FCC-G-19000-41 / K104BGD1
MANUAL
Installation, use, maintenance and safety
! OUTDOORUSEONLY
READTHEMANUAL, FOLLOWTHE
ASSEMBLYINSTRUCTIONSSTEPBY
STEP. GETTOKNOWYOURGRILL
ANDTHESAFETYINSTRUCTIONS
BEFOREUSINGTHEAPPLIANCE!
REGISTER THE BBQ FOR
EXTENDED WARRANTY:
WATCH BBQ ASSEMBLY
ON VIDEO HERE:
Contents
Warnings ..........................................................................................................................................3
Technical Data ...............................................................................................................................4
Read before assembly .............................................................................................................5
Parts list ............................................................................................................................................6
Exploded Drawing .......................................................................................................................7
Hardware ..........................................................................................................................................7
Assembly instructions ..............................................................................................................8
Connecting gas ........................................................................................................................16
Gas leak test - To be done before using the grill .....................................................17
Last check ......................................................................................................................................18
Lighting instructions ................................................................................................................19
Maintenance ..............................................................................................................................20
Advice, tips and safety ....................................................................................................22
Troubleshooting .........................................................................................................................23
Consumer Contact ..................................................................................................................24
WARNINGS!
●ACCESSIBLE PARTS OF THE GRILL BECOME VERY HOT
DURING USE. KEEP CHILDREN AND OTHERS WHO NEED
SUPERVISION AT A SAFE DISTANCE.
●THE GRILL IS INTENDED FOR OUTDOOR USE ONLY IN WELL-
VENTILATED AREAS.
●LEAK TESTS (SEE PAGE 17) MUST ALWAYS BE CARRIED OUT
BEFORE THE GRILL IS USED AND WHEN REPLACING THE
GAS CONTAINER. ALSO PERFORM A LEAK TEST IF THE
PRODUCT HAS NOT BEEN IN USE FOR A LONG TIME AND IN
ADVANCE OF A NEW BARBECUE SEASON. ALWAYS CHECK
THE GAS HOSE FOR DAMAGE AND CRACKS BEFORE USING
THE BARBECUE.
●NEVER BARBECUE IN CLOSED ROOMS OR UNDER ROOFS,
AS THIS MAY LEAD TO A LACK OF OXYGEN.
●FAILURE TO FOLLOW THE INSTRUCTIONS PROVIDED CAN
IMPLY A RISK OF SERIOUS INJURY TO PERSONNEL AND
FIXED INSTALLATIONS.
●REBUILDING / MODIFYING THE BARBECUE CAN CAUSE
DANGER AND WILL INVALIDATE THE WARRANTY.
●ALWAYS SUPERVISE THE BARBECUE DURING USE AND KEEP
SUITABLE EXTINGUISHING EQUIPMENT WITHIN REACH.
THE GRILL SHOULD NOT BE OPERATED BY INTOXICATED
PERSONS.
●THE BARBECUE MUST NOT BE USED IN PLACES THAT ARE
BELOW NORMAL GROUND LEVEL. GAS CAN ACCUMULATE
AND REPRESENT A DANGER OF EXPLOSION. GAS
ACCUMULATION CAN ALSO CAUSE OXYGEN DEFICIENCY.
●THE BARBECUE MUST BE CLEANED REGULARLY AND
THOROUGHLY TO PREVENT UNCONTROLLED GREASE FIRE.
READ MORE ABOUT GREASE FIRE ON PAGE 22.
ALSO READ PAGE 24 FOR MORE ADVICE AND TIPS ON GRILLING AND SAFETY.
WARNINGS!
3fccbbq.com
Tekniske data
Total Heat input: 17 kW
Gas consumption: 1238 gram/hour
Gascylinder (not included): Use standard cylinder approved for use in the Nordic Region.
Even though butane and propane gas can be used, we recommend propane for use in the
Nordic Region. Approved hoses and regulators are available from most outlets selling gas
equipment.
Perform the gas leak test as instructed on page 17 before using the product.
NB! Gas hoses used for this product must not exceed 120 cm in length.
Technical Data
CY, CZ, DK, EE, FI, FR,
HU, LT, IT, NO, NL, SE, SI,
SK, RO, HR, TR, BG, IS,
LU, MT
Ø 0.92 mm main burner
Ø 0.88 mm side burner
G30(Butane
G31(Propane)
and their mixtures
I3B/P(30)
The product is manufactured in accordance with European Gas Appliances Regulation (EU) 2016/426
ONLY THE GAS TYPE AND GAS CATEGORY LISTED IN
THE RATING LABEL IS TO BE USED ON YOUR APPLIANCE.
!
DESTINATION OF
COUNTRIES TO USE
GAS TYPEVALVE SIZE GAS CATEGORY
4
h: 116 cm
w: 138cm d: 60 cm
Read before assenbly
A screwdriver and adjustable/allen wrench (not provided)
is necessary when assembling the BBQ.
The BBQ should be assembled by two persons.
Make sure that all parts and screws are included and that they are
undamaged before assembling the product.
If the grill is damaged during transport, do not assemble the grill
before contacting your dealer or support@fccbbq.com.
Transport damage to parts, varnish or enamel must be reported to
the dealer or support@fccbbq.com before the grill is installed and
used.
Please note that some parts may be located in the Styrofoam to
protect the part during transport. If parts are missing, first check
the packaging carefully.
Compare the parts list with the contents of the box. Do not
assemble this grill if there is damages or parts are missing, contact
Remove all remnants of packaging material and any plastic wrap
from the grill.
●FOLLOW THE ORDER IN THIS MANUAL TO AVOID INCORRECT ASSEMBLY.
PARTS OF THE ASSEMBLY WILL REQUIRE HEAVY LIFTING WHICH
SHOULD BE PERFORMED BY TWO PEOPLE TOGETHER, TO AVOID
PERSONAL INJURY AND DAMAGE TO THE GRILL. SOME METAL PARTS
MAY BE SHARP, WEAR PROTECTIVE GLOVES.
●POWER TOOLS SHOULD NOT BE USED TO ASSEMBLE THE GRILL.
TOOLS WITH TOO MUCH FORCE CAN DAMAGE THE SURFACE
TREATMENT ON SCREWS, DAMAGE ENAMELLED / LACQUERED PARTS
OF THE GRILL, AS WELL AS LOOSEN PRE-ASSEMBLED NUTS.
●IF THE PRODUCT'S VARNISH OR ENAMEL IS DAMAGED DURING
ASSEMBLY, WE RECOMMEND THAT THE DAMAGE BE TREATED
IMMEDIATELY TO AVOID LATER RUST DAMAGE. SUITABLE HEAT-
RESISTANT VARNISH CAN BE ORDERED FROM SUPPORT@FCCBBQ.COM.
!
FOLLOW THESE INSTRUCTIONS CAREFULLY TO AVOID
SERIOUS PERSON INJURY OR DAMAGE TO YOUR BARBECUE.
5fccbbq.com
Parts list
CODE DESCRIPTION QTY
LID
THERMOMETER
THERMOMETERBEZEL
LIDSCREW
LIDHANDLE
LIDBUFFER
WARMINGRACK
CASTIRONGRID 195MM
HEATDISTRIBUTIONPANEL
BURNERCLIP
MAINTUBEBURNER 4
FIREBOXBACKCOVER
GREASECUPHOLDER
GREASETRAYCUP
GREASETRAY
SIDEBURNERLIDAXIS
SIDEBURNERLID
SIDEBURNERCOOKINGGRID
SIDEBURNERASSEMBLY
SIDEBURNERBASE
SIDEBURNERCONNECTIONBAR
SIDEBURNERIGNITIONNEEDLE
SIDEBURNERNOZZLE
SIDEBURNERCONNECTIONPIPE
SIDEBURNERTABLE
SIDELOWPANELLEFT
DOORMAGNET
CART FRONT BEAM
CODE DESCRIPTION QTY
REAR LOW PANEL
BOTTOM PANEL
SIDE LOW PANEL RIGHT
DOORSPINDLE
DOORSTOPPER
CARTTRIANGURSUPPORTBRACKET
WHEELPLUG
WHEELCASTOR
DOOR
DOORHANDLE
SIDEBURNERKNOB
MAIN BURNER KNOB
DOORHINGE
CONTROLPANEL
CONTROLPANELORNAMENT
GASCONNECTIONNOZZLE
GASCONNECTIONFIXATION
GASCONNECTIONPIPE
GASPIPEASSEMBLY
MAINBURNERGASVALVE
SIDEBURNERGASVALVE
INNERCONTROLPANEL
CONTROLPANELLEFTCONNECTION
BAR
CONTROLPANELRIGHTCONNECTION
BAR
BARRIERSTRIPFORCASTIRONGRIDS
LEFTSIDETABLE
INSERTSYSTEMBASICGRILLMGS
INSERTSYSTEMROUNDGRILLØ 305MM
GASCONNECTIONNOZZLEADAPTOR
6
A
C
B
D
Exploded drawing
7fccbbq.com
1.
2.
Assembly
8
Assembly
3.
4.
4 x B4 x B
9fccbbq.com
Assembly
5.
6.
10
