Quick Start Guide for DEMO9S08SF4

DEMO9S08SF4

8-bit microcontrollers

Get to Know the DEMO9S08SF4 Board

Reset Button

Open Source BDM

USB Port

SW1 and SW2

Potentiometer

MC9S08SF4

Buzzer

Quick Start Guide for DEMO9S08SF4

Introduction

DEMO9S08SF4 is a cost-effective kit targeting quick

MC9S08SF4 evaluation. It can be used to demonstrate the

features of the MC9S08SF4 devices. This quick start guide is

designed to get you ready to develop your next cost-effective

application using the MC9S08SF4 within minutes.

Install CodeWarrior™

Development Studio for

Microcontrollers

CodeWarrior is a powerful tool designed

to help you minimize your time to market.

CodeWarrior installation is a one-time

required step before connecting the board

to your computer.

1. Insert the provided DVD into your

computer.

2. Double click Install CodeWarrior

Development Studio for

Microcontrollers 6.2.

3. Follow the on-screen instructions

until installation is complete.

Once the installation is complete, you can

take advantage of several CodeWarrior

tutorials that will walk you through

various development tool features,

such as C Programming, Assembly

Programming, Using Processor

Expert™ and more. Simply open

CodeWarrior using the path Programs

> Freescale CodeWarrior > CW for

Microcontroller V6.x > CodeWarrior

IDE.exe.

Click Run Getting Started Tutorial from

the startup dialog, select a tutorial and

follow the on-screen instructions.

Install CodeWarrior

for Microcontrollers

6.2.2 Patch

You must install the CodeWarrior 6.2.2

patch so CodeWarrior can create and

compile the MC9S08SF4 project. The

CodeWarrior patch 6.2.2 includes

MC9S08SF4 service pack and provides

open source BDM (OSBDM) support.

This installation is a one-time required

step before connecting the board to your

computer.

1. Insert the provided DVD into your

computer.

2. Double click Install CodeWarrior

Development Studio for

Microcontroller 6.2.2 patch.

3. Follow the on-screen instructions

until installation is complete.

After the CodeWarrior 6.2.2 patch is

installed, you can select MC9S08SF4

silicon when you create an application.

STEP

Quick Start Guide for DEMO9S08SF4

Connect Board

to Computer

USB driver installation is a one-time

required step, to be completed after

CodeWarrior installation.

1. Remove DEMO9S08SF4 demo board

from anti-static bags.

2. Connect the provided A to B USB

cable from a free USB port on your

computer to the USB connector on

the board.

3. The operating system will recognize

your board as new hardware and will

prompt you to install the USB drivers.

Choose the recommended option to

install the software automatically. USB

drivers for your board were pre-loaded

in the CodeWarrior installation.

4. Follow on-screen instructions until all

USB driver installations are complete.

The green USB LED on the board

should illuminate.

Run and Debug

Example Code on Board

1. Copy DEMO9S08SF4 Demo code

from the provided DVD and save to

your PC folder

2. Start CodeWarrior from Windows

Start menu.

3. From the CodeWarrior main menu,

choose File > Open and choose the

DEMO9S08SF4\SF4_Demo.mcp file

from the folder where you saved the

DEMO9S08SF4 Demo code. Click

Open. The Project window will open.

4. The C code of this example is

contained in the main.c file. Double

click on the file to open it.

5. From the main menu, choose

Project > Change MCU/Connection.

When the Device and Connection

dialog box appears, select HCS08 FSL

Open Source BDM from top

right window in the dialog and click the

Finish button. The operation allows

you to select different debug tools

for the targets. In DEMO9S08SF4,

FSL OSBDM is applied and must be

selected as the tool before debug.

STEP

6. From the main menu, choose

Project > Debug. This will compile the

source code, generate an executable

file and download it to the demo board.

When the Loader Warning dialog

appears, click OK to proceed.

7. A new debugger environment will

open. From the main menu, choose

Run > Start/Continue. The program

will be executed in real time.

8. Press the SW1 key and the buzzer

on the demo board will work with the

preset frequency. Press the SW1 key

continuously to change the frequency

of the sound. The duty will be changed

when the potentiometer is adjusted.

9. Press the SW2 key on the demo

board to stop the buzzer. The buzzer

will stop automatically after several

seconds.

10. From the main menu, choose

Run > Halt. The program execution

will stop. The next instruction to

be executed is highlighted in the

Source window.

11. From the main menu, choose

Run > Single Step. The instruction

highlighted in the Source window

will be executed, and the program

execution will be stopped

immediately after.

12. From the main menu, choose

Run > Start/Continue. The application

will restart from where it was previously

stopped.

Start Your Development

Congratulations, you have successfully

completed this tutorial! We encourage

you to continue experimenting with

the CodeWarrior user interface. For an

in-depth guide of all of the user interface

features, select Help > CodeWarrior

Help from CodeWarrior Development

Studio’s main menu.

Freescale and the Freescale logo are trademarks or registered

trademarks of Freescale Semiconductor, Inc. in the U.S. and other

countries. All other product or service names are the property of

their respective owners. © Freescale Semiconductor, Inc. 2009.

Doc Number: DEMO9S08SF4QSG / REV 0

Agile Number: 926-26145 / REV A

Learn more at www.freescale.com/8bit.
