Frigidaire EFIC239 Manual del propietario
Introduction..............................................................................
Important Safety Information............................................
Getting to Know Your Unit..................................................
Operating Procedures & Maintenance............................
Using Your Ice Maker.............................................................
Troubleshooting Guide........................................................
Product Specifications.........................................................
Limited Warranty...................................................................
2
3
Safety Instructions..................................................................4
5
6
7
11
12
13
USA CANADA 1-800-
ICE MAKER
EFIC239
2INTRODUCTION
When you unpack your ice maker, you
may find a small amount of water inside.
Your unit is brand new.
Please follow the initial preparation and
cleaning instructions as detailed in the
User Guide prior to using your new
icemaker.
Any water you may find is from the
standard quality control testing that all
of our ice makers undergo as part of the
manufacturing process.
When using, please avoid direct sunlight.
3IMPORTANT SAFETY INFORMATION
WARNING
WARNING indicates apotentially
hazardous situation which, if not avoided,
could result indeath or serious injury.
IMPORTANT
IMPORTANT indicates installation, oper-
ation or maintenance information which
is important but not hazard-related.
DANGER
DANGER indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
CAUTION
CAUTION indicates a potentially
hazardous situation which, if not
avoided, may result in minor or
moderate injury.
Safety Definitions
This is the safety alert symbol. It is
used to alert of potential personal injury
hazards. Obey all safety messages that
follow this symbol to avoid possible injury
or death.
Safety Instructions
•DO NOT store or use gasoline, or
other flammable liquids in the vicinity
of this or any other appliance. Read
product labels for warnings regarding
flammability and other hazards.
•Avoid contact with any moving parts
of automatic ice maker.
•Remove all staples from the carton.
Staples can cause severe cuts, and also
destroy finishes if they come in contact
withother appliances or furniture.
WARNING
Please read all instructions before using
this appliance.
Child Safety
Destroy or recycle the carton, plastic
bags, and any exterior wrapping material
immediately after the Ice Maker is unpacked.
Children should NEVER use these items to
play. Cartons covered with rugs, bedspreads,
plastic sheets or stretch wrap may become
airtight chambers, and can quickly cause
suocation.
4SAFETY INSTRUCTIONS
This appliance must be plugged into at least a 15 AMP 110-115 VOLT 60 Hz
GROUNDED OUTLET. This appliance must be grounded. It is equipped with a
3-wire cord having a grounding plug. The plug must be plugged into an outlet that
is properly installed and grounded.
Avoid the use of an extension cord because it may overheat and cause a risk of
fire. However, if it is necessary to use an extension cord:
A. Use only 3-wire extension cords with 3-blade grounding plug.
B. The marked rating of an extension cord must be be equal to or greater than the
rating of this appliance.
C. It should be positioned such that it does not drape over the counter or tabletop
where it can be pulled on by children intentionally.
Attempting any maintenance or cleaning:
To minimize the possibility of electric shock, unplug this appliance from the power
suply or disconnect at the household distribution panel by removing the fuse or
switching o the circuit breaker before attempting any maintenance or cleaning.
NOTE: Pressing the Power ON/OFF button to an o position does not disconnect
the appliance from the power supply.
WARNING!
Improper use of grounded wire can result in the risk of electric shock.
Consult a physician if necessary. Do not attempt to defeat this safety
feature by modifying the plug.
5GETTING TO KNOW YOUR UNIT
1. lce basket
2. Top cover, removable from the top
3. Secondary water reservoir: It connects directly with the evaporator
4. Float switch
5. Metal shell
6. Water drain cap: at the front bottom side of the unit
7. Filter
8. Control panel
9. Water reservoir
10. Hot Air outlet
11. MAXIMUM WATER LEVEL:
1
2
3
4
5
6 7 8
9
10
11
6OPERATING PROCEDURES & MAINTENANCE
DANGER
1. Remove the exterior and interior packaging, and then check all the accessories
are included. If any parts are missing, please contact our customer service.
2. Remove all the tapes on the unit; take out the accessory parts inside.
3. Clean the interior with lukewarm water and a soft cloth.
4. Locating your ice maker on a level counter table far from direct sunlight and other
sources of heat (i.e.: stove, furnace, and radiator). Make sure that there is at least 6
inches between the back and sides of your ice maker with the wall.
5. Allow one hour for the refrigerant fluid to settle down before plugging your ice
maker in.
6. The power plug must be accessible directly.
WARNING: Fill with drinking water (potable water) only.
*Improper use of the grounded plug can result in the risk of electrical shock. If
the power cord is damaged please call our customer service.
1. This unit should be properly grounded for your safety. The power cord of this
appliance is equipped with a grounding plug which mates with standard grounding
wall outlets to minimize the possibility of electric shock.
2. Plug your appliance into an exclusive, properly installed, grounding wall outlet. Do
not be under any circumstances; damage the grounding means of the plug. Any
questions concerning power and or grounding should be directed toward a
certified electrician.
3. This appliance requires a standard 110-120Volt, 60Hz electrical outlet with good
grounding means.
Before using your ice maker, it is strongly recommended to clean it thoroughly.
Unplug the unit before cleaning or making any maintenance.
1. Take out the ice basket.
2. Clean the interior with diluted detergent, warm water and a soft cloth.
3. Then rinse the inside parts with water, and drain out the water by unplugging the
drain cap on the front bottom side.
4. The outside of the ice maker should be cleaned regularly with a mild detergent
solution and warm water.
5. Dry the interior and exterior with a clean soft cloth.
6. When the machine is not in use for a long time, drain water completely out and
dry the interior.
UNPACKING YOUR ICE MAKER
CONNECTING YOUR ICE MAKER
CLEANING AND MAINTAINING YOUR ICE MAKER
7USING YOUR ICE MAKER
How to start the unit
Operation and display areas
Pour water
1. Take out the ice basket and pour potable water into the water reservoir, 0.58
gallon (2.2 liters) waterat most at one time.
2. Put back the ice basket.
3. Plug in the power cord.
Plug in the power cord and the screen is on: You can operate this appliance by
touching the buttonon the panel as shown above.The main function includes: ice,
clean and timer.
USING YOUR ICE MAKER
8
4. Before the cleaning procedure, please make sure the water drain cap has been
inserted into the appliance; otherwise it will not work properly.
5. Press“ICE/CLEAN” button“ ” for 5 seconds and the screen displays 15M and
the “CLEAN" symbol“ ”(as shown in the picture below). lt will run the cleaning
procedure for 15 minutes and automatically exit. Press this button again during
the cleaning procedure and it will exit immediately.
6. After the cleaning procedure, remove the top cover and the ice basket, rinse the
main water tely. Reservoir and the secondary water reservoir, and then move the
appliance to the edge of the desktop. Make sure that the appliance is placed
steadily. Place a water container under the appliance and remove the drain cap
from the bottom. The dirty water will drain into the water container and
then reinsert the drain cap.
Change water in the water reservoir every 24 hours to ensure a reasonable hygiene
level. If the unitisn't to be used, drain all water and dry the water reservoir.
Secondary
water reservoir
Water drain cap
Main water
reservoir
Clean
For the first time, or the clean procedure has not been running for a long time, it
is highly recommended to run this procedure at first.
USING YOUR ICE MAKER 9
How to obtain the ice cube
7. Before we start making ice,please make sure the water drain cap has been
inserted into the appliance; otherwise it will not work properly.
8. Press “ICEICLEAN” button “ ”, the screen displays “ICE”symbol “ ”(as shown
in the figure below) and it begins to work. Press this button again and it will stop
making ice.
9. For the first time, or if the appliance has not been used for a long time, it is
recommended to clean this appliance before starting to make ice.
10. While the ice maker is on, check the water level periodically. If the water pump
can't pump out water, the ice maker will stop automatically and the “Add Water”
symbol “ ”will appear (as shown in thefigure below). You need to pour water
into the water reservoir.
11. The ice maker automatically stops working when the ice basket is full of ice cubes
and the “Ice Full” symbol “ ” appears(as shown in the figure below).
10USING YOUR ICE MAKER
How to set the timer
Timer's Delay Range: 0-24 hours Press once to change: 1H
When the unit is running, you can set the unit with OFF-TIMER to let the unit stop
running after your setting delay time.
And when the unit is at the standby mode, you can set the unit with ON-TIMER to
let the unit start to run automatically after your setting delay time. Then when you go
back home or have a dinner, you can enjoy a happy life accompanied by this ice maker.
12. Press the“TIMER" button “▲” or “▼” to start setting time. Press the “▲” button to
increase the time, and press the “▼” button to decrease the time. Press the
“TIMER” button at the standby mode and it will start after the countdown (as
shown in the figure a); Press the“TIMER” button at the ice-making mode and it
will shut down after the countdown (as shown in the figure b).
13. When the unit has been set with the timer, press the TIMER button, then the delay
time digit and “H” letter display will disappear, which means the timer set has been
canceled.
Tips: The background light on the screen automatically goes out after 30 seconds
without operation. lf you want to keep the light on, press the“TIMER” button “▲”
for 5 seconds; and if you want to cancel the constant light, press the“TIMER”button
“▲” for 5 seconds again.
Timer delay time
a. (Start ice making in three hours) b. (Exit ice making after three hours)
Means Hour, and timer setting duration
Tabla de contenidos
Idiomas:
Otros manuales de Máquina de hielo de Frigidaire
Frigidaire
Frigidaire EFIC108-C Manual de usuario
Frigidaire
Frigidaire EFIC101 Manual de usuario
Frigidaire
Frigidaire EFIC123-SS Manual de usuario
Frigidaire
Frigidaire EFIC235-AMZ Manual de usuario
Frigidaire
Frigidaire EFIC111-B-SILVER Manual del propietario
Frigidaire
Frigidaire 242102400 Manual de usuario
Frigidaire
Frigidaire EFIC128-BLACK-6COM Manual del propietario
Frigidaire
Frigidaire EFIC108 Manual de usuario
Frigidaire
Frigidaire EFIC113 Manual de usuario
Frigidaire
Frigidaire EFIC102-RED Manual de usuario
Frigidaire
Frigidaire EFIC117-SSCOPPER-B-COM Manual de usuario
Frigidaire
Frigidaire EFIC121-SS Manual de usuario
Frigidaire
Frigidaire EFIC121-B-SS Manual del propietario
Frigidaire
Frigidaire EFIC206-B-TG-SILVER Manual del propietario
Frigidaire
Frigidaire EFIC452-SS Manual de usuario
Frigidaire
Frigidaire FFU20B6BW1 Manual de usuario
Frigidaire
Frigidaire EFIC130-SS Manual del propietario
Frigidaire
Frigidaire EFIC103-AMZ-SC Manual del propietario
Frigidaire
Frigidaire EFIC117-SSBLACK-B-CU Manual de usuario
Frigidaire
Frigidaire EFIC120-SS-SC Manual de usuario
