Foxconn D250S Manual de usuario

D270S/D250S

Motherboard

User’s Manual

Statement:

This manual is the intellectual property of Foxconn, Inc. Although the information

in this manual may be changed or modied at any time, Foxconn does not obligate

itself to inform the user of these changes.

Trademark:

All trademarks are the property of their respective owners.

Version:

User’s Manual V1.0 for D270S/D250S motherboard.D270S/D250S motherboard.motherboard.

Symbol description:

Caution : refers to important information that can help you to use motherboard

better, and tells you how to avoid problems.

Warning : indicating a potential risk of hardware damage or physical injury may

exist.

WEEE:

The use of this symbol indicates that this product may not be treated as household

waste. By ensuring this product is disposed of correctly, you will help prevent potential

negative consequences for the environment and human health, which could otherwise

be caused by inappropriate waste handling of this product. For more detailed

information about recycling of this product, please contact your local city ofce, your

household waste disposal service or the shop where you purchased this product.

More information:

If you want more information about our products, please visit Foxconn’s

website: http://www.foxconnchannel.com

CAUTION

All trade names are registered trademarks of respective manufacturers listed.

All images are for reference only, please refer to the physical motherboard for specic features.

Declaration of conformity

HON HAI PRECISION INDUSTRY COMPANY LTD

66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,

TAIPEI HSIEN, TAIWAN, R.O.C.

declares that the product

Motherboard D270S/D250S

is in conformity with

(reference to the specication under which conformity is declared in

accordance with 89/336 EEC-EMC Directive)

■ EN 55022:1998/A2: 2003 Limits and methods of measurements of radio

disturbance characteristics of information technology

equipment

■ EN 61000-3-2/:2000 Electromagnetic compatibility (EMC)

Part 3: Limits

Section 2: Limits for harmonic current emissions

(equipment input current <= 16A per phase)

■ EN 61000-3-3/A1:2001 Electromagnetic compatibility (EMC)

Part 3: Limits

Section 2: Limits of voltage uctuations and icker in low

voltage supply systems for equipment with rated current

<= 16A

■ EN 55024/A2:2003 Information technology equipment-Immunity

characteristics limits and methods of measurement

Signature : Place / Date : TAIPEI/2011

Printed Name : James Liang

Declaration of conformity

Trade Name: FOXCONN

Model Name: D270S/D250S

Responsible Party: PCE Industry Inc.

Address: 458 E. Lambert Rd.

Fullerton, CA 92835

Telephone: 714-738-8868

Facsimile: 714-738-8838

Equipment Classication: FCC Class B Subassembly

Type of Product: Motherboard

Manufacturer: HON HAI PRECISION INDUSTRY

COMPANY LTD

Address: 66 , CHUNG SHAN RD., TU-CHENG

INDUSTRIAL DISTRICT, TAIPEI HSIEN,

TAIWAN, R.O.C.

Supplementary Information:

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions : (1) this device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

Tested to comply with FCC standards.

Signature : Date : 2011

Installation Precautions

Please carefully read the following procedures to install your computer :

■ It is suggested to select high-quality, certied fans in order to avoid damage

to the motherboard and CPU due to high temperature. Never turn on the

computer if the CPU fan is not properly installed.

■ We cannot guarantee that your system can operate normally when your

CPU/Memory is overclocked. Normal operation depends on the overclocking

capacity of your device.

■ If there is any, when connecting USB, audio, 1394a, RS232 COM, IrDA or

S/PDIF cables to the internal connectors on the motherboard, make sure

their pinouts are matching with the connectors on the motherboard. Incorrect

connections might damage the motherboard.

■ When handling the motherboard, avoid touching any metal leads or connec-

tors.

■ If there is a PCI Express x16 graphics card installed in your system, we

recommend using a 24-pin ATX power supply to get the best performance.

■ Before turning on the power, please make sure the power supply AC input

voltage setting has been congured to the local standard.

■ To prevent damage to the motherboard, do not allow screws to come in contact

with the motherboard circuit or its components. Also, make sure there are no

leftover screws or metal components placed on the motherboard or within the

computer casing.

■ If you are uncertain about any installation steps or have a problem related to

the use of the product, please consult a certied computer technician.

CAUTION

■ Electrostatic discharge (ESD) is the sudden and momentary electric current

that ows between two objects at different electrical potentials. Normally it

comes out as a spark which will quickly damage your electronic equipment.

Please wear an electrostatic discharge (ESD) wrist strap when handling

components such as a motherboard, CPU or memory.

■ Ensure that the DC power supply is turned off before installing or removing

CPU, memory, expansion cards or other peripherals. It is recommended to

unplug the AC power cord from the power supply outlet. Failure to unplug

the power supply cord may result in serious damage to your system.

TABLE OF CONTENTS

Chapter 1 Product Introduction

Product Specications.................................................................. 2

Layout...........................................................................................4

Back Panel Connectors................................................................ 5

Chapter 2 Installation

Install the Memory ........................................................................ 8

Install other Internal Connectors .................................................. 9

Jumpers......................................................................................13

Install Driver and Utility...............................................................14

Chapter 3 BIOS Setup

Enter BIOS Setup....................................................................... 15

Main ...........................................................................................16

F-Center....................................................................................... 17

Advanced ...................................................................................21

Boot ............................................................................................27

Power ........................................................................................28

Health ........................................................................................29

Security ......................................................................................31

Save & ExitSave & Exit ...............................................................................32

Chapter 4 CD Instruction

Utility CD content........................................................................35

Install driver and utility................................................................ 36

FOX ONE

Main Page............................................................................. 37

CPU Control.......................................................................... 42

Frequency Control ................................................................45

Limit Setting ..........................................................................46

Voltage Control .....................................................................47

Fan Control............................................................................48

FOX LiveUpdate

Local Update......................................................................... 51

Online Update .......................................................................53

Congure ............................................................................. 55

About & Help......................................................................... 57

FOX LOGO.................................................................................58

FOX DMI/Smart Charger............................................................ 59

Technical Support :

Website :

http://www.foxconnchannel.com

Support Website :

http://www.foxconnsupport.com

Worldwide online contact Support :

http://www.foxconnsupport.com/inquiry.aspx

CPU Support List :

http://www.foxconnsupport.com/cpusupportlist.aspx

Memory, VGA Compatibility List :

http://www.foxconnsupport.com/complist.aspx

Support

Thank you for buying Foxconn D270S/D250S motherboard. FoxconnD270S/D250S motherboard. Foxconnmotherboard. Foxconn

products are engineered to maximize computing power, providing only

what you need for break-through performance.

D270S/D250S enables you to unleash more power from yourenables you to unleash more power from your

computer.

This chapter includes the following information:

■ Product Specications

■ Layout

■ Back Panel Connectors

1-1 Product Specications

CPU

Support

Cedarview-D,Dual core CPU processor D2700&D2500,

Max processor power up to 10W

For the latest CPU information,

please visit:

http://www.foxconnsupport.com/cpusupportlist.aspx

Chipset Tigerpoint - NM10

Memory

2 x SO-DIMM DDR3 SDRAM

Support up to 4GB of system memory

DDR3 1066 MHz architecture

Expansion Slots 1 x PCI slot

Storage 2 x SATAII

LAN

Realtek 8111E Gbe LAN chip8111E Gbe LAN chip

Audio Realtek ALC662 Audio chip

- High Denition Audio

-2/4/5.1-channel

- Support Jack-Sensing function

USB Support up to 8 x USB ports (2 USB 2.0+ 2 USB 3.0 rear panel ports,

2 onboard USB headers providing 4 extra ports) (D270S)

Support up to 8 x USB 2.0 ports (4 rear panel ports,

2 onboard USB headers providing 4 extra ports) (D250S)

Support USB 2.0 protocol up to 480Mb/s

Support USB 3.0 protocol up to 5Gbps.

Internal Connectors

1 x 24-pin ATX main power connector

1 x 4-pin ATX 12V power connector

2 x SATAII

connectors

2 x USB 2.0 header (supporting 4 x USB devices)

1 x CPU fan header (4-pin)

1 x System fan header (4-pin)

1 x Front panel header

1 x Front audio header

1 x Speaker header

1 x Clear CMOS

header

1 x TPM/TCM header

1 x IR/CIR header

1 x Intrusion Alarm header

(Continued on the next page)

Back Panel

Connectors

1 x PS/2 Keyboard port

1 x PS/2 mouse port

1 x RJ-45 LAN port

1 x COM1 port

1 x VGA port

1 x HDMI port

2 x USB 2.0 + 2 x USB 3.0 port

(D270S)

4 x USB 2.0 port

(D250S)

3 ports audio jacks

Hardware Monitor

System voltage detection

CPU/System temperature detection

CPU/System fan speed detection

CPU overheating warning

CPU/System fan speed control

Green Function

Support ACPI (Advanced Conguration and Power Interface)

Support S0 (normal), S1 (power on suspend), S3 (suspend to RAM),

S4 (suspend to disk), S5 (soft - off)

Support EuP function

Bundled Software

FOX ONE, FOX LiveUpdate, FOX LOGO, FOX DMI,Smart Charger

Operating System

Support for Microsoft® Windows® 7/Vista

Form Factor

Mini-ITX Form Factor, 6.7 inches x 6.7 inches (17 cm x 17 cm)

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Placa madre de Foxconn

Foxconn

Foxconn K7S741GXMG-6L Manual de usuario

Foxconn

Foxconn 845GV4MR-ES Hoja de datos

Foxconn

Foxconn PL7MA User's Manual de usuario

Foxconn

Foxconn K7S741MG Hoja de datos

Foxconn

Foxconn Z68A-S Series Manual de usuario

Foxconn

Foxconn A75M Series Manual de usuario

Foxconn

Foxconn H61MD Series Manual de usuario

Foxconn

Foxconn M7PMX series User's Manual de usuario

Foxconn

Foxconn G41MD Manual de usuario

Foxconn

Foxconn 671MX Series Manual de usuario

Foxconn

Foxconn K8T890M2AB Instrucciones de uso

Foxconn

Foxconn 661FX7MJ Series Manual de usuario

Foxconn

Foxconn D51S series Manual de usuario

Foxconn

Foxconn H61MXV Series Manual de usuario

Foxconn

Foxconn 975X7AB Manual de usuario

Foxconn

Foxconn B75M Manual de usuario

Foxconn

Foxconn 650M02 Series Manual de usuario

Foxconn

Foxconn 600A01 series Manual de usuario

Foxconn

Foxconn 661M03 Series Manual de usuario

Foxconn

Foxconn 661FX7MF series Manual de usuario

Foxconn

Foxconn Quantumian1 Manual de usuario

Foxconn

Foxconn G41MX 2.0 Manual de usuario

Foxconn

Foxconn 915PL7AE series Manual de usuario

Foxconn

Foxconn A7GMX-K Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario
