FDS FD171CV-C-1 Manual de usuario

Document Number:

MAN –FD171CV-C-1

Rev:

Revision Date:

10/12/2011

Page 1 of 16

Installation and Operation Manual

FD171CV-C-1

17” LCD Monitor

Document Number:

MAN –FD171CV-C-1

Rev:

Revision Date:

10/12/2011

Page 2 of 16

Table of Contents

General Information......................................................................................................................3

1. Front View..........................................................................................................................3

2. Additional Information....................................................................................................3

Specifications................................................................................................................................4

Installation Instructions .............................................................................................................4

1. Power ..................................................................................................................................4

Wiring Instructions......................................................................................................................6

1. S-Video and Audio Wiring..............................................................................................5

2. VGA Wiring.......................................................................................................................6

3. Power and Ground Wiring..............................................................................................7

Power/Video..................................................................................................................................8

4. VGA Pin out.......................................................................................................................8

5. Power Pin out ....................................................................................................................9

6. HD-SDI Pin out .................................................................................................................9

7. S-Video Pin out..................................................................................................................9

8. Composite Pin out ..........................................................................................................10

9. DVI-D Pin out..................................................................................................................10

Operation Instructions..............................................................................................................11

1. Button Control.................................................................................................................11

Technical Drawing.....................................................................................................................12

Troubleshooting.........................................................................................................................13

Technical Support......................................................................................................................14

Instructions for Continued Airworthiness ...........................................................................14

Warranty ......................................................................................................................................15

Log of Revisions.........................................................................................................................16

Document Number:

MAN –FD171CV-C-1

Rev:

Revision Date:

10/12/2011

Page 3 of 16

General Information

The FD171CV-C-1 is a panel mounted 17” monitor. Built with retrofit aircraft integration

in mind, this display can switch between five video input sources using an infrared

remote control or with the buttons located on the top of the unit.

Front View

Additional Information

The FD171CV-C-1 features five available video sources: HD-SDI In-Out, DVI-D, Industry

Standard VGA (computer graphics i.e. moving maps), S-Video (via BNC connectors for Y

and C components), and Composite Video (via BNC connector).

The LCD is protected with a .060” thick anti-glare, anti-abrasion Lexan lens to prevent

scratching of the LCD, and to meet stringent FAA abrasive load criteria.

Document Number:

MAN –FD171CV-C-1

Rev:

Revision Date:

10/12/2011

Page 4 of 16

Specifications

Display Type

17.1” TFT Color LCD

Display Color

16.7 Million Colors

Screen Resolution

1440 x 900

Brightness

250 cd/m2

Dimensions

16.25”(W) x 11.00” (H) x 1.750”(D)

Display Size

14.36”(W) x 8.950”(H)

Weight

7.60 Lb.

Power @ Amp

28V DC @ 1.3A Max. Cont. Steady-

State

Video Type Supported

NTSC/PAL

Video Sources

HD-SDI (In-Out), DVI-D, Industry

Standard VGA, S-Video, Composite

Screen Control

On Screen Display Menu

Viewing Angle

178° on Both Axis

Materials

Aluminum

Remote Control

IR, included

Pixel Pitch

.255 mm X .255 mm

Operating Temperature

0-50° C (32-122° F)

Test Certifications

FD171CV: DO-160, Sec 21, Cat B

DO-160, Sec 7, 8

Installation Instructions

All cabin equipment, such as the FD171CV-C-1, should be installed on a non-essential

bus and have a dedicated circuit breaker. It is a requirement that a switch be installed in

the cockpit so that the pilot can de-energize the system should it become necessary.

There are (8) 8-32 UNC mounting holes located on the sides and back of the display.

Four mounting points are located on the rear and two on each side of the bezel. See

installation drawing at end of manual for dimensional details.

Power

This is a 28VDC monitor that requires 1.3 Amps of maximum continuous steady-state

power to operate. The unit turns on automatically upon power application.

Document Number:

MAN –FD171CV-C-1

Rev:

Revision Date:

10/12/2011

Page 5 of 16

Wiring Suggestions

For balanced signals on twisted pair cable, all shields should be grounded to the

connector at the source, and floating at the display.

Avoid routing video wiring parallel to:

AC wiring

Strobe wiring

DC motor supply cables

Inverter cabling

Or any other potential noise source.

Composite, S-Video, and Audio Wiring

Recommended cable for s-video and audio purposes is PIC 75 Ohm Coax, P/N V76261.

This is a lightweight, flexible, and low signal loss cable which meets FAA flammability

requirements of FAR 23.1359(d), FAR 25.853(a) and FAR 25.869(a)(4).

Similar aviation coaxial cable can be used from other vendors, as well.

Some aircraft are prone to AC noise - we recommend adding to the composite source a

75 Ohm video isolation transformer such as Deerfield Laboratory, Inc. Part No. 162-1

(www.deerfieldlab.com, (650) 632-4090). In most cases this should be added to the video

output of the source.

Document Number:

MAN –FD171CV-C-1

Rev:

Revision Date:

10/12/2011

Page 6 of 16

VGA Wiring

Recommended cable for VGA purpose is ECS P/N 453005. This is a single shielded

cable containing 5 separate coaxial cables, color-coded to match the functions of the

wires.

We recommend coax cables be terminated using solder sleeve coaxial cable

terminators such as Raychem Part Number CWT-4174-W122-5/9.

Document Number:

MAN –FD171CV-C-1

Rev:

Revision Date:

10/12/2011

Page 7 of 16

Power and Ground Wiring

20 AWG wire is recommended for Power and Ground applications.

This is a 28VDC monitor that requires 3 amps of power to operate. To operate properly

this monitor requires an input voltage of 24-29VDC.

The rated current of the equipment and associated voltage drop should be taken into

consideration when selecting wire gauge. The following example is based on an install

with a 28VDC power system and a total of 50 feet of wire between the circuit breaker,

monitor and ground.

Example: 22awg wire has 16.2 Ohms per 1000 feet, this equates to .81 Ohms for 50 feet.

3 Amps of current on .81 Ohms will drop 2.43 Volts.

Resistance of Wire Type M22759/16-**

(** = Gauge)

Gauge (AWG)

OHMS/1000’

26.20

16.20

9.88

4.81

2.02

1.26

.70

Also, use short heavy gauge wire and a clean tight connection for ground.

It is the installer's responsibility to understand the product's requirements to install the

product in compliance with industry standards and safety.

Document Number:

MAN –FD171CV-C-1

Rev:

Revision Date:

10/12/2011

Page 8 of 16

Rear View with Connectors

VGA Video

Pin out for DB-15 Female Connector (Industry Standard VGA)

Connector P/N: 748364-1 or Equivalent

Crimp Contacts P/N: M39029/58-360 or Equivalent

Number

Description

Red Signal

Green Signal

Blue Signal

N/C

Ground –Horizontal Sync

Red Return

Green Return

Blue Return

N/C

Ground –Vertical Sync

N/C

Horizontal Sync

Vertical Sync

N/C

Document Number:

MAN –FD171CV-C-1

Rev:

Revision Date:

10/12/2011

Page 9 of 16

Pin out for 28V PWR –D38999 connector (supplied)

Mating Connector P/N: D38999/26FB5SA or Equivalent

Crimp Contacts P/N: M39029/56-351 or Equivalent

MATING FACE

Number

Description

28VDC Power

28VDC Ground

N/C

Pin out for HD-SDI Input (In-Out Pass Thru)

(Standard BNC –75 OHM) –31-242 (Supplied)

Description

Center

Video Signal

Shell

Video Return

Pin out for S-Video (Luminance - Y Component)

(Standard BNC –75 OHM) –31-242 (Supplied)

Description

Center

Y Signal

Shell

Y Return

Pin out for S-Video (Chrominance - C Component)

(Standard BNC –75 OHM) –31-242 (Supplied)

Description

Center

C Signal

Shell

C Return

Document Number:

MAN –FD171CV-C-1

Rev:

Revision Date:

10/12/2011

Page 10 of 16

Pin out for Composite Video

(Standard BNC –75 OHM) –31-242 (Supplied)

Description

Center

C Signal

Shell

C Return

Pin out for DVI-D

Accepts a standard DVI-D (Single Link) male connector (supplied)

Number

Description

TMDS data 2-

TMDS data 2+

TMDS data 2 shield

N/C

DDC clock

DDC data

N/C

TMDS data 1-

TMDS data 1+

TMDS data 1 shield

N/C

+5 V

Ground

Hot plug detect

TMDS data 0-

TMDS data 0+

TMDS data 0 shield

N/C

TMDS clock shield

TMDS clock+

TMDS clock-

N/C
