Friedrich KCS08A10A Manual de usuario
1PB
Service Manual
Room Air Conditioners
Standard Chassis Models
Kühl KCS08A10A, KCS10A10A, KCS12A10A, KCS14A10A, KCM14A10A
KCS12A30A, KCS16A30A, KCM18A30A, KCM21A30A KCL24A30A,
KCL24A30B, KCL28A30A, KCL36A30A
KHS10A10A
KHM12A33A, KHM18A34A, KHL24A35A
115-Volt:
230-Volt:
Kühl +
Electric Heat
Kühl +
Heat Pump
230-Volt:
93001403_04
KES12A33A, KES16A33A, KEM18A34A, KEL24A35A,
KEL24A35B, KEL36A35A
115-Volt:
230-Volt:
2PB
Table of Contents
INTRODUCTION 3
Important Safety Information 3
Personal Injury Or Death Hazards 4
New Kühl Control Options 6
Component Identication 7
Model and Serial Number Location 7
Model Number Reference Guide 8
Serial Number Reference Guide 9
SPECIFICATIONS 10
Refrigeration Systems Performance Data 10
Installation 12
Electrical Data 13
OPERATION 15
Airow Selection and Adjustment 15
User Interface 16
Control Panel 28
Remote Control 29
Unit 30
General Knowledge Sequence Of Refrigeration 36
ROUTINE MAINTENANCE 37
Remove And Install The Front Cover 37
Standard Filter Removal / Installation Instructions 39
REMOVE AND INSTALL THE CHASSIS 41
TROUBLESHOOTING 43
Cooling Sizing Guide 43
Diagnostic Codes 44
Troubleshooting Tips 45
COMPONENT TESTING 53
Capillary Tube and Check Valve Assy (Heat Pump Units) 53
Capillary Tube Assy (Cool Only Units) 54
Reversing Valve Description And Operation 55
Testing The Reversing Valve Solenoid Coil 56
Checking The Reversing Valve 57
Touch Test Chart : To Service Reversing Valves 58
Compressor Checks 59
Fan Motor 61
Capacitors 61
Heating Element 62
Drain Pan Valve 62
Testing the User Interface and Electronic Control Board 63
Thermistors Description 63
Electronic Control Board Identication 64
Replace the Electronic Control Board 65
Replace the User Interface 65
R-410A SEALED SYSTEM REPAIR 66
Refrigerant Charging 67
Undercharged Refrigerant Systems 68
Overcharged Refrigerant Systems 69
Restricted Refrigerant System 70
Sealed System Method of Charging/ Repairs 71
Compressor Replacement 72
Replace The Reversing Valve 74
WIRING DIAGRAMS 75
INTERACTIVE PARTS VIEWER 86
Available Accessories 87
APPENDIX 88
Appendix 1 Thermistor Resistence Values (This Table Applies to All Thermistors) 88
3PB
Your safety and the safety of others is very
important.
We have provided many important safety messages in this manual and on your appliance. Always
read and obey all safety messages.
This is a safety Alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol with the word
“WARNING”
or “CAUTION”. These words mean:
Indicates a hazard which, if not avoided, can result in severe personal
injury or death and damage to product or other property.
Indicates a hazard which, if not avoided, can result in personal injury and
damage to product or other property.
All safety messages will tell you what the potential hazard is, tell you
how to reduce the chance of injury, and tell you what will happen if the
instructions are not followed.
Indicates property damage can occur if instructions are not followed.
WARNING
Refrigeration system
under high pressure
Do not puncture, heat, expose to ame or
incinerate.
Only certied refrigeration technicians
should service this equipment.
R410A systems operate at higher pressures
than R22 equipment. Appropriate safe ser-
vice and handling practices must be used.
Only use gauge sets designed for use with
R410A.
Do not use standard R22 gauge sets.
NOTICE
CAUTION
WARNING
The information in this manual is intended for use by a qualied technician who is familiar with the safety procedures
required for installation and repair, and who is equipped with the proper tools and test instruments required to
service this product.
Installation or repairs made by unqualied persons can result in subjecting the unqualied person making such
repairs as well as the persons being served by the equipment to hazards resulting in injury or electrical shock which
can be serious or even fatal.
Safety warnings have been placed throughout this manual to alert you to potential hazards that may be encountered.
If you install or perform service on equipment, it is your responsibility to read and obey these warnings to guard
against any bodily injury or property damage which may result to you or others.
Important Safety Information
INTRODUCTION
4PB
SAFETY
FIRST
WARNING AVERTISSEMENT ADVERTENCIA
Do not remove, disable
or bypass this unit’s
safety devices. Doing so
may cause re, Doing so
may cause re, injuries,
or death.
Ne pas supprime, désacti-
ver ou contourner cette
l´unité des dispositifs de
sécurité, faire vous risque-
riez de provoquer le feu, les
blessures ou la mort.
No eliminar, desactivar o
pasar por alto los dispositi-
vos de seguridad de la
unidad. Si lo hace podría
producirse fuego, lesiones
o muerte.
ELECTRICAL HAZARDS:
• Unplug and/or disconnect all electrical power to the unit before performing inspections, maintenance, or service.
• Make sure to follow proper lockout/tag out procedures.
• Always work in the company of a qualied assistant if possible.
• Capacitors, even when disconnected from the electrical power source, retain an electrical charge potential
capable of causing electric shock or electrocution.
• Handle, discharge, and test capacitors according to safe, established, standards, and approved procedures.
• Extreme care, proper judgment, and safety procedures must be exercised if it becomes necessary to test or
troubleshoot equipment with the power on to the unit.
• Do not spray water on the air conditioning unit while the power is on.
• Electrical component malfunction caused by water could result in electric shock or other electrically unsafe
conditions when the power is restored and the unit is turned on, even after the exterior is dry.
• Use air conditioner on a single dedicated circuit within the specied amperage rating.
• Use on a properly grounded outlet only.
• Do not cut or modify the power supply cord or remove the ground prong of the plug.
• Never operate the unit on an extension cord.
• Follow all safety precautions and use proper and adequate protective safety aids such as: gloves, goggles,
clothing, properly insulated tools, and testing equipment etc.
• Failure to follow proper safety procedures and/or these warnings can result in serious injury or death.
INTRODUCTION
Personal Injury Or Death Hazards
WARNING
ALWAYS USE INDUSTRY STANDARD PERSONAL
PROTECTIVE EQUIPMENT (PPE)
5PB
• REFRIGERATION SYSTEM REPAIR HAZARDS:
• Use approved standard refrigerant recovering procedures and equipment to relieve high pressure before open-
ing system for repair. Reference EPA regulations (40 CFR Part 82, Subpart F ) Section 608.
• Do not allow liquid refrigerant to contact skin. Direct contact with liquid refrigerant can result in minor to moder-
ate injury.
• Be extremely careful when using an oxy-acetylene torch. Direct contact with the torch’s ame or hot surfaces
can cause serious burns.
• Make certain to protect personal and surrounding property with re proof materials and have a re extinguisher
at hand while using a torch.
• Provide adequate ventilation to vent off toxic fumes, and work with a qualied assistant whenever possible.
• Always use a pressure regulator when using dry nitrogen to test the sealed refrigeration system for leaks, ush-
ing etc.
• MECHANICAL HAZARDS:
• Extreme care, proper judgment and all safety procedures must be followed when testing, troubleshooting, han-
dling, or working around unit with moving and/or rotating parts.
• Be careful when, handling and working around exposed edges and corners of the sleeve, chassis, and other unit
components especially the sharp ns of the indoor and outdoor coils.
• Use proper and adequate protective aids such as: gloves, clothing, safety glasses etc.
• Failure to follow proper safety procedures and/or these warnings can result in serious injury or death.
• PROPERTY DAMAGE HAZARDS
• FIRE DAMAGE HAZARDS:
• Read the Installation/Operation Manual for the air conditioning unit prior to operating.
• Use air conditioner on a single dedicated circuit within the specied amperage rating.
• Connect to a properly grounded outlet only.
• Do not remove ground prong of plug.
• Do not cut or modify the power supply cord.
• Do not use extension cords with the unit.
• Be extremely careful when using acetylene torch and protect surrounding property.
• Failure to follow these instructions can result in re and minor to serious property damage.
• WATER DAMAGE HAZARDS:
• Improper installation, maintenance or servicing of the air conditioner unit can result in water damage to personal
items or property.
• Insure that the unit has a sufcient pitch to the outside to allow water to drain from the unit.
• Do not drill holes in the bottom of the drain pan or the underside of the unit.
• Failure to follow these instructions can result in damage to the unit and/or minor to serious property damage.
INTRODUCTION
PERSONAL INJURY OR DEATH HAZARDS
6PB
INTRODUCTION
New Kühl Control Options
The new Kühl gives you a variety of options for control, programming, and scheduling including wireless capabilities.
Wireless Programming and Control:
Friedrich Connect allows you to conveniently control, program, and monitor your air conditioning unit remotely from a smartphone
or computer.
Programmable Timer Options:
Your unit’s digital control comes equipped with a 24-hour timer.
24-Hour Timer
The 24-hour timer allows you to set 2 temperature changes at pre-set times on the unit control panel.
Customizable Programming Options:
Customizable timers, with up to four temperature adjustments per day, can be set using Friedrich Connect for one or multiple units.
See www.friedrich.com for complete details on Friedrich Connect.
Figure 101 (New Kuhl Options)
7PB
INTRODUCTION
This service manual is designed to be used in conjunction with the installation and operation manuals provided
with each air conditioning system.
This service manual was written to assist the professional service technician to quickly and accurately diagnose
and repair malfunctions.
Installation procedures are not given in this manual. They are given in the Installation/Operation manual which can
be aquired on the Friedrich website.
Model and Serial Number Location
MODELNUMBER
YS10M10A
SERIALNUMBER
LICY00008
VOLTS 115
60HZ / 1 PH
VOLTS MIN 108
COOLING
BTH/HR6500
EER12.0
AMPS8.0
HEATING
BTH/HR6500
EER10.4
AMPS7.0
REFRIGERANT
30.1OZ R410A
XXXXXXXXX
600PSIG HS
300PSIG LS
XXXXXXXXXX
XXXXXXXXX
XXXXXXXXXX
XXXXXXXXXX
FUSEPROTECTED
CIRCUITSUSE 15A
TIMEDELAY FUSE
X XX
XXXXX
XXXXXXXXXX
UL
AIRCONDITIONING CO.
SANANTONIO, TEXAS
ASSEMBLEDIN MEXICO
MODEL NUMBER
YS10M10A
SERIAL NUMBER
LICY00008
AIR CONDITIONING CO.
SAN ANTONIO, TEXAS
ASSEMBLED IN MEXICO
Accumulator
Compressor
Reversing Valve
Evaporator Coil
Blower Wheel
Electronic Control
Board
Control Key Pad
(User Interface)
Fan/Blower Motor
Fan Blade
Condenser Coil
Component Identication
Figure 102 (Component Identication)
Figure 103 (Model and Serial Number Location)
8PB
INTRODUCTION
Model Number Reference Guide
MODEL TYPE
K - KUHL
W - WALLMASTER
FUNCTION
C - COOL ONLY
E - ELECTRIC HEAT
H - HEAT PUMP
APPLICATION
S - SMALL
M - MEDIUM
L - LARGE
APPROXIMATE COOLING
BTU / HR
ENGINEERING REVSION
LETTER INDICATES AN
ENGINEERING MODIFI-
CATION TO AN EXISTING
MODEL
MARKETING SUFFIX LETTER
INDICATES MODIFICATION TO
AN EXISTING MODEL
HEAT STRIP
0 - STRAIGHT COOL & HEAT
PUMP
3 -3.3 KW HEAT STRIP, NOMINAL
4 - 4.0 KW HEAT STRIP, NOMINAL
5 - 5.2 KW HEAT STRIP, NOMINAL
VOLTAGE
1 - 115 VOLTS
3 - 230 VOLTS
MODEL INTRODUCTORY
CHARACTER
A - 2019
B -
C -
D -
IMPORTANT: It will be necessary for you to accurately identify the unit you are servicing, so you can be certain of a
proper diagnosis and repair.
Figure 104 (Model Number Reference Guide)
K C M 21 A 3 0 A - A
9PB
INTRODUCTION
Serial Number Reference Guide
YEAR OF MANUFACTURE
17 = 2017 18 = 2018
19 = 2019 20 = 2020
21 = 2021 22 = 2022
MONTH OF MANUFACTURE
01 = JANUARY
02 = FEBRUARY
03 = MARCH
04 = APRIL
05 = MAY
06 = JUNE
07 = JULY
08 = AUGUST
09 = SEPTEMBER
10 = OCTOBER
11 = NOVEMBER
12 = DECEMBER
FACTORY DESIGNATION
M = FRIEDRICH MTY
NUMERIC SEQUENCE
FIRST UNIT OF EACH MONTH = 00001
Figure 105 (Serial Number Reference Guide)
17 12 M 00001
10 PB
SPECIFICATIONS
Refrigeration Systems Performance Data
Model
Condensor
Temp
Deg F.
Discharge
Temp
Deg. F
Suction
Temp
Deg F
Electrical Ratings R-410A
REF. Breaker
AMPS
COOL AMPS
HEAT
LOCKED
ROTOR
AMPS CHARGE
IN OZ Voltage
60
HERTZ
AMPS
Kühl® (Cool Only)
KCS08A10A 111 154 59 6.5 30.5 24.5 115 15
KCS10A10A 114 155 56 8.5 49 32 115 15
KCS12A10A 118 159 54 9.5 52 33 115 15
KCS12A30A-A 117 170 69 4.8 29 35.9 230 15
KCS12A30A-B 117 170 69 4.8 29 35.5 230 15
KCS12A30A-C 117 170 69 4.8 29 35.9 230 15
KCS12A30A-D 117 170 69 4.8 29 27.7 230 15
KCS14A10A-C 120 169 57 11.8 54.5 26 115 15
KCS14A10A-D 120 169 57 11.8 54.5 25 115 15
KCS16A30A-(A THRU D) 121 163 45 6.6 33 38.3 230 15
KCS16A30A-E 121 163 45 6.6 33 31 230 15
KCM14A10A 113 147 49 10.9 54.5 38 115 15
KCM18A30A 119 180 61 9.6 46 46 230 15
KCM21A30A 123 171 53 9.6 46 46 230 15
KCL24A30A
KCL24A30B 122 168 55 11.1 52 46 230 20
43
KCL28A30A-A, -C, -D 126 167 45 13.4 60 58.5 230 20
KCL28A30A-A, -C, -D 126 167 45 13.4 60 51.2 230 20
KCL36A30A 130 179 44 18.2 76 68 230 30
Kühl® + (Heat Pump)
KHS10A10A-A 116 153 54 8.8 9.1 50 28.5 115 15
KHS10A10A-B, -C 25.6 115
KHS12A33A 120 163 53 54.7 29 28 230 20
KHM18A34A 117 160 52 7.4 7.4 37 43.1 230 30
KHL24A35A 122 175 64 11.1 10.3 52 48 230 30
Kühl® + (Electric Heat)
KES12A33A 117 170 69 4.9 29 33 230 20
KES16A33A-(A THRU D) 121 163 45 6.6 33 38.3 230 20
KES16A33A-E 121 163 45 6.6 33 31 230 20
KEM18A34A 119 180 61 9.6 46 230 30
KEL24A35A
KEL24A35B 122 168 55 11.1 52 46 230 30
43
KEL36A35A 130 179 44 18.2 76 68 230 30
*Rating Conditions: 80 degrees F, room air temp. & 50% relative humidity, with 95 degree F, outside air temp &
40% relative humidity, all systems use R-410A. Test done at highest unit fan speed.
Figure 201 (Refrigeration Systems Performance Data)
Este manual sirve para los siguientes modelos
21
Tabla de contenidos
Otros manuales de Acondicionador de aire de Friedrich
Friedrich
Friedrich X-Star XQ05 Manual de usuario
Friedrich
Friedrich P09B-A Guía
Friedrich
Friedrich MR18Y3H Instrucciones de construcción
Friedrich
Friedrich CP Line CP08 Manual de usuario
Friedrich
Friedrich Uni-Fit US10C10 Manual de usuario
Friedrich
Friedrich MW09Y3FM Manual de usuario
Friedrich
Friedrich Kuhl SQ05N10 Series Manual de usuario
Friedrich
Friedrich 2001 Hazardgard SH14J30A-1 Manual de usuario
Friedrich
Friedrich M2404ER Instrucciones de construcción
Friedrich
Friedrich Climate Master 702 Series Manual de usuario
Friedrich
Friedrich Z-Star ZQ05C10 Manual de usuario
Friedrich
Friedrich MD36Y3J Manual de usuario
Friedrich
Friedrich ZStar ZQ08 ZQ10 Manual de usuario
Friedrich
Friedrich MD12Y3JM Manual de usuario
Friedrich
Friedrich UE08 Instrucciones de funcionamiento originales
Friedrich
Friedrich MR36TQY3F Manual de usuario
Friedrich
Friedrich VRP Series Guía
Friedrich
Friedrich WallMaster PTAC Manual de usuario
Friedrich
Friedrich S S 08 Manual de usuario
Friedrich
Friedrich QuietMaster KS10 Manual de usuario
