Introducon
With the marvellous success of Flycam Flowline series, Flycam feels proud to
introduce a two axis spring arm - Flycam Flowline Placid that controls vibraons on
the vercal axis or side to side axis which come from walking or running. It aaches
at the end of the Flycam Flowline top arm and allows you to go from high to low
mode and to control the vercal and side to side stabilizaon simultaneously.
Please inspect the contents of your shipped package to ensure you have received
everything that is listed below.
What’s In The Box
Tensioner Spring
Assembling
Remove the hook from Flowline support
bar.
Safety Shock Cord
5
Take the cord bundle out from the cup and pull the whole cord unl a cord lock comes out.
Separate the cord from cord lock and
keep the lock aside for aaching it back
aerwards.
Separate the cord also from the cup
and keep aside for mounng it back
later.
6
Pull out the front pulley carefully, so it doesn’t drop into the Flowline support bar and Insert
the cord from the boom hole and tug it out from the top hole.
Use a tool to unscrew small bolts that
hold the front pulley, from each side.
Mount front pulley in between the cord,
and pull the cord so that it goes back
inside the support arm.
7
Again use tools to ghten the bolts from
each side and set the pulley at its
posion.
Turn the Placid Arm upside down. By using an allen key, loosen the mounng bracket of Arm.
Now the bracket has enough space for the cord to pass through it.
Insert cord into the mounng bracket. Make sure that it is going exactly in the centre, up into
the hole of the Placid arm. Then Pull the cord from boom of Placid arm, near the spring,
while sll holding it upside down.
8
Now you can hold the Placid arm in its
standard posion. The cord is aptly set
to perform its funcon.
By using an allen key, ghten the
mounng bracket of Placid Arm with
Flowline support arm.
To x Placid arm at its appropriate
posion, aach one side of Safety
Elasc Cord to a knob on Placid arm.
9
Then, drag the other side of elasc cord
across Flowline support arm, and aach
to the knob on other side of Placid arm.
Put-in the cup back through the cord
and relock it with the cord lock. Roll the
leover cord inside the cup.
Fix the hook back at its actual posion, using an allen key. Now Set the provided Spring in the
hook back again side of Placid arm.
10
Wear support jacket and ghten the
buckles provided at the waist, adjust as
per your convenience cup.
Tighten the buckles provided at the
chest of support jacket, and adjust as
per your convenience.
By adjusng side support, you will move
the weight on your hips, thus resulng
in comfortable long hour shoong.
