&rubber

*5303323277 ABCScrew, 8-18 x 13/32

*5303308450 ABCScrew, 8 x 3/8

*08002868 ABCScrew, 10-24 x ½

*5303211311 ABCScrew, 8 x ½

*5303300265 ABCScrew,8-18 x ½

*3051070 ABCScrew, 10-24 x 7/16

A = FEB766CJ (FEB766CJSA)

B = FEB766CJ (FEB766CJBA)

C = FEB766CJ (FEB766CJTA)

PublicationNo. FEB766CJ

5995336939

04/00 8

WIRING DIAGRAM
