Foxconn K8M890M2MA Manual de usuario

Thismanualistheintellectualpropertyof Foxconn,Inc.Althoughthe

informationinthismanualmaybechangedormodifiedatanytime,

Foxconn doesnot obligateitself toinformtheuser of these changes.

Statement:

Alltrademarksarethepropertyoftheir respectiveowners.

Moreinformation:

If you want moreinformationaboutourproducts,pleasevisit Foxconn s

website: http://www.foxconnchannel.com

Version:

Trademark:

User sManualV1.0forK8M890M2MAmotherboard.

P/N:91-181K8MM30E-00-G

Symboldescription:

Note: referstoimportantinformationthatcanhelpyoutousemotherboard

better.

Attention: indicates thatit maydamagehardwareorcause dataloss,

and tellsyou howtoavoidsuch problems.

Warning: means thatapotentialriskofpropertydamage or physical

injuryexists.

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Declaration ofconformity

HONHAIPRECISIONINDUSTRYCOMPANYLTD

66,CHUNGSHAN RD.,TU-CHENGINDUSTRIALDISTRICT,

TAIPEI HSIEN,TAIWAN, R.O.C.

declaresthatthe product

Motherboard

K8M890M2MA

isinconformitywith

(referencetothespecification under which conformityisdeclared in

accordance with89/336EEC-EMCDirective)

þEN55022:1998/A2:2003Limitsandmethodsofmeasurementsofradiodisturbance

characteristicsofinformationtechnologyequipment

þEN61000-3-2/:2000 Electromagneticcompatibility(EMC)

Part3: Limits

Section 2:Limitsforharmoniccurrent emissions

(equipmentinput current <=16Aperphase)

þEN61000-3-3/A1:2001 Electromagneticcompatibility(EMC)

Part3: Limits

Section2:Limitsof voltagefluctuationsand flickerin low-voltage

supplysystems forequipmentwithratedcurrent<= 16A

þEN55024/A2:2003 Informationtechnologyequipment-Immunitycharacteristicslimits

andmethodsof measurement

Signature: Place/ Date: TAIPEI/2006

PrintedName: JamesLiangPosition/Title: AssistantPresident

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Declaration ofconformity

Trade Name: WinFast

ModelName: K8M890M2MA

ResponsibleParty: PCE IndustryInc.

Address: 458 E.Lambert Rd.

Fullerton,CA92835

Telephone: 714-738-8868

Facsimile: 714-738-8838

Equipment Classification: FCCClassBSubassembly

Type ofProduct: Motherboard

Manufacturer:HON HAIPRECISION INDUSTRY

COMPANYLTD

Address: 66,CHUNG SHANRD.,TU-CHENG

INDUSTRIALDISTRICT, TAIPEIHSIEN,

TAIWAN,R.O.C.

SupplementaryInformation:

ThisdevicecomplieswithPart15oftheFCC Rules. Operationissubjecttothefollow-

ingtwoconditions:(1) thisdevice maynotcauseharmfulinterference,and(2) this

devicemustacceptanyinterference received,includinginterferencethat maycause

undesiredoperation.

TestedtocomplywithFCC standards.

Signature: Date: 2006

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

ProductIntroduction

MainFeatures.............................................................................................2

MotherboardLayout...................................................................................4

RearI/OPorts.............................................................................................5

InstallationInstructions

CPU............................................................................................................7

Memory......................................................................................................8

PowerSupply.............................................................................................9

OtherConnectors.....................................................................................10

Expansion Slots........................................................................................14

Jumpers...................................................................................................15

BIOSDescription

EnterBIOSSetup......................................................................................17

Mainmenu................................................................................................17

StandardCMOSFeatures.........................................................................19

CentrolControlUnit...................................................................................22

AdvancedBIOSFeatures.........................................................................24

AdvancedChipsetFeatures.....................................................................27

IntegratedPeripherals...............................................................................31

PowerManagementSetup........................................................................35

PnP/PCIConfigurations.............................................................................41

PCHealthStatus.......................................................................................42

LoadFail-SafeDefaults............................................................................44

LoadOptimizedDefaults...........................................................................44

SetSupervisor/UserPassword................................................................44

Save&ExitSetup.....................................................................................45

ExitWithoutSaving...................................................................................45

TableofContents

Chapter 1

Chapter 2

Chapter 3

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Driver CD Introduction

UtilityCDcontent.................................................................................47

Start toInstall drivers...........................................................................48

DirectionsforBundledSoftware

FOXONE.................................................................................................50

FoxLiveUpdate.....................................................................................56

TableofContents

Chapter

5Chapter

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

1.Attach the CPUand heatsinkusing silicageltoensurefullcontact.

2.Itissuggestedtoselecthigh-quality, certified fansinordertoavoid

damagetothemotherboardandCPU duehigh temperatures.

3.Neverturnon themachineiftheCPU fanisnot properlyinstalled.

4.EnsurethattheDC powersupplyisturnedoff beforeinserting or

removingexpansioncardsorotherperipherals,especiallywhen

youinsert orremoveamemorymodule.Failuretoswitchoff the DC

powersupplymayresultinseriousdamagetoyoursystemor

memorymodule.

Warning:

Wecannotguarantee thatyoursystemwill operatenormallywhile

over-clocked. Normaloperation dependson theover-clock capacity

ofyourdevice.

Warning:

Attention:

SinceBIOSprogramsareupgradedfromtimetotime,theBIOS

description inthismanualisjustforreference.Wedo notguarantee

thatthecontentofthismanualwillremainconsistentwiththeactual

BIOSversion atanygiventimeinthefuture.

Attention:

The pictures of objectsusedinthismanualarejustforyour reference.

Pleaserefertothe physicalmotherboard.

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Thismanualissuitableformotherboardof K8M890M2MA.

Each motherboardiscarefullydesigned forthe PCuser

who wantsdiversefeatures.

-L withonboard10/100MLAN

-K withonboardGigabit LAN

-6 with6-Channelaudio

-8 with8-Channelaudio

-E with1394function

-S withSATAfunction

-2 withDDR2function

-R withRAIDfunction

Youcanfind PPIDlabelonthemotherboard.It indicatesthe

functions thatthemotherboardhas.

Forexample:

OntheblackmarkofthePPIDlabel, it meansthe

motherboardsupports6-ChannelAudio(-6), 1394 port(-E),

onboard10/100MLAN (-L), SATAfunction (-S).

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter

Thankyou foryourbuying WinFast sK8M890K8MAse-

riesmotherboard.Thisseriesofmotherboardisoneofour

newproductsand offerssuperiorperformance,reliability

andquality,atareasonableprice.Thismotherboardadopts

the advanced VIA®K8M890 +VT8237R Plus/VT8237A Plus

chipset,providingusersacomputerplatformwithahigh

integration-compatibility-performance price ratio.

Thischapterincludesthe followinginformation:

vMainFeatures

vMotherboardLayout

vRear I/OPorts

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter1ProductIntroduction

Main Features

Size

·mATX formfactor of 9.6inch x8.8inch

Microprocessor

·SupportssocketAM2forAMD®Athlon TM 64 FX /Athlon64 X2Dual-Core/AthlonTM

64/Sempron processors

·SupportsHyperTransport TM upto2000MT/s

Chipset

·VIA®K8M890 (NorthBridge)+VT8237RPlus/VT8237A(SouthBridge)

SystemMemory

·Two240-pinDDRII slots

·SupportsDualChannelDDRII 800/667/533 memory

·Supportstechnologyupto2GB

USB 2.0Ports

·Supportshotplug

·EightUSB 2.0ports

·Supportswake-up fromS1andS3mode

·SupportsUSB2.0protocolupto480Mbpstransmission rate

OnboardSerialATA(-s)

·150MBpstransferrate

·SupportstwoSATA devices

·SupportsRAID0, 1,0+1andJBOD

Onboard1394 (-E)(optional)

·Supportshotplug

·Withrateof transmissionup to400Mbps

·Canconnectwith2independent1394unitssynchronouslyatmost

PDF 件使用 "pdfFactory" 试用版本创建 www.fineprint.com.cn

Chapter1ProductIntroduction

OnboardLAN (-L/-K)(optional)

·Supports10/100/1000Mbit/sec Ethernet

·LANinterfacebuilt-inonboard

OnboardAudio(-6)(optional)

·AC 97 2.3Specification Compliant

·SupportsSPDIFoutput

·OnboardLine-injack, Microphone-injack, Line-outjack

·Supports6channelsaudio(settingviasoftware)

OnboardAudio(-8)(optional)

·Supports8channelsaudio

·SupportsIntelHighDefinitionAudio

·Supportshigh qualitydifferentialCD input

ExpansionSlots

·TwoPCIslots

·One PCIExpress16Xslot

·OnePCIExpress1Xslot

Green Function

·SupportsACPI(Advanced ConfigurationandPower Interface)

·SupportsS0(normal), S1(power onsuspend),S3(suspendtoRAM), S4

(suspend todisk –depends onOS)andS5(soft-off)

AdvancedFeatures

·PCI2.3SpecificationCompliant

·SupportsWindows98/2000/ME/XPsoft-off

·SupportsPCHealthfunction(capableofmonitoringsystemvoltage,CPU

temperature,systemtemperatureand fanspeed)
