Frigidaire EFIC237 Manual del propietario

Introduction.....................................................................................

Important Safety Information...................................................

Getting to Know Your Unit........................................................

Operating Procedures & Maintenance...................................

Using Your Ice Maker...................................................................

Troubleshooting.............................................................................

Product Speciﬁcations...............................................................

Limited Warranty..........................................................................

USA CANADA 1-800-

ICE MAKER

EFIC237

INTRODUCTION

WARNING

WARNING indicates apotentially

hazardous situation which, if not avoided,

could result indeath or serious injury.

IMPORTANT

IMPORTANT indicates installation, oper-

ation or maintenance information which

is important but not hazard-related.

DANGER

DANGER indicates an imminently

hazardous situation which, if not avoided,

will result in death or serious injury.

CAUTION

CAUTION indicates a potentially

hazardous situation which, if not

avoided, may result in minor or

moderate injury.

Safety Deﬁnitions

This is the safety alert symbol. It is

used to alert of potential personal injury

hazards. Obey all safety messages that

follow this symbol to avoid possible injury

or death.

Safety Instructions

•DO NOT store or use gasoline, or

other ﬂammable liquids in the vicinity

of this or any other appliance. Read

product labels for warnings regarding

ﬂammability and other hazards.

•Avoid contact with any moving parts

of automatic ice maker.

•Remove all staples from the carton.

Staples can cause severe cuts, and also

destroy ﬁnishes if they come in contact

withother appliances or furniture.

WARNING

Please read all instructions before using

this appliance.

Child Safety

Destroy or recycle the carton, plastic

bags, and any exterior wrapping material

immediately after the Ice Maker is unpacked.

Children should NEVER use these items to

play. Cartons covered with rugs, bedspreads,

plastic sheets or stretch wrap may become

airtight chambers, and can quickly cause

suocation.

3IMPORTANT SAFETY INFORMATION

1. Metal shell

2. Drawer

3. Observation window: See how much ice has been stored in the drawer.

4. Handle for drawer.

5. Control Panel:

Indicator light: Lack of water in reservoir, Power, Ice full

Button: ICE, CLEAN, LIGHT

6. Water reservoir

7. Handle for water reservoir

8. Hot Air outlet

9. Drip tray

Water drain cap: After cleaning procedure, remove drain cap from the back of

the appliance, pull out the cap from the drainpipe, empty the tank under the

drawer, then reinsert the cap and put it back again.

Drainpipe: After cleaning procedure, you can collect dirty water from the

drainpipe (there are two pipes: one connects to the evaporator, the other one

connects to the water tank under the drawer).

Power cord

10.

11.

12.

GETTING TO KNOW YOUR UNIT

DANGER

1. Remove the exterior and interior packaging, and then check all the accessories are included.

If any parts are missing, please contact our customer service.

2. Remove all the tapes on the unit; take out the accessory parts inside.

3. Clean the interior with lukewarm water and a soft cloth.

4. Locating your ice maker on a level counter table far from direct sunlight and other sources

of heat (i.e.: stove, furnace, and radiator). Make sure that there is at least 6 inches between

the back and sides of your ice maker with the wall.

5. Allow one hour for the refrigerant ﬂuid to settle down before plugging your ice maker in.

6. The power plug must be accessible directly.

WARNING: ﬁll with potable water only. Only use drinking water.

*Improper use of the grounded plug can result in the risk of electrical shock. If the

power cord is damaged please call our customer service.

1. This unit should be properly grounded for your safety. The power cord of this appliance is

equipped with a grounding plug which mates with standard grounding wall outlets to

minimize the possibility of electric shock.

2. Plug your appliance into an exclusive, properly installed, grounding wall outlet. Do not under

any circumstances; damage the grounding means of the plug. Any questions concerning

power and or grounding should be directed toward a certiﬁed electrician.

3. This appliance requires a standard 110-120Volt, 60Hz electrical outlet with good grounding

means.

Before using your ice maker, it is strongly recommended to clean it thoroughly. Unplug the

unit before cleaning or making any maintenance.

1. Take out the drawer and water reservoir on the top.

2. Clean the interior with diluted detergent, warm water and a soft cloth. First pour the warm

water with diluted detergent into the internal water reservoir, and then use the soft cloth

to wipe the surface.

3. Again use the water to rinse the inside parts, and drain out the water by unplugging the

drain cap on the back.

4. The outside of the ice maker should be cleaned regularly with a mild detergent solution and

warm water.

5. Dry the interior and exterior with a soft cloth.

6. When the appliance is not in use for a long time, open water drain cap to drain out water

completely from water reservoir.

UNPACKING YOUR ICE MAKER

CONNECTING YOUR ICE MAKER

CLEANING AND MAINTAINING YOUR ICE MAKER

5OPERATING PROCEDURES & MAINTENANCE

CLEAN

For the ﬁrst time, or the clean procedure has not been ran for a long time, it is highly

recommended to run this procedure at ﬁrst.

Before start the cleaning process,please check the drain pipe and make sure it is with the

cap and hang on the back of the machine.

Plug in the power cord, the power indicator is on: you can operate this appliance by touch

the button on panel as shown above, the main function includes: ice, clean, and light.

How to start the unit

1. Take out the water reservoir on the top, place the bottom up, open the cap, pour potable

water into water reservoir, 0.97 gallon (3.7 liters) water at most at one time. Screw the cap

on to the reservoir, and put it back on the top of the appliance again.

2. Before you put back the drawer, please make sure the water tank under the drawer is empty，

if not, unplug water drain cap to drain out water completely.

3. Put the drip tray in position.

Add water, screw the cap

and put it back.

Open the cap

Operation and display areas

USING YOUR ICE MAKER

5. Press “CLEAN” button “ ”, the icon lights up, 5 seconds later, this icon ﬂashes, it will run

cleaning procedure for at least 20 minutes, then the icon goes out. Press this button again,

it will stop cleaning.

6. After cleaning procedure, move the appliance to the edge of the desktop, make sure that

the appliance is placed steady, place a water container under the appliance, remove drain

plug from the back, unscrew the tie on the pipe, pull out the plug from the drainpipe, water

in the tank under the drawer and the evaporator will drain into the water container, then

reinsert the plug and put it back again.

Change water in the water reservoir every 24 hours to ensure a reasonable hygiene level. If

the unit isn’t to be used, drain all water & dry the water reservoir.

How to obtain the ice cube

10.

Before starting the ice making process, please check the drain pipe and drain pipe plug on

the back of the machine. Be sure to plug the drain pipe with a drain pipe plug and hang it

on the back of the machine.

Press the “ICE” button “ ”, the icon lights up, 5 seconds later, this icon ﬂashes, it begin to

work, Press this button again, it will stop making ice. During ice making procedure, you can

see how much ice has been stored in the drawer through the observation window.

For the ﬁrst time, or if the appliance has not been used for a long time, it is recommended

to clean this appliance before you start to make ice.

While the ice-maker is on, verify water level periodically. If water pump can’t pump out

water, the ice maker will stop automatically, and the “Add water” indicator will on. Need to

pour water into the water reservoir inside.

We suggest you should press “ICE” button to turn o the unit ﬁrst, then ﬁll water up, again

press “ICE” button to restart the unit. Allow the refrigerant liquid inside the compressor at

least 3 minutes to settle before restarting.

7USING YOUR ICE MAKER

Light on/off

11. Press the “LIGHT” button “ ”, the light inside the appliance is on, press this button again,

the light is o.

When Ice Full indicator is on

12. The ice maker automatically stops working when the ice-cube is full inside and the “ ice full”

Indicator is on.

Open the drawer

13. Hold the drawer handle gently and pull it out along the horizontal direction, until the back

of the drawer contacts the front panel and then gently put it down, the drawer will have a

certain angle hanging in the front panel. Instead, when you need to close the drawer, hold

the drawer handle and place the drawer horizontally, then gently push it into full closure.

Take out the drawer

14. Hold the drawer handle gently and pull it out along the horizontal direction, until the back

of the drawer contacts the front panel, and then gently lifted it up at a certain angle and

pulled it out. Instead, when you need to reload the drawer, you tilt the drawer in the same

direction at a certain angle. First, you put the back side of the drawer into the front panel,

slowly ﬂatten the drawer, and then gently push it into full closure.

USING YOUR ICE MAKER

PROBLEM POSSIBLE CAUSE SOLUTION

“Add Water”

indicator lights up Lack of Water.

Stop the ice maker, ﬁll water, and

press “ICE”/“CLEAN” button again

to restart the unit.

“Ice-Full” indicator

lights up

There is too much ice. Suggest you to obtain the ice-cube.

(No ice cube inside).

Remove the probable obstacle

inside or clean the inside wall of

the ice storage.

Press and hold the ice making

button for 5 seconds to forcibly

cancel full ice and restart ice

making for 80 minutes.

“Power” indicator

and ICE icon

ﬂashing

Ambient temperature or water

temperature in inner tank is too high.

Please run the ice maker below

90 Fahrenheit degree ambient

and pour colder water into tank.

Refrigerant liquid leakage. Press the ICE button twice, restart

ice making program, wait for 50

minutes, if this problem show up

again, verify by a qualiﬁed

technician.

Cover motor is broken.

Pipe in the cooling system is blocked.

Making Ice too

slowly

Hot Air outlet has been blocked by

something.

Hot Air outlet must be guaranteed

to have more than 15 CM of

ventilation distance.

Water temperature in inner tank is

too high.

Water temperature requirement

between 44.6℉-89.6℉.

Refrigeration system malfunctions. Verify by a qualiﬁed technician.

Water leakage

Drain plug not in place. Put the drain plug in place.

Pipe Joint in the appliance may

Loose. Verify by a qualiﬁed technician.

The seal has reached service life Verify by a qualiﬁed technician.

9TROUBLESHOOTING

Input Voltage: 115V 60Hz

Power Consumption: 200 W

Daily Ice Output: 20 KGS/24H

Refrigerant: R600a

Dimensions

Product Depth (IN.) 16.9

Product Height (IN.) 19

Product Width (IN.) 9.8

PRODUCT SPECIFICATIONS

Tabla de contenidos

Idiomas:

Otros manuales de Máquina de hielo de Frigidaire

Frigidaire

Frigidaire EFIC235 Manual de usuario

Frigidaire

Frigidaire IM115 - Ice Maker Kit Manual de usuario

Frigidaire

Frigidaire EFIC450 Manual de usuario

Frigidaire

Frigidaire EFIC206-B-TG-SILVER Manual del propietario

Frigidaire

Frigidaire EFIC123-B-SSRED Manual de usuario

Frigidaire

Frigidaire EFIC245-SS Manual del propietario

Frigidaire

Frigidaire EFIC452-SS Manual de usuario

Frigidaire

Frigidaire EFIC113 Manual de usuario

Frigidaire

Frigidaire EFIC255-GREY Manual del propietario

Frigidaire

Frigidaire EFIC236-WHITE Manual del propietario

Frigidaire

Frigidaire EFIC229-VCM Instrucciones de funcionamiento

Frigidaire

Frigidaire EFIC120-SS-SC Manual de usuario

Frigidaire

Frigidaire EFIC102-RED Manual de usuario

Frigidaire

Frigidaire FGHS2655PF6B Manual de usuario

Frigidaire

Frigidaire FXIC151-SS Manual del propietario

Frigidaire

Frigidaire EFIC117-SSBLACK-B-CU Manual de usuario

Frigidaire

Frigidaire EFIC123-SS Manual de usuario

Frigidaire

Frigidaire EFIC128-BLACK-6COM Manual del propietario

Frigidaire

Frigidaire EFIC157-BLACK Manual del propietario

Frigidaire

Frigidaire FFTR1835VS Manual de usuario

Frigidaire

Frigidaire EFIC117-SSCOPPER-B-COM Manual de usuario

Frigidaire

Frigidaire FFU20B6BW1 Manual de usuario

Frigidaire

Frigidaire EFIC117-SS Manual de usuario

Frigidaire

Frigidaire EFIC103-AMZ-SC Manual del propietario

Manuales populares de Máquina de hielo de otras marcas

Hoshizaki

Hoshizaki KMD-460MWJ Manual de usuario

Sub-Zero

Sub-Zero 315I Instrucciones de uso

Unold

Unold 48945 Manual de usuario

Kenmore

Kenmore 2217402A Manual de usuario

Cornelius

Cornelius WM600 Instrucciones de funcionamiento

GE XPIO43SCSS Manual de usuario

Hoshizaki

Hoshizaki KMD-901MAH Manual de usuario

Whynter

Whynter FIM-450HA Manual de usuario

U-Line

U-Line UMCR014-SC01A Manual de instalación

Andrew James

Andrew James AJ000522 Manual de usuario

Scotsman

Scotsman CME1356 Manual de usuario

Scotsman

Scotsman ACM 25 Manual de usuario

Kärcher

Kärcher IP 120 Manual de usuario

U-Line

U-Line SS1095 Manual de usuario

Maytag

Maytag MIM1554WRS - Ice Maker Manual de usuario

Hoshizaki

Hoshizaki KM-630MAH Manual de usuario

Princess

Princess Yonanas Manual de usuario

Unold

Unold 48946 Manual de usuario
