General Information

The FDPMAID is a 5” Panel Mount Advisory Information Display, which creates panel

space where none previously existed, providing an excellent opportunity to bring EVS

video, satellite weather, or any other VGA/Composite source into the cockpit with a low-

profile, panel mounted display.

Front View

FDPMAID-R Detached Electronics Box*

(FD90AID-DEB-SM shown)

Document Number:

MAN –FDPMAID

Rev:

Revision Date:

08/06/2012

Page 5 of 18

TECHNICAL SUPPORT

470-239-7421 or FlightDisplay.com

Additional Information

The FDPMAID can be ordered as two different part numbers, depending on the desired

orientation of the display. To order the display with the control buttons on the right-side of

the unit, order the FDPMAID-R (shown above). To order with the buttons on the left-side,

order the FDPMAID-L. NOTE: Button locations and viewing display vary slightly between

FDPMAID-L & FDPMAID-R models.

* The Detached Electronics Box ("DEB") allows the LCD monitor to be panel mounted

anywhere in the cockpit. The DEB contains essential graphics circuitry critical to the

operation of the FDPMAID. The cabling between the DEB and the LCD contains two

break plus and should not be cut nor extended. There is no degradation of image quality

or input sources in this configuration.

Specifications

Display Type

5.0” TFT Color LCD

Screen Resolution

640x480

Brightness

600 cd/m²

LCD Dimensions

5.175”(W) x 4.750”(H) x 0.660”(D)

DEB Dimensions

5.7”(W) x 1.14”(H) x 5.05”(D)

Power

28VDC @ .3 Amps

Video Inputs Supported

Analog RGB, Composite Video

Video Types Supported

VGA, NTSC/PAL

Screen Control

On Screen Display Menu

DO-160E testing

In Progress

Weight

Display: TBD

DEB: .72 lb

Cable: .82 lb

Installation Instructions

All cockpit accessory equipment, such as the FDPMAID, should be installed on a non-

essential bus and have a dedicated circuit breaker. It is a requirement that a switch be

installed so that the pilot can de-energize the system should it become necessary.

Document Number:

MAN –FDPMAID

Rev:

Revision Date:

08/06/2012

Page 6 of 18

TECHNICAL SUPPORT

470-239-7421 or FlightDisplay.com

The FDPMAID has four 8-32 screws that are used to mount the unit in the cockpit. In

addition, there is a 0.375” diameter hole in which the data cable is protruded to run to the

DEB located elsewhere.The rear mounting plate can be removed in order to relocate the

mounting screws.

Document Number:

MAN –FDPMAID

Rev:

Revision Date:

08/06/2012

Page 7 of 18

TECHNICAL SUPPORT

470-239-7421 or FlightDisplay.com

Power

This is a 28VDC monitor that requires 1 Amps (28 Watts) of power to operate.

Document Number:

MAN –FDPMAID

Rev:

Revision Date:

08/06/2012

Page 8 of 18

TECHNICAL SUPPORT

470-239-7421 or FlightDisplay.com

Wiring Suggestions

All shields should be grounded to the connector at the source, and floating at the display.

Avoid routing video wiring parallel to:

AC wiring

Strobe wiring

DC motor supply cables

Inverter cabling

Or any other potential noise source

Composite and Audio Wiring

Recommended cable for s-video/composite and audio purposes is PIC 75 Ohm Coax, P/N

V75268. This is a lightweight, flexible, and low signal loss cable which meets FAA

flammability requirements of FAR 23.1359(d), FAR 25.853(a) and FAR 25.869(a)(4).

Similar aviation coaxial cable can be used from other vendors, as well.

Some aircraft are prone to AC noise - we recommend adding to the composite source a

75Ohm video isolation transformer such as Deerfield Laboratory, Inc. Part No. 162-1

(www.deerfieldlab.com, (650) 632-4090). In most cases this should be added to the video

output of the source.

Document Number:

MAN –FDPMAID

Rev:

Revision Date:

08/06/2012

Page 9 of 18

TECHNICAL SUPPORT

470-239-7421 or FlightDisplay.com

VGA Wiring

Recommended cable for VGA purpose is ECS P/N 453005. This is a single shielded

cable containing 5 separate coaxial cables, color-coded to match the functions of the

wires.

We recommend coax cables be terminated using solder sleeve coaxial cable terminators

such as Raychem Part Number CWT-4174-W122-5/9.

Document Number:

MAN –FDPMAID

Rev:

Revision Date:

08/06/2012

Page 10 of 18

TECHNICAL SUPPORT

470-239-7421 or FlightDisplay.com

Power and Ground Wiring

This is a 28VDC monitor that requires 0.3 amps of power to operate. To operate properly

this monitor requires an input voltage of 18-29VDC.

The rated current of the equipment and associated voltage drop should be taken into

consideration when selecting wire gauge. The following example is based on an install

with a 28VDC power system and a total of 50 feet of wire between the circuit breaker,

monitor and ground.

Example: 22awg wire has 16.2 Ohms per 1000 feet, this equates to .81 Ohms for 50 feet.

0.3 Amps of current on .81 Ohms will drop 0.243 Volts.

Resistance of Wire Type M22759/16-**

(** = Gauge)

Gauge (AWG)

OHMS/1000’

26.20

16.20

9.88

4.81

2.02

1.26

.701

Also, use short heavy gauge wire and a clean tight connection for ground.

It is the installer's responsibility to understand the product's requirements to install the

product in compliance with industry standards and safety.

Dual Installation

As with all of our displays, multiple FDPMAID configurations are possible. A DAPS321 is

used to split and amplify the composite signal to multiple units.

For assistance with installation of multiple displays, please contact Flight Display Systems

at (470) 239-7400.
