Foxtech EH30-MTIR Manual de usuario

User Manual

V1.0

EH30-M TIR Dual Sensor 30X

Optical Zoom Camera with 3-axis

Gimbal

2022.02

Thank you for purchasing this product. This is a special web page for gimbal and cameras, you can enter

this page for the latest product information, technical support and user manuals.

https://www.foxtechfpv.com/industrial-drone/camera-for-drones.html

We recommend that you download and use the latest user manual. And no further update notice will be

given separately. Due to different production batches, the appearance or function parameters are slightly

different, which does not affect the normal use of the product.

Please read this statement carefully before use. Once used, it is deemed to be an endorsement and

acceptance of the entire contents of this statement. Please read the instruction manual carefully and

strictly follow the requirements of this manual to install and use this product. Foxtech will not bear any legal

responsibility for any results or losses caused by improper use, installation, final assembly and modification

by users.

Note

Disclaimer

Intellectual Property Rights

The intellectual property rights of this product and manual are owned by Foxtech Trade Co., Ltd. Without

written permission, no organization or individual may copy, reproduce or distribute in any form. If quotation is

needed, the source must be indicated, and this manual must not be modified, deleted or quoted against its

original intention.

Note

Disclaimer

Intellectual Property Rights

System Composition

Product System Atlas

Installation

Installation and setup methods of third-party videolink

GCS Software Usage Instructions

Operating Pods

Frequently Asked Questions

Parameter

Contents

System Composition

Product System Atlas

Product Wiring Diagram

Foxtech EH30-MTIR Dual Sensor 30X Optical Zoom Camera User Manual

A. Modify IP of Pod and IDU (segment to meet videolink requirements)

Pod segment modification, take “change 42 segment to 1 segment” as an example:

1→pod electrified, and connected the pod to the computer through the wire, the pod works normally after

about 15 seconds, the computer recognizes the camera network.

2→TCPIPV4 settings, as shown below, are saved after confirmation

3. Use GCS ground station for gateway setting

Click to search device, then double-click the pop-up IP bar, save it after modification, and restart the gimbal.

Installation and setup methods of third-party videolink

192 168 42 10

255 255 255 0

192 108 42 0

4.→Camera IP modification

Open any browser, enter 192.168.42.108

After entering the following interface, username, password are admin

Confirmation

Then the following password modification interface appears, click cancel

After entering the setup interface, click Settings → Network Settings → General Settings

Change the IP address and default gateway “42” to “1”, then click Save.

Do not modify the password, otherwise the software will not working properly.

5.→Pod net segment setup complete.

Change the network segment settings in the computer TCPIPV4 to the normal network segment. (Different

videolink requires different settings, the equipment used shall prevail.)

Pod RTSP Common Address:

Main stream rtsp ://admin: admin @< ip >:554/cam/realmonito? Channel=1& subtype=0

Secondary stream 1 rtsp ://admin: admin @< ip >:554/cam/realmonito? Channel =1& subtype =1

Secondary stream 2 rtsp ://admin: admin @< ip >:554/cam/realmonito? Channel=1& subtype=2

usually uses secondary stream 2 for preview

RTSP ://admin: admin @192.168.42.108:554/cam/realmonito? Channel=1& subtype=2

Setting area

Interface shifting

Camera setting


REC

One key downward

One key forward

Yaw following

Manual focus+

Auto focus

Manual focus-

Target following

GCS Software Usage Instructions

Operating Pods

GCS pod software through the mouse, virtual keys, USB joystick to achieve the full operation of the pod.
