USER INSTRUCTIONS

Installation

Operation

Maintenance

Limitorque

®B320 Series

FCD LMENIM3201-02 – 01/15

Limitorque B320 Series FCD LMENIM3201-02 – 01/15

This page is left intentionally blank.

Limitorque B320 Series FCD LMENIM3201-02 – 01/15

ﬂowserve.com

Contents

1 Introduction 5

1.1 Purpose 5

1.2 User Safety 5

2 Product Capabilities and Features 6

2.1 Initial Inspection and Storage Instructions 6

2.2 Product Identiﬁcation 7

2.3 Inspection and Recording 7

2.4 Storage Procedure 8

3 Operator Weights 9

4 Installation Instructions 10

4.1 Safety Precautions 10

4.2 Safety Practices 11

4.3 Installation 11

4.3.1 Installing an Operator with a Threaded Stem Nut 11

4.3.2 Installing an Operator with a Blank Stem Nut (B320-10 through -90, one-piece) 11

4.3.3 Installing an Operator with a Blank Stem Nut (B320-90, two-piece) 12

5 Lubrication 13

5.1 Lubrication Inspection 13

5.2 Factory Lubricant 13

5.3 Minimum Lubricant Qualities Required 14

6 Disassembly and Reassembly 15

6.1 Disassembly and Reassembly of B320-10 through -80 16

6.1.1 Disassembly 16

6.1.2 Reassembly 16

6.2 Disassembly and Reassembly of B320-90 20

6.2.1 Disassembly 20

6.2.2 Reassembly 20

6.3 Disassembly and Reassembly of Spur Gear Attachments 21

6.3.1 Disassembly of 3:1 Spur Gear Attachment for B320-10 through -40 21

6.3.2 Reassembly of 3:1 Spur Gear Attachment for B320-10 through -40 22

6.3.3 Disassembly of 6.3:1, 10.3:1, and 10.8:1

Spur Gear Attachments for B320-50, -70, and -80 23

6.3.4 Reassembly of 6.3:1, 10.3:1, and 10.8:1

Spur Gear Attachments for B320-50, -70, and -80 23

6.3.5 Disassembly of 5:1 Spur Gear Attachment for B320-90 25

6.3.6 Reassembly of 5:1 Spur Gear Attachment for B320-90 25

6.3.7 Disassembly of 17.5:1 Spur Gear Attachment for B320-90 27

6.3.8 Reassembly of 17.5:1 Spur Gear Attachment for B320-90 27

7 How to Order Parts 30

Limitorque B320 Series FCD LMENIM3201-02 – 01/15

Figures

Figure 2.1 – B320 Bevel Gear Operator 7

Figure 2.2 – B320 Nameplate 8

Figure 6.1 – B320-10 and 20 Parts Diagram 17

Figure 6.2 – B320-30 and -40 Parts Diagram 17

Figure 6.3 – B320-50 and -70 Parts Diagram 18

Figure 6.4 – B320-80 Parts Diagram 18

Figure 6.5 – B320-90 Parts Diagram 20

Figure 6.6 – 3:1 SGA Parts Diagram for B320-10 through -40 22

Figure 6.7 – 6.3:1, 10.3:1, and 10.8:1 SGA Parts Diagram for B320-50 through 80 24

Figure 6.8 – 5:1 SGA Parts Diagram for B320-90 26

Figure 6.9 – 17.5:1 SGA Parts Diagram for B320-90 28

Tables

Table 3.1 – Operator Weights 9

Table 5.1 – Lubricant Quantities 14

Table 6.1 – Quantity of Ball Bearings 15

Table 6.2– Common Parts List 19

Table 6.3 – B320-90 Parts List 21

Table 6.4 – 3:1 SGA Parts List for B320-10 through -40 23

Table 6.5 – 6.3:1 , 10.3:1, and 10.8:1 SGA Parts List for B320-50 through 80 24

Table 6.6 – 5:1 SGA Parts List for B320-90 26

Table 6.7 – 17.5:1 SGA Parts List for B320-90 29

Limitorque B320 Series FCD LMENIM3201-02 – 01/15

ﬂowserve.com

1 Introduction

1.1 Purpose

This Installation, Operation and Maintenance Manual (IOM) explains how to install and maintain the

B320 bevel gear operator. Information on installation, disassembly, lubrication, and spare parts is

provided.

1.2 User Safety

Safety notices in this manual detail precautions the user must take to reduce the risk of personal

injury and damage to the equipment. The user must read and be familiar with these instructions

before attempting installation, operation, or maintenance. Failure to observe these precautions could

result in serious bodily injury, damage to the equipment, void of the warranty, or operational difﬁculty.

Safety notices are presented in this manual in three forms:

cWARNING: Refers to personal safety. Alerts the user to potential danger. Failure to follow warning

notices could result in personal injury or death.

aCAUTION: Directs the user’s attention to general precautions that, if not followed, could result in

personal injury and/or equipment damage.

NOTE: Highlights information critical to the user’s understanding of the gear operator’s installation

and operation.

Limitorque B320 Series FCD LMENIM3201-02 – 01/15

Designed to make operation of multi-turn valves easier The B320 gear operator makes it easier to both

manually operate multi-turn valves and convert to a motorized service.

Built for reliable valve control — whether manual or motorized The B320 offers torque ranges up to

8,000 ft-lb (10,856 N m) and thrust capacities to 325,000 lb (1,445 kN) for any application

demanding superior strength and accuracy.

Easily adaptable for other applications The B320 is designed to be conﬁgured to each customer’s needs:

• Optional handwheel available for manual actuation

• Add a spur gear attachment for greater mechanical advantage

• Couple with an electric actuator from Limitorque for an economical, motorized, multi-turn package

2.1 Initial Inspection and Storage Instructions

cWARNING: Read this Installation, Operation and Maintenance Manual carefully and completely

before attempting to store the gear operator.

2 Product Capabilities

and Features

Limitorque B320 Series FCD LMENIM3201-02 – 01/15

ﬂowserve.com

2.2 Product Identiﬁcation

Figure 2.1 – B320 Bevel Gear Operator

2.3 Inspection and Recording

Upon receipt of the gear operator, inspect the condition of the equipment and record nameplate

information.

1. Carefully remove gear operator from shipping carton or skid. Thoroughly examine the equipment

for any physical damage that may have occurred during shipment. If damaged, immediately

report the damage to the transport company.

2. A nameplate is attached to each gear operator with the following information:

• Operator Size

• Limitorque Order Number

• Ratio

• Serial Number

Record this information for future reference, for ordering parts or obtaining further information.

Input Shaft Mounting Base Housing

Nameplate

Limitorque B320 Series FCD LMENIM3201-02 – 01/15

Figure 2.2 – B320 Nameplate

2.4 Storage Procedure

NOTE: The following is the recommended storage procedure to retain maximum product integrity

during storage. Failure to comply with recommended procedure will void the warranty.

Storage (Less Than One Year)

Operators should be stored in a clean, dry, protected warehouse and should be stored on wooden

skids to protect the machined mounting ﬂange. If the operators must be stored outside, they must be

covered in polyethylene protection with silica gel crystals to absorb moisture. Input shafts should be

rotated every three months to mix lubricant.

Limitorque B320 Series FCD LMENIM3201-02 – 01/15

ﬂowserve.com

3 Operator Weights

The approximate weights of the gear operators, with and without spur gear attachments, are provided

below:

Table 3.1 – Operator Weights

Operator Without SGA With SGA

lb kg lb kg

B320-10 45 21 75 34

B320-20 51 23 80 36

B320-30 57 26 86 39

B320-40 68 31 97 44

B320-50 143 65 198 90

B320-70 254 115 309 140

B320-80 418 190 474 215

B320-90 745 339 875 398

Limitorque B320 Series FCD LMENIM3201-02 – 01/15

4 Installation Instructions

4.1 Safety Precautions

cWARNING: Read this Installation, Operation and Maintenance Manual carefully and completely

before attempting to install, operate, or troubleshoot the Limitorque operator.

cWARNING: Potential HIGH PRESSURE vessel — be aware of high-pressure hazards associated

with the attached valve or other actuated device when installing or performing maintenance

on the operator. Do not remove the operator mounting bolts from the valve or actuated device

unless the valve or device stem is secured or there is no pressure in the line.

cWARNING: For maintenance and/or disassembly of the operator while installed on the valve,

ensure that the operator is not under thrust or torque load. If the valve must be left in service, the

valve stem must be locked in such a way as to prevent any movement of the valve stem.

cWARNING: Do not manually operate the operator with devices other than the installed hand-

wheel. Using force beyond the ratings of the operator and/or using additive force devices such as

cheater bars, wheel wrenches, pipe wrenches, or other devices on the operator handwheel may

cause serious personal injury and/or damage to the operator and valve.

cWARNING: Do not exceed any design limitations or make modiﬁcations to this equipment

without ﬁrst consulting Limitorque.

cWARNING: Use of the product must be suspended any time it fails to operate properly.

aCAUTION: If a motor actuator is driving the manual operator, do not operate the valve under

motor operation without ﬁrst checking and setting the limit switch setting and checking for

correct motor rotation.

aCAUTION: Do not use replacement parts that are not genuine Flowserve Limitorque parts, as

serious personal injury and/or damage to the operator and valve may result.
