Fellowes PS70-2 Manual de usuario

Get More Done Today™

ENGLISH FRANÇAIS ESPAÑOL

PS70-2, PS70-2CD, PS80C-2

PS70-2CD

ENGLISH

Contents

Product Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Set-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Dear Customer,

Thank you for buying a Fellowes Personal Shredder. We have

made many improvements in our personal shredder since its

introduction in 1990 as the first of its kind on the market.

We are confident that it offers you the greatest value for your

money in its product category today. We hope it meets – or even

exceeds – your expectations.

To ensure years of safe, efficient use, please read these few

pages about your new shredder. If this manual doesn’t answer

all your questions or if you wish to comment on this product, we

welcome your call or letter.

Sincerely,

James Fellowes

Chairman & CEO

ENGLISH

Product Profile

This product is built to shred

paper, staples, small paper

clips, credit cards, and CD’s (PS70-2CD in CD entry only)

It is not built to take large paper clips, continuous forms, adhe-

sive labels, transparencies, newspaper, cardboard or any plastic

other than credit cards. Using it for these purposes is likely to

cause damage.

Model PS80C-2 PS70-2CD PS70-2

Type of Cut Confetti Strip Strip

Sheet capacity* 10 sheets 15 sheets 12 sheets

CD capacity N/A 1 N/A

Paper shred size 5/32 x 4/5” 7/32" 5/32”

(3.9 x 20 mm) (5.8 mm) (3.9 mm)

Maximum paper width 9" (229 mm) 9" (229 mm) 9" (229 mm)

Recommended daily capacity 50-100 50-100 50-100

(shredding passes)

Maximum running time (min.) 15-20 15-20 15-20

Automatic cool-down period (min.) 25 25 25

*Based on 20 lb., 8-1/2" x 11" paper with shredder operating at rated voltage; heavier paper, high humidity, or other than

rated voltage may reduce sheet capacity.

This shredder is not designed to shred CDs continuously. Recommended daily capacity of CDs is 10-20

IMPORTANT SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE USING

While setting up shredder

•Check shredder for damage or defects; some paper particles in the basket are normal

due to product testing and does not indicate a defect.

•Plug power cord in an outlet that can easily be reached.

•Do not place shredder near or over a heat or water source.

While operating shredder

•Keep hands and hanging objects (jewelry, ties, loose clothing,

long hair, etc.) away from paper entry.

•Keep children and pets away from the shredder.

When not in use

•Always turn off and unplug shredder

•Unplug before emptying basket

•Do not open shredder head: Danger of electric shock.

NOTE:

Do not use flammable synthetic oil, petroleum-based products or aerosols of any

kind on or near product at any time.

ENGLISH

Set-Up

This shredder will only operate when used with the supplied basket. The supplied basket

has a built-in safety feature which prevents the shredder from operating if used with any

other basket or if improperly assembled.

•Position shredder head (6) over cabinet (2). Place shredder head on top of cabinet as

shown in Figure A.

•Firmly push down on four corners of shredder head to “lock” shredder head into position.

•Push basket (3) into shredder cabinet as shown in Figure B. Basket must be pushed firmly,

so edges of basket/cabinet are aligned properly.

NOTE:

To disassemble, pull out basket, hold cabinet down by placing foot on bottom

shelf, and firmly pull up on shredder head.

Operation

For convenience, your shredder is equipped with an

automatic-start sensor (8)

. This

means that when the control switch (5) is on automatic [I] position, the shredder will start

running when you put paper into it and stop a few seconds after the paper has passed

through. Because the sensor cannot tell the difference between paper and other objects,

this feature can also be a hazard, especially to children and pets. To avoid accidents,

turn off the shredder as soon as you are finished. Unplug shredder if it will not be used

for an extended period.

To shred

•Plug in shredder with control switch (5) in off [O] position

•Press control switch to automatic [I] position; cutting cylinders will run for 1-2 seconds to

signal readiness and green light (4) will turn on.

PAPER

•Feed paper straight into entry (1), until the shredder automatically begins shredding; see

Product Profile for limits on paper width, shreddable items, sheet capacity, etc.

•Shred for no more than 15-20 minutes; shredding longer will cause shredder to turn itself

off for 25 minutes to cool down.

•Press control switch to off [O] position after cutting has stopped.

CDs (PS70-2CD only)

•Feed one CD at a time, straight into CD entry (10), releasing when shredding begins.

Shredder will stop when CD has passed through entry. CDs will be shredded into small

particles.

NOTE:

For safety reasons, CDs should only be shredded using the CD entry

(10)

In case of a

paper jam

, which may occur if the sheet capacity is exceeded or if paper is

not put in straight, turn off and empty the basket if full. Then:

1) Press and hold control switch in reverse [R] position and attempt to back paper out of

shredder.

2) If shredder jams in reverse mode, press control switch to automatic [I] position and

attempt to continue shredding operation.

3) If shredder jams again, alternate control switch slowly between reverse [R] and auto-

matic [I] positions to attempt to move jammed paper completely through shredder.

ENGLISH

If you are unable to clear the jam using this method, turn off and unplug the shredder;

remove wastebasket from the cabinet and carefully remove any paper extending below

the cutting cylinders; insert wastebasket and repeat jam clearing procedure.

Maintenance

Regular emptying of the basket

is important to ensure the smooth operation of the

cutting cylinders. If you can see paper in the basket window (7), turn off the shredder,

pull out basket and empty basket contents.

Regular oiling of the confetti-cut model (PS80C-2) is also neces-

sary to ensure proper performance. If you are running the shredder at or

near capacity, we recommend oiling it monthly. Using Fellowes Powershred

Lubricant #35250 or other non-aerosol vegetable-based oil in a long-nozzle container:

• Apply oil over full width of paper entry (1) with shredder in off (0) position.

• Press control switch (5) to automatic (I) position which will cause shredder to run for

about 2 seconds.

• Press and hold control switch (5) in reverse (R) position for 3-5 seconds.

• Repeat above automatic (I) and reverse (R) sequence three times.

REMINDER: Do not use flammable synthetic oil, petroleum-based products or aerosol

lubricants of any kind in or near the shredder at any time.

Troubleshooting

If you have a problem with your shredder, check the symptoms and remedies below. If

you cannot solve the problem this way, contact Fellowes Customer Service.

Do not open

shredder head

to attempt repair: It could expose you to serious electric shock and will

void your warranty.

Symptom

Shredder does not start or stops while

shredding.

Red display light (9) turns on and shredder

will not operate.

Shredder continues to run for a few sec-

onds after paper has cleared the cutting

cylinders.

Shredder shreds less than capacity (Model

PS80C-2 only)

Remedy

•Make sure shredder is plugged in and

switch is in automatic [I] position.

•If paper appears to be jammed. Follow

instructions under Operation.

•Check basket position; basket must be

pushed all the way in the cabinet.

Follow instructions under Set-Up.

•Wait 25 minutes for shredder to cool

down before trying again.

•If paper appears to be jammed. Follow

instructions under Operation.

•Check basket position; basket must be

pushed all the way into the cabinet.

Follow instructions under Set-Up.

No action required. This is a self-cleaning

function.

Oil the cutting cylinders. Follow the instruc-

tions under Maintenance.

ENGLISH

Warranty

Fellowes, Inc. (the "Company") warrants the cutting cylinders of the machine to be free

from defects in material and workmanship for 7 years from the date of purchase by the

original consumer. Fellowes warrants all other parts of the machine to be free of defects

in material and workmanship for 1 year from the date of purchase by the original con-

sumer. If any part is found to be defective during the warranty period, your sole and

exclusive remedy will be repair or replacement, at Fellowes’ option and expense, of the

defective part.

This warranty does not apply in cases of abuse, mishandling or unauthorized repair.

ANY IMPLIED WARRANTY, INCLUDING THAT OF MERCHANTABILITY OR FITNESS FOR

A PARTICULAR PURPOSE, IS HEREBY LIMITED IN DURATION TO THE APPROPRIATE

WARRANTY PERIOD SET FORTH ABOVE. In no event shall Fellowes be liable for any

consequential or incidental damages attributable to this product. This warranty gives you

specific legal rights. You may have other legal rights that vary from this warranty. The

duration, terms and conditions of this warranty are valid worldwide, except where differ-

ent limitations, restrictions or conditions may be required by local law. For more details

or to obtain service under this warranty, please see below.

Fellowes offers toll free consumer service in the following regions: United States, Canada,

Mexico, Australia, and Europe. Residents in these regions should contact the appropriate

Consumer Helpline located on the back of this manual.

If you are unable to access the Consumer Helpline from your calling area, call the nearest

Fellowes location, also listed on the back of this manual. You may also contact your local

dealer, contact us online at www.fellowes.com or write to us at:

Fellowes, Inc.

ATTN: Customer Service

1789 Norwood Avenue

Itasca, IL 60143

USA

www.fellowes.com

Contact for Customer Service

Service Clientèle

Servicio al Cliente

Australia 1-800-33-11-77

Canada 1-800-665-4339

Mexico 1-800-234-1185

United States 1-800-955-0959
