FLIR FC S Series Instrucciones de montaje

427-0073-11-28 Rev 100 Feb 2013

FC-Series S Camera

Quick Connect Guide

For installations that are using the Concealed Cable Mounting Arm,

refer to the installation manual for instructions:

FLIR FC-Series S Installation Manual (427-0073-11-12)

Caution!

Note

Except as described in this guide, do not disassemble the FC-Series S camera.

Damage to the camera can occur as the result of careless handling or

electrostatic discharge (ESD).

Prior to making any connections, ensure the power is switched off.

Power: Power Over Ethernet (PoE) or 12-40VDC, 24VAC

Power terminal blocks: wire size from 16 AWG to 20 AWG

Analog Video Cable: BNC-terminated RG-59/U solid-center coax cable

Items Included in Kit

3 mm hex

2.4 mm slotted

screwdriver

key

427-0073-11-28 v100 FC-Series S Quick Connect.fm Page 1 Saturday, March 9, 2013 5:07 PM

427-0073-11-28 Rev 100 Feb 2013

Step 1 Remove cover: Using 3 mm hex key, loosen four captive

screws. Removal of sunshield not necessary.

Step 2 Install cables through sealing gland:

Step 3 If using conventional power cable, strip cables as

described below:

Access captive

screws through

slots in sunshield.

Video coax

Gland nut

Not Used

Power

Ethernet

Ground

Re-tighten gland nut

after installation is

completed.

Fill any unused hole

with orange plug.

(0.8±.20 in)

20.0±5 mm

Remove outer

jacket

(0.2±.04 in)

6.0±1 mm

Strip ends

3 Places

Min diameter = 6.8 mm (0.27 in)

Max diameter = 9.4 mm (0.37 in)

Power Cable

427-0073-11-28 v100 FC-Series S Quick Connect.fm Page 2 Saturday, March 9, 2013 5:07 PM

427-0073-11-28 Rev 100 Feb 2013

Step 4 Te r m i n a te c a b l e s :

Step 5 Connect a ground wire between the ground stud on the

back of the camera and the nearest earth-grounding point.

Step 6 Test camera: Power on the camera and test video.

Use a web browser to test IP communications

(default IP: 192.168.250.116; login: user/fliradmin)

Step 7 Tighten Cable seal gland nut to ensure a watertight seal.

Step 8 Replace cover: Alternately tighten the four captive

screws in the cover; torque to 1.8 N-m (16.0 in-lbs).

Connection Purpose

13-pinJumper Lensheateron/off

2 RCA Analog video test point

3BNC Analogvideo

4 3-pin Terminal AC/DC Power

5 Ethernet PoE power, communications, IP video stream

6 Accessory inputs Reserved for future use

Ta b l e 1 - 1 : Po w e r C o n n e c t o r

1Chassis

2VAC/DC-

3VAC/DC+

427-0073-11-28 v100 FC-Series S Quick Connect.fm Page 3 Saturday, March 9, 2013 5:07 PM

427-0073-11-28 Rev 100 Feb 2013

FLIR Systems, Inc.

70 Castilian Drive

Goleta, CA 93117

USA

PH: + 1 805.964.9797

PH: + 1 877.773.3547 (Sales)

PH: + 1 888.747.3547 (Support)

FX: + 1 805.685.2711

www.flir.com

Corporate Headquarters

FLIR Systems, Inc.

27700 SW Parkway Ave.

Wilsonville, OR 97070

USA

PH: +1 503.498.3547

FX: +1 503.498.3153

sales@flir.com

Ensure the camera is properly grounded. Failure to properly ground the camera

can lead to permanent damage to the camera. Typical to good grounding

practices, the camera chassis ground should be connected to the lowest

resistance path possible. FLIR requires a grounding strap anchored to the

grounding lug and connected to the nearest earth-grounding point.

Before installing the FC-Series S camera you should read and understand the

following documents which provide details regarding mechanical dimensions

and installation safety.

• FLIR FC-Series S Installation Manual (427-0073-11-12)

• FLIR FC-Series S Interface Control Document (427-00XX-XX-19S)

Documents provided on the documentation CD or from the FLIR website
